Gear Cutting Tools Dealers

• Product Name: Serration Hobs
• Type: CNC Machine
• Brand Name: Tool Masters India
• Condition: Good
• Place of Origin: Patiala
• Min. Order Quantity: As per Client Requirement

We are offering serration hobs. Din 5481 & nfe 22161 soft jaw serration cutters for cnc machinesspecial profile as per customer’s requirement

SHB Manufacture Spline Hobs to standard as well as to specific requirements of the user for Straight Sided Spline Hobs as well as Involute Splines in Class ‘A’ and Class ‘AA’ accuracies with following features: With lugs without chamfer. Without lugs without chamfer. With lugs and chamfer. Without lugs but with chamfer. With full fillet radius without chamfer. With full fillet radius with chamfer. We are a renowned Manufacturer of Straight Spline Hobs in India.

We are offering maxwell spline hobs these spline hobs are fabricated as per the set industrial standards by using the finest raw materials for their assured reliability and best performance.

• Weight App. (MT.): 1.9
• Floor Space: 6' x 8'
• Motor H.P.: 3.0

Gear type Reel to Sheet Cutter This machine is designed for accurate cutting of reels. Size can be varied by changing gears from one position to another as chart to be provided Machine can be synchroized with single facer or can work as seperate unit.

• Material: All common high-speed and powder-metal-steels like HSS/EMo5Co5, PM 30, PM-S390
• Module: 5 to16 mm
• Diamater: 100 to 250 mm Bore with standard and transversal keyway
• Width / Length: 100 to 400 mm
• Construction: 2-tooth-system profile ground, 3-tooth-system profile unground, with and without chip breakers (depending on work piece material)
• Accuracy class: unground C, B
• Coatings: Saacke deliveres all common coatings e.g. TiN, TiCN, TiALN, AlCrN

SAACKE Heavy duty roughing hobs Tools for the bold and mighty Heavy duty roughing hobs from Saacke allow you to produce gears starting from module 5 faster and more cost efficient. Because of our high efficiency, Saacke-tools contribute to your businesses success. Saacke-heavy duty roughing hobs can be manufactured as follows:

Gear Hob Cutters Use straight angled sides for generating spur & helical gears of maximum accuracy on geat hobbing machines. Precision hobs are available for involute splines, straight splines, sprockets, worm wheels, timing pulleys etc.

• Material: tool
• Shape: round
• Color: White
• Condition: Used
• Application: cut
• Size: 12inch
• Certification: ISO 9001:2008
• Grade: 30
• Type: y
• Blade Thickness: 0-15micron
• Country of Origin: India
• Blade Finishing: Non Coated
• sdi: c
• sdi: b
• sdi: a

• Type: Gear Cutting Tool
• Material: SS
• Condition: New
• Country of Origin: Mumbai
• Brand Name: Malkar
• Diameter: Customized
• Coating: Galvanized
• Overall Length: Customized
• Model Number: NA
• Service: OEM

HARBIN TOOL WORKS was set up in 1990, who is a modern enterprise mainly produces gear cutting tools. For more than 20 years’ continuous development, we have acquired powerful capability and adequate production facility. We have got 13 national patents for invention and utility model. Some important operations in the production process are completed on sophisticated foreign facilities imported from Germany, Switzerland, Italy and Japan. We adopt advanced technology from Germany into heat treatment process according to the material and specifications of different products. We have introduced the Swiss Balzers coating equipment, which can be used in various coatings to achieve dry cutting. 　　HARBIN TOOL WORKS not only provides high-precision, high-performance products, but also offers comprehensive and high quality service. After 20 years’ study in gear industry, we become acquainted with the questions and needs of clients in choosing products, purchasing equipments, booking and using cutters. It is a great fortune for us to serve clients with different needs. 　　HARBIN TOOL WORKS has been certified by the quality security standard ISO9001:2008

Our Spline Hob Cutter is manufactured in standards as well as according to the requisites of the clients, straight sided and involute spline hobs in class 'A', ‘B’ & ‘C’ accuracies with following features can be supplied : With lugs without chamfer Without lugs without chamfer With lugs and chamfer Without lugs but with chamfers With full fillet radius without chamfer With full fillet radius with chamfer Today, we are well reckoned as one of the distinguished spline cutter manufacturers and rectangular spline hob cutter suppliers, based in India.

• Material: ASP2052/S390/S290/ASP2030/M35

Involute Spline hobs are used for cutting all kinds of standard and non-standard involute splines as per DIN 5480, 5481 & 5482. These are produced in the pressure angles of 20°, 30°, 37.5° & 45°, with or without shoulder clearances in single and multi-start designs.Accuracy Class: AAAAAA as per DIN 3968, Types: Bore & Shank type, Shoulder Clearance type.

We are offering gear hobs cutter chain sprocket hobs spline hobs.gear hobs cutter chain sprocket hobs spline hobs gear hobs for spur and helical gears are manufactured in machine relieved and ground relieved profiles. Gear hobs with bore and keyway or with end drive slot in single start as well as multi start pitches in accuracies class "aa" "a" 'b' and class 'c' with special features like topping, semi-topping, protuberance, pre-grinding, pre-shaving etc. Manufactured to din, bs and is specifications are available in following sizes. Non standard gear hobs also manufactured by us

DP and MODULE series in the range of 0.3 module to 55 module & 64 DP to 0.5 DP. Spline milling cutter, sprocket milling cutter form relieved milling cutters for involute and special forms.

• Material: M2, M35 High Speed Steel

All kinds of special profile cutters gear hob cutter are designed and manufactured to accompalish a particular job with utmost precision tailored according to user's requirements. These cutters are a type of form tool and are used in hobbing machines to generate gears. A cross section of the cutter's tooth will generate the required shape on the work piece, once set to the appropriate conditions.

• Type: Spline Hob Cutter
• Material: HSS
• Application: Gear Cutting
• Condition: New
• Finishing: Polished
• Surface Finishing: Coating as per customer demand
• Country of Origin: India

We at UBC, manufacture and export SplineHob Cutters. These gear cutters can be made with Accuracy Class: AAA/AA/A/ as per DIN 3968 Standard. We manufacture these gear cutters in High-Speed Steel Grade: ASP2052/S390/S290/ASP2030/M35.Hob Cutters can be supplied in Gold (TiN), Futura Nano (TiAlN), Alcrona Pro (AlCrN), Altensa (AlCrNX) coating and other coatings available on request. Available in a variety of sizes and diameters in Module (D.P.) or as per customer's requirement

• Type: GEAR HOB TESTER
• Color: Grey
• Condition: Used
• Automatic Grade: Manual
• Brand Name: KLINGELNBERG
• MODULE MAX: 20 mm
• MODULE MIN: 2,5 mm

gear hob tester make : klingelnberg
  model : pwf 250
max. diameter: 250 mm min module: 2,5 mmmax module: 20 mmdistance between centers: 470 mm  weight: 1500 mm


Used Gear Hobbing Machine is offered by us at very lowest prices within the stipulated time frame. The range is equipped with the high technology spares with optimum control system that offer high hobbing head as well as work spindle speeds. The array ensures high cutting speeds with quality pinions as well as shafts with the quality teeth. The base comes in slant bed design with matchless vibration dampening, torsion as well as bending resistant features. The slant bed design is available with appropriate chip as well as coolant removal system. The machine body is available with sturdy body to ensure excellent damping properties, unmatched surface quality as well as long tool service life. The range is available with high tech cutting speeds, unmatched loading process as well as ease of setting. This economic device cones with accurate positioning of pinions and shafts for matchless efficacy.

The company is renowned Gear Hob Cutters Manufacturer and Supplier in the market. These Gear Hob Cutters are precisely manufactured under the strict parameters of industrial standards. The wide variety of Gear Hob Cutters is offered to the clients. The company assures quick delivery of Gear Hob Cutters in the predetermined time. The company is also capable of serving its clients with up to 40 Module/1 DP of Gear Hob Cutters. Range Spur and helical gear hobs Pre-shaving gear hobs Pre-grinding gear hobs Straight and involute spline hobs Serration hobs Sprocket hobs Worm gear hobs Timing belt hobs   Basic Parameters Module : 0.1 to 40 (24 mm to 360mm diameter) DP : 120 DP to 0.7 Start : Single or Multi Start Accuracy : A, B & C (as per DIN 3968, BS 2062) Forms : Non-Topping, Semi-Topping, Topping, finishing, pre-shaving, pre- grinding, with or without protuberance , full fillet etc. Material : M-2, M35, ASP 30 etc. Chain Sprocket Hobs are usually supplied in unground form to cut roller chain sprockets to din, American standard with the range from 1/4" to 3" pitch or 5mm to 76.2 mm pitch. The above Gear Hob Cutters can be supplied with latest PVD Coatings. The above Gear Hob Cutters can be supplied as per BS, JIS, DIN, ASA standards.

We are offering comprehensive range of Gear Hob Cutters. The Gear Hob Cutters offered by us includes best quality Threading Tools. These Gear Hob Cutters are made from high grades Steels. A team of highly qualified Engineers has made these Gear Hob Cutters using latest machines and advanced technology. By providing these quality rich Gear Hob Cutters, we meet the exact standards expected in the international market. We are sub Dealer & Stockiest of Ceratizit make Turning & Grooving Inserts. Besides, we also supply Special Gear Hob Cutters as per Customer Drawing/data. Standard BIS BS DIN ASA JIS GOST

• Type: Gear Hob Cutters
• Material: Metal
• Application: Gear Cutting
• Automatic Grade: Manual
• Surface Finishing: Chemical Coated
• Finshing: Polished

They are mainly used for clamping surface and if required, for fine adjustment. Serration Cutters help in producing high speed and high quality steel. We are one of the finest Serration Milling Cutters Exporters in India. These products are primarily used by Carbon Brush Holders Manufacturers. Our Serrated Edge Cutters have also got a great presence in the market and is one of the most sought after products amongst our clientele.

We Manufacturer Side & Face Cutter & Slotting Cutter which is further Complimented With highly Competitive Prices.
