Head Mounted Transmitter Dealers

• Output: 2wire 4-20mA
• Temperature Sensors Can Use: PT100, Thermo couple (J, K, R, S, T, B, E, N-Types)
• Range: 0-100 Degree
• Total Accuracy: +/-1 Degree
• Resolution: 0.1mA
• Response Time: <500ms
• Power Supply: 12 to 32V DC
• Humidity: 0 to 90%RH
• Weight: 50 Grams

• Country of Origin: Ahmedabad
• Feature: Compact size & durability
• Brand Name: Charun
• Input Type: RTD, Thermocouple
• Output: 4-20 mA

We have an immense expertise in delivering Temperature Transmitter to our clients. The offered range of temperature transmitters is made by utilizing the high-grade raw materials and innovative technology in complete adherence with the international quality standards. Along with this, the offered range of temperature transmitters is acclaimed for its compact size and durability. All the pieces of our Head Mounted Temperature Transmitter are thoroughly examined on the basis of various quality parameters before being forwarded to the clients.   Details : Input Type : RTD, Thermocouple Output : 4-20 mA

• Accuracy: 0.1%FS
• Output Signal: 4-20mA
• Max Load: max. (V power supply-7.5V)/0.022A (current output)
• Measurement: tempt-lineatiry,resistance-linearity, voltage-linearity
• Circuit limit: ＜=22Ma
• Response time: ＜=1second
• Saturation current: Low side 3.9mA, high side 20.5Ma
• Alarm current: sensor damger or sensor turnoff output is 3.9mA or 22mA(except TC)
• Power supply: U=12V to 40V
• Working temperature: -40 to 85℃
• Storage temperature: -40 to 100℃
• Condenstaion: Allowable
• Protection: IP00; IP66 (mounted)
• Earthquake resistance: 4g/2 to 150HZ
• Voltage effection: can ignore
• Mounted angle: no limit
• Mount area: top of B type box

• Application: Industrial
• Certification: CE Certified
• Feature: Durability
• Warranty: 1 Year
• Mounting Type: Head Mounted

NK Instruments Pvt. Ltd. has Head Mounted Temperature Transmitters.These Transmitters are normally mounted in the terminal housing of RTD's and Thermocouples. These Transmitters also can be mounted in Panel. These Temperature transmitters are available with 4 to 20 mA output or, RS 232 also.

Supplier & Distributor of Temperature Transmitter & Head Mounted Temperature Transmitters. Our product range also comprises of Controllers, Power Supply Equipment and Transmitters.Head Mounted Temperature Transmitters(Item Code : head mounted -Programmable)Offered by us is an exhaustive range of Head Mounted Temperature Transmitters. These compact head mounted transmitters are procured from ABB. Our transmitters are designed for standard type b sensor heads. These transmitters have advantages of increased measuring accuracy, which results from conversion of the sensor signal into a stable output signal close to the sensor.

Inputs:Combined gas electrode,Input span:Minimum 2 pH,Power consumption:0.5 VA max.,Compensation:RTD, 0-100 deg. C,Storage temperature:0 – 70° C.Mounting:Head Panel Wall Field Dinrail Eurocard.

• Material: ABS
• Shape: Round
• Application: industrial

We are offering Head Mounted Temperature Transmitter • Programmable Input : Thermocouple types J, K, R, S,T,N,B and E; Pt-100; Cu-50, Ohms • 2-wire Loop Powered 4-20 mA DC Output • 2 or 3 wire Pt-100 with linearization • Built cold junction compensation • Configuration by PC • Accuracy : Pt-100 and 0-50 mV ±0.15% full scale. Thermocouple ±0.25% max. of full scale. • Sensor Failure Protection : Programmable burnout upscale or downscale • Power Supply : 12-35 VDC.

• Accuracy: 0.1%Fs
• Output Signal: 4-20ma
• Max Load: Max. (V Power Supply-7.5v)/0.022a (Current Output)
• Measurement: Tempt-Linearity, Resistance-Linearity, Voltage-Linearity
• Circuit Limit: ＜=22ma
• Response Time: ＜=1second
• Saturation Current: Low Side 3.9ma, High Side 20.5ma
• Alarm Current: Sensor Damager Or Sensor Turnoff Output Is 3.9maOr 22ma(Except Tc)
• Note: Measuring Accuracy Is Related To Measuring Rang
• Power Supply: U=12V To 40V
• Working Temperature: -40 To 85℃
• Storage Temperature: -40 To 100℃
• Condensation: Allowable
• Protection: Ip00; Ip66 (Mounted)
• Earthquake Resistance: 4g/2 To 150hz
• Voltage Affection: Can Ignore
• Mounted Angle: No Limit
• Mount Area: Top Of B Type Box

• Material: High quality Raw materials
• Condition: Good
• Country of Origin: Ahmedabad,Gujrat
• Product Name: Head Mounted Temperature Transmitter
• Brand Name: Vinayak
• For RTD: 80 to 400o AND K-TYPE - 0 to 1200o

We are capable of handling both automated inbound and outbound consignments, we have excellent warehousing solutions available. We keep the extensive array of products sorted to make sure that the delivery commences thoroughly. Raw materials used in the production of our entire range are sourced from the reliable providers present in the market. Due to this, we guarantee quality products at buyer's end.   For RTD : 80 to 400o  AND K-TYPE -  0 to 1200oO/P- 4-20 Mili Amper : Two Wire Temperature Transmitter (Head Mounted) for Simplex sensor 44 Dia.x 26 (H). Two Wire Temperature Transmitter (Head Mounted) for Duplex sensor44 Dia. x 26 (H).

• Current: 4 - 20 mA
• Span, selectable: 50 to 500 °C
• Ambient, storage: -40 to +100 °C
• Weight: 40 g

TT7S00-HR is an non-isolated two-wire transmitter which converts the measuring signal of a 3-wire Pt100 RTD into a standardized loadindependent, 4-20 mA current which is linearly proportional to the measured temperature.  Multi range design with solder pads and potentio-meters.  Flat design gives easy access to terminals and adjustments.  Only 6.5 V voltage drop over the transmitter allows for high loads in the 4- 20 mA output loop.

• Brand: Radix
• Model Number: SCC-641
• Dimensions: 44 x 22.5 mm
• Potting: Silicon based compound
• MOC: Polycarbonate
• Mounting: For DIN form B sensor head
• Wire Size: 1×1.5 mm2 stranded wire
• Maximum Torque on Screw: 0.5Nm
• Weight: 40g
• Supply Voltage: 7.5 to 48 VDC

We are the famous Manufacturer and Supplier of Field & Head Mount Transmitter located in Durgapur, West Bengal, India. The raw materials are procured from reliable vendors to ensure the quality and durability of these transmitters. All our products are tested on different parameters to maintain industry standards. Our experts have designed the products to make it suitable for many industries. These products are available at low price.

• Brand Name: ABB
• Model Number: TTH200.Y0.H.BS

The ABB compact head mounted temperature transmitter type is designed for standard type B sensor heads. The advantage increased measuring accuracy resulting from conversion of the sensor signal into a stable output signal close to the sensor,for RTD Pt-100 & thermocouple applications without compensation cables

With a highly experienced Manpower and significant breadth of skills, Henix provides for your requirement in Heating and temperature. Our R&D department keeps in touch with the latest and offers a the latest technology to our Products.

• Application: Temperature measurement
• Output Value: 4 to 20 mA
• Input Value: Thermocouple, RTD PT100 & PT1000
• Brand Name: Novus
• Typical Accuracy: Thermocouple and mV plus or mininus 0.1 percent
• Dimensions: 43.5 mm x 20.5 mm D x H

• Feature: High accuracy, Easy to install and reliable with unique design, Digital Filter & Sensor break protection, Sensor diagnostics & loop check-up.
• Application: Power, Cement, Metals, Chemicals-Pharma.

• Accuracy: : ±0.1% of F.S
• Type: : Universal Head Mounted SMART Temperature Transmitter
• Model: : T648R
• Input Sensors: : RTD, Thermocouples, mV, Ω
• Temperature Range: : -270 to 1820°C
• Output: : 4 - 20mA, 2 wire, superimposed HART
• Power Supply: : 12 - 36V DC

Food & beverage, pharmaceutical, chemical & petrochemical industries, conventional & nuclear plants, pumps, presses, turbines, hydro-cleaning machines, diesel engines & refrigerating plants. Special Features : Programmable Input (RTD / Thermocouples / mV, Ω ) Linear Signal Output Current Loop Powered Configuration with a PC via USB cable High Accuracy and Repeatability
