Mechanical Drives Dealers

The creep drive is manufactured from high quality raw materials that make it highly efficient in performance. The creep drive offered by the company provides low backlash that is the major reason for high demand in the market. special features large ratio in compact sizespecial seal design for bearing long lifeused in winch, cranes etc technical specifications mounting : footratio : as per customer requirementhp : 0.5 hp to 50 hp

Winch Drive This range covers from 5.000 Nm to 400.000 Nm nominal torque. It comprises rotating case gearboxes designed to fit inside the winch drum. In order to ensure an isostatic distribution of the load on the winch, the gearbox is designed with a single supporting bearing. The external negative static brake facillitates the ease of maintainance sought after in marine applications. Several models have the DNV type approval; design approval is available on demand with the other major classification societies.

The Planetary Creep Drives that we bring forth are highly appreciated by the customers for their superb quality. The Planetary Creep Drives that we provide are fabricated from high grade components that results in their longer functional life. Additionally, we are one of the celebrated Manufacturers and Suppliers of Planetary Creep Drives. Ideal For Extra speed and power reduction in overhead cranes Attributes Thruster brake Diameter : from 100 mm to 400 mm Power : from 0.33 Kw to 15 Kw Ratio : from 3.5:1 to 30:1 Inline power transmission

• Torque: 100Nm To 4500Nm
• Ratio: 3;1 To 45;1
• Input Power: 0.18Kw To 25Kw

We are manufacturing and supplying various types are reciprocating roller drive assly as per customer requirement.

• Power rating: 2.2 to 3.7 Kw
• Maximum Input Speed: Not to Exceed 1500 Rpm
• Maximum input torque: 25 Nm
• Input Phase: Single Phase
• IP Rating: IP20
• Automation Grades: Manual & Automatic

• Dimensions: 24" x 12" x 18 inch
• Power Supply: 230 v, 50 Hz, Single Phase  230 v, 60 Hz, Three Phase
• Main Gear Motor: 0.75 kw
• Maximum Output Torque at Continuous Operation: 55 Nm torque
• Timer Adjustment: 0 to 999 minute
• Speed Adjustment: Infinitely
• RPM: 5 Minimum to 434 Max
• Net Weight: 52 Kg
• Gross Weight: 74 Kg
• Packing Size-Outer: 31" x 21" x 32" inch

• Material: Mild Steel
• Application: Material Handling Equipments
• Color: Blue
• Feature: Long Working Life
• Finishing: Paint Coated
• Phase: Single Phase

• Torque Capacity: 100 – 10, 00,000 Nm
• Reduction Ratio: 3.48:1 onwards
• Power Rating: 0.18 - 300 kW
• Mounting Type: Foot/Flange/Agitator

These drives are energy saving, sturdy and compact speed reducers working on simple Planetary principle used for high torque requirement, based on modular design, with nominal rated torque value and various reduction ratios.

Feel free to approach us, if seeking for top-of-the-line quality Shaft Mounted Planetgear! Since, our entire range is produced by following rules set by global quality regulation standards it is of supreme grade.

• Size: 6

Indexing Device     Features : Optional unit to enable the user to convert quickly Rotary Milling to using Indexing Plates. The dividing plate set consist of 2 indexing plates, a sector & a handle with plunger. The dividing plate set consist of 2 indexing plates, a sector & a handle with plunger. Using this dividing plate set the indexing of 2 to 60 divisions can be attained quickly and accurately. Application : APEX ROTARY TABLES have a sturdy design to suit many achining operations on Milling Machines including circular cutting, setting angles and indexing. They are available in a range of sizes to suit various machines and machining applications. Construction : The table and base is manufactured from close grain shock resisting Cast Iron dully stress relieved Worm & center table bush made of selected steel. Inspection : Direct reading to 2 minute for size 6",8" and 10" on hand wheel scale. Direct reading to 1 minute for size 12",15",18" and 20" on hand wheel scale. ACCURACY:- Maximum error 4 minutes of circular division using hand wheels. Table flat to within 0.01 mm / 100 mm. Working surface rotates in its own plane to within 0.030 mm. Horizontal and Vertical supporting surface square with 0.01mm/100 mm. Centre bush bore is true to table axis within 0.03 mm. Maximum parallelism error through 360° rotation of table is .025 mm . Both horizontal slots in & Vertical mounting on machine table. Finish : Hammer tone mid grey

• Capacity : 250 Kg to 5000 Kg.: Input Power : 0.18kW to 20 kW.
• Rope Dia. : 6 mm to 20mm.: Line Speed : 0.1m/min to 25m/min.

We supply Electric Winch as per customer requirement. Winch is supplied with Brake Motor. We supply winch with Winch-Trolley and Geared Motor for Cross travel. We offer complete solution for vertical lifting, cross travel, long travel, etc. Our winch comes with “USHA MARTIN” make wire rope and other fittings like Thimble, Lifting Hook, Fall Assembly. Technical specifications of Winch are as follows.

• Ratio: 3.46 onwards
• Drum Diameter: 130 onwards
• Input: suitable for Electric motor

Unique, safe, designed planetary drive with the ring gear rotating. These totally enclosed inside the drum .With stands high impact loads and shock loads, very high intermittent operations. This are replacing with the huge helical gearbox.  Inbuilt with Hydraulic brake and Hydraulic motor

• Size: 80 – 110 – 140 (mm)

Camfield’s Parallel Cam Indexers are ideal for High Speed Application or for actuation type applications. Parallel Cam Indexers use a pair of conjugate plate cams with yoke – mounted followers parallel to the axis of the output. The input and output shafts are parallel, in a combination that means there are no ribs on the Cam and no reversal of the Cam followers. Rates of more than 1000 indexes per minute are possible with parallel Indexers. Due to the Cam and Turret design, extremely small index angles are possible resulting in a longer Dowel period. These units can be used as a modern, accurate replacement for Geneva style mechanism, and are also available as oscillators.   CNC Profile Cut and Hardened Extra Heavy Duty Cam Followers Eccentric Bushing Bearing Housing for Pre-loading adjustment between Cam and Followers. Oscillating Cam-Motions available can be fitted with Reducer and Drive. C.I. / Aluminum housing & Oil Bath Lubrication High Load capacity, precision repeatability of the Indexing self locking in positions.

• Torque Capacity: 1400 Nm to 1700 Nm
• Torque Capacity: 1400 Nm to 1700 Nm
• Power Ratio: 3.7 kw to 7.5 kw
• Mounting: Foot / Flange

Bevel planetary drives suits the application demand where in space constraints for inline prime mover. The range of Bevel Planetary Drives comes with spiral bevel gears at input stage. The prime mover arrangement can be offered as solid shaft to mount a pulley or sprocket or coupling, and also for hollow female type where in flange mounted electric or hydraulic motor can be directly installed through a flexible shaft. Gear box mounting can be offered as foot mounting or flange mounting as per application demands. Use of Bevel Planetary Drives is becoming popular in various applications mainly for right angle transmission & replacement of conventional worm or bevel helical gearboxes

Fitted with world-class multiaxis CNC machines and the latest production technologies, the PGI Drives Production Unit can easily fulfill any kind of requirement, from a fast mass production to complete customized special parts. Extreme flexibility and continuous upgrades are the strenght behind PGI Drives machining speciality. Quality is ensured due our Total Control policy, from the raw to the finished part

• Power: 15 kW
• Country of Origin: Made in India
• Brand: Trisons Drives
• IP Rating: IP40
• Usage/Application: Industrial
• Frequency: 50 Hz
• Input Speed: 1500 RPM
• Material: Cast Iron
• Phase: Single Phase

Unique head design consisting of fully enclosed bearing for long & trouble free life. Both models equipped with roll throttle as standard. Lever throttle optional. Easy adjustable torque. Angle head can be setup in numerous positions. 360 degree adjustable air exhaust.

The horizontal drive which is completely maintenance free, has 1HP (0.5KW),three phase AC motor. The motor rpm can be controlled with AC variable drive to adjust the speed steplessly from 0 to 410 rpm. The process time is auto controlled through timer relays.The various attachments can be quickly attached & interchanged to the main drive unit. A separate power supply socket is also provided for the attachments requiring heating.

The Shaft Mounted Planetary Drive offered by us is manufactured with two helical reduction stages for input and output. Shaft mounted Planetary Drive available with us offers appropriate reduction ratio, thus, it is widely appreciated by the clients. Features : Long performing life Compact size High overhang load capacityEasy mounting Uniform stress distribution High torque capacity Maintenance free performance Used in : Wind mills Plastic industry Rubber industry Chemical industry, etc.

Compact, and yet extremely powerful, are the units of the 300 series. Their planetary drive train makes them the ideal choice for all the severe duty applications where shock loadings and impacts are more the rule than the exception. The product configuration is highly versatile, due to several options as far as the mounting, the gear layout, the output shaft and the motor interface. All the features are available for each of the 16 finely spaced frame sizes, spanning over the 1.000 – 450.000 Nm torque range. Finding the perfect match to any drive problem is therefore more than a wish, it is something users can safely rely on – always.

This product has been supplied with solid input or hollow input as per requirement. Electric or other type of motor can directly couple to gearbox with hollow input. This is a standard product which is available in foot, Flange or agitator mounting. These are of modular construction and can be offer in single double or multiple stages as a standard product. Reduction ratio is available from 3: 1 to 10000 : 1. Torque Capacity 1 Kgm to 20000 Kgm. Input power is 0.25 HP to 100 HP.

• Material: Stainless Steel
• Application: Industrial
• Brand Name: Saifi Make
• Material: MS
• Capacity: 100 Spin
• Design: Customized

• Brand Name: Engimech
• Type: Timing
• Supply Ability: 100000 Piece/Pieces per Year
• meterial: metal
• Port: Nahva Sheva,Pipavav,ICD Ahmedabad

• Type: Motor Drives
• Color: Grey
• Voltage: 110V,220V,380V
• Condition: New
• Automatic Grade: Automatic,Fully Automatic
• Driven Type: Electric,Mechanical
• Warranty: 1yrs
• Country of Origin: China
• Brand Name: Sango Automation
• Name: Cam Indexers

Being one of the largest companies, we are involved in manufacturing as well as supplying an outstanding range of Planetary Gear Drive to our esteemed patrons. The offered Planetary Gear Drive is highly appreciated and demanded by our valued clients for its desired performance and quality. These Gear Drive are designed at our ultra-modern manufacturing unit using the superb quality material and progressive technology. In order to ensure quality, our products are rigorously tested on various parameters.
