HDPE Welding Machine Dealers

• Type: Hdpe Pipe Welding Machine
• Application: Plastic Pipe
• Color: YELLOW
• Voltage: 220
• Condition: Good, New
• Automatic Grade: Manual
• Warranty: 12 Months, 1year
• Country of Origin: India
• Brand Name: SOLWET

HDPE PIPE JOINT MACHINE , HDPE PIPE WELDING MACHINE

• RANGE: For 63mm, 75mm, 90mm, 110mm Pipe Diameter

We have designed a fully automated, simple and quick method of joining coupler to both end of pipe at same time by friction welding process. The machine is for 63mm, 75mm, 90mm, 110mm OD Pipes. In this method, the pipe is tied coupled and coupler on both side are being rotated at high RPM and are pushing on pipe by guided mechanical mechanism up to desired position automatically. The operation time for one pipe with both side joint is 15 to 20 sec. The Machine is automated such a way that it detects the pipe and decide how long to push coupler on pipe automatically. After the Start button push, It takes 6 to 8 seconds to joint coupler with pipe at both end as both side get start simultaneously. Once operator release pipe it get auto reverse to home position and pipe is auto throw from machine. Salient Features Of Machine: RIGID HIGH-QUALITY MS PIPE STRUCTURE CNC MACHINED COMPONENTS MAKE IT MORE PRECISE PLC CONTROLLED BY ALLEN BRADLEY (USA) MAKE PLC ALL ELECTRICAL SWITCH GEAR FROM SCHNEIDER ELECTRIC FRANCE ALUMINUM PROFILE PNEUMATIC CYLINDER FROM CAMOZZI ITALY PNEUMATIC VALVES FROM CAMOZZI ITALY PHOTO ELECTRIC SENSORS FROM BANNER GERMANY LINEAR BEARINGS FROM HIWIN TAIWAN SKF MAKE MAIN HEAD BEARINGS ABB MAKE IE2 HIGH EFFICIENT MOTORS CONTROL WIRING BY LAPP CABLES

• Brand Name: Marwal
• Material: Aluminium
• Condition: New
• Warranty: 1 Year
• Type: Manual
• Clamps: 4 Clamps with heater and trimmer

Butt Fusion is a process of joining two HDPE pipes/ fitting components which involves simultaneous heating of the both ends of pipe until a molten state is attained on each contact surface. Marwal Fusion Group is the leading entity in manufacturing HDPE Butt Fusion Welding Machine.Other details: HDPE Pipe Butt Fusion Welding Machines 40 mm to 1000 mm We are engaged in supplying latest technology HDPE Pipe Jointing Machine This Butt Fusion machine is manually operated   The main features and technical specifications of the machine are as follows: Suitable for welding of plastic pipes and fittings made from PE, PP PVDF Made of Aluminium material easy to carry and transport Consist of Planning Tool, Heating Plate, Basic Frame, Hydraulic Unit and Support The main accessories of the welding machine are made by fully automatic aluminum casting It is lighter, more solid and smooth than the machine made by sand-casting and steel-form technology

• Prod. No.: 393 A
• Size (mm): 63 - 160
• No. of Dies: 63, 75, 90, 110, 125, 140, 160
• Spec.: 220 V / 1.75 W, 270°C
• Wt. (Kgs.): 41

• Automatic Grade: Automatic
• Output Current (Ampere): 300-400 Ampere
• Heating Plate Max. Temp.: 2700 Degree C

• Automatic Grade: Automatic
• Condition: New
• Machine Type: Automatic
• Output Current: 0-100 A, 100-200 A, 200-300 A, 300-400 A

• Automatic Grade: Manual
• Hydraulic: Hand Wheel Operated
• 4 Clamp: Pressure Gauge

• Country of Origin: India
• Type: Hdpe Pipe Welding Machine
• Application: Plastic Pipe
• Weight: 100-1000kg
• Color: Black
• Voltage: 220
• Condition: New
• Frequency: 50-60HZ
• Automatic Grade: Automatic
• Power: 1-3kw
• Warranty: 12 Months
• Plastic Processed: PE

• Voltage: 110v
• Power: 800W
• Weight: 5.0kg
• Model no: LST800
• Frequency: 50/60Hz
• Welding speed: 0.5-5m/min
• Heating temperature: 0-450℃
• Thickness of material to be welded: 0.2mm-1.5mm
• Overlap width: 10cm
• Welding width: 12.5mm×2, interior cavity 12mm
• SKU: hdpe-sheet-welding-machine-lst800

• Weight: 120 Kg
• Heating Plate Max Temp: 2700 C
• Temp Deviation in Surface: Less Than +- 50 C
• Working Voltage: 220 V 50 HZ
• Heating Plate Power: 1.50 kW
• Planning Tool Power: 1.10 kW
• Total Power: 3.35 kW
• Hydraulic Unit Power: 0.75 kW
• Pressure Adjustable Range: 0-6.3 MPa
• Volume: 0.50 M3

• Material: MS
• Welding Type: Butt Fusion
• Model: SNI-M-110
• Machine Type: Manual
• Usage/Application: HDPE PIPE JOINTING MACHINE
• Brand: +SNI+

• Application: Plastic Pipe
• Weight: 1000-2000 Kg
• Voltage: 110V, 220, 380, Other
• Condition: New, Used
• Automatic Grade: Fully Automatic, Manual, Semi Automatic
• Use: Pipe Welding
• Colour: Black, Brown , Grey , Light White

• Type: Welding Machine
• Voltage: 220 Volt
• Frequency: 50 Hz
• Pipe Size: 90 to 250 mm
• Power Source: Electric
• Usage: To Weld HDPE Products

• Power: 3.25 KW
• Fusion Range (mm): 200 mm
• Operation Type: Semi Automatic
• Brand: MARUTI SAFEX
• Motor Type: Induction Motor
• Power Source: Electric or Genset
• Type of HDPE Pipe Joints: Butt Fusion
• Power Consumption: 3250 Watt
• Welding Range (mm): 200 mm
• Capacity: 12 Hrs
• Phase: 1 Ph

• Automatic Grade: Manual
• Brand Name: Polymold
• Condition: New
• Machine Type: Manual
• Capacity (products per hours): 5+
• Temperature Deviation In Surface: +/-5%
• Temperature Range: 50-300 DEG C
• Heating Plate Maximum Temperature: 300 DEG C
• Voltage (V): 220v
• Phase: 1
• Minimum Order Quantity: 1 Number

• Automatic Grade: Semi-Automatic
• Weight: 25 Kg
• Size/Dimension: 315mm
• Brand: Hydro Tech
• Surface Finish: Paint Coated

S.B.Enterprises are capable of manufacturing and supplying high performing range of HDPE Pipe Welding Machine. These machines are manufactured using optimum grade raw material in adherence with industry defined standards.
