Sheet Metal Lever Limit Switch
Get Price Quote
Features : The lever Limit switch operates when its lever reaches its pre-determined position and the lever is moved over a projecting member fixed on the Girder. The Limit Switch contacts are automatically reset when the lever returns to zero position due to spring action. The Lever Limit Switch is made in IP-41 as well as in IP-54 enclosure. In case of IP 41 enclosure the housing is made from suitably reinforced sheet steel where as in case of IP-54, the cover is of Cast Aluminum. Also in this case the base and cover have machined surface to protect the Limit Switch against dust. The cam shaft on which the cams are fitted is mounted in the housing on moulded bushes of synthetic material which are fixed to the front and rear walls by means of screws. The Cams which are fitted on the cam shaft are moulded from the highest quality synthetic material and are accurately cut to correspond to the switching sequence desired. The contacts have a maximum continuous Current capacity of 40 amps AC. The contact tips are made of high grade Silver Cadmium Oxide alloy. When used for Series operation[ up to 40 Amps maximum], the Contacts are suitable for 720 operations per hour and in case of Shunt operation [ for Control Circuit ] , the Contacts are suitable for 1200 operation per hour. The same Contacts can be used in Series as well as in Shunt configurations The switching capacity of the Contacts when used for Shunt operation is 15 amps at 400 Volts, AC on highly inductive load and 2.5 amps at 220 Volts DC . These switching capacities in fact are far in excess of what is actually required in practise and hence replacement of Contacts for Shunt may not be necessary for a long time. The body of the Contacts is made of high grade Melamine which is specifically suited for heavy duty operation .The material is non – tracking and is capable of with standing heavy arcing.
40 AMP Lever Type Limit Switch
2,350 Per Piece
5 Piece (MOQ)
Best Deals from Lever Switch
Crane Lever Limit Switch
Get Price Quote
100 Piece (MOQ)
Peco 0170 LHD Ex-Lever Combination Switches
1,916 Per
1 Carton (MOQ)
THIS COMBINATION SWITCH IS MANUFACTURED FOR ALL TATA MOTORS VEHICLES FOR LEFT HAND DRIVE EXTENDED LEVER MODELS 1613/3118/TILTCAB. O.E.MANUFACTURER PART NO - 288454500101
Roller Lever Micro Switch
25 Per Piece
100 Piece (MOQ)
0.0
Website
Lever Limit Switch
2,000 - 5,000 Per Piece
0.0
View Profile
Non Lever KW7 Micro Switch
8 Per Piece
0.0
View Profile
Z-15GW-B 15A 250V to 450V Heavy duty SPCO Stainless steel lever arm plastic switch
46 - 57 Per piece
1000 Piece (MOQ)
This is a stainless steel lever arm switch. It has 3 pins, number one is used for input and the other two are used as output. The color of this switch is shiny black. It can withstand high room temperature. The switch offers momentary terminal switching but one output at a time. When the switch is pressed down, it changes the pole to terminal 2. And when again it is pressed down, it changes the output to terminal 3. The switch is built from high plastic material which gives the switch strength and hardness. The wear and tear properties are also very high. It can work for longer durations. The life cycle continues for approximately 10,000 clicks. The switch is not waterproof but it resists water and dust particles. The lever is made up of high-quality stainless steel. Package includes This is the pack of a single piece of Z-15GW-B 15A 250V to 450V Heavy duty SPCO Stainless steel lever arm plastic switch Features High temperature resistance Standard size offers easy installation Momentary switching one output pole at a time Change over feature Hard plastic material use in the making of this switch High wear and tear properties.
0.0
View Profile
Lever Limit Switch
2,000 - 4,000 Per Piece
10 Piece (MOQ)
Mono Lever Switch
500 - 1,000 Per Piece
0.0
View Profile
Lever Combination Switch
1,600 Per Piece
1 Piece (MOQ)
0.0
View Profile
No-nc Lever Micro Switches
Get Price Quote
0.0
View Profile
Lever Limit Switch
Get Price Quote
Description: Suni Lever Limit Switch is used for heavy duty E.O.T. Cranes, Wagon shunting devices etc., to prevent over travelling or over traversing on power and control circuit up to 500 volts A.C. 50 cycles / second and 40 amps current rating. We are counted among the ecstatic Lever Operated Limit Switch Manufacturers in India. Suni makes Lever type Limit Switch normally remains closed and cuts off power to stop the motor of the particulars motion. Suni Make lever Limit switch operates when its lever reaches its pre-determined position and the lever is moved over a projecting member fixed on the Girder. The Limit Switch contacts are automatically reset when the lever returns to zero position due to spring action. The Lever Limit Switch is made in IP-54 enclosure. In case of IP-54, the cover is of Cast Aluminum. Also in this case the base and cover have machined surface to protect the Limit Switch against dust. The cam shaft on which the cams are fitted is mounted in the housing on moulded bushes of synthetic material which are fixed to the front and rear walls by means of screws. The Cams which are fitted on the cam shaft are moulded from the highest quality synthetic material and are accurately cut to correspond to the switching sequence desired. The contacts have a maximum continuous Current capacity of 40 amps AC. The contact tips are made of high grade Silver Cadmium Oxide alloy. When used for Series operation [up to 40 Amps maximum], the Contacts are suitable for 720 operations per hour and in case of Shunt operation [for Control Circuit], the Contacts are suitable for 1000 operation per hour. The same Contacts can be used in Series as well as in Shunt configurations The switching capacity of the Contacts when used for Shunt operation is 15 amps at 400 Volts, AC on highly inductive load and 2.5 amps at 220 Volts DC. These switching capacities in fact are far in excess of what is actually required in practice and hence replacement of Contacts for Shunt may not be necessary for a long time. The body of the Contacts is made of high grade Melamine which is specifically suited for heavy duty operation .The material is non tracking and is capable of with standing heavy arcing.
0.0
View Profile
Flameproof Fork Lever Type Limit Switch
Get Price Quote
Applications : 1) FLAMEPROOF-WEATHERPROOF for limit switch with contact element. • Features : 1) High Tensile strength 2) Protect IP65/66 3) Available for Zone1 & Zone 2 4) Gas Group IIA , IIB and IIC 5) Ex d , Explosion Proof, FlameProof, Weatherproof
0.0
View Profile
lever type limit switch
1,600 Per Piece
Lever Type Limit Switch is used for heavy duty E.O.T. Cranes, Wagon shunting devices etc., to prevent over traveling or over traversing on power and control circuit up to 500 volts A.C. 50 Hz and 40 amps current rating
0.0
View Profile
Lever Limit Switch
Get Price Quote
We are offering a wide assortment of quality Lever Limit Switches. The Lever Limit Switches are used to prevent over travel of hoisting motion on power. The limit switches generally remain closed and cut off power to stop the motor of the crane. They operate when on reaching a pre-determined position when the lever is moved over a projecting member fixed on the grid. We are a prominent Lever Limit Switch Manufacturer and Supplier from Delhi (India). We can make them available in standard and customized dimensions as per the buyer’s requirements. Specifications Control circuit up to 500 V 40 Amps continuous current
0.0
View Profile
MONO LEVER LIMIT SWITCH
449 Per PCS
Brand SIBASS Usage/Application INDUSTRIAL Switch Type Lever Limit Switch Pole Throw SPST Rated Voltage 240 VAC Model Name/Number XD2-PA14 Current Rating 10A
Roller Lever Micro Switch
60 Per Piece
1 Piece (MOQ)
Lever Limit Switch
Get Price Quote
Cam used in Lever limit switch, counter weight limit switch.
