Ointment Mixer Dealers

MAIN MIXER OPTIONS : SEMI CONTRA ROTARY / CONTRA ROTARY / PLANETARY/ ANCHOR TYPE MIXERS BATCH SIZE RANGE : 5 / 10 / 25 / 50 Kgs / Batch CONFIGURATIONS : Stand alone Pilot mixer with control panel Skid Mounted Mixer with oil phase & water phase Main Mixer with one phase kettle With or without homogenizer Skid mounted plant with pilot size utilities

We are engrossed in the arena of presenting to our customers an exceptional assortment of Ointment Mixer. Coming with digital metering pump fitted in hopper of filling machine, this plant is used for production of lotion and is so designed that it saves on valuable batch processing time. The plant offers efficient heating & cooling with support of accurate temperature control even in cases where processing is done for small qualities.

The Anish ointment manufacturing plant is a state-of-the-art ointment cream gel manufacturing facility. The ointment manufacturing Vessel provides through and homogeneous mixing of wax phase and aqueous phase material. The ointment manufacturing vessel has its drive from bottom, thus the machine becomes accessible with the top dish opening with a swing out arrangement. This enables the ointment manufacturing plant with easy cleaning for every change over. Anish ointment manufacturing plant is ergonomically designed & provided with anti skid working platform with safety railing for better and safe operational movements. Flow meter in process lines assures accurate quantity monitoring. These ointment manufacturing plants are SCADA (supervisory control and data acquisition system) based IPC Plus PLC operated control station compatible with USFDA EUFDA GAMP norms. Total documentation support for ointment manufacturing plant starts from design qualification to performance qualification.

• Capacity: 12 Liter to 600 Liter

Planetary mixer has great function of blending, shearing and dispersing, which suits well in dispersing and blending of materials in solid to solid, solid to liquid, liquid to liquid. Planetary mixer is widely used in chemical, food processing, drug producing, construction materials and light industries. Meanwhile, it also fits for cosmetic, ink, chocolate, sealing adhesive, adhesive, ointment, paste materials etc.

The ointment mixer is highly versatile and mostly used for manufacturing Tooth Paste, Creams, Cosmetics shaving cream, beauty cream and chyavanparash.

GMP Model Jacketed Vessel S.S. 316 Anchor Type Mixing Stirrer S.S. 316 M.S. stand cladded by S.S. 304 sheet

The NewLABOplanetary machine is used to mix Liquid to Liquid, Liquid to solid, and solid to solid are in Pharmaceutical Powder, Granules, Ointment, Cream, Galantine, Cosmetics, Food, Confectionary, Chemical and Soaps. It has a homogeneous mixing action and planetary motion (Single or Double Planetary) of the beater enables faster and better mixing of material. The planetary mixer is an intensive mixing, dispersing, kneading and degassing viscous, heat sensitive and above all, cohesive pastes, dough and moist, crumbly masses, such as sealing compounds, adhesives, printing inks, dental plastics, plastisols, condensed soups, battery compounds, cream cracker dough, etc

Catering to the demand of pharma & cosmetic industries for cream manufacturing, these precision engineered pilot Ointment mixer plants are attuned to international quality standards. These pilot Ointment mixer plant are fabricated by us using highest grade of rust proof materials, that make them highly durable in quality. Our pilot Ointment mixer plant are characterized by precise dimension, high tensile strength and superior functionality.

• Power: 4 Kw (max.)
• Voltage: 440V, 50 Hz
• Weight: 80 Kg
• Application: For uniform mixing of fluids and semi fluids with constant and uniform heating
• Dimensions (L x W x H): 4 x 4 x 5 ft.

Feature Jacketed tank for oil/water bath. Has a built-in temperature controller to maintain temperature of the outer jacket. Simple control panel for easy and smooth functioning. Slow moving blade for constant stirring action.

We are counted among the leading manufacturers and suppliers of Ointment Mixers in the markets. By using graded raw material, we have developed a wide array of Ointment Mixing machines that is widely used to mix wet or dry materials as well as the dispensed material. The mixer can be displaced from one place to other and is available with stainless steel and mild steel finishes. Ointment mixers are ideal for homogeneous mixing and preparation of ointment and are equipped with double stirrer a scrapper with PTFE blades for better mixing of material. Attributes Homogeneous Mixing of wax phase & aqueous phase materialWax phase vessel for malting of Wax & Oil baseWater Phase vessel for aqueous phase material processingInline high speed emulsifierCharging Hopper to charge Active IngredientsOintment / Cream storage vesselsJacketed/ non JacketedVacuum Transfer of water & waxTransfer pumps for transferring finished product into Batch Storage/Staging VesselTransfer pumpsErgonomic anti skid Working platform for fatigue Free plant operation Applications Pharmaceutical creamsOintmentsCosmetic creamsHerbal creamsCeramicsAdhesivesPasteResins Advantages Drive is placed at the bottom, which makes the machines access to top dish opening with a swing our arrangement, thus it helps in easy cleaning in every changeover.‘W’ shaped anchor type agitator renders semi contra motion for mixing, thus helps in saving time to manufacture products which need phase reversal process.Cleaning of machine is very easy as it has multiple batch systemEasy to remove and fix moving parts (anchor)The Bottom Drive also ensure that leakage of oil don’t get mixed up with the product.The Teflon scrappers properly cleans wall and leave no particle remained in the vassal.Gives fast moving production rate and better product quality with the help of special blade design.CIP and SIP facilities can be integrated easilyControlling of globule size of finished product is easy as inline type Homogenizer design ensure full re-circulation of product Available In (only on optional basis) : Flameproof Motors along with Flameproof Push Button stationRemotely mounted Power panelFully automatic manufacturing systems including:Oil Phase Vessel in Load cells or ManufacturingRow meter for Water Phase VesselPneumatically operated automatic valves for all process lines & PLC controls Utility linesSCADA bate IPC and PLC operated control panel compatible including Current FDA Norms Specifications Which Can be Changed According to the Requirement : Power required for standard 3 vessels onlyStandard recommended Block DimensionsVarious Capacity Vessels for base preparation Inline Homogeniser

• CAPACITY: 25 to 3000 Kgs.

By Manual Control OR By auto Control (Optional) Manual Control – Have temperature indicator Timer Push Button for operate the complete plant. Auto Control – PLC based with Touch screen and password level to feed the parameters of process for Heating Cooling Stirrer timingHomogeniser Timing Stirrer speed Homogeniser speed Vacuum Pressure CIP etc. RECIPE SYSTEM : To stored processed parameter to give high batch to batch consistency. MMI (Touch Screen) for visualization of machines of specific process condition and data.

Ointment mixer Designed for the Process With long experience at the leading edge of vacuum processing, Adam Fabriwerk has developed a system which addresses the fundamental requirements of the served markets, including. The principal applications for the system are in the pharmaceutical and premium cosmetics sectors.

The Ointment Mixer Effectively Mix Materials to Make Ointments Stirrer options: SEMI CONTRA ROTARY / CONTRA ROTARY / PLANETARY/ ANCHOR TYPE Combines the Solid and Liquid Particles Effectively Under Vacuum and Whirl Force Anchor Paddles & Scrapers with Sets of Fixed Baffle Plates Ensure Thorough Mix Materials May Be Either Charged Open Cover Or by Vacuum Feed. Large Quantities of Material From Phase Vessel Is Sucked Efficiently by Vacuum Top Main Stirrer Speed-6-60 RPM, Driven by suitable Motor Bottom Mounted High Shear Emulsifier System will be provided Motor : Crompton / Kirloskar Make – FLP and Gearbox – Radicon / Elecon / Santhi Shaft Is Supported Through A Heavy Duty Bearing Housing with Mechanical Seals Bottom Discharge Valve Is Pneumatically Operated and CIP Optional Extra Hydraulic Lifting on Top Dish to Facilitate Product Recovery and Cleaning-Optional

The Planetary motion of the mixing beater ensures effective homogenous mixing of the various ingredients. Std. Mixer consists of single mixing . beater which rotates in planetary motion i.e. clock wise direction about the central axis, anticlock wise direction about its own axis. The main drive, lifting and lowering operations is motorised. The product bowl is mounted on caster wheel for easy portability for washing and transporting the material. Vacuum Jacketed Mixer consists of 2 open beaters moving in planetary motion, scraper blade ¢rally located high shear emulsifier run by separate motor for mfr. of creams, ointments, suspensions etc

The machine for mixing of ointment. The unit is provided with jacketed mixing vessel fitted with stand on fixed low-speed anchor type stirrer driven by motor and reduction gearbox as per following models.

For Ointment - Cream - Lotion - Paste etc. ManufacturingWith Double Stirrer, Scrapper & Centrally Located High Speed Emulsifier Special Feature • Range of models to suit gross volume 60, 100, 140, 200, 350, 600, 1000, 1500 & 2500 Liters for OINTMENT - CREAM - LOTION - PASTE - TOOTH PASTE.• All contact parts are made out of S.S.304 quality material. (SS316 provided on demand on extra cost)• Compact design requires comparatively smaller floor space.• Lowering and lifting movement achieved through motorized drive in 140 & 200 liters model & hydraulic lifting system from 350 liters to 2500 liters size   models. (In 60 & 100 liters models product container moving up & down manually. Motorised system can be provided on demand on extra cost, if required.)   In all other bigger size models product container remain fixed and mixing drives comes up and down by means of mechanical or hydraulic system.• Castore wheel mounted product container for the ease of mobility. (This facility available from 60 liters to 350 liters model only.)• Container with fixed legs above 350 Liters model. Hence no facility of mobility of container.• A high-speed emulsifier (Homoginizer) will be provided at the center axis, in 140 liters model and above capacity model only. (It can be interchangeable with   disperser & necessary assembly provided with m/c)• In-Line Homoginizer also provided on demand, if required.• Double stirrer & SS scraper with PTFE blades for better mixing of the material. ( In 140 Liters & above model only ) • Single stirrer with scrapper in 60 & 100 Liters model.• Planetory motion of the stirrer ( beaters ) enables faster and better mixing of the material at a considerable lesser time.• As stirrer is a top driven and sealing doesn't comes in contact with product, there isn't any black particle contamination problem.• Water / steam circulation jacket for mixing bowl, to heat or cool the mix during operation in OINTMENT MIXER only. (Water jacket recommended only in   60 to 350 liters model. Steam heating recommended in 600 litres to onward all models. Jacket also made out of mild steel in Standard Model & SS304 in GMP Model.)• All non contact parts (general structure) made out of mild steel and claded with SS304 or chrome plated or made out of SS304 in GMP Model. Contact   parts are polished to the mirror finished and non contact parts are polished to the matt finished in GMP Model. All safety guards & covers made out of SS304   material in GMP model & made out of mild steel & painted in standard model.• General structure & all non contact parts are made out of Mild Steel & same wil painted in Standard Model.• Fixed type product container in 600 litres and above capacity models.• Heater with temperature controller for heating facility. (For 60 / 100 / 200 / 350 litres OINTMENT MIXER only)• 100 % utilisation of machine can be possible due to facility of change of extra product container.  (In 60 to 350 litres model only)• Vacuum facility provided on demand for de airation during mixing in Gel product. (For OINTMENT MIXER only)• Insulation will be provided on jacket of container. (For OINTMENT MIXER only ) as a optional facility.• Material discharge from bottom. Flush bottom valve provided for material discharge in 350 litres  and above model only. (For OINTMENT MIXER only)• M/C provided with Light glass, Sight glass , material inlet, air suction valve for vacuum,  CIP port facility. (For OINTMENT MIXER only)• All connection of valve, light glass, sight glass will be triclover ended.• Sampling port provided in 600 litres & above model.• Flush bottom type valve in 600 litres & above model.• All moving parts are enclosed with safety guards. Optional • SS316 product contact parts instead of SS304.• Vacuum system for deairation during mixing. (For gel products)• Variable speed drive for main agitators motor and emulsifier motor.• Vacuum Pump Set.• Flameproof model.• "PLC" based operating panel for automation.• Hydraulic lifting system in 60 to 200 litres model, instead of mechanical lifting system. Application Ideal for mixing of Pharmaceutical powders, ointments, creams, lotions, pastes, tooth paste, cosmetics, food and confectioneries, rubber and rubber compound, colours and pigments, PVC & plastic material, ceramics, pesticides, insecticides, adhesives, metal powder, resins etc. etc.

• Voltage: 210-480 V
• Frequency: 50-60 Hz
• Capacity: 50 Litres
• Material: Stainless Steel
• Phase: 3 Phase

Semi Contra design agitator with blades having holes to cut the mass. Jacket have heating & cooling with temperature controller. Separate vessel for wax melting & water heating. Process piping are highly Electro polished and joints are DIN TC standard for easy opening & re-fixing. Hydraulic Power Pack with cylinder to lift complete agitator assembly with top lid for product recovery Easy to cleaning Change over of batch & for maintenance. VFD for Anchor agitators to vary the RPM as per product Recipe. Cleaning validation by SWEB testing match international standard less than 10 PPM OR by CIP system with online conductivity. Imported gear box with synthetic oil (Zero noise level) Load Cell for accurate weighing of final products. Watering vacuum pumps to create vacuum in Mfg. vessel and transfer other ingredients Molten wax Hot water in Mfg. Vessel. Vacuum system save timing to transfer product from one vessel to another vessel and zero retention in pre phase vessel & inter connecting pipeline. To remove Air enter peal from the product. No Air contamination. Human contamination. FEATURES :

• Voltage: 380V
• Application: Pharma industry
• Minimum Order Quantity: 1 Piece
• Phase: Three Phase
• Capacity: 50 Litres
• Material: stainless steel
• Automation Grade: Automatic

The Ointment Manufacturing Plants are ideal tools for the pharmaceutical & cosmetic industries for the production of Ointment, Cream, Lotions, Tooth Paste & other emulsions & homogenizations. Ointment Manufacturing Plant is designed to handle processes right from transferring of raw material to the delivery of finished products. Coming with digital metering pump fitted in hopper of filling machine, this plant is used for production of lotion and is so designed that it saves on valuable batch processing time. The plant offers efficient heating & cooling with support of accurate temperature control even in cases where processing is done for small qualities.
