Multifunction Energy Meter Dealers

• Country of Origin: India
• Type: Multifunction Energy Meter
• Certification: CE Certified, ISO 9001:2008
• Application: Energy Monitoring
• Weight: 200-300gm
• Display Type: Digital
• Frequency: 50Hz-65Hz
• Warranty: 1Year
• Brand Name: ICD
• Operating Temperature: 55
• Application: LT / HT Panels, Generation, MCC
• Aux Supply: 90-240V AC/DC
• Communication: RS485

Multifunction Energy Meter and Power Analyzer – PM130 EH Plus / PM175   Major Features   Bright 3-row LED display enabling easy reading Standard RS-485 communication port and an additional plug-in RS-232/RS-422/RS-485, Ethernet, Profibus, GPRS module True RMS Volts, amps, power, power factor, frequency, Power, Energies in all 4 quadrant with 128 samples/cycle. KWH Imp/Exp, KVARH, KVAH, MD measurements 25/50/60/400 Hz measurement capabilities Class 0.5S and 0.2 S IEC 62053-22 four-quadrant active and reactive energy meter Voltage and current THD, current TDD and K-Factor, up to 50th order harmonic Real-time waveform monitoring capability Add on TOU, RTC, DI/DO modules EN50160 compliance statistics, harmonic survey statistics IEEE519 & IEEE 1159 measurement compliance, IEC 61000 Flicker CBEMA/ITIC, IEC 6100-4-7 Harmonics

• Features: Isolation for input and output, Ture effective value measuring, Transformed analog output for voltage, current, active power, reactive power
• Measurement parameter: 3 phase voltage, current, active power, reactive power

• Feature: Available in Accuracy class 1.0 as per Is13779/ IEC 62053-21,Optional Accuracy class 0.5s or 0.2s as per IS14697/ IEC 62053-22,True RMS measurement,ON Hour, LOAD HOUR & IDLE HOUR register in Non-Volatile Memory

Multi Function Panel Meter 2160-A is an easy-to-use, cost effective electrical energy meter that offers all the basic measurement capabilities required for monitoring an electrical installation. Multi Function Panel Meter 2160-A is available in three display options either 16 x 4 LCD or bright LED or large multi-line backlit LCD panel for superior readability in poor lighting conditions. It provides four parameters display at a same time. Based on field requirement 2160-A offers various accuracy class options like Class 0.2s Class 0.5s accuracy as per IS14697 IEC 62053-22 and Class 1.0 accuracy as per Is13779 IEC 62053-21.

We offer multifunction energy meter. Elmax model no.em32 is a multifunction avf meter based on micro controller technology. The lcd display provides parameter like amp, volt, hz, kw, pf, kva, kwh, and mdi. Designed at par with international quality standards, multifunction energy meter is also available in various specifications and is widely used for monitoring current, voltage, and frequency of 13 phase supply in an effective manner. The entire range of multifunctionavf meter delivered by us is highly appreciated for their compact design, easy installation, optimum performance, and longer functional life. Owing to the unmatched range, we have become the most reliable manufacturer of multifunction & avf meter in india. features lcd displayparameters displayed;- voltages per phase& phase to phase, pf, kw, kva, amp, hz per phase, etc.single three phase application.avf meter- display, amp, volt, hz of each phaseinput voltage 230 voltcurrent 5 amp. Size 96x96x110, 96x96x72mm

• Brand Name: L&T, Schnieder, Elmeasure, Meco, HPL, Trinity
• Certification: IEC
• Display Type: LED, LCD,
• Operating Temperature: 45 Degree
• Phase: Single, Three
• Dimension: 96*96
• Measuring Energy Range: Any

We are offering digital multifunction energy meters. Multi function meter accuracy class 1.0, 0.5, 0.5s, 0.2 as per iec 62052-11 iec 62053-22 monitors all electrical parameters : per phase, voltage, current, demand, w, va, var monitors all instantaneous, integrated and demand parameters neutral current, frequency, power factor, % load, %unbalance (v&i), phase angle , thd demand calculation method – sliding & fixed block, importexport monitoring color coded analog load bar indicators for percentage of load through led segments ct reversal : auto correction of energy integration in star (wye) mode user programmable deltastar2ph1ph pt ct primary & secondary turbo key for one touch operation & setup ul, c ul listed, ce, c-tick certified metering voltage inputs range from 80 to 600v ac l-lrs485 communication port with modbus rtu protocol

• Dimensions:: 96 * 96 * 86 mm
• Current Rating: -/1A & -/5A

Three push buttons on the front panel for programming and scrolling, CT secondary -1A or -5 A (user selectable), CT primary can be varied from 5A to 6000A in steps of 5 for -5A.CT primary can be varied from 1A to 1200A in steps of 1 for -1A, IP 54 degree of protection.

• Weight: 350gms. (app.)
• Dimension: (96 x 96 x 48) mm

Multifunction energy meter Meter measures Active, Reactive, Apparent energy on 3 phase 4 wire system, 7 segment (3*4 digits) LED type – The parameters are calculated by the meter are displayed, Selectable Parameters – Can select any out of 31 parameters. Scroll rate – The scroll rate of the display parameter scroll in steps of 4secs. Keys are provided to stop, scroll, edit and to view the particular parameter.

• Weight:: 1.5 lbs / 0.7 kg
• Operating temperature:: 30 C to 60 C (-22 F to 140 F)
• Operating Range:: 690V AC line to line, 400V

Multifunctional three-phase power meter with basic revenue metering, power quality and harmonics analysis. It provides a cost-effective substitute for numerous analog meters used by industrial, commercial and utility customers for basic power metering. The PM135 is widely integrated in panel boards and SCADA systems. With the addition of the unique TOU module, the EH model answers the needs of revenue metering applications. It is also suitable for utility substation automation with its support of the industry standard DNP 3.0, Modbus RTU and IEC 60870-5-101104 protocols, as well as its IO capabilities (using the Digital Inputoutput modules)

Product Features : Microcontroller based multifunction A/C Energy Meter. Accuracy Class1.0 / (Class 0.5 calibration on Request). CT /PT (Pri/Sec) Programmable. Digital Measurement. IEC 62052-11 IEC 62053-21 IEC 62053-22 IEC 62053-23. RS 485 Serial Port with Modbus RTU Output. Flush / Panel Mounting . 96 x 96 mm DIN Mounting. Auto Scroll / Hold Facility. Internal Resettable fuse for protection of device against voltage fluctuations.Digital display will blink whenever voltage exceeds specified voltage range.Switch off the unit for sometime & then switch on when voltage returns to normal. Protection from dust and water as per IP-51.

The EM132 is a cost-effective multi-function transducer with local display, designed to replace analog or digital transducers. Its local display allows setup and verification of installation, without the hassle of using computers. One device supports all network configurations (i.e., 3 wire, 4 wire, wye, delta, etc.) and is field configurable.

We are the manufacturer of our products. Some of our successful collaborations have been in manufacturing of Meter movements, Complete analogdigital meters, Multilayer SMT PCB assemblies, Digital meters sub-assemblies, Transformer cores, Coil windings, Small transformers, Punched metal components & Plastics injection moulding components.

• Voltage: 45 to 300 V

Minilec offers multifunction meter F3MFM1 to 4 for simultaneous measurement of various Electrical Parameters of 3 Phase 3 Wire or 4 Wire electric power system. The Meters are widely used in application areas where accurate and reliable monitoring of Power Line parameters is essential.

The CSM Series offers single function and multi function digital panel meters. These digital panel meters measure all electrical qualities like Voltage, current, Power, energy, Frequency & Power Factor accurately. CSM Series is widely used for industrial & commercial application. All the models are very compact in size and are user friendly.

• Size: 96 x 96mm
• Supply Voltage: 100 to 240V AC

Electrical Connection: 3Ø-34 wire, 2Ø-3 wire, 1Ø- 2 wire, Features: THD upto 31st Level, MaxMin Demand(Power), Max Demand Current, Phase Sequence Detection. Display Type: LCD with backlight, Bargraph representation.

Multifunction meter with LED Display, four rows of four digits for multi parameter display with communication port. LED Display Site Programmable CT & PT Ratio True RMS Measurement Password protection Maximum Demand with relay contact Optional Features: RS485 computer interface 60A direct current(external CT Module available) Harmonic measurement (total and individual) Autoranging Universal auxiliary supply

• Frequency: 50Hz
• Current Input: / 5 A, /1 A (optional)

In today’s industries, knowing more about your power system is necessary to get control over it. This requires a system or a Meter which is capable of getting measurement continuously from your power system. Our industrial electrical system is of 3 phase power input viz. R, Y and B. Getting measurement of a parameter in all three phase simultaneously is more desired while deciding the load. The SYCON Multifunction Meter 9900 is made to fulfill this requirement. The Multi Function Meter 9900 consist of 20 characters 4 line LCD display for displaying parameters. This is the advanced version in Panel Meters with small volume and light weight, capable of displaying total of 41 electrical parameters. General Features Friendly user interface. Easy to install. RS-485 MODBUS Communication available

• Display: 4 Rows of 4 Digit

TRMS Measurement 23 Parameters on 46 Pages 4 Rows of 4 Digit Super Bright RED LED Display 3 Phase 3 Wire 3 Phase 4 Wire System (User Selectable) Programmable CTR, PTR, Instrument Address, Password and MD Period Energy Import - Export (4 Quadrant Operation) IP54 (For Meter Front) POWER MASTER Software (Optional) RS485 Port, 5KV Isolated with MODBUS RTU Protocol (Optional) CE Compliance with EN61010- 1, EN61326- 1 Inbuilt Memory to Store CTR, PTR, Instrument Address, Password and MD period Auto Scroll (5 sec.) Manual Scroll Display Built in 20 Energy Meters of 8 Digit Resolution Energy Retention and Password Protected Energy Reset Facility Max. Demand for KW or KVA with user Selectable Demand Interval 5-30 Minutes THD for Voltage and Current Password for Protection of Programmable Parameters RUN Hours, ON Hours Phase Angle and Phasor Angle Measurement Display Previous Energies Set Date and Time Measurement of Min. and Max. Voltage and Current Values.

Multifunction energy meter It is possible to program primary of external potential Transformer (PT), primary of external Current Transformer (CT) on site via front panel keys by entering into Programming mode.

This panel meter measures voltage, current and kWh energy in a 3 phase 4 wire system. The meter has an LCD display with backlight, thus enabling ease of reading. Features: Class 1 accuracy ACDC auxiliary supply RS 485 communication Password protected CTPT value programming Dimensions: 96 L x 96 B x 105 D mm
