Kymograph Dealers

We are offering Recording Drum. This is an electrically driven recording drum or kymograph suitable for use by students for lab.Experiments. These Kymographs are also used to measure atmospheric pressure, tuning fork vibrations and functioning of steam engines. Its drive mechanism consists of constant speed heavy duty electric motor and an accurate gear box contained in the base together with robust plate clutch. Engagement of various gear ratios are affected by sliding the lever into the slot marked with surface speed or by a knob. The recording drum or cylinder has a 6' dia and stainless steel spindle have been standardized to make the same universal and interchangeable. It has 8 variable speeds. The speed is measured in mm per second. Eight variable speeds are 0.12, 0.25, 1.25, 2.5, 12.5, 25, 320 and 640 mm per second. A hand gear is provided to change the speed of the kymograph. Double electric contact arms are clamped on the main spindle and a stout double-contact block is fitted on top of the base. It runs on 220V, AC 50Hz.

• Brand Name: MEDITECH
• Power: 230V & 110V
• Application: Labouratory Use
• Color: Blue

Meditech technologies india pvt. Ltd is the largest manufacturer and exporter of brodie starling kymograph (large extension kymograph). Super speed kymographs are known as life experimenting gadgets, which are designed by the renowned experts. We are offering these super speed kymographs, featured with the major characteristics that will help you to simplify you work. In addition to that, we are acknowledged as the topnotch super speed kymograph manufacturer and exporter.

Recording drum (kymograph) technical specifications:- electrical student kymograph with special heavy duty motor, oil lapped gear systems, speeds from 0.12 mmsec to 640 mmsec, in 8 steps, jerk free running, instantaneous start & stop clutch. Stainless steel spindle with screw lift 15 x 15cm cylinder with leveling screws, pilot lamp, plug & cord. Recording accessories: it consists of below accessories: accessories 19 no.:- 1. kymograph paper 2. induction coil 3. universal lever 4. hook weight 5. tambour 6. tuning fork 100 7. tuning fork starter 8. semir clamp (brass) 9. double clamp 10. electric time maker 11. heart lever 12. frog board 13. stylus with pointer (aluminum) 14. simple key 15. electrode with copper wire 16. smoking burner 17. muscle chamber with muscle lever & electrode 18. heart chamber with heart lever & electrode 19. simple stand accessories 11 no.:- 1. double fatta induction coil 2. dubois key complete with table clamp 3. tuning fork 100 4. myograph complete with lever 5. drum paper clip 6. simple electrode with copper wire 7. adjustable stand 8. smoking burner 9. kymographic glazed striper (25 sheet) 10. muscle chamber with electrode 11. heart chamber with electrode

• Condition: New
• Warranty: 1 Year
• Application: Industrial,Laboratory
• Power Source: Electric
• Paper Length: 2. 5 meters
• Features: Efficient Performance, Sturdy and Durable

Known for its efficient performance, sturdy and durable construction, this Super Speed Kymograph is highly appreciated in the market. Manufactured using high quality raw materials and advanced machinery, it is processed through a number of quality checks. We being one of the leading suppliers of this product, provide this quality product at a very reasonable rate. This product is used for the purpose of graphical representation of spital position over time. Features : We offer very good quality super speed kymograph with improved life time pinion lift Range of fine vertical adjustment 15cm. Close mesh 10 speed gear box, gear ratios 1:2 no. Backlash. Instantaneous start at all speeds with built in vibration free, noiseless motor, speed variation from 1 rev. In 25 min. To i rev in ii hours. Research Kymograph permissible paper length 2. 5 meters, adjustable along machined 120 cm bed; automatic paper tensioning devices, flat writing surface attachment 3 jointed arm uprights with fine tangential adjustment, auxiliary cylinder with fine tilt adjustment to permit equalization of tension at the top & bottom of the paper, neutralization clutch for immediate start & stop, centralized electrical points for respiration pump, time clock and operation table, mounted on heavy metal platform with castora, with manometer & two way time marker.

• Driven Type: Electric
• Color: Grey
• Application: Laboratory
• Certification: CE Certified
• Voltage: 220V
• Warranty: 1 Year
• Country of Origin: India
• Brand Name: Janta India
• Material: Stainless Steel

This is an electrically driven recording drum or kymograph suitable for use by students for lab experiments to measure atmospheric pressure, tuning fork vibrations and functioning of steam engines.

• Condition: New
• Application: Laboratory, Industrial
• Weight: 7.5 kg
• Voltage: 220 V
• Warranty: 1Year
• Power Source: Electric

• Color: White
• Warranty: 1 Year
• Usage: Laboratory, Industrial
• Power Source: Electric
• Paper Length: 2. 5 meters
• Features: Sturdy and Durable, Efficient Performance

The Electrically Opened E-8 recording drum is very suitable for student use and general experimental work. The entire driving mechanism, consisting of constant speed electric motor workable on 220 V AC Hz single phase and gear box contained in the base together with robust plate clutch is a synchronized system. Engagement of the various gear ratios is effected by sliding the lever into the slot marked with the surface speed required. Considered care has taken in selected the gear ratio to provide speed which will be suitable for all student experiments.   Various accessories like Adjustable Stand, Frog Board, Myograph Lever, Muscle Holder, Heart Clip, Starling Heart Lever, Simple Electrode, Tuning Fork, Aerator etc are available to be used along with Kymograph.

KYMOGRAPH 1. Kymograph (Recording Drum) 2. Du Bios Key 3. Smoking Burner 4. Smoking Stand 5. Simple Lever 6. Paper Clip 7. Staring Heart Lever 8. Muscle Chamber 9. Starling Writing Lever 10. Mayo Graph Lever 11. Mayo Graph Board 12. Mayo Graph Stand 13. Simple Electrode 14. Student Stimulator 15. Student Stimulator Digital 16. Tunic Fork 17. Muscle Electrode 18. Muscle Lever 19. Muscle Lever 20. Hook Weight Set 21. Induction Coil 22. Kymograph Paper 23. Simele Key

Owing to our excellent connectivity, trusted shipping facilities, we smoothly deliver the product basket to the clientele. We are supported by a well-managed and automated warehouse system wherein we store the entire lot in a secured manner. The automatic handling, storage and distribution of the goods thus become an ease. Microprocessor Controlled Speed Selections 0.12, 0.25, 0.50, 0.75, 1.00, 1.25 mm/sec Special Mode for Concentration Responses Curve. In this mode we have to select contact time and number of doses. 16X2 LCD display. Maintenance Free. Very Low Power Consumption -12V D.C. 1 Amp. Timer & Multiplier Select With Audio AND Visual Alarm Indicator Easy Height Adjustment of Drum. Very Handy Keypad.

• Brand Name: Orchid Scientific
• Power: 220 V
• Application: Used in Pharmacology Labs for Research Purpose

Kymograph consisting of a revolving drum, bearing a kymograph paper on which a stylus moves up and down displaying the effects of the drugs on contractile tissues, is commonly used in experimental physiology and pharmacology laboratories in teaching institutions. Muscle or tissue movements are recorded on paper fixed on moving drum using recording lever. Orchid’s Sherrington recording drum is microprocessor controlled unit and is advanced version in comparison to old type of electrically driven pulley adjustment drum. Features:(DIGITAL KYMOGRAPH- Model SRD01)• Maintenance free: Microprocessor controlled unit• 16×2 LCD Display• Digital speed selection• Highly accurate speeds-0.12,0.25,0.50,0.75,1.00,1.25,2.50 mm/sec• Digital Timer & Time multiplier with Audio & Visual Alarm• Very low power consumption• Easy height adjustment of drum• Auto concentration response curve(CRC) mode & Normal mode• Sturdy, corrosion resistant body• Battery backup(optional)

• Type: Kymograph
• Application: Laboratory,Laboratory
• Color: White
• Voltage: 240 V
• Condition: New
• Automatic Grade: Automatic
• Driven Type: Electric
• Country of Origin: India

The Kymograph that we offer consists of various accessories and is therefore widely demanded in the market. We are renowned among the reliable Kymograph Manufacturers, Suppliers and Exporters offering Kymograph at reasonable cost. Technical Specifications Electrical Student Kymograph with special heavy duty motor, oil lapped gear systems, speeds from 0.12 mm/sec to 640 mm/sec, in 8 steps, jerk free running, instantaneous start & stop clutch. Stainless steel spindle with screw lift 15 x 15cm cylinder with leveling screws, pilot lamp, plug & cord. Recording Accessories : It consists of below accessoriesKymograph PaperInduction CoilUniversal LeverHook WeightTambourTuning Fork 100Tuning Fork StarterSemir Clamp (Brass)Double ClampElectric time makerHeart LeverFrog BoardStylus with Pointer (Aluminum)Simple keyElectrode with Copper wireSmoking BurnerMuscle Chamber with Muscle Lever & ElectrodeHeart Chamber with Heart Lever & ElectrodeSimple StandDouble fatta Induction CoilDubois Key complete with Table ClampTuning Fork 100Myograph complete with LeverDrum Paper ClipSimple Electrode with Copper wireAdjustable StandSmoking BurnerKymographic glazed striper (25 sheet)Muscle Chamber with ElectrodeHeart Chamber with Electrode
