Flameproof Limit Switch Dealers

• Type: Rotary Gear Limit Switch
• Color: Gery, Blue
• Feature: Easy To Operate, High Performance
• Frequency: 50Hz
• Country of Origin: India
• Current Type: AC

Suni makes Flameproof (FLP/WP )Rotary Gear type Limit Switch that is used on Control / Power circuit of reversing drives so as to limit their rotation / movement within a predetermined position.The Flameproof (FLP/WP) Rotary Limit switch FlameproofTesting as per IS/IEC 60079-1:2007 & Dust ignition protection as per Is/IEC 60079-31:2008 & Weatherproof Testing as per IS/IEC 60529:2001 for IP 66 Enclosue Material is in Die Cast Aluminium Ally LM6 & used in Zone 21, 22 & 1&2, for gas Group-IIA,IIB & IIC atmosphere   The function of the Limit Switch is to stop the mechanism of drive at the extreme clock wise / anti clock wise position. Suni Make Rotary Limit Switches are particularly suited for use on reversing drives such as Electric Hoists, Winches, Over Head Cranes, Traversers etc. The contacts of these Limit Switches are rated for 40 amps at 500 Volts A.C.The Limit Switch can be provided with 2NC contacts or (2No + 2NC) contacts as per the requirement.The geared type rotary limit switch basically consists of heavy duty worm gear drive with a ratio of 48:1 The Crane Duty Rotary Geared Limit Switch is made in IP-66 enclosure.   in case of IP-66, the cover is of cast Aluminum. Also the Base and cover have machined surface to protect the Limit Switch against dust.The cam shaft which extends from behind the gear into the Aluminium housing accommodates the cams.   2 or 4 cams are used depending upon whether the Rotary Limit Switch is of 2 contacts or 4 contacts operation.The contacts have a maximum continuous Current capacity of 40 amps AC.The contact tips are made of high grade Silver Cadmium Oxide alloy.   When used for Series operation [up to 40 Amps maximum], the Contacts are suitable for 720 operations per hour and in case of Shunt operation [ for Control Circuit ] , the Contacts are suitable for 1000 operation per hour.The same Contacts can be used in Series as well as in Shunt configurationsThe switching capacity of the Contacts when used for Shunt operation is 15 amps at 400 Volts, AC on highly inductive load and 2.5 amps at 220 Volts DC.These switching capacities in fact are far in excess of what is actually required in practice and hence replacement of Contacts for Shunt may not be necessary for a long time.The body of the Contacts is made of high grade Melamine which is specifically suited for heavy duty operation .The material is non – tracking and is capable of with standing heavy arcing.The FLP/WP Rotary Limit Switch operates in the following manner:The Mechanism or the Drive coupled to the Limit Switch actuates the Contacts through the Worm Gear Drive and the Cams.When the Mechanism or the Drive approaches the pre determined position, the Cam strikes the Contact finger of the corresponding Contact which in normal condition is in a closed position. This immediately opens the Contacts and the Circuit is broken there by disconnecting the respective Motor from the supply and resulting in the stoppage of the Drive or Mechanism.The Actuator or Cam is provided with a maximum follow-through angle of 60 degrees there by ensuring that the normally closed Contact, which has been opened by the Actuator / Cam, shall remain in the open position for at least 8 full additional revolutions of the Input Shaft.This provision is adequate for most of the Reversing Drives where the Mechanism or Drive comes to a complete stop with in 1/5th of a revolution of the Input Shaft of the limit Switch.In addition to the adjustment provided for the Actuator/Cam a further fine adjustment knurled Screw is provided for each Contact. This adjustment can be locked in position by locking Screws provided with each Contact fitting.

• Cat No: KJB-A-08
• Gas Group: I, IIA & IIB
• Protection: IP 66
• Elect.Rating: 10 A, 415 VAC

The drive consists of flame proof motor, brakes, switches and push buttons. All electrical fittings are flame proof suitable for group I, IIA and IIB gases. Flame proof limit switches for extreme ends in horizontal and vertical movement. Flame proof local control panel and main incoming isolator with contactor, thermal over-load relays & MCBs.

• Usage: Industrial use
• Type: Flameproof Limit Switch
• Certification: ISO 9001:2008 Certified
• Condition: New
• Max. Voltage: 240 VAC
• Surface Finishing: Power Coated
• Phase: Single Phase
• Switch Type: Rotary Limit Switch

IP 67 degree of protection, Choice of 16 operating heads, Interchangeable heads ensure complete modularity and flexibility, Zinc die cast body for heavy duty applications, Easily replaceable contact blocks, Precabled version with 2m cable length

• Size: 130mmx130mm, 62.5mm max dia
• Gas Group: IIA, IIB and IIC
• Zone Protection Class: Zone 1 and Zone 2
• IP Protection: IP65/66
• MOC: SS304,SS316,SS316L, Brass Nickel Plated, Aluminium Alloy (LM6)

 Applications :   1) FLAMEPROOF-WEATHERPROOF for limit switch with contact     element.   •  Features :   1) High Tensile strength   2) Protect  IP65/66   3) Available for Zone1 & Zone 2   4) Gas Group IIA , IIB and IIC   5) Ex d , Explosion Proof, FlameProof, Weatherproof

• Cable Entry: 03 No. for ¾” ET
• EX-Protection: - Ex-“d” Type
• Gas Gr.: - I ,IIA &IIB
• MOC: - Pressure Die Cast Aluminum Alloy LM6 Zone Classification-Zone 1 & Zone 2
• IP Protection Class: -IP65
• Finish: - Light gray Epoxy Polyester Powder Coating Shade No 631
• Earthling: -Internal -01 No. External -02 Nos. Cable Entry - 03 No. for ¾” ET
• “O” Ring: -Endless molded neoprene
• Hardware: -In Stainless Steel

• RATINGS: TOP PUSH ROLLER 1NO+1NC

the products to meet more stringent benchmarks for Safety, Reliability & Performance. Explosion protected equipments are meant for installation and use in these hazardous locations to ensure safety of plant, equipment and personnel and to ensure safety and reliability of operation.

• Current Rating: 40 AMPS at 500 V.A.C.
• CONTACT SEQUENCE: 2 NC.

Limit Switch is a switch operated by the motion of a machine part or presence of an object. These are used for control of a machine as, a safety interlock or to count an object passing a point. Limit Switch may be directly mechanically operated by the motion of the operating lever.

• Type: Crane Limit Switches
• Certification: CIMFR
• Voltage: 230VAC
• Frequency: 50HZ
• Power: 10-15Amp
• Country of Origin: India
• Hole Diameter: 0-20mm
• Max. Lifting Height: 500-700GM

Flameproof Flasher Light RED GREEN AMBER coloured 8W LED type OR 21 W Filament type light Exd_IIC_IP65 FLPW-1245Flameproof red rotating Beacon Lamp (25W, 24V) with 240 24V OR 110V 24V tranformer Flameproof red rotating Beacon Lamp (25W, 24V) with 240 24V OR 110V 24V tranformer Exd_IIB_IP65 FTL-503Flameproof Traffic Light with Red , Green & Amber LED clusters with 3 glass windows , each 10 W; 12V dc OR 110 230 V ac

• Temperature Range: - 12* C to 121* C
• Mechanical Life: 10 x 106 Operations

JAIBALAJI CONTROL GEARS PVT. LTD., Offers the EPHA LIMIT SWITCHES in an enclosure suitable for use in hazardous atmosphere. The EPHA type is available in 2NO + 2 NC output.JAI EPHA LIMIT SWITCHES are for use either indoor or outdoor in hazardous atmospheres, as they are completely sealed explosion proof device.Mounting Holes are provided for front or rear mounting making the switch interchangeable with other hazardous location switches.Various types of heads helps to suit in any typeof cam and-application.JAI EPHA switches feature the smallest housing available in India for use in hazardous location. Flame paths within the housing cool exploading gases below the kinding temperature before they reach to explosive gases surroundings the housing.

A limit switch box is mounted on and coupled to the actuator in order to operate position-indicating lights on control panels; to control other equipment such as pumps, compressors and mixers; to sequence other valves, or for feedback and PLC position confirmation. Two single pole double throw (SPDT) switches are mounted in one enclosure and are activated by individual, adjustable cams. The limit switch box is available in weatherproof enclosures, and switches can be supplied in mechanical or proximity models.

• Brand Name: SUDHIR
• Rated Voltage: 240 VAC
• Switch Configuration: Both
• Switch Type: Lever Limit Switch
• Country of Origin: Made in India
• Pole Throw: SPST
• Features: Vibration resistance, Shock resistance and high durability

We are leading manufacturer & exporter of flameproof lever limit switches. The flame-proof type of lever limit switch are designed for operation in hazardous environment where explosive gases/vapors are present. The robustly designed flameproof enclosure is a closed grain aluminum casting and is vacuum impregnated. The enclosure is certified by cimfr for groups i, ia and iib. Each casting is subjected to hydrostatic pressure test as specified in the standard. Lever limit switch is used for heavy duty e.o.t. Cranes, wagon shunting devices etc., to prevent over traveling or over traversing on power and control circuit up to 500 volts a.c. 50 hz and 10amps and 40 amps current rating. specifications: material:box and cover a1. Lm-6 enclosure: totally enclosed protection: ip - 44 rated voltages: 24 v to 550 v

• Rated Voltage: 240 VAC
• Country of Origin: Made in India
• Brand Name: shivasai
• Usage: Assembly Machines
• Switch Type: Lever Limit Switch
• Pole Throw: SPDT
• Features: Optimum performance, Longer service life, Quality-tested
• Item Code: flpl
