Medium Wire Drawing Machine Dealers

• Model No.: DC/213/9
• Gear Belt Drive: Wet Type Intermediate Machin
• Inlet All/Cop.: 3.6 mm
• Outlet All/Cop.: 1.6 mm
• Motor Req. All/Cop.: 30/35 HP

• Brand Name: SEW
• Material: Copper
• Color: Blue
• Voltage: 440V
• Driven Type: Electric
• Warranty: 1 Year
• Country of Origin: India
• Weight: 5000-7000kg
• Packaging Type: Wooden Box
• Surface Finishing: Unpolished
• Operating Mode: Automatic
• Speaciality: Easy To Use
• Usage: Wire Drawing
• Shape: Horizontal
• Condition: New
• Phase: Three Phase
• Corrosion Resistance: No
• Machine Structure: Horizontal

The Wire Drawing Machine RBD Pay Off, provided by us, is acclaimed for its robust structure & long service life. From the point of view of marketing, shipping, and handling, our products are securely packed in top-grade supplies using ultramodern packaging machines. The packaging is extremely reliable. We are actively engaged in supplying exemplary range of products from our ultramodern warehousing facility in Delhi(India).

• Material: Mild Steel
• Automation Grade: Automatic
• Warranty: 1 Year

• Max Inlet Wire Diameter: 0-3mm
• Min Finish Wire Diameter: 0-1mm
• Speaciality: Easy To Use, High Efficiency, Reliable, Robust Construction
• Machine Structure: Horizontal
• Corrosion Resistance: Yes
• Operating Mode: Semi Automatic
• Country of Origin: India
• Warranty: 1 Year
• Phase: Three Phase
• Frequency: 50 Hz
• Weight: 1000-2000kg
• Voltage: 440V
• Usage: Wire And Cable Making Industry, Wire Drawing, Jewellery Making Machine
• Power Source: Electric
• Brand Name: Rushikesh Industries
• Material: All Metals
• Driven Type: Electric
• Surface Finishing: Spray Paint
• Shape: Rectangular
• Color: Blue
• Condition: New
• Power: 20+2 HP

We have invested a huge amount in the automated warehousing system that is sprawling over a large area. We make certain that the wide array of product range we offer is strictly packed and kept safe till the final delivery. It is due to our guarantee of providing damage-free products to the clients; we are highly in demand amongst the buyers. Our packaging experts keep a stringent check on the entire packing procedure ensuring the same.Features : Low maintenance Well design Longer life Specifications : Model No. - SEW-IWDM Inlet Wire Diameter(mm) - 2.64 Finished Wire Diameter(mm) - 0.50 Approx Price : Rs 5.5 Lakh / Unit(s)

We give our patrons the choice to make payments online or offline. Our company understands the concerns of its customers. Therefore, we make sure our payment options are safe. We give utmost importance to the quality of the products and thus we produce the entire range in accordance to the quality standards.   Features of the range are given below : Resistance against corrosion No sharp edges High effectiveness

• Voltage: 415 - 440 V
• Frequency: 50 Hz
• Capstan Diameter: 250 mm
• Automation Grade: Automatic
• Input Wire: 2 - 3 mm
• Output Wire: 0.4 - 1.2 mm
• Maximum Line Speed: 1800 M/min
• Mechanical Elongation: 25%+18.7%
• Annealing Capacity: 85 - 120 kVA
• Air Consumption: 20 - 30 m3/h
• Annealing Current: 1000A

• Max Inlet Wire Diameter: 3.25mm & 1.62mm
• Voltage: 440 V
• Usage/Application: For Wire Industries
• Types Of Metal: Copper, Aluminum, SS and GI Wire
• Type: Intermediate Wire Drawing Machine
• Automation Grade: Semi-Automatic

  Al  3.0mm to 1.2mm Cu 2.5mm to 0.90mm MS 1.4mm to 0.45mm

The machine can draw wire continuously from 1.5 to 0.3 mm as per the customers requirements, we can suggest medium fine wire drawing machines, with line speed of 40 meters second.

• Power Source: 415V/50Hz
• Features: Drive and control by AC three-phase dual-inverter.High productivity, low power consumption.
• MODEL: ZLT350/9
• Control system: Digital
• Power Control: Dual-Inverter
• Wire Inlet Dia: 2.6-3.5mm
• Wire Finished Dia: 1.0-2.76mm
• Max Wire Speed: 1200M/min
• Max No. of Dies: 9
• Transmission Type: Gear drive
• Mechanical Elongation: 25%+16.7%
• Drawing Capstan: Tungsten Carbide
• Construction of the Machine Body: Plate Welding and Annealing
• Capston Dia: 350mm
• Fix Speed Capston Dia: 350mm
• Spool Bobbin Size: SN500, SN630 (optional )
• Bobbin Loading & Unloading Type: Bi-shafts cone
• Traversing Unit: AC Reducer Motor and Timing Belt
• Main Motor: 55kw(6p)
• Spooler Motor: AC11kw
• Correction System: Automatic Digital Control of Take-up
• Tension Control: Buffer Rod with Air Cylender and Rocket Arm
• Max Loading Capacity: 250Kg(SN500) or 500kg(SN630)
• Lubrication Type: Lubrication By Full Immersion<
• Lubricant capacity: 100L/min
• Brake: Disk Type Brake
• Lubrication Type For Bearing: Pump Enforce Oil
• Annealing Control: 3 Pole DC Current Output
• Annealing capacity: 150Kva
• Annealing Voltage: Max 65v
• Annealing Current: 2500A
• Connect Load: 77Kw+150kva
• Steam Consumption: 2-0.3Mpa(with 9kw steam generator)
• Cooling Water Consumption: 2-0.3Mpa
• Air Consumption: 0.4-0.6Mpa
• Machine Dimension: 14 x 3.5 x 4M
• Gross Weight: 7000Kg

• Model No.: SEW-IWDM
• Inlet Wire Diameter(mm): 2.64
• Inlet Wire Diameter(mm): 0.50

We are engaged in manufacturing, exporting and supplying an extensive assortment of Intermediate Wire Drawing Machine: 4-Spindle Stepped Cone Type. Manufactured using the finest quality raw material, this machine is designed at par with the set quality standards. Available in various specifications, this machine is extremely cherished for its robust construction, user-friendliness and durability features. Clients can avail this machine from us at industry leading prices.

Medium wire drawing machine is designed to cater to the requirements of diverse applications of engineering industry. Wire drawing machines offered by us are known for offering high resolution and performance. Supported by our vast industry experience

• Color: Blue
• Condition: New
• Warranty: 1year
• Brand Name: Velocity Engineers
• Capacity: 100-400kg
• Type: Intermediate Wire Drawing Machine
• Application: Wire Drawing
• Driven: Electric

Intermediate Wire Drawing Machine With Annealer (17DT)No Of Dies 17Inlet:3.2-2.5mmOutlet:1.2-0.4mmMain Motor: 37KWSpool Motor: 11KW Annealing Power:72KVASpeed:1500Mechanical Reduction: 18% + 12.5%Transmission Method: By GearsCapstan: Tungsten CoatedTake Up Bobbin: 500-630mmCapacity: 100-400kg We Provide Service After Sale Too

Intermediate Wire Drawing Machine, solder wire drawing machine

We are one of the leading manufacturers and suppliers of intermediate machines, which is easy to operate with graphical instructions. Our range is stringently tested on various quality parameters to assure its quality and reliability.

Intermediate Wire Drawing Machine

Intermediate Wire Drawing Machine, Polycrystalline Diamond Dies
