Penetrometer Dealers

• Brand Name: Steco,Steco
• Weight: 300 gm (Approx)
• Material: Stainless Steel
• Application: Lab
• Automation Grade: Semi-Automatic
• Scale Range: 0-50 kg/cm2

This instrument is used to estimate approximate unconfined compressive strength and the estimation for shear strength of soil. Cohesive soils can also be classified in terms of consistency using this penetrometer. This is a handy and convenient instrument. Salient Features Specifications : It cosists of a light weight barrel assembly with a polished and ground steel loading piston plunger. A direct reading scale is engraved on the piston barrel and indicates load in kg./sq.cm. A maximum load indicator ring is provided on the penetration plunger. The calibrated spring is heat treated and plated for rust resistance. The barrel diameter is 20 mm and the length 150 mm. Supplied in storage box.

• Material: Stainless Steel, Aluminum, Copper, Nickel, Inconel, Titanium
• Brand Name: Gamma Solutions
• Size: Standard
• Length: 25 mm, 50 mm
• Material Grade: SS304, SS316 etc.
• Features: High performance, Accurate functioning, Application specific design
• I Deal: in new only

• Material: Metal
• Application: Laboratory
• Product: Penetrometer with Needle
• Usage: For Cement
• Warranty: 1 Year

• Material: Aluminum
• Frequency: 50Hz
• Usage: Laboratory
• Weight Approx: 0.5 kg
• Power Source: Electric
• Finish: Polished

Completely manual version, the head is raised or lowered manually and secured using a knob. sturdy cast iron base, with levelling legs at the bottom to adjust. supplied with one 50gms and 100 gms each weights with standard 47.5g plunger assembly.   Astm d5, d217, d937, d1321, d1403, d2884, d4950; ip 49, ip50, ip179, ip310; iso 2137; din 51 579, din 51 580, din 51 804; ftm 791-311, ftm 791-312, ftm 791-313; aocs cc 16-60; aacc 58-14; nf t60-119, nf t60-123, nf t60-132, nf t66-004, bs: 1377   Application Used for penetration tests on petroleum products and for consistency tests on a wide range of food products, cosmetics, pastes, destempers and other solid to semi-solid products. consists of a dial scale 0-40.0mm with 1⁄10mm sub divisions. (0-400 penetration scale). suits cones and needles to perform all the astm tests on lubricating greases, asphalts, petroleum waxes. compact design facilitates transport for field use. geared dial and plunger movement for accurate placement of the tip of the needle or cone on the surface of the sample.   Models 11045-00 standard penetrometer 11045-01 standard penetrometer with digital timer. 11045-02 fully automatic penetrometer

• Material: Mild Steel
• Brand Name: Novotech
• Display Type: Analog
• Usage/Application: Laboratory
• Height: 1-2 feet

Product Description For determining the consistency of masonry mortar.Cone Penetrometer consists of a movable bearing rod to which a cone 145mm. Long and 75mm dia at a base is fixed. The bearing rod passes freely through a bracket which is provided with release mechanism. A dial graduated in mm with rack and pinion is provided for measuring the penetration. Complete with a conical container 150mm id x 180mm deep and a platform.

• Model Number: ALPHA CHEM-1370
• Brand Name: ALPHA CHEM

Hand Held Cone Penetrometer: Alpha Chem is manufactures,exporter & suppliers Hand Held Cone Penetrometer. Hand Held Cone Penetrometer : The drive is by means of a rack and pinion manually through a gearing arrangement. The gear box and pinion are fixed on two handles, sprockets and chain arrangement. The movement of the rack is guided by a bracket ( attached to the rack) and two pillars. The penetration resistance i.e. the pressure is indicated on hydraulic gauges through a hydraulic measuring head. Two pressure gauges of 15cm dia dial and 2 capacities 0-160kg/cm are provided. An automatic cut-off valve, to protect the low capacity gauge from being overloaded is provided. The 2 valve can be adjusted and locked at desirable values between 20 to 60cm . A provision is made to anchor the unit to the ground (with the help of four anchors supplied with the unit) and there is a provision for lateral 2 movement of the unit so that subsequent tests could be performed without shifting the entire anchorage. A 10cm penetration cone with friction jacket is provided along with fifteen mantle tubes (non-uniform having an effective length of 1 m each with sounding rods for finding out the cone (point) resistance or jacket friction.

• Condition: New
• Application: Household, industrial, Laboratory
• Power Source: Electric
• Material: Steel
• Finish: Polished

Universal Cone Penetrometer We have best place in the market by offering best offering best and perfect quality collection of Universal Cone Penetrometer that are designed for used to evaluate the consistency of soils. Features: Best quality Compact designs Many sizes available Latest designs Perfect finish Nominal rates This apparatus is used for penetration on a wide variety of material such as greases petroleum, bitumen tar wax and polish. It consists of Timer (for setting the number of fall of needle) head support mounted on a vertical rod, which can be adjusted for a height. Rack and pinion assemblies provide a fine adjustment of needle tip to a sample and incorporate slipping clutch mechanisms which make a reading of penetration and subsequent resetting of a sample and accurate operation. The dial is graduated from 0- 400 in one tenth millimeter sub division. It is supplied with on e container and one set of needle Yes! I am interes

Proctor Penetrometer, Spring Type, 0-40 kg x 1 The instrument consists of a needle attached to a spring loaded plunger, the stem of which is calibrated to read 0 to 40 kg division. Long stem is graduated at every 12.5mm to read depth of penetration and for use with needles of larger areas . The small penetration stem is also graduation in 12.5mm division and is used with needles of smaller areas. Needle points one each of 0.25, 0.5, 1.0, 1.5, 2.0, 3.5 and 6.0 sq Cm. and one tommy pin is supplied. Complete as above in a wooden carrying case. Proctor Penetrometer, Hydraulic Type, 0-40 kg x 2 This instruments is same as above but the penetration pressure on the needle is conveyed through a hydraulic system Comprises hydraulic proctor needle system complete with a pressure gauge fixed at easily readable angle reading 0-70 kg x 2 kg. A set of needle points consisting one each 0.25, 0.5, 1.0, 1.5, 2.0, 3.5 and 6.0 sq. cm. and a wooden carrying case. Penetrometer, Proving Ring Type. (Vicksberg Penetrometer) Simple and light instrument for measuring static penetration resistance. The thrust force is provided directly by the operator who, by pushing on the T handle, forces the cone into the soil.The encountered resistance is measured on the fitted load ring. Testing is only possible in soils with good consistency and for short depths. Specifications 1. 3 cones with 30° cone angle and 1 sq. inch sectional area 2. 1 KN (100 kgf) load ring

The unit is compact with in-built timer to control duration of penetration presetted in factory to 5 seconds. The instrument is provided with leveling screws. Product Code : EKE 512-2.

• Brand Name: Quality Engineering Corporation
• Feature: Superlative, Qualiy, Flawless finish, Easy usage & High durability
• Country of Origin: Roorkee
• Size: Different
• Usage: Evaluating the strength of soil on field exploration

We have carved a niche for ourselves in markets across India for offering optimum quality Pocket Penetrometer. Our Pocket Penetrometer is extensively used for evaluating the strength of soil on field exploration or construction site and in the preliminary laboratory studies. It gives directly the unconfined strength. Our Pocket Penetrometer is widely acclaimed for its superlative quality, flawless finish, easy usage and high durability. Further, Pocket Penetrometer is made available in different sizes at the best market prices.

• Weight: Approx 3kg
• Frequency: 50 Hz
• Material: Cast Iron
• Display: Analog
• Angle: 30 Degree
• Supply: Ac Supply

Our company name figures among top-notch Manufacturers, Exporters and Suppliers of Cone Penetrometer in Delhi, India. Our Cone Penetrometer always complies with industry standards and features longevity, high grade and pocket friendly prices. The Vicksberg Penetrometer that we bring forth is a Simple and light instrument used for measuring static penetration resistance. Buyers can acquire it custom-built specifications, from us. More about Cone Penetrometer : The thrust force is provided directly by the operator who, by pushing on the T handle, forces the cone into the soil. The encountered resistance is measured on the fitted load ring. Testing is only possible in soils with good consistency and for short depths.Specifications:- 1 cones with 30o cone angle  2 KN (200 kg f) load ring  Road length 45 cm.

Gmp-gc-85 digital penetrometer: microprocessor based unit provides automatically timed operator programmable penetration measurements • conforms to all is,astm, ip, iso 9001 and related specifications possible user groups are: adhesives, airports & aviation, asphalt, automotive, beverages, bitumen, chemicals, confectionery, constituent, cosmetics, fats, food, lubricant, mastics, motor vehicles, paraffin, penetration, pharmaceuticals, plastics, polishes, soap regulatory authorities, road research, rubber, tar, various, wax unit tests the consistency of lubricating greases, petroleum waxes, bitumen’s, pastes, creams and other solid to semi-solid products, including a variety of food products. Microprocessor control provides a full range of measurement and reporting options. The penetrometer defaults to the standard astm interval of 5 seconds “or” 60 seconds “or” as per choice. All selected parameters are retained in memory and automatically repeated in subsequent tests until changed by the operator. Penetration measurements in the full range of 0-400 “or” 0-600 in 110th of mm scale “or” 1100th of mm are reported directly in digits. If a test result falls outside of the programmed range, an audible signal and visual error message alert the user of a failed sample. It is incorporated with motorized placement of rack on the penetrated plunger carrying needle & locks the reading once it touches tip of the plunger-head with auto-positioning of rack at its home position for subsequent next measurement. It is also coupled with electrically operated plunger solenoid coil to activate release of plunger shaft as per set duration of time. For precise placement of tip of needle to the specimen sample surface, the unit is coupled with jack for updown movement.the height of the whole assembly (rack &pinion ,plunger with electrical coil etc)can also be adjusted & fixed for test-run results can be communicated to a printer or computer via a built-in rs232 interface (as
