Floor Boring Machine Dealers

TOS WD 130A Ram Floor Type Horizontal Boring Milling Machine, X axis 5000 mm, Y 2400 mm Z axis 1120 mm Tailstock, Boring Bar, Facing Head, Nr 5 Milling Heads to suit with additional Head Attachment 1Floor Plates – 4500 mm x 1750mmWMW Rotary Table 2000X1800

• Certification: CE Certified
• Voltage: 220V/380V
• Condition: New
• After-Sales Service Provided: Spare Parts
• Warranty: 1 Year
• Power: 10-20 Kw
• Weight: 100-500 Kg

• Brand Name: Karam Machine Tools
• Condition: Good
• Type: Boring Machine
• Country of Origin: Batala
• Size: Various
• Grade: Grade-1

We are pleased to inform you that we are manufacturing grade-1 quality floor boring machine of various sizes.

• APPLE GREEN: ORANGE

KARAM TECHNICAL SPECIFICATION OF FLOOR BORING MACHINE SR NO. DESCRIPTION MM 1. ALLOY STEEL WORK SPINDLE HARDENED & GROUND DIAMETER 100 2. MORSE TAPER NUMBER 6 3. MAX. LONGITUDINAL MOVEMENT OF WORKING SPINDLE 600 4. NUMBER OF SPINDLE SPEEDS 9 5. RANGE OF SPINDLE SPEEDS - R.P.M. 15 TO 300 6. LONGITUDINAL WORK SPINDLE FEEDS NOS. 10 7. VERTICAL HEADSTOCK TRAVEL FEEDS (INCLUDING ONE RAPID) 10 8. Y - AXIS 1250 9. Z - AXIS 2000 10. ELECTRIC MOTORS (SIEMENS MAKE) 7.5 HP & 2 HP 11. STEEL TELESCOPIC COVER 2 NOS . 12. LUBRICATION PUMP 2 NOS. 13. LIMIT SWTICHES 4 NOS. 14. PANEL BOARD (MAKE) SIEMENS

• Application: Boring
• Voltage: 230v
• Automatic Grade: Semi Automatic
• Driven Type: Electric
• Feature: Easy To Operate, Good Capacity, High Performance, Low Maintainance
• Frequency: 50/60 Hz
• Material: Mild Steel

• USED: MACHINERY
• NO: NO

We are offering skoda wd-200a ram type floor boring machine. Model: wd-200a (ram type) yom: 1965 technical specifications spindle diameter 200 mm ram size 520 x 520 mm vertical head travel, y 3300 mm horizontal column travel, x 4500 mm ram travel 1600 mm spindle travel 2000 mm spindle speeds: 1.5 to 630 rpm spindle taper: #120 metic w#50 adapter rapid traverse: 3200 mmmin feeds: spindle 0.5 - 3200 mm ram .05 - 3200 mm vertical 1 - 3200 mm longitudinal 1 - 3200 mm equipped with: rotary table model e20 , size : 2000x2000mm, 20tons loading capacity floor plates : 3750 x 1250 x 300 mm, 2 nos.

• Machine Name: Floor Boring Machine-CWB - ALF 147,5
• Manufacturer: Innocenti
• Model: CWB - ALF 147,5
• Country: Italy
• Stock-no.: S02032113

Travels x 6500 mm y 3000 mm Boring Spindle diameter 150 mm Milling spindle diameter 204 mm Spindle taper SA 50 Spindle speed 2,6 - 640 rpm Spindle travel 1500 mm Ram travel 750 mm Total Ram + Spindle 2250 mm Spindle motor 30/40 HP Distance between Spindle-Floor Plate mini/maxi 870/3870mm Ram Type Floor Boring Accessories: 4 Axis DRO Face plate 1 milling heads Rotary table 2000 x 2000 mm / 15 tons load cap. Floor plates 2500 x 8000 mm

Floor Boring Machine, offered by us, is quality-tested by the auditors at the unit before purchase and also before delivery to the customers. Made in compliance with high industrial standards, our Floor Boring Machine is perfect for various industry based applications. We can deliver Floor Boring Machine to the customers within specified time frame. Details : Make : SkodaModel : WD-200ALocation : Navi MumbaiStock : STK0001511Origin : Germany Technical Specifications : Spindle Diameter : 200 MMRam Size : 520 x 520 MMVertical Head Travel, Y : 3300 MMHorizontal Column Travel, X : 4500 MMRam Travel : 1600 MMSpindle Travel : 2000 MMSpindle Speeds : 1.5 to 630 RPMSpindle Taper : 120 Metic W/#50 AdapterRapid Traverse : 3200 mm/minFeeds :Spindle : 0.5 - 3200 MMRam : 05 - 3200 MMVertical : 1 - 3200 MMLongitudinal :1 - 3200 MM Equipped With : Rotary table model E20,size : 2000x2000mm20Tons Loading capacityFloor Plates : 3750 x 1250 x 300 MM, 2 Nos.

• Brand Name: CERUTI
• Model Number: CEREMATIC 100L

We make use of the quality basic material in the production of the entire range. The material is thoroughly checked by our quality experts before procurement from vendors. For the utmost customer satisfaction, we are flexible in delivering the product range at the place agreed by the customers and that too in the set time.   Details : Make - Ceruti Model - Cerematic 100l. Spindle Diameter - 101.6 Mm. Morse Taper Iso 50. X Axis - 4500 Mm. Y Axis - 1000 Mm. Z Axis - 1800 Mm. With Plc Fagor. All Motors Are Siemens Servodrive. With Chip Conveyor - 5500 Mm. Horizontal Stroke - 4000 Mm. Vertical Travel - 1800 Mm. Longitudinal Stroke Of The Gutter - 500 Mm. Boat Travel - 800 Mm. Speed Range 12:1200 Rpm. Rapid Movements - 2500 Rpm. Rotary Table Boring Skoda E 20. Clamping Length - 2000 Mm. Clamping Width - 2000 Mm. Workpiece Weight - 20000 Kg. Bed Length - 3000 Mm. Table Height - 900 Mm. Table Width - 2766 Mm. Table X Travel - 1200 Mm. Fast Longitudinal Movements - 1265 Rpm. Fast Rotating Movements On Diameter Of 1450 Mm - 1665 Rpm. Weight Of Table - 9 Ton. Universal Head. 6 Floor Plate - 1200 Mm Width X 2400 Mm Length X 300 Mm Hight

• Certification: ISO 9001:2008
• Application: Industrial
• Weight: 100-1000kg
• Warranty: 1 year
• Condition: Used
• Type: Horizontal

We are engaged in offering heavy-duty Used Horizontal Floor Boring Machine. Matching with the international standards, our Used Horizontal Floor Boring Machine performs just like a new one. Loaded with advanced features, our Used Horizontal Floor Boring Machine is highly easy to operate and assures optimum functionality. With such attributes, the cost-effectiveness of the Used Horizontal Floor Boring Machine acts as an add-on to the clients.

• Condition: Good
• Usage: Used For Cutting Metal Sheet
• Bore Size: 4-5 inch
• Automation Grade: Automatic
• Max Boring Depth: 0-50 feet

The company has reached the pinnacle of success in offering CNC horizontal boring machines. Our offered product is known for the strength, excellent quality, reliability, low maintenance cost and ease of operation. The product is use in variegated industries, and is used to conduct efficient boring operations. Driven by a desire to attain maximum customer satisfaction, we have been able to deliver the products within the stipulated time frame.

•       Machine: Floor boring machine
•       Make\\Company: RESTELLINI (ITALY)
•       Spindle diameter: Dia 100 mm
•       Spindle travel: 1000 mm (1 meter)
•       X cross travel length: 8000 mm (8 meter)
•       Y travel length (vertical): 2000 mm (2 meter)
•       Motor: 20 H.P. (new)
•       Rotary table size: 1400 mm x 1200 mm
•       Rotary table travel: 1000 mm
•       Tail stock: Available
•       Floor plate: 1 no
•       Floor plate size: 2150 mm x 1950 mm
•       Weight (apprx.): 40 tons

We are offering floor boring machine. These are state-of-art machines equipped with most advanced technology to ensure maximum and best quality output is generated with less efforts and within shortest time.

• Type: Floor Boring Machines
• Application: Boring
• Voltage: 110v, 230v
• Condition: New
• Automatic Grade: Automatic, Fully Automatic, Semi Automatic
• Driven Type: Electric
• Feature: Easy To Operate, Good Capacity, High Performance, Long Life, Low Maintainance
• Warranty: 1year
