Thermostat Panel Heater
10 Per Piece
1000 Piece (MOQ)
Panel Heater With Built In Thermostats "Combi Model" PRODUCT DESCRIPTION: ‘Saiego’ Combi Space Heaters with built-in capillary Thermostat are ideal for prevention of condensation, corrosion & Leakage currents in L.T. & H.T. Switchgear panel boards / electronic instruments & panels etc. PRINCIPLE & FEATURES: In this, a long life and sturdy extruded aluminium sheathed, mica insulated heater and an accurate capillary thermostat are place in a Rust resistant steel perforated body. A 2 x 2.5 sqr. mm porcelain terminal block is provided for electrical connection. INTENDED USE: Prevention of condensation, corrosion & Leakage currents in L.T. & H.T. Switchgear panel boards, enclosures, switch boards, & electronic instruments etc. INSTALLATION: Four side slot holes for fixing tabs are provided for fitting the heater in the panel. Installation can be done in vertical or horizontal position although vertical mounting is preferred. Distance from surface of panel should be at least 10mm and distance from plastic parts should be at least 50mm. Connection wire must be on the side or below to avoid warming up of the wire Additional Information: Packaging Details: BOX PACKING
Panel Hopper Heater
Get Price Quote
The PH Hopper Heating Module is a rugged design, the high-performance heating surface of the hopper. The Marathon hopper heater are self-contained heaters whose designed provide heat outputs up to 3 watt/squire inch, with a maximum circuit size of 4500watts depending on the application, the design of the hopper heater is such that it distributes heat over its entire surface. The PH module is according to customer requirements of surface heating area and application. The heater is offered in multiple designs, each one includes a heater element made of Inconel/Nichrome/SS. The heater element which provides multiple flow paths for electrical current to pass. This design eliminates the burnout chances common with series wire-based design.Construction Parallel circuit high-temperature alloy heating element. Temperature-rated insulation- Mica and glass wool. Aluminum/Aluminized steel protective enclosure and its cover with mounting channel attachment. High temperature insulated lead wire for connection Hopper Heating Modules for Power PlantsConveying coal/oil (other material) from stockpiles to boiler during winter months is a well-documented nightmare for plant operators. Identical conveying problems exist within the mining industry as coal is moved around the mine site. Coal stored outdoors on the stockpile or delivered by unit train or barges picks up moisture from rain and snow. When this wet or frozen coal is conveyed, it inevitably comes into contact with the plate steel of the various hoppers and chutes within the coal handling system. During winter, this plate steel is below freezing for extended periods. When wet or frozen coal encounters steel at sub-freezing temperatures an instantaneous bond is formed. This bond causes immediate and often catastrophic blockage of the hopper and chutes. The bond and resultant blockage are so severe that often pneumatic drilling equipment and explosives are required to free up the system. This problem, known as Flash Freezing, is extremely inconvenient and very costly. Several cases are documented where utility and industrial boilers have been shut down due to blocked conveying systems.
Best Deals from Panel Heater
Panel Space Heaters
Get Price Quote
A panel heater is an energy-efficient and cost-effective heater which is also known as a panel space heater. It is used in residential as well as commercial spaces and comes in 12-480V and 2000W wattage. it comes in a length of 300-1500mm which makes it suitable for limited spaces. These heaters can be mounted on walls and provide localized heating for rooms or specific areas. Panel heater is easily available from reputable panel space heater manufacturers. While searching for reputed panel space heater manufacturers, you need to check for the reputation of the supplier. Make sure that the supplier has long-term experience in the business and has been supplying panel heaters to clients and customers. You should also check the testimonials and feedback so that you will know about their products and services and how satisfied clients are from the purchase. This will help you get assistance post-purchase if you have any issues. You can also ask for installation with the panel space heater manufacturers which will save you time and money. You will also be able to understand how the heater works to avoid any unexpected situation. You will also be able to get good quality panel space heater that will serve the purpose well.
Space Panel Heater
100 Per Piece
50 Piece (MOQ)
HT & LT panel Heater
Get Price Quote
Premium grade, cost-effective prices and unsurpassed standard distinguishes our HT & LT panel Heater from others in the marketplace. We have a massive inventory in Vadodara(India), and thus, we are capable of presenting the best in class range.
Panel Heater (Middle Left Fixing Without Cover)
110 Per Piece
50 Piece (MOQ)
Working Principle & Features : Body is made of anodized heatsink grade extruded aluminium for Fast dissipation of heat into air. High quality resistance heating element is insulated with mica for optimum insulation even in extreme humid conditions. Resistance element and insulation are held tight in between aluminium parts and squeezed for quick and uniform heating. Heater can withstand much higher degree of mechanical shock and vibration. Elevated body provides for easy passage of heat directly to air, ithout heating panel body and with perforated sheet metal enclosure. A black powder coated finish ensures rapid heat. Intended Use :Prevention of condensation, corrosion, Leakagecurrents in LT. & H.T. Switchgear panel boards / electronic instruments & panels etc.Installation : Four Holes of 6.3mm are provided for mounting on one side of the heater. Installation can be done in vertical or horizontal position although horizontal mounting is preferred. Distance from surface of panel should be at least 10mm. and distance from plastic parts should be at least 50mm. Remark :It is recommended to use a thermostat to control the heater.
0.0
View Profile
panel heater
Get Price Quote
Power Saver BMS Compatible Constructed as standard Units. Tailored to suit customer’s specific requirement Designed for operation in temperature conditions up to 950 degree F in winter Suitable for Use in relative humidity up to 90%.
0.0
View Profile
panel heater
Get Price Quote
We have maintained our high standards in the market by delivering only high-quality products and this is done by using quality raw materials obtained from reliable sources. Designed to brave shipping and handling related damages, our packaging materials are industrial grade and keep the products protected. Thus, ensuring products remain brand new. The offered Panel Heater has aluminium as heating element and offers maximum heat due to a larger surface area.
0.0
View Profile
Electrical Panel Room Heater 250W
3,000 - 5,000 Per Piece
0.0
View Profile
panel heater
1,500 Per Piece
panel heater
Get Price Quote
Control Controller Accept input RTDs Thermocouples Three Phase Mains Operated Three single Phase Control Output Control Device Contactor or Solid state Relay or Tyristor Capacity available 254070100120 A Fabricated wit Stainless Steel or MS with Powder Coated Temperature Range 50 to 1200 º C.
0.0
View Profile
Control Panel Heater
Get Price Quote
We are the main supplier of this product.
0.0
View Profile
Flate Panel Split Solar Water Heater
Get Price Quote
Techhnical Characteristics:Split System is manufactured in compliance with the industry standards and norms in order to provide strong construction and optimum functionality. These splits can be installed on almost all roof types and can be used in areas of high and low pressure. Reliable and efficient in their performance. split system simplify the installation and heat transfer. More Info
0.0
View Profile
Plain Panel Heater
10,500 Per Units
0.0
View Profile
Elstein FSL long panel heaters
Get Price Quote
Elstein FSL long panel heaters are ceramic infrared heaters with a low overall height, designed for operating temperatures up to 700 °C and surface ratings up to 45 kW m². They have two sockets with integrated twisted litz fixing wires, so that FSL heaters are easy to install and are space-saving. No special pre-punched holders or reflector plates are required for the assembly. FSL series heaters are particularly suitable for lamellar heating tasks due to their long narrow design. An example for lamellar heating tasks can be found in the lamp industry where FSL heaters are used for curing the coating of fluorescent tubes.
0.0
View Profile
electric panel heaters
Get Price Quote
We are reckoned as one of the chief Manufacturers, Exporters and Suppliers of Electric Panel Heaters from India. Electric Panel Heaters are fabricated using the latest manufacturing technology as per the set industry standards. Available in customized specifications, this Electric Panel Heater is supplied with all necessary accessories for hassle-free installation. It features an adjustable thermostat that facilitates precise control of the heat output. Simple to operate and modify, our Electric Panel Heater controls energy costs.
0.0
View Profile
BH - AL BOX HEATER
Get Price Quote
Anti condensation Air/Panel heater Compact in size Economical, effective and widely used BH series is one of the most popular anti condensation heaters. The construction of this heater is extremely robust and most reliable. This series provides excellent heating for wide range of applications. The standard heaters are designed for operation up to 250V AC for single phase supply and up to 440V AC for three phase supply.
0.0
View Profile
panel heater
Get Price Quote
Infrared panel heaters are custom built heaters operating primarily in the long wave range. The basic construction consists of a resistance coil embedded into a ceramic fibre board which is then located behind an emitting surface of either anodised aluminium or glass ceramic. This is then placed inside a 75mm high aluminised steel housing which normally contains 50mm of thermal insulation to reduce heat loss through the rear of the unit.
0.0
View Profile
wall mounted room panel heaters
14,699 - 18,500 Per Piece
1 Piece (MOQ)
wall mounted room panel heaters
0.0
View Profile
panel heaters
Get Price Quote
panel heaters, foil heaters
0.0
View Profile
