Insulating Kraft Paper Dealers

• Pulp Material:: Wood Pulp
• Paper Type:: Craft Paper
• Feature:: Moisture Proof
• Size:: 50CM*70CM
• Pulping Type:: Mechanical Pulp

 1) Material: Virgin wood pulp or recycled pulp; 2) The product is made from selected quality virgin fiber and manufactured with latest state of art technology;3) GSM (weight of per square meter): 40gsm-450gsm;4) Standard sheet size: 787*1092mm / 889*1194mm;5) Roll size: As per your requested;6) Color: Brown, natural white and bleached high white, black, gold and so on;7) Logo:G&J paper or customized;

We VT EXIM INDIA Pvt Ltd, Deals in wide range of voice coil insulation paper for Bobbin and for KraftingReinforcement. We mainly deals in Self bonded Paper either theBobbin material or the Reinforcement paper it specially made for voice coil insulation work. We also supply without coated Polymide paper(KSV) and TIL Glass-fibre paper on demand.

• Width: Upto 50 mm
• Color: Brown
• Brand Name: Arihant Impex
• Thickness: 3 Mm
• Usage/Application: Transformer Winding
• Packaging Type: Roll
• Width Per Roll: 40 Mm

• Thickness: 0.006-0.2mm
• Form: Roll
• Paper Type: Insulation Paper
• Treatment: Coated
• Temper: Soft

We are the supplier of this products.

• Brand Name: VinCork
• Application: Electrical And Automotive Industry
• Type: Insulating Kraft Paper
• Thickness: As per customer requirement
• Country of Origin: India

• Material: Kraft Paper, Wood pulp
• Color: Natural
• Form: Paper
• GSM: 130
• Width Per Roll: 500,1000mm
• Pattern: Plain
• Grade: Electrical
• Packaging Type: Rolls
• Paper Size: 500, 1000mm
• Usage/Application: Transformer Insulation

• Material: Kraft / Crepe
• Thickness: 0.5-1mm, 1-1.5mm
• Color: Brown
• Feature: Antistatic, Moisture Proof
• Packaging Type: Jumbo Rolls & Slitted Rolls
• Elongation: 10 - 300 %

We are engaged in offering our valuable buyers with high quality Insulating Kraft Paper. The Insulating Kraft Paper we offer is made in compliance with set industrial standards, hence is highly dependable. As a reliable Manufacturer and Supplier from Meerut, Uttar Pradesh, we ensure that customers from all over the country receive their order of Insulating Kraft Paper within the postulated period of time.   Specifications :  UOM : Kg.

• Color: Brown
• Brand Name: Lee Vedla
• Usage/Application: Transformer Winding
• Size: Roll Width 500, 750 & 1000 (mm)
• Packaging Type: Carton Box
• Pack Size: 100 Pieces

• Type: Insulating Kraft Paper, Slitted
• Color: Brown
• Application: Industrial
• Width: 500 M
• Color: Brown
• Slit Size: 15 mm and above
• Pack Type: Roll

• Color: Brown
• Usage/Application: Transformers Winding
• Packaging Type: Roll
• Thickness: 1.5 mil upto 20 mil

• Features: Sturdy construction,Durable,High functionality, Compact design ,Impeccable finish

• thicknesses: 1.5 mil (40 microns)

The quality Insulation Kraft Papers offered by us are appreciated for features such as good insulation property, high temperature tolerance, non toxic, bio-degradable and easy to use. These are used in various electrical applications such as insulation of transformers, wrapping of DPC wires, cable industry and other electrical items. Further, our Insulating Kraft Papers are slitted paper as per the accepted industrial specifications.

Electrical Grade Insulating Kraft Paper manufactured by M/s: Aura Paper Industries. We offer this material in 2 mil, 2.5mil, 3 mil, 5 mil and 10 mil.And Crape Paper, Semi Conducting Crape Paper.

Electrical Grade Insulating Kraft Paper that we supply is made from excellent grade of virgin fibers. These raw materials are imported from different countries. These are widely used as an insulation material of copper and aluminum wires. Apart from this these are also used in winding of transformer, motor, rotor coils.

• Size Range: 70 sq mm to 150 sq mm

Kraft paper insulation is most commonly used in oil filled transformers. The plain kraft papers are wrapped in number of layers on conductors, to acquire the needed insulation strength. However, plain kraft paper has limitations of the flexibility and leads to breakage of insulation in tight shaping of the coils. For this purpose, kraft papers are fabricated or creped. The folds made in creping process, increases the elasticity and flexibility during shaping of coils. It also enlarges the surface area of insulation and absorbs insulating oils resulting in better insulation and heat dissipation during operation. Crepe Kraft Paper Insulated Copper Cables are mainly used as an insulation in oil cooled transformers, current transformers of type IMB, CT, CVT as leads and shields. Crepe paper has 300% more strength in machine and cross machine direction and hence is more resistant to breakage. It can also take various shapes of the surface being insulated. The cable is wound on FRP Rings, 3 to 12 turns as per transformer application. This is also most suitable as lead wire and terminal wires of PT windings.

Direct Importer Of "AMOTFORS" Sweedish Origin Electrical Grade Insulation kraft Paper Used For Interlaying Of Transformers and Copper & Aluminium Conductors wrapping ( Coverings Ranges Form 40 Micron (1.5 mill) To 125 micron (5ml). *   Transformer Industries interlayer insulation*  Wrapper of Copper & Aluminium Conductors.   INSULATING KRAFT PAPERElectrical Grade Insulating Kraft Paper available in jumbo orslit rolls from 1.5 to 6 mils thicknessSlit Widths : Insulating Kraft Paper in slit width (ready to use)

Stockist Of "ITC" Brand "UBIL" Electrical Insulation Craft Paper Suitable For Aluminium & Copper Conductors Wrappings Sizes Rauges Form 1.5 mill to 5mill

• Color: Natural Brown

We are offering electrical grade insulating kraft paper made entirely from high purity imported virgin fibres. used widely as electrical insulation wrap on aluminium and copper wires by conductor manufacturers, electrical insulation between layers of wound coils in electrical motors, in capacitors, transformers & such other electrical equipment available in natural brown finish

• Brand Name: Imported
• Color: Brown
• Thickness: 1.5,2,2.5,3,4,5,6 Mil
• GSM: 40, 50, 60, 80, 100, 120 Gsm
• Paper Type: Insulating grade
• Pulp Material: Wood Pulp
• Usage/Application: Transformer Winding
• Packaging Type: Roll
• Paper Size: 1.5 mil to 20 mil
• Weather Proof: Yes

• Color: Brown
• Country of Origin: Made in India
• GSM: 35 GSM
• Usage/Application: Transformer Winding
• Brand: Goyal Engineers
• Packaging Type: Roll
• Length: 10 m

laminated insulating kraft papers, insulating kraft papers

Insulating Kraft Paper, Beryllium Copper Alloy, aluminium crepe paper

We are engaged in importing and supplying of Thermally Upgraded Insulating Kraft Paper. Thermally Upgraded Insulating Kraft Paper is a kraft paper with nitrogen-based additive. The Thermally Upgraded Insulating Kraft Paper is defined by the IEC60076-2 ed 3 section 3.18. Its definition is based on a life expectancy, which shall be at least 65000 h for 50 % retained tensile strength at 110oC in a sealed tube. However, definitely it is considered by the IEC as a class 120oC insulating material. Details Make : Finnish �Tervakoski�Thickness : 50µm, 63µm & 75µmColour : GreenDimensional availability : In rolls of 500 mm width

electrical grade insulating kraft papers
