Halogen Free Cable Dealers

• Application: Industrial
• Thickness: 10-15mm
• Color: Multi-Color
• Voltage: 110V
• Power: 1-3kw
• Feature: Crack Free

We have carved a niche as one of the overruling Halogen Free Control Cables Manufacturers, Exporters, and Suppliers based in India. The Halogen Free Control Cables that we offer find their application in electrical installations in dry and damp areas. It is also suitable for interiors and outdoors if UV protection and temperature ranges are observed. These Halogen Free Control Cables are made from top quality raw materials, in order to ensure better performance and durable life. Applications : Measurement, sensing and control cable in the machine tool manufacturing Engineering installations Power stations installations Heating installations Air conditioning installations Refrigeration installations Date processing installations Benefits : The halogen free control cables are oil resistant (SEV TP 20B), widely resistant against chemicals, rough but extremely flexible. The materials are flame retardant and self extinguishing according to IEC 60 332.1, IEC 60 332.2, IEC 60 332.3 : The amount of gas and smoke produced is very low (IEC 61034-1). No corrosive substances or gases will be released Used in all areas where fire hazards and / or many people or high property values are concentrated In the event of fire very low corrosive values only are measured in the conflagration gases (IEC 60 754-2) and lack of halogen in the materials (In accordance to IEC 60 754-1) prevent the formation of poisonous gases, dioxins and furanes Considerable damage to human life, the environment, building and installations are avoided Specifications : Fine strands of plain copper wires Halogen free polymer compound insulation Cores twisted in layers Black with white numbers or Colour coded Green-yellow protecting conductor Outer sheath of oil resistant (SEV TP 20 B) halogen free compound Flame resistant (IEC 60 332.3) Silver grey (RAL 7001) or black and white Add for More Details Please Send You Requirements with Technical Details Inquiry Now!!!!!

We offer the finest RZ-1k Halogen Free Cable that describes the long safety limit and offers high flexibility. The RZ-1k Halogen Free Cable is resistant to temperature and all other chemical hazards. The maximum limit of RZ-1k Halogen Free Cable is 1.1 KV power. The RZ-1k Halogen Free Cable is designed as per Spanish quality standards.

• Type: Zero Halogen Cable
• Application: Home, Industrial
• Certification: CE Certified, ISI
• Color: Black, Green, Red, White, Yellow
• Voltage: 1.1 KV
• Power: 9-12kw
• Feature: Crack Free, Durable, Quality Assured
• Brand Name: NATCAB
• Insulation: ZHFR (Zero Halogen Flame Retardant)
• Range: 1 to 6 sqmm
• Conductor: Pure Electrolytic Grade Annealed Bare Copper with More than 100% Conductivity
• Specifications: IEC 60332-1 & 3, IEC 60754-1 & 2, IS 8130

• Type: Halogen Free Cable
• Application: Home, Industrial
• Thickness: 10-15mm, 15-20mm, 20-25mm
• Color: Multi Colour
• Voltage: 220V
• Power: 1-3kw, 3-6kw
• Feature: Crack Free, Durable
• Internal Material: Copper

For the varied necessities of our valued patrons, we are indulged in offering an extensive array of Halogen Free Cables. These cables are precisely manufactured by using the premium grade basic materials and advanced techniques in order to ensure a great performance. In addition to this, these cables are accessible in various sizes, lengths, thicknesses, and other specifications so as to match the varied needs of our clients. We offer our Halogen Free Cables at a reasonable price.

• Country of Origin: India
• Type: Halogen Free Cable
• Thickness: 10-15mm
• Color: ORANGE
• Brand Name: ALANKAR / ALANCAB
• HALOGEN: FREE
• LEAD: FREE

we are offering bfsi 1 kv. halogen free lead free conductor: multi stranded copper conductor insulation: hf-xlpe sheath: halogen free polyolefin screen: copper wires + copper tapes outer sheath color: orange

Cable Structure• Class 5 bare copper conductor as per IEC 60228 and IS 8130• ZHLS Insulation• Cores twisted• Polyester tape binded• Almylar and ATC wire braid screen• ZHLS outer sheath, grey Special Features Low bend diameter Flexible Space saving construction Excellent fire retardance Low halogen content Excellent electrical properties Good oil resistance Low smoke and toxicity Excellent EMI protection Application Range Industrial machinery and air conditioning systems For general purpose installations in dry environment subjected to low mechanical loads Areas where human or animals are present Tunnels and transportation Suitable for outdoor installations For installation near electro-magnetic noise – near power cables, heavy power consuming machinery and appliances Measurement and control Data processing and signaling

• Red: Yellow
• Black: Blue
• Green: Grey

We are offering firex hffr halogen free flame retardant cable - upto 1100v - india's 1st fire-safe cable with hffr insulation and unilay conductor. - zero halogn. - does not catch flame, does not propagate fire. - non-toxic, non-corrosive. applications : wiring in all installations where fire safety is of utmost importance. Schools, theaters, commercial complexes, apartments, high rise buildings, laboratories, etc conductor : thin strands of electrolytic copper are multi - drawn for uniformity of resistance, dimension and flexibility. The drawn strands are uni-laid in high precision machines and compacted. Thus forming a perfectly circular conductor which enables reduction in overall diameter for space saving in high density wiring. The strands do not get cut when stripping the insulation. The conductor offers perfect contact at pins, terminals and sockets. Thus eliminating spot heating and sparking. Insulation : specially formulated grade of halogen free flame retardant (hffr) compound is used. The insulation does not burn readily. It does not melt and drip, smoke is negligible, transparent, non toxic. The victims trapped in fire do not suffocate and this facilitates fire fighting operations. Unlike pvc, the smoke emitted is non-corrosive. insulation conformity : iec 60332-1 & 3, iec 60754-1&2 marking : the cables are marked "firex-hffr". Colours : red, yellow, blue, black, green, grey. Packing : 90 mtrs. Coils packed in protective cartons. note: rr kabel will not be liable for damages arising due to incorrect installations. The above data is indicative and may be revised without prior intimation.

• Type: Halogen Free
• Application: Industrial
• Certification: CE Certified
• Color: Available In Many Colors
• Feature: Crack Free, Durable, High Tensile Strength
• Outer Material: Rubber
• Internal Material: Copper
• Available Brands: Polycab, Havells, R.R, Finolex, KEI

The demand for public safety in public areas has increased tremendously, with the objective being not only the prevention of fire, but also the prevention of people and keeping them from inhaling the smoke caused by the fire. There have been a lot of cases where a majority of people have lost their lives by inhaling the smoke. Keeping this in mind, many have turned their attention to the application of the new halogen free cables for better safety. Halogens constitute of elements like Chlorine, Bromine, and Iodine. Low Smoke Zero Halogen (LSZH) is a material classification used in cable jacketing in the wire and cable industry. The cable jacketing is composed of thermoplastic or thermoset compounds that emit very low smoke and halogens when exposed to high amounts of heat. Cable jacket is the protective cover outside the cable that prevents direct exposure to the cable.

• Brand Name: KEI
• Insulation Material: PVC
• Feature: Flexible,Oil Resistant,Recyclable,Highly flame retardant
• Number Of Cores: Single Core
• No Of Cores: 3 G 1.5
• Outer Diameter: 8.6 mm
• Insulation Voltage: 1100 V

Cable Structure• Class 5 bare copper conductor as per IEC 60228 and IS 8130• ZHLS Insulation• Cores twisted• ZHLS outer sheath, grey   Standard References BS EN 50525-3-11 BS EN 50288-7 Special Features Low bend diameter Highly flexible Space saving construction Execllent fire retardance Low halogen content Excellent electrical properties Good oil resistance Low smoke and toxicity Application Range Industrial machinery and air conditioning systems For general purpose installations in dry environment subjected to low mechanical loads Areas where human or animals are present Tunnels and transportation Suitable for outdoor installations Technical Data Temperature Range  -15°C to +70°C Nominal Voltage  300/500V Test Voltage  1500V Insulation Resistance  Min. 200Mohm-km Min. Bending Radius  8 x cable dia Short Circuit Temperature  Upto 160°C Flame Retardance  As per IEC 60332-1

* India's 1st Fire-safe Cable with HFFR insulation and UNILAY conductor. * Does not catch flame, does not Propagate Fire. * Non-Toxic, Non-Corrosive * Range : 1.0 to 4.0 sqmm with UNILAY Conductor 6.0 to 16.0 sqmm available * Generally conforms to, IEC 60332-1 & 3, IEEE 383, IEC 60754-1 & 2, BS 4066-1 & 3, BS 7211, IS 8130.

In order to keep the quality of the products up to the mark, we check the entire range against varied quality parameters. If seeking for purchasing Halogen Free Control Cables at levelheaded prices, contact us! We are a dependable name in this area of operation.

We, at Elcab Conductors are a trusted name among manufacturers of electric cables and wires. We deal in manufacturing and supplying quality and ecofriendly halogen free cables with varying temperature resistances and varying insulation properties. Brand: Elcab Conductors Detailed Description Elcab Conductors is proud of providing its loyal customers with highly standard auto batter cables at a cost that fits their budget. No matter what types of cables you are searching for, we have a wide range of products for you. We have the cable for your car battery that fits your needs of hour. Our cables are approved for use of wiring for starter or battery ground circuits. The following type of halogen free cables are made by us:LSZH (low smoke zero halogen)ZFFRLSOHHalogen free cables are used in various fields where the there are chances of fire outbreak.

• Application: Electric Connection
• Power/Voltage: 1100 V
• Temperature Range: -40C up to + 60C
• Shape: Round
• Core: 1 Core , 2 Core , 3 Core etc
• Conductor Material: Copper

For the varied necessities of our valued patrons, we are indulged in offering an extensive array of Halogen Free Cables. These cables are precisely manufactured by using the premium grade basic materials and advanced techniques in order to ensure a great performance. In addition to this, these cables are accessible in various sizes, lengths, thicknesses, and other specifications so as to match the varied needs of our clients. We offer our Halogen Free Cables at a reasonable price.
