Panel Saw Dealers

• Brand Name: Ruei
• Main Saw Motor Power: 5.5 kW
• Main Saw Size: 305 x 30mm
• Main Saw Spindle Speed: 4000 to 5000 rpm
• Maximum Working Length: 3000mm
• Maximum Working Thickness: 78mm
• Model: RI-6130
• Scoring Saw Motor Power: 0.75 kW
• Scoring Saw Size: 120 x 20mm
• Scoring Saw Spindle Speed: 9000 rpm

• Application: Cutting
• Phase: 3 phase
• Size: 3200x380mm
• Speed: 6000/8000 RPM
• Max Saw Blade Diameter: 305mm
• Max Thickness Of Cut: 80mm
• Brand Name: Umiya
• Max Length Of Cut: 3200mm
• Power: 7.5 + 1 HP

• Features: Quality product,Highly demanded.

Sliding Panel Saw Machine Matching up with the requirements of our clients, we are involved in offering Automatic Panel Saw Machine (A2 Panel Saw Machine).

• Application: Cutting solid wood, MDF, Plywood
• Voltage: 380V, 220V Power
• Weight: 1100KG
• Model Number             : PNE 3035
• W: 5.5KW Dimension
• (LxWxH): 3200mmx3150mmx900mm
• Sliding table material: High-strength extruded aluminum alloy
• Rail style: Linear rail Sliding
• Table length: 2200mmx3200mmx3800mm
• Dust hood style: European,italian,economic
• Style digital readout: Available

• Brand Name: Sun Digital Technology
• Driven Type: Mechanical, Wood Work
• Color: Brown, Grey, Light White, White
• Condition: New
• Automatic Grade: Semi Automatic
• Size: 3200*360 Mm
• Voltage: 380V
• Type: Sliding Table Panel Saw
• Warranty: 1year
• Country of Origin: India
• Powder: 3-6kw
• Sliding Table Length: 3200 Mm
• Sliding Table Width: 380mm

• Application: Panel Cutting
• Phase: 3
• Voltage: 230 V
• Max Saw Blade Diameter: 350 mm
• Max Thickness Of Cut: 121.4 mm
• Brand Name: Hammer
• Sliding Table Length: 3200 mm
• Saw Blade Tilt: 45 Degree
• Outrigger Table Length: 2600 mm
• Main Saw Blade Motor Power: 7.5 HP
• Scoring Blade Motor Power: 1 HP
• Rip Side: 1250 mm

• Application: Industrial
• Automatic Grade: semi automatic
• Brand Name: red wood
• Size/Dimension: 8feet
• Model Name/Number: Aps48

• Country of Origin: India
• Type: Panel Saw
• Condition: New
• Warranty: 1year
• Brand Name: Woodcraft
• Dimension of Sliding Table: 3200mm x 360mm
• Gross Cut Capacity: 3200mm x 360mm
• Width of Cut Between Saw Blade and Rip Fence: 1250mm
• Saw Blade Diameter: 300m (250-300)
• Height of Cut: 80mm
• Speed of Main Saw Spindle: 4000/6000rpm
• Spindle Diameter: 30mm
• Tilting Saw Blade: 0-45
• Main Motor: 5.5 K.W.
• Scoring Saw Blade Diameter: 120mm
• Speed of Scoring Saw Blade: 9000r/min
• Scoring Spindle Diameter: 20mm
• Scoring Motor: 0.75kw
• Overall Dimension: 3250 x 3250 x 900 (mm)

• Model: Nova SI 400
• Squaring Capacity: 3200x3200 mm
• Main Blade Diameter: 400 mm
• Cutting Height: 140/97 mm
• Motor Power: 9.5 kw Hp
• Frequency: 50-60 Hz
• Minimum Order Quantity: 1 Piece

We are the leading manufacturer, supplier & exporter of the export quality panel saw machines located at Ahmadabad India. Basically it is the machine with the sliding table that cuts the different material in to the required sizes. It is the quicker, accurate, effortless & safe and sound way for cutting plywood, plastic, & aluminum sheets. We have a different model of the existing product with gross capacity from 1600 mm to 3200 mm, as like UPS 1600, UPS 3200 A, UPS 3200 B, UPS 3200 C. It has sliding table that runs extremely smooth; also it contain a manual clamp for undersized job cutting .it also enclose a multi chamber system with the linier bar which provide the longer life to the machine. The main spindle runs at the speed of 4000 to 6000 RPM.it has an electric control panel with the digital screen, with setting of saw blade angle 900-450 degree.

• Item Weight (Kgs): 750 kg and 800 kg
• Saw Blade Speed: 3000 / 4000 / 5000 rpm
• Cutting length: Up to 1250 mm
• Panel cutting angle: Up to 45 degree on both sides of the table
• Sliding Table Length: 3200 mm

• Application: MDF
• Phase: 3 Phase
• Model Number: MJ1132F
• Application: For Interiors Make All Other Wood Works
• Size: 3200 MM
• Voltage: 415V
• Warranty: 2 years
• Max Saw Blade Diameter: 400MM
• Max Thickness Of Cut: 125mm
• Brand Name: NANXING MACHINERY CO. LTD.
• Job Material: Wood
• Size/Dimension: 3200MM
• Speed Of Scoring Saw Spindle: 9000 RPM
• Cutting Blade Size: 14 inch
• Scoring Motor: 1.1KW
• Cross Cut Fence Read Out: DIGITAL
• Model Number/Name: MJ1132F
• Item Weight: 1000kg
• Max Length Of Cut: 9*6 FEET
• Max Cutting Height: 125MM
• Power Consumption: 9 HP

• Sliding Table Length: 3200 mm
• Sliding Table Width: 360 mm
• Motor Power Saw Blade: 5 Hp
• Up Down Movement of Saw Blade: Manual
• Motot Power Of Scoring Blade: 1 Hp
• Minimum Order Quantity: 1 Piece

At Nihar Industries, New Panel Saw models are designed and developed that offer a range of technical advantages over the classic panel saw machines. These machines are characterized by highly user friendly design, a sturdy and compact structure that can deliver years of robust performance even with little to no maintenance. Such features make the new panel saw machines ideal for different kinds of wood cutting projects.

• Application: Wood
• Phase: Single Phase
• Size: 8''x4''
• Voltage: 240 V
• Speed: 4200 RPM
• Brand Name: Gorsan/Wudmax
• Model Number: GP-330 ECO

• Weight: 600kgs
• Voltage: 380v
• Model Name/Number: HN-MJ6132-45
• Frequency: 50Hz
• Size/Dimension: 3200*360 mm

Features Sliding Table HOLYTEK Sliding   Panel Saws are designed with the latest  software and precision  CNC Machined works. With the utilisation of  only top quality parts  and production,  HOLYTEK's  saws  guarantees a lifetime  of high performance and the best accuracy. Multi-chamber of sliding table is manufactured by an excellent reputation aluminium supplier in European. Precision in-house, wheel type sliding mechanism and the rail is manufactured from high tensile steel, heat treated and surface is chrome plated for lifetime straightness.

• Gross cut capacity: 3200mm

Panel saw Precision aluminium sliding table assembly, with excellent accuracy. Smooth table movement on hardened steel rods Heavy duty outrigger frame locks to sliding table with screw clamp. Large section aluminium crosscut fence with two work stops. Heavy swinging support arm below outrigger frame, to easily support panels. Electric rise and fall of main saw blade by a switch on control panel. Sideways adjustment of scoring blade by a knob below rip fence bar. Rise & fall adjustment of scoring blade by a knob on control panel.Tilting of saw blade assembly to required angle by handwheel with angle setting gauge in centre of handwheel. Heavy duty ripping fence mounted on 50mm diameter round bar. Overhead frame mounted safety guard with dust exhaust outlet. Machined cast iron main table supported by heavy gauge pressed steel machine body. Table hinges up for convenient servicing. All sealed ball race bearings on saw blade arbors. Two blade speeds by belt change on pulleys. One main saw blade and split scoring blade included.

• Application: Industrial
• Model Number: MTPS 3200A
• Phase: 3 Phase
• Voltage: 380V
• Brand Name: MechTek
• Scoring Motor: 1 HP
• Cross Cut Fence Read Out: 4 m
• Spindle Speed: 8000 RPM
• Frequency: 50 Hz
• Gross Cut Capacity: 3200 mm

• Usage/Application: Industrial
• Model Name/Number: LUXTER LT100
• Speed Of Scoring Saw Spindle: 4400 Watt
• Automation Grade: Automatic
• Brand: LUXTER

• Application: Wood, door and windows
• Brand Name: Thulasimuthu
• Size: Customised
• Warranty: 6 months
• Cutting Blade Size: 5 inch

• Brand Name: Woodmaster
• Voltage: 380 V
• Frequency: 50 Hz
• Sliding Table Size (mm): 380 x 3200 mm
• Main drive motor: 5 HP
• Minimum Order Quantity: 1 Piece

• Application: Wood
• Model Number: STS3200D
• Brand Name: ICW
• Country of Origin: Made in India
• Scoring Motor: 0.75kW
• Dimensional Sliding Table: 3200*375 mm
• Gross Cut Capacity: 3100 mm
• Width Of Cut Between Saw Blade And Rip Fenc: 1250mm
• Saw Wade Diameter: 4300 mm
• Height of Cut: 75mm
• Height of Cut with Saw Blade: 51.5mm
• Speed Of Main Saw Spindle: 6000 rpm
• Main Spindle Diameter: 30mm
• Main Motor: 5.5kW
• Scoring Saw Blade Diameter: 120mm
• Speed Of Scoring Saw Blade: 800 r/min
• Scoring Spindle Diameter: 20mm
• Net Weight: 780 kg
• Overall Dimensions: 3250*3500*870 mm
• Tilting Saw Blade: 45mm

Salient Features :   Sturdily built heavy duty m/c that gives precise cut with burr free cutting Motorized scoring unit up-down and manual lateral adjustment. When scoring blade is switched-on, the scorer moves to the stored height Extra second support for wider work pieces Central lubrication system facilitate smooth & precise movement Made in India with best service & spares support

• * Main Blade Power: 4 KW
• Scoring Blade Speed: 9000 RPM

* Automatic motorized movement is provided for Main Saw Blade raising & lowering through Linear Actuator. * Automatic motorized movement is provided for Scoring Blade raising & lowering through Linear Actuator whereby Saw Bridge can be may accurately canted up to 45 degree to any desired degree. * Extremely exact cut. No more cutting edge damages. Burr Free Cutting. Cutting Accuracy Less than 0.15 mm * Perfect Job Cutting on Wood, Plastic or Non Ferrous Metals.

• Voltage: 380 V
• Brand Name: Gorsan
• Usage/Application: Industrial
• Phase: 3 Phase
• Tilting Saw Blade: 45 degree Celsius
• Dimension Of Sliding Table: 3200 X 360 mm
• Main Saw Spindle Speed: 6000 RPM
• Scoring Saw Spindle Speed: 8000 RPM
• Main Saw Motor Power: 7.5 hp
• Model Name: GP 300 Eco
