Membrane Keyboard Dealers

Our Membrane Keyboard features Inter-Device Sync, 1000 MHz Ultrapolling, Fixed wrist rest, etc. We are backed by modern transit facilities and thus while located in Uttar Pradesh(India), we are able to reach any destination easily. Supplying wide array of products, we successfully make deliveries within the dedicated time span.

• Color: Yellow, Green, etc
• Material: Polyester
• Contact Resistance: 100 Ohms
• Operating Current: 100mA
• Storage Temperature: 25 to 90 degrees Celsius
• Operating Temperature: 35 to 70 degrees Celsius
• Operating Voltage: 35VDC
• Life Expectancy: 500,000 to 10,000,00 cycles
• Usage/Application: Automatic Control System, Household appliances, Human Machine Interface, etc
• Features: Flexible

• Type: Flexible Membrane Keyboard
• Material: Customized
• Application: Medical Device, Industrial Equipment, Manufacturing Equipment, Aerospace Industry
• Brand Name: Rangvishwa
• Country of Origin: India
• Color: Multicolor
• Product Name: Flexible Membrane Keyboard

flexible membrane switch keypad can bend, move and twist without damaging the conductor and used where flexibility is required. these switches have small size, thin thickness, light weight, shock resistant, abrasion resistant and convenient in installation and connection. it is used in ultrasound probe, medical device, industrial equipment, manufacturing equipment, aerospace industry etc. we manufacture these flexible membrane switches with latest technology and superfine material for better performance and longer life.

Quality membrane keyboards by maharani technologies give us a chance to change the way your machines are operated, with membrane keyboards from maharani technologies flexible non-tactile membrane keyboard with embossed graphic, 20 pin blue crimflex female connector.

• Material: 6061-T6 Alluminium
• Color: customised
• Condition: New
• Operating Style: Wired
• Application: Computer, Laptops, industry/mil
• Cable Length: 3.5Ft, 3Ft
• Type: Membrane Keyboard
• Weight: 500-700Gm
• Warranty: 1year
• Country of Origin: India

• -: -

As a respectable firm, headquartered in maharashtra(india), we are making available top-of-the-line quality products in the market. Buyers can rely on us for on-time and safe delivery as we are aided by modern transit facilities.

• Material: Polyester
• Warranty: 1year
• Thickness: Upto 6mm
• Shape: Rectangular
• Packaging Type: Packet

• Size: 466mm*132.5mm
• Operating Temp Range: -20 to 70 degree C
• Model Number: LP 3051
• Number Of Buttons: 103
• Packaging Type: Box
• Shape: Rectangle
• Protection Level: IP 65 ( front panel)

• Operating Temperature: 10 to 70 deg centigrade.

Metallic keyboard are fully sealed and can be used for all kind of outdoor application. Metallic keyboards are very much suited for harsh environments. Available with Computer compatible interface option ( i.e. : USB & PS2 ). Also Available in Standard 4x3 & 4x4 keyboard option. 100% vandal proof option.

• Warranty: 1year
• Keyboard: Height: 186.7 mm (7.35 in) Width: 447.2 mm (17.61 in) Depth: 21.4 mm (0.84 in Weight: 603 g (1.33 lb)
• Mouse: Height: 105.4 mm (4.15 in) Width: 67.9 mm (2.67 in) Depth: 38.4mm (1.51 in) Weight: 86.4 g (3.05 oz)
• SYSTEM REQUIREMENTS: Windows Vista, Windows 7, Windows 8, Windows 10 Chrome OS USB port
• TECHNICAL SPECIFICATIONS: Battery life: 48 months Battery: 2-AAA On/Off switch: Yes Full-size layout with 12 enhanced F-keys for media control Unifying-ready keyboard: No Unifying-ready receiver: No Wireless operating distance: 10m maximum Wireless system: Adv
• PACKAGE CONTENTS: Keyboard, Mouse, USB receiver 2 AAA alkaline batteries in keyboard (pre-installed) 1 AA alkaline battery in mouse (pre-installed) User documentation
• PART NUMBER: PN: 920-006491
• Note: ***Features, Price and specifications are subject to change without notice

Features of LOGITECH MK345 RGB Full Size Membrane Wireless keyboard and Mouse Combo INCREASE YOUR PRODUCTIVITYType on a full-size layout with 12 enhanced F-keys for media control. Skip a song, pause a video or mute audio instantlyEXTRA-LONG BATTERY LIFEEnjoy an awesome 4-year keyboard and 18-month mouse battery life, provided by our energy efficient engineering.IMPROVED COMFORTThe generous palm rest, the contoured right-handed mouse and the adjustable keyboard height give you more comfort.WIRELESS COMBO, IMPROVED COMFORTIntroducing our wireless LOGITECH MK345 full-sized combo for all-day comfort and long-lasting battery life. With a contoured right-handed mouse and full-size keyboard, you can tackle any task with ease.FULL-SIZED, EXTRA COMFORTEnjoy comfortable, quiet typing on a familiar full-size keyboard with a generous palm rest and adjustable height. Plus, easy-access media keys and a number pad for efficient work at home or in the office

A membrane Keyboard has two screen printed polyester films with conductive ink to form the circuit layer of the Keyboard.   Between the two circuits, a die-cut spacer at contact points is placed. To complete the circuit a touch of finger on the die-cut holes allows to close the contact.   Embossing offers better aesthetic look & key feel.   Instant touch feedback on contact.   Sleek & compact to save the space in any electronics instruments.   Front over lay design, size and color combination can be made as per customer’s requirement.

• Connector: Dupont 7 Pins, 0.1
• Keyboard Type: With Wire
• Color: Multicolor
• Max Circuit Rating: 35 VDC,100 mA
• Operation Temperature: -20 to +40 deg C
• Dielectric Withstand: 250VRms (60Hz,1min)

It is a Keypad with flexible tail with without connector as per design and application. The Keys are mounted on multi layers of punched flaxible polymer sheets (typically polyester) sandwiched together. Circuits are silk-screened with conductive silver ink on both the top and bottom membrane layers. Low cost , reliable Keypads, alternative Key-life exceeds - - 5 million Keystrokes, also lighter than a PCB, Flaxible circuits allow Product from which is not possible with rigid PCB. Rim & Pillow Type Emboss available on demand . Male Female Clincher connector are used.

• Country of Origin: Made in India
• Color: Black
• Usage/Application: Industrial
• Keyboard Type: Wire
• Brand: Cutek
• Packaging Type: Box

PCB"S allow for greater design flexibility than a flexible membrane switch. Standard thickness of bare PCB range from 1mm to 3.2 mm and the board can be single-sided, double sided or multi layer . A PCB allows components to be soldered directlyto the board. It also provides a wider, as well as more Connector locations , depending on the complexity of the design. In built Mounting screw can be used for fixing LCD, Dispaly PCB & Keyboards. Mainly used for Textile Industrial Automation & Control Panels . It eliminates backing plate.

Siltech Corporation Inc manufactures and supplies Tactile Membrane Keyboard that consists of conductive silver circuit printed on polyester sheet with metal domes.

• Contact Arrangement: SPST, Normally Open.
• Current/Voltage Rating: 10 mA at 24 VDC (Max) in to resistive load only
• Contact Resistance: Compatible with MOS, TTL & DTL Circuits.
• Contact Bounce: Less than 10 milliseconds at make & 20 milliseconds at break.
• Key Travel: 380 microns.
• Life Expectancy: One million to 3 million operations per switch.
• Operating Temperature: -20oC to + 65oC.
• Humidity: 95% RH at 40oC.
• Base: Glass Epoxy PCB FR4 Grade in thicknesses ranging from 0.4 mm to 3.2 mm.
• Plating: Gold Over Nickel; Bright Acid Tin.
• Adhesives: Industrial Grade from 3M..
• Overlays: Different types of Polyesters from Autotype

• Color: Off White
• Charging Current: 110mA
• Folding Angle: 185 Degree
• Min Operating voltage: 4.1 V
• Max Operating voltage: 5 V
• Usage/Application: Industrial

Membrane Keyboards also known as Membrane Keypads, we provided with different types of Customized Membrane Keypads as per customer requirement. We supply Membrane Keyboard to fields like Industrial, Medical, Automation, etc. Rigid or PCB Membrane Keypads. Flexible Keypads. Touch Membrane Keypads.

• Brand Name: PROTOLAB
• Country of Origin: Made in India
• Material: POLYCARBONATE/ POLYESTER
• Max Supply Voltage: DC 24v

• Size: As Per Requirement
• Material: Polyester
• Usage/Application: Industrial
• Adhesive Side: Back Side
• Thickness: 200 Microns

PCB Keypads use a rigid circuit board in spite of using screen printed flex circuits and help in easy addition of other components like LED's and resistors and this can be achieved by applying a graphics layer directly onto a PCB. This is applicable in low shock and vibration applications Our Company has special design for manufacturing these rigid membrane switches. These are prepared of excellent quality material with the use of latest technology for superb performance and durability.

Purchasers can rely on us to make on time distribution of orders, as we have cooperated with established transportation facility providers. Notable name in this field, we successfully cater to the demands of our clientele from Rudrapur(India) to every nook and corner.

• Material: Polycarbonate Membrane panel
• Weight: 0.5 kgs
• Relay Humidity: 95% RH.
• Memory: Non-volatile on EEPROM.
• Operating Temperature: 0 to 50 deg C

Rigid Printed circuit board switches are utilized in situations where the OEM customer may like to utilize the PCB as a rigid backer which a membrane keyboard lacks. The PCB can also be populated with active and passive components reducing the amount of materials and interconnections.

These Membrane keypadsKeyboards comprise of a Snap Dome Switch and a screen printed (with Silver Alloy Paste) polyester layer, which is used as a base and for the circuit.

These Keypads are available in a wide range of Standard Matrix to meet the small quantity and urgent need of development jobs or customized jobs. The Keypads are available with insertion facility so that any customized legend can be defined as per the user choice. In addition to these Keypads, SR Graphics offers a range of Keypads, required for the process industry, where the dust & liquid protection are the top most requirements.

Dotkey's core competence is the design, development and production of membrane keypads for Automobile Industries, Textile Units, Medical Electronics, Test & Measuring Equipments, Customized equipments & Automation Industries. We have responded to market demands and deliver in high volume as well as prototypes. We can do re- engineering an existing part to determine the material construction, mechanical outline and electrical properties to recreate an existing membrane keypads We pride ourselves on immediate responsiveness with quick quote turnaround in 24 hours or less and promptly address technical inquiries and design challenges. Our technical staff works with customers to provide solutions for any application with the most cost effective option.
