Flange Machine Dealers

• Type: 3 or 4 Roll
• Type: Horizontal or Vertical
• Min. dia. of bend: 1.2 times top roll

Designer and Manufacturer of Ring / Flange Rolling machine. 3 roll / 4 roll size , vertical / horizontal design. Roll Rings / Flanges from Flats. Save on your cost of material, don't cut circles from plate, but roll flat to ring/flange. Contact us with your application. Machine is design for high production. Remote control panel for ease in operation by single operator. Robust Design having gearbox, hydraulics etc. for long life.

• Brand Name: Blue Valley
• Production Capacity: Upton 4200 mm jobs

We keep the finished assortment of products in highly developed and spacious space. This helps us in keeping products secure and sorted. As a promising name, we bring forth a quality-centralized range of products that are designed and produced using the high quality raw material. We check the material on several counts prior to procurement.Features : Superior finish Long lasting Customized options Exceptional quality Capacity : Thickness - 5 mm to 25 mm Diameter - Torispherical 4200x20 thk Diameter - Ellipsoidal 550 mm to 2800 mm Knuckle Radius - 50 mm to 400 mm

This is a process by which Raw MillCement Mill Trunnion Journals can be repaired by INSITU machining at site. The scorings formed over a period of time, can be removed and the Trunnion Journal diameter will be undersized to standard diametrical tolerances as per OEM's specification. The Trunnion Journal will be stationary while our INSITU attachment will rotate around to effect grinding. This will generate true spherical surface. Using this state of art INSITU machine, any shafts upto 3200mm diameter can be INSITU machinedground

Large Pipe Cutting and Bevelling Machine - from 200 mm Ø onwards - are designed, manufactured & supplied for site as well as workshop use. The machine is a split-ring frame (also called 'clamshell') design and can be fitted at any point along the length of pipe. And can be mounted and used at any elevation , axis or environment.The tool slide can be set to machine any bevel angle , using a standard HSS tool-bit.

H Beam Flange Straightening Machine -

We are offering flange facing machine. Eurotech's range of flange facing machines includes both internally and externally mounted rugged machines capable of handling the toughest working conditions.

• Brand Name: Sepson Textile Machines
• Machine Type: Semi-Automatic
• Power Consumption: 3 HP to 5 HP
• Capacity: 10000-14000 RPM
• Minimum Order Quantity: 1 Piece

The rotary drive unit consists of a pair of pre-loaded, extra heavy duty taper roller bearings, located in an accurately dimensioned, forged alloy steel body. The rotary drive is through a gear box and a motor. A vector VFD provides step less rotational speeds. The main body and the cross axis ram are made of high grade CI casting, heavily ribbed and stress-relieved. The box type ram is quite unique in design, perfectly balanced, light in weight, robust in construction to withstand the deflection. The cross feed drive is through a worm reduction gear box & VFD controlled motor. Proper balancing and additional care in design ensure smooth cutting even when the cutting takes place in the extreme end of the ram. The rotational drive and feed axis are synchronized through a PLC. Adjustable feed end limit switches are provided for the ram movement.

Model Number: RNFMM-001 Brand: Rangani Materials: Carbon Steel, Stainless Steel, Alloy Steel Standard: ASME, JIS(KS), ANSI, API, MSS, AWWA, DIN, BS and etc Varieties: Threaded Flange, Slip On Flange (SO), Socket Welding Flange, Lap Joint Flange (LJF), Welding Neck Flange (WNF), Blind Flange, Orifice Flange, Reducing Flange, Pad Type Flange, Loose Hubbed Flange, Welding Plate Flange, Welding Neck Collar, Welding-On Collar, Loose Plate Flange, Companion Flange, Plate (PL) Flange, Spectacle FLG8 (Spacer & Blanks), Square Flange, Long Welding

Flange facing Machines can be quickly and easily assemble at site. These portable, powerful units are ideal for use in the shop or in the field for flange reconditioning of both raised and flat surface flanges.

We are one of the leading Facing Machines Suppliers, from India. We manufacture wide range of Flange Facing Machines which include Centering Facing Machines and facing machines. We possess a gigantic range of flange facing machines which is also admired by global clients. Furthermore, our entire collections of flange facing machines are available at the most genuine price.

This machine is widely used in welding works for the purpose of correction of the steel flange and straighten the flange plates This machine is of high precision and efficiency and has the features of strong straightening force, large straightening range, high working efficiency and good product quality. There are hydraulic drift rollers in the front and back of the main machine.

This machine is a remote controlled portable In-Situ Flange facing and Boring machine used for facing the large FlangesShells at the ship breaking yards and oil industries. Any type of drilling, tapping, machining, boring etc operations are possible to do on this machine. This machine can be operated horizontally as well as vertically. It can be mounted to the flanges horizontally or vertically. A specially designed octagonal capsule has the clamping facility with interchangeability for internal diameter as well as different setting arrangements for external clamping on the same settings. The complete machine is held with eight rigid clamping to do the machining in both the settings. This machine can handle job sizes of Range 550 mm to 3000 mm. The entire operation is done with remote control. The machine can be customized for any sizes of Od and Id machining as per the requirement of the customers.

This is a CNC special purpose machine which incorporates two Modulo Equipe "1" units one opposite the other and 2 self-centering chucks, suitable for clamping special shafts. These units allow to work each individual part on both sides simultaneously and to perform turning operations by means of CNC rotary-tool turning heads, as well as all types of drillingtapping jobs. The bed and self-centering chucks are made of electro-welded metal plate, subjected to a stress-relieving treatment.

• Flange thickness: 3mm-6mm
• Angle iron spec: 40×40×6T；45×45×6T；50×50×6T
• Flange diameter: ψ400～ψ2000

Specifications: 1. Forming roller moto: 25HP, speed can be adjusted. 2. Forming roller material: SKD11 3. Hardness: HRC60℃ 4. Forming roller base: S541 5. Forming roller transmission: powerful 6. Adjustable device between forming roller 7. Hydraulic system 8. Forming roller can be adjusted, assembled and unloaded. 9. Section bending to cutting can be chosen automatically or manually. 10. Operation: button or remote control 11. Decoil: loading 1200KG, hyd. Tension Cutting blade: 1. Material: SKD11 2. Hardness: HRC60℃ 3. Upper and lower blade base are changeable. 4. Blade movement: hyd. 5. Blade base and section roller is combined to one complete set. 6. Forming roller and section bender are producing line. Controller: 1. Producing controller are manual type, auto type and remote control, all of them are with emergency device. 2. Forming roller machine is NC control system, TFT screen with touch panel. 3. Hyd. System with adjustable speed.

Our range of products extends from light portable manual machines for small trade up to automatically controlled machines for industrial production. With our machines you can work up to a thickness of 10 mm depending on the type of machine.With our sheet processing machines you can bead, flange, crease, fold, wrap or cut sheets, metal grids or other suitable materials. It is also possible to combine the various types of machine with one another.Sheet metal bending machines,Tube seaming machines,Crimping machines,Curling machines,Circle cutting shears,Tube flanging machines,Special sheet metal forming machines

• SPECIFICATIONS:: Max. fold 1000 mm long and Folds 7 mm-20 mm flanges

WNS Flange Folder designed to create a right angled flange on precut sheet material.This machine provides quick easy folding of material up to (1.0mm) 20 gauge as there is no need for clamping it is also ideal for use with Pittsburgh lock rollformers. Another advantage of this machine is that it is open-ended.
