Maximum Demand Controllers Dealers

We are offering demand controllerelmeasure's advanced micro-controller based load manager demand controller acts as a comprehensive load managing unit with inbuilt relay providing you with complete control over your electrical system. It enables the user to program the threshold values of max demand and initiate alarm cut - off when the forecast demand present demand max demand surpasses the threshold values. This will help the user from exceeding the sanctioned demand and avoid causing a trip or paying huge penalty.

• Country of Origin: India
• Type: Maximum Demand Controllers
• Weight: 0-500 Gm

We are a reputed Supplier of Maximum Demand Controller. The device offered by us is designed to allow stage wise load restoration to maximize the use of a sanctioned load. Our Maximum Demand Controller is the best choice for demand control of industrial consumers, HT consumers and commercial establishments. More about Maximum Demand Controller : Maxchek 400 is a smart maximum demand controller with standard size 96x96 mm specifically designed for industries to keep a check on their maximum demand. It gives an alarm when demand approaches a preset value and also switches off nonessential loads in a pre-programmed logical sequence.   Applications : Commercial and industrial sanctioned demand monitoring &controlling applications Control panels for complete plant demand controlling Demand management for commerce and industry  Benefits : Easy interface with external devices through built-in Modbus (RS-485) Detachable connectors for easy installation Three relay and one alarm output Suitable for star or delta connections and for low or high voltage applications Alarm output for audible indication. Field-configurable CT / PT primary and secondary values using push-buttons Calibration LED for on-site accuracy check Configurable software (ConfigView) for reading of parameters and load survey Shift wise demand configuration  Features : Two modes of programming - Preventive Mode (only Alarm nocontrol), Predictive Mode (Alarm and automatic control) Predictive demand control to forewarn, take corrective measures and check maximum demand crossovers Multi-level (phase wise and shift wise) priority based automatic load control mechanism to disconnect low priority loads in phased manner Configurable demand integration period for sliding and fixed type Optimised load disconnection time Online load planning by continuously indicating loads that can be added or need to be disconnected (within safe operating limits) Check meter with accuracy class 0.2s,0.5s and 1.0 Auto and push button display An user friendly software to program and monitor Control Outputs for alarm and trip applications - it provides 3 control and one alarm outputs, in the form of potential free contacts Large four-line seven-digit display (9.7 H x 5 W mm) with quadrant identification section and bar graph for instantaneous power-level indication

• Item Code: KM7200B
• Model Name/Number: KM 7200 B
• Brand: Kusam - Meco
• Accuracy: +- 0.2 %
• Relay Output: 4
• Mounting Type: Panel
• Supply Voltage: 220 V

We specialize in the production of highly reliable Maximum Demand Controller required for various electrical purposes. Our strict quality checking and unique manufacturing process have earned us fame in the market. Our clients speak very highly of our products due to the quality we maintain. They have passed tough safety checks and are covered under warranty. Our factory is ISO certified and fitted with ultra modern manufacturing equipments for smooth and safe production.

Features : Measurement of basic, power, energy and demand parameters. On-site programmable PT and CT ratios. High brightness LED display (alpha numeric for parameter, numeric for value). Automatic CT reverse correction for energy and demand. Programmable demand techniques : block / sliding window. Programmable demand parameters : Apparent / Active power. Programmable demand range : Kilo / Mega. Programmable Alarm / hysterisis settings. Program RTC time to match EB meter's clock. For EMS-15C : Max. Demand Controller = Max. demand indicator + Relay module (4 relay) (RR-4). 4 control outputs for alarm and trip settings. Dimensions : Overall : EMS 15,EMS 15C 96 x 96 x 117mm (W x H x D) RR-4 : 195x90x59mm(WxHxD) Cutout: 92 x 92mm(W x H) Applications : In-comer distribution panels

• Features: Crisp, High Visibility Display.

Maximum demand controllers Multi-Function series instruments help you to reduce electrical energy bills through better management of electrical energy usage. Data and settings retained upto 10 years under power failure.Communication with eLAN Energy Management System through optically isolated RS 485 serial port.

• Type: Maximum Demand Controllers
• Certification: CE Certified
• Auxiliary Supply: 240 VAC
• Country of Origin: India
• Accuracy: Class 0.5 S
• Mounting: Panel Mountable
• Application: LT/HT

MD Controller - To avoiding penalty for exceed Maximum Demand - Reduced operation cost - load Management - Reduce Demand Peaks without affecting operation - Predictive control method to optimise demand control - Built in TOD function

We are offering demand controller elmeasure's advanced micro-controller based load manager demand controller acts as a comprehensive load managing unit with inbuilt relay providing you with complete control over your electrical system. It enables the user to program the threshold values of max demand and initiate alarm cut - off when the forecast demand present demand max demand surpasses the threshold values. This will help the user from exceeding the sanctioned demand and avoid causing a trip or paying huge penalty.

• Brand Name: PENTACON

We are offering maximum demand controller. 1-microcontroller based 2-wide working voltage between r-n, 150v to 240v 3-default display kva/mva 4-display of phase ampere and voltage of individual phase is on selection. 5-current sensing through up to 5000a/ 5a ct auto range selection 99.9 kva to 999 kva to mva range 6-ct ratio selection 5a, up to 995 and 50a in ka range 1.00ka 7-auto range selection 99.9 kva to 999 kva to mva range 8-200% over load capacity 9-resolution 0.1 kva instruction : for selection the display press and hold the button `up` the short form of related parameters will scroll on display window. Releasing the button at desire parameter would be selected to display. The explanation of display short forms are given below ctr : ct ratio trp : kva/mva selection to trip (range up to 4.5 mva) a.dl : alarm delay (range up to 30 second) c.dl : contactor delay (range up to 15 minuts in 30 seconds resolution) f.dl : off delay or reset delay (range up to 30 seconds) r_u : r phase voltage y_u : y phase voltage b_u : b phase voltage r_a : r phase ampere y_a : y phase ampere b_a : b phase ampere ret : return to display kva/mva mode note - selection of parameters `ctr, trp, a.dl, c.dl, f.dl` to display, will display for only two seconds

• Driven Type: Electric
• Certification: CE Certified
• Features: Low power factor monitoring, Computer connectivity, True RMS and 4Q- measurements, Monitors and Controls Maximum Demand either in KW or KVA
• Item Code: H-6

We are offering maximum demand controller. General features: 1 alarm point and 1 tripping point (potential free) friendly user interface easy to install display features continuous display of average kva demand instantaneous demand, rms voltage, rms current selectable display of setting selectable display present and previous maximum demand trip status of contacts control features password protection for settings adjustable integration time of 15 minutes or 30 minutes programmable ct primary adjustable demand settings manipulating facility clock setting facility to match eb clock voltage input 415v ac -15% current input --5a --1a optional frequency 50hz switching contact 10a at 250v ac accuracy 1 digit mechanical specifications dimensions 144(l) x 144(w) x 120(d) mm panel cutout 138 mm x 138 mm.

• Throw Type: Double Throw
• Phase: 3 Phase
• Capacitor Banks: 6, 8, 12 Stages

We are supplier and exporter of this product.

Global Energy Management Solutions India Private Limited (Circutor INDIA) is engaged in manufacturing a qualitative range of Maximum Demand Controller which is widely acclaimed in the electricity and power industries. Our Maximum Demand Controller results in the most efficient utilization of energy and is quite economical. We provide a prompt delivery to our clients.

DESCRIPTION:- Maximum Demand meter is used for monitoring thermal loading in Power Distribution systems, Networks, Machines etc. It indicates maximum loading current over a period. Short-period current peaks are not registered but long overloads are registered. In the Maximum Demand meter the measuring current flows through the bimetal spiral which is temperature sensitive. The free end of the spiral is connected to a black measuring pointer. The moving system is activated by heat generated by the current flowing through the spiral. The instrument is provided with an additional red slave pointer with a higher friction, which makes it to remain at its maximum position, which determines the maximum average loading current. The high torque of metallic movement drags the red pointer along with the black pointer. The red pointer remains stationary at the maximum value reached. This can be reset by rotating the knob provided on front facia. To prevent false indication due to fluctuations in ambient temperature, an additional bimetallic spiral is wound in opposite direction, which is mounted on the same spindle to compensate variation in temperature from -10 to + 55 degrees Centigrade. Frequently there is a need to measure instantaneous current simultaneously & hence moving iron movement having the same range is incorporated in the same meter. FEATURES:- RMS measurement of maximum current. Long current peaks are registered. Red pointer to indicate maximum current reached. Analogue Indication. 20% overload capacity. ELECTRICAL SPECIFICATIONS:- TYPE:- BIMETALLIC; ANALOGUE AMMETER. OPERATING CURRENT:- 1 Amp or 5Amp FREQUENCY:- 40 ~ 65Hz. OPERATING TEMP. :- -10°C to 55°C (for Analogue Instrument) STORAGE TEMP.:- -20° to 70°C HUMIDITY:- Up to 95% RH

We take pride in introducing ourselves as one of the leading Suppliers of Maximum Demand Controller in Mumbai. Maximum Demand Controller is specifically designed for industries to keep a check on their maximum demand. Maximum Demand Controller gives an alarm when demand approaches a preset value and also switches off non-essential loads in a logical sequence. This predictive Maximum Demand Controller (MDC) allows stage wise load restoration to maximize the use of a sanctioned load. Maximum Demand Controller is most suitable for the demand control of industrial consumers, HT consumers and commercial establishments. Features of Maximum Demand Controller Predictive demand control to forewarn, take corrective measures and check maximum demand crossovers Multi-level priority based automatic load control mechanism to disconnect low priority loads in phased manner Optimized load disconnection time. Online load planning by continuously indicating loads that can be added or need to be disconnected (within safe operating limits). Check meter with accuracy class 1.0s and 0.5s Auto and push button display A compact user friendly hand-held programmer for field usage Two modes of programming Configuration Mode - user can program Maximum Demand Controller for contract demand, DIP, demand unit and basis of MD calculation. Setup Mode - user can set priority wise trip load value setting, allowed demand limit setting (TOU) and time setting in Maximum Demand Controller. Control Outputs for alarm and trip applications â�� it provides 4 control outputs, in the form of potential free contacts

Meter measures Active, Reactive, Apparent energy on 3 phase 4 wire system, All four quadrant measurement for MD, KWh, KVAh, KVArh (import lag, import lead, export lag and export lead) are measured and stored in four energy accumulators, Parameters can be viewed through 7 segment LED (3 row), Soft Keys are provided to stop, scroll, edit and to view the parameters, RTC with battery backup is used for time keeping and has a calendar of 100 years, Power Line Communication can be done using RS485 communication with MODBUS RTU (Baud rate : 9600, 19200, 38400)

• Weight: 0.5 kg (approx)
• Dimension: 96 x 96 x 115 mm, Cut out size 92 x 92 mm
• Measurement Voltage Range: 57.7 V (100V) - 240 V (415 V) AC 3 phase 4 wire (3 phase 3 wire)
• Tolerance: -30% to +20% of Vn
• Aux Power Supply Range: 80 - 300 V AC/DC or 24 - 60 V DC (Variant)
• Current Range: Available 1-2A and 5-10 A in single variant (field configurable)
• Main Frequency: 50/60Hz with +/- 5%
• Mechanical Enclosure: FRPC
• Max Conductor Size: 2.5 mm2
• Operating Temperature: -20 to 60 Deg C
• Storage Temperature: -25 to +80 Deg C
• Humidity: 95% non-condensing

• Color: Black And Silver
• Condition: New

Maxchek 400 is a smart maximum demand controller with standard size 96x96 mm specifically designed for industries to keep a check on their maximum demand. It gives an alarm when demand approaches a preset value and also switches off non-essential loads in a pre-programmed logical sequence. This predictive maximum demand controller (MDC) allows stage wise load restoration to maximize the use of a sanctioned load. Maxchek 400 is most suitable for the demand control of industrial consumers, HT consumers and commercial establishments. It also supports ethernet module for communication.  Application Commercial and industrial sanctioned demand monitoring & controlling applications. Control panels for complete plant demand controlling. Demand management for commerce and industry.   Benefits Easy interface with external devices through built-in Modbus (RS-485/Ethernet). Detachable connectors for easy installation.

• Dimension: 96 X 96 X 117 mm
• Brand Name: EAPL
• Operating Voltage Range: 170V - 270V AC/DC
• Rated Frequency: 50 / 60 Hz +/- 5% for AC only
• Power Consumption: 5 VA / 1W

Demand control is a method of controlling the consumption not to overload the grid.Demand is calculated in different ways, different parameters depends on the regioncountry.

• Frequency: 50/60 Hz
• Weight: 0.5 kg Approx
• Temperature: -20 Deg C to + 60 Deg C
• Humidity: 95% non-condensing
• Ingress Protection: IP54
• Aux Power Suppluy Range: 80-300 V AC/DC OR 24-60 V DC (Variant)

The digital power meter GOBLIN is a micro-controller based unit which not only measures a host of electrical parameters to display them on a 128 x 64 backlit LCD, but also acts as a comprehensive load managing device due to its four numbers of output relay contacts. These outputs are individually field programmable for both the parameter on which to generate alarm as well as the values on which to activate alarm and deactivate it. In addition to this flexibility in terms of load management, the meter also has two serial ports: USB port and RS485. RS485 supports MODBUS RTU protocol for connections to EMSSCADA. Goblin has two USB ports-one where a cable connection to laptoppc is made(Device mode) and another where the unit directly accepts a pendrive(Host mode).

An MD controller enables the user to program the threshold values of maximum demand and initiate actions i.e. alarm or cut off load when maximum demand / forecast demand / present demand crosses the threshold values. This helps the user to ensure that demand doesn’t exceed the sanctioned demand and avoid paying huge penalties. Parameters: V, A, F, kW, KVA, kVAr, kWh, kVAh, kVArh, PF, Runhr, Onhr, Intr, Phase angle, THD, Events, Neutral current, Max Demand (with RTC) with 4 relay outputs. Salient features Accuracy Class 1 as per IEC 62053-21 True RMS measurement Password Protection provision for security Phase wise Voltage & Current Wave Forms in LCD meter Site selectable for 3 Phase 4 wire, 3 Phase 3 wire, 1 phase Maximum demand measurement with Real time clock Time of Day (TOD) provision is available 6 Demand and 6 Energy option with MD occurance captured for each TOD 4 relay outputs available for proper load control Data logging provision is available Auto scrolling and freeze mode for constant single page viewing available Terminals with sealing provision (optional) Direct access key for Basic parameters, Power and Energy parameters

• Voltage: 110 V
• Input Frequency: 45 Hz

MICROPROCESSOR TRMS MAXIMUM DEMAND CONTROLLER, User friendly setting of Demand parameters, Demand Time interval setting (0-60 minutes), Synchronising time with Electricity Board meter timing. Maximum Demand (Sanctioned Demand) & Target Demand Setting.

        Salient Features Suitable for 3 Phase 4 Wire LT Network. Three line LCD backlit display. Displays: Voltage, Current, Power Factor, Power, Trivector Energy & THD. Last 6 month history parameters for kWh, kVAh, kVArh (lag, lead) & MD KW, kVA through Communication Relay Output for V, I, Total kW, Total kVA, F, kW MD & kVA MD. Last 30 days Load Survey through communication. Last 10 Occ. / Res. event for each relay 1 & 2 through communication Application Electrical Panels - Industrial HT & LT Panels. Motor Control Centres, Distribution Contol & Relay Panels. Air Conditioning and Refrigeration Panels. Genset Panels. Generation, Transmission and Distribution Panels Test Benches and Laboratory Equipment. Uninterrupted Power Supply. Special OEM Application.

• Displays: 12 parameters

User friendly setting of Demand parameters, Demand Time interval setting (0-60 minutes), Synchronising time with Electricity Board meter timing.Maximum Demand (Sanctioned Demand) & Target Demand Setting.Displays Demand forecast, Displays Remaining Time interval (of the demand period).Displays Present Demand.Displays usable remaing Demand.

Now a days in many industries, electrical loads are prone to failure due to the many situations like overload, undercurrent, voltage spikes, earth leakage, earth fault, neutral fault, single phasing, reverse phasing etc. SYCON provides solutions to many of these problems through its protection relays. These relays are easy to install, user friendly and best in performance. Being our own designs, we can give any size and shape of CBCT required for these protection relays. Protection Relay Range The range includes motor protection relays, earth leakage relays, earth fault relays, under-current/over-current relay, under-voltage/over-voltage relay, neutral fault relay.
