Lever Operated Directional Control Valve Dealers

A hydraulic valve properly directs the flow of a liquid medium, usually oil, through your hydraulic system. The direction of the oil flow is determined by the position of a spool. A hydraulic system can only function - as per requirements - by using valves. Thus, you should always look for the correct type of hydraulic valve to serve your intended purpose.

• Fluid temperature: 20 to 70 degree C
• Viscosity Range: 10 CST to 380 CST
• Normal flow capacity: 32 LPM
• Max flow capacity: 100 LPM
• Working Pressure Port T: 16 Mpa

BRN - Joystick operated Double Action Directi Control Valve

• Type: Hydraulic Directional Control Valve
• Material: Carbon Steeel
• Certification: ISO 9001:2015
• Application: Oil Fitting
• Feature: Casting Approved
• Temperature Of Media: Normal Temperature
• Country of Origin: India
• Pattern: Plain
• Automatic Grade: Manual
• Pressure: High
• Number Of Way: 4way

• Country of Origin: India

Brand : YukenMax Flow : 63 Ltr/MinMax Operating Pressure : 315 KG/cm2Max Back Pressure : 160 KG/cm8   Valve Model

• Country of Origin: India
• Size: NG 06
• Application: Oil Fitting
• Automatic Grade: Manual
• Pressure: Medium Pressure
• Type: Lever Operated Directional Control Valve
• Temperature Of Media: Normal Temperature
• Features: Rust resistance, Flawless finish, Dimensionally accurate
• Item Code: MV-03

We introduce ourselves as a prominent manufacturer, trader and supplier of an extensive array of Lever Operated Directional Control Valve. This valve is designed and manufactured using exceptional quality steel that is procured from the most trusted vendors of the industry. The offered valve is made available in different sizes and dimensions for our clients to choose from. Our precious clients can purchase the offered valve from us at reasonable prices.Features: Rust resistance Flawless  finish Dimensionally accurate

• Automatic Grade: Manual

Completely encapsulated mechanism for protection against dirt. Five chamber design for better reduction in dynamic forces and longer valve life. Available as spring centered, spring off-set or detented model. Operating head can be rotated by 90° x 4 around spool axis for flexibility in mounting. Valve mounting interface conforms to ISO 4401-03-02. Five chamber body and spool design provides low-pressure drop, with maximum performance. Balanced spool design ensures proper shifting force for maximum reliability and long life. All spools and bodies are interchangable, simplifying maintenance.

• Material: Mild Steel
• Size: 4DCL20
• Pressure: High Pressure
• Brand Name: PRISM
• Valve Size: 4DCL20
• Model Name/Number: 4DCL20

Completely encapsulated control mechanism for protection against dirt. Five chamber design. Flexibility in rotating the operating mechanism by 90 x 4. Wide variety of spool types with spring centered, spring offset & detent arrangements.

Lever operated directional control valve Aluminium Alloy mounting panel for quick mounting and dismounting. Pneumatic circuits can be designed in software and the same can be demonstrated on training kit.

• Country of Origin: India
• Size: 1/2inch
• Material: Metal
• Certification: ISO 9000:2015
• Application: Oil Fitting
• Automatic Grade: Manual
• Pressure: High Pressure
• Number Of Way: 2way,3way,4way
• Type: Lever Operated Directional Control Valve
• Temperature Of Media: Normal Temperature

Lever operated directional control valve with or without safety valve, WINDE is monoblock distributor. Its body is made of cast iron EN -GJL300. Plungers are made of carburized steel with hard chrome plating,

• Material: Mild Steel
• Model Name/Number: DL06 CETOP 03
• Type: Liver Operated
• Weight: 0.75 Kg
• Mounting Type: Subplate body
• Viscosity Range: 10 to 380 cSt
• Construction: Spool type
• Operating Pressure: 150-315 Bar
• Nominal Flow Handling Capacity: 63 lpm
• Working Temperature Range: -20 Degree C to +70 Degree C.

• Material: Stainless Steel
• Usage/Application: Water
• Model Name/Number: A4VG
• Brand: Rexroth
• Power Consumption: 30 Watt
• Mounting Type: Flange Type
• Nominal Pressure: 450 Bar

• Max. Operating Pressure Kgf/cm2: 250
• Mass Kg: 1.8

Varies depending of the spool type. For the detail, see the “List of standard models and max. flow” for DSG-03 Series Solenoid Operated Directional Valves,Lever operating torque varies depending on the T-Line back pressure. See the figure below.

• Brand Name: Polyhydron
• Mounting Position: Optional
• Hydraulic Medium: Mineral Oil
• Viscosity Range: 10 to 380 cst
• Working Temperature Range: -20 Deg C to +70 Deg C
• Weight: 17.5 Kg Approx
• Operating Pressure: 350 Bar

We are supplier of Lever Operated Directional Control Valve.

• Size: CETOP 03, 05
• Brand Name: Duplomatic
• Model Name/Number: DSH3, DSH3L, DSR3L, DSR3H, DSA3, DSC3, DSH5, DSA5
• I Deal In: New Only
• Directional Control: Yes
• Valve Style: Lever Operated Directional Control Valve
• Maximum Operating Pressure: 320 BAR
• Mounting: Subplate
• Features: Higher efficiency, Compact size, Cost-effective for Automotive applications, High product quality

lever operated directional control valve, Solenoid Operated Valve

• Size: NG6, NG10
• Pressure: 350 Bar
• Brands: Atos, Epitome, Nachi, Polyhydron, Rexroth, Vickers, Yuken
• Model No.: 4DL6, 4DL10, DMG-03, DMG-06

Hand Lever Operated DC Valve, Male Connector, Female Connector, Male Elbow
