Overcurrent Relay Dealers

• Packaging Type: Carton Box, Wooden Box, Metal Sheet Box
• Overall Weight: 100gm, 200gm, 300gm
• Usage: Factories, Power Plants, Shopping Malls, VCB
• Specialities: Stable Performance, Shocked Proof, High Performance, Heat Resistance, Durable, Dipped In Epoxy Resin
• Size (Inches): 4-6 Inches, 6-8 Inches, 8-10 Inches
• Overall Dimension: 580x260x465mm
• Witdh: 80-120mm
• Relay Height: 40mm
• Relay Length: 30mm
• Brand Name: CG
• Shape: Square
• Condition: New
• Phase: Single Phase
• Warranty: 1 Year
• Country of Origin: India
• Current Type: AC
• IP Rating: IP30-50
• Corrosion Resistance: Yes
• Number of Poles: 3 Pole
• Terminals: 3 Terminal
• Switching Voltage For Zero: 220V

Supported by a well-organized network and dependable resources, we have developed as a reputed supplier of Induction Type Non Directional Overcurrent Relay. The company is deep rooted in Nashik(India) and has gained a distinguished position in the market.   Specifications : Single Pole. 5A or 1A. IDMT type. Setting Range: 50 to 200% in Steps. Relay should have Identical time/current characteristics on all taps. Self-powered, High torque, ensuring consistent timing even under adverse conditions. Very low overshoot. Simple construction, easily accessible. Comprehensive range of high-set unit ratings. Dustproof drawout case and tropicalised finish. Housed in MS Enclosure with important terminals brought out.

• Brand Name: Siemens
• Voltage: 220-240 V
• Number of Poles: 3 Pole
• Frequency: 50 Hz
• Model Name/Number: P120
• Usage/Application: Industrial
• Current: 120A

• Current: 10 A
• Brand: BCH
• Model Number: BOCR-SSD05
• Voltage AC: 240 AC
• Voltage DC: 24 V
• Trip Indication: Digital Display

• Brand Name: BASLER
• Type: Overcurrent Relay
• MODEL: BE1-851
• STYLE NO: G3A1S1
• SENSING INPUT RANGE: 5A PH, 1A N
• POWER SUPPLY: 48-125V AC/DC

basler be1-851 overcurrent relay model: be1-851 type: overcurrent relay style no: g3a1s1 sensing input range: 5a ph, 1a n power supply: 48-125v ac/dc condition: used & working qty: 5 pc available  ref: mm.

Rated data : Nominal current IN 1A or 5A, Nominal voltage UN 100 V, 230 V, 400 V, Nominal frequency fN 50 Hz; 60 Hz adjustable Power consumption in current circuit : at IN = 1 A 0.2 VA, at IN = 5 A 0.1 VA Power consumption in voltage circuit : < 1 VA Thermal with stand in voltage circuit : continuously 1.5 x UN GL-Approbation : 98776-96HH Bureau Veritas Approbation : 2650 6807 A00 H

• Brand Name: SIEMENS
• Protect Feature: Sealed
• Certifications: IEC 61850 Certificate Level A1
• Application: Protective
• Size: Miniature
• Model Number: 7SR158 Argus
• Place of Origin: Maharashtra, India
• Port: Mumbai

We offer numerical directional overcurrent protection relay. Mit121131 is micro-controller based numerical true rms single pole directional over-current protection with voltage polarization, and the relay will operate depending on the direction of fault current and relay setting. versions: mit 121 - single pole directional over-current protection mit 131 - single pole directional over-current protection with dc transient free high set application distribution feeders transmission lines solidly or resistance grounded systems

Backed by a team of engineering experts, we are able to deliver precision-made Overcurrent Relay in the national market. The Overcurrent Relays offered by us are available in varied grades and sizes to meet the diverse requirements of the clients in an efficient manner. The Overcurrent Relay is widely used in varied industries for protection of any 3 phase supply working equipment against over and under current. The clients can avail the Overcurrent Relay from us at the industry leading price. Technical Specifications Senses load any two phase : Up to 40 ampsAdjustable trip setting frequency : 50/60 Hz +-3%O/P contact rating : amp-230V, ICOAccuracy : Class 1

• Voltage: 24-50 V AC/DC or 100-230 V AC/DC
• Usage/Application: Industrial
• Operating Temperature: -25 to +65 Deg C

The SEL-387 Current Differential and Overcurrent Relay provides protection, control, and metering for transformers, buses, breakers, and feeders. Features include four three-phase current inputs with independent restrained and unrestrained differential protection, programmable single- or dual-slope differential characteristic, circuit breaker monitor, battery voltage monitor, and enhanced SELogic control equations.

MJT 314B (Self powered numerical over current protection) & MJT 314C (Self powered with series trip numerical over current protection) relay combines the power and flexibility of microprocessor technology with decades of experience in the field of protection. A wide range of protection elements and characteristics are supplemented by advance features such as metering, fault recorder and communication. MJT 314 (B&C) offers inverse time and definite time over current protection for phase fault and earth fault with communication Application Distribution Feeders Transmission lines AC machines Capacitor banks Transformers Used in Compact MV Switch boards with CB Where Auxiliary Voltage is not available or guaranteed

• Brand Name: Schneider Electric
• Voltage: 240 V
• Material: Mild Steel
• Frequency: 50 Hz
• Phase: Single Phase
• Model Name/Number: P11x
• Usage/Application: Industrial
• Current: 30 A
• Power: 12 W
