Four Bin Feeder Dealers

• Application: Construction Use
• Weight: 100-1000kg
• Capacity: 100kg/hr
• Automatic Grade: Automatic
• Warranty: 2yrs

All the four bins are fitted with individual AC/ DC motors and appropriate gear boxes to control and regulate the flow of aggregate from each bin. Gathering conveyor is equipped with scrapper and driven by AC motor. Aggregate from the gathering is feed to the drum with a slinger conveyor after removing oversize material.

• Type: Gravimetric Feeders
• Capacity: 2-4 Tons
• Material: Mild Steel
• Brand Name: Aadesh Industries
• Industry: Construction
• Minimum Order Quantity: 1 Number

• Application: Construction Use
• Weight: 50-500kg
• Capacity: 100kg/hr
• Frequency: 50Hz
• Driven Type: Hydraulic, Mechanical
• Warranty: 1 Year

Backed with industrious professionals, we keep a stern check on the products to ensure that the range is commensurate to international norms. Making sure to capture all marketplaces of Bhilai(India), our organization has arisen as an established provider of this range of product. Four Bin Feeder, each bin has independent conveyor belt and is driven by synchronized variable speed D.C.

• Application: Construction Use
• Weight: 1000-2000kg
• Capacity: 100kg/hr
• Warranty: 2yrs
• Surface: Polished

• Type: Gravimetric Feeders,Fin Beeder
• Warranty: 0-6 Months,6-12 Months
• Condition: New,Used
• Industry: Construction,Manufacturing,Hot Mix Plant
• Materials: Mild Steel,Cast Iron,Stainless Steel
• Power Source: AC,DC
• Finishing: Polished,Color Coated

• Certification: CE Certified
• Application: Construction Use
• Weight: 100-1000kg
• Voltage: 110V
• Capacity: 100kg/hr
• Frequency: 50Hz
• Automatic Grade: Automatic
• Power: 10-15kw
• Driven Type: Electric
• Warranty: 1yrs

The bins of asphalt mixing plants are all-welded and modular in construction, permitting easy addition of bins to meet growing needs. Steep bin walls and valley angels allow free flow of aggregates from the feeders minimizing hold up to materials in the corners and bridging with sticky aggregates. The bins supplied with adjustable calibrated gate openings and variable speed feeder drives, together offer total proportional control, greater flexibility and accuracy of operations to drum mix plants.

• Features: High strength, Non corrosive body, Durable

• PLATE & SHEETS: SAIL COMPANY
• MOTORS: HAVELLS MAKE
• CONVEYOR BELTS: NRC BRAND
• GEAR BOX: ORKAY MAKE

We are offering four bin feeder no.of bins 4 storage capacity 55 tons auxiliary drive motor 1.125 kw x 4 nos. Auxiliary conveyor bolt 500 mm x 2.5 mtrs.x 4 ply auxiliary conveyor gear box smsr x 4 nos. Gathering drive motor 3.75 kw gathering gear box smsr gathering conveyor bolt 600 mm x 24 mtrs.x 4 ply bin vibrator (1 no.) 0.75 kw feeding capacity 140 tph overall dimension (approx.) 12 mtrs x 2.50 mtrs x 2.55 mtrs total connected load 9.0 kw

Our clients can avail from us Four Bin Feeder, which is resistant to wear & tear and available in different capacities. Provided with extractor belt, these are suitable for various road construction machines. These are manufactured using certified material, which ensures durability and fine performance. Four Bin Feeder is sturdy and can be availed at most competitive price.

The Four Bin Feeder, provided by us, has impeccable make and long service life. Our organization has a team of competent workers to make sure accurate quality control of products is done in order to ensure purchaser's quality demands are met. We make sure that the packing of our products is done using quality materials and advanced machines. Our packaging experts handle the entire task of packaging keeping in mind the requirements of the clients.

We make available Four Bin Feeder which is reckoned for its sturdy make. We make use of suitable packaging material to deliver the product safely and in the stipulated time span. We have with us a well-maintained and capacious storage unit that is facilitated by advanced and automated warehousing system, which is operated and supervised by experts only.

we are an eminent four bin feeders manufacturer, exporter, and supplier, based in india. The four bin feeders are offered by us in a wide range that is especially designed in compliance with the international quality standards. Our four bin feeders have been proved to be high in performance, rugged in designs, and cost effective in nature. salient features increased fuel efficiency storage capacity : 32, 40, 52 ton. trouble free performance minimal operational cost

We are renowned as one of the prime Four Bin Feeder Unit Manufacturers in India. The Four Bin Feeder, offered by us, is manufactured using optimum quality materials that ensure high durability, tensile strength and resistivity to adverse conditions. Further, to meet the specific requirements of the applications, we provide Heavy Duty Four Bin Feeder in different capacities like 32, 40 and 52 Ton. Storage capacity : 32,40,52 Ton. Feeders Bins : Feeder bins are 8 to 12.5 tons each,fabricated from M.S steel.Each bin top and mid-section is reinforced for added rigidity.Bin bottom is designed with tapered opening to minimize bridging.Adjustable rubber sidings are provided to prevent leakage between bin bottom and belt surface.Adjustable clam shell gate allows metering of material from the bins. Feeder Belts : Each feeder belt has multiple ply rated belting.Rollers are 4"-5" diameter.Feeder belts are to be driven by TEFC DC or AC Variable speed motors, with shaft mounted reducers.The head shaft pulley is self centring, herring bone lagged. The tail shaft wing pulley is self centring. Includes heavy duty self centring head shaft and tail shaft bearings. Collecting Conveyor : The collecting conveyor has multiple ply rated belting, supported on 20-35 deg. trunion rollers. Includes conveyor extension beyond bins.Head pulley is self centring, with heavy duty bearings. Tail pulley is wing type self-cleaning.Belt is driven by a 1440 / 1800 RPM TEFC motor with shaft mounted reducer. Frame : Bins and conveyors are supported on a heavy duty wide flange frame and braced for optimum rigidity. Optional Running Gear for Mobile version : The entire feeder bins and bed-frame structure can be supported on axles with 12 ply tires, air breaks, king pin, rear lighting and mud flaps.

• Type: Gravimetric Feeders,Reciprocating Feeder,Vibratory Feeders
• Condition: New
• Material: Stainless Steel
• Capacity(Tons): 0-2,2-4,4-6,6-8,8-10
• Finishing: Paint Coated

We are the leading supplier of this products.

We have carved a niche by offering our clients the finest quality range of Four Bin Feeder

• Power: 15 kW
• Capacity: 0-2 Tons
• Type: Reciprocating Feeder
• Frequency: 60 Hz
• Material: Stainless Steel
• Voltage: 380 volt
• Phase: Three Phase

Cold Aggregate Feeder ( Four Bin Feeder), Vibrating Screen, Pugmill (Twin Shaft Type), Anti-segregation Gob Hopper, Slinger Conveyor, Fully automatic Control Panel in Air-conditioned Control Cabin

• Power: 45 kW
• Material: Mild Steel
• Country of Origin: Made in India
• Capacity: 54Tons
• Feeding Speed: 1440 RPM
• Power Source: AC
• Phase: Three Phase
• Finishing: Paint Coated

At the bottom of bins, adjustable gates are provided to regulate the flow of aggregate with four auxiliary conveyors. Gathering conveyor is equipped with scraper and driven by A.C. Motor. Aggregate from the Gathering conveyor is fed in to the drum by a slinger conveyor through vibrating screen.

We have established ourselves as the prominent manufacturer, exporter and supplier of sophisticated four bin feeder.

Backed by a team of highly experienced professionals, we are involved in providing a wide range of four bin feeder.
