Peripheral Pump Dealers

• Power: 0.37kW
• Model Name/Number: LKSM370
• Motor Horsepower: 0.5 HP
• Power Source: Electric
• Motor Phase: Single Phase
• Frequency: 50-60 Hz
• Voltage: 220-240 V
• Body Material: Cast Iron
• Protection Class: IPX4

• Type: 0.5HP-1HP
• Brand Name: Torren Pumps
• Material: Cast Iron
• Application: Pressure Boosting, Small gardens/ Sprinkler, Domestic Water Supply, Small gardens/ Sprinkler

The TORREN Peripheral Pump comes equipped with a Thermal Overload Protector (TOP) to prevent overheating, ensuring safe operation. It utilizes high-grade ‘F’ class enameled copper wires capable of withstanding wide voltage fluctuations. Developed and manufactured by our experienced R&D Team, who possess over 50 years of expertise in pump manufacturing, these pumps reflect a dedication to continuous innovation and improvement.

• Country of Origin: India
• Type: Self Priming Peripheral Pump
• Certification: As Per ISI
• Application: Water
• Weight: 10-20kg
• Color: ORANGE
• Condition: New
• Automatic Grade: Manual
• Power: 0.5 Hp
• Driven Type: Electric
• Warranty: 1year
• Brand: Winmax
• Material: Aluminium Die cast Motor Body
• Size: 25 x 25 mm Pipe Size
• Electric Supply: A.C Supply -1Phase -230 V- 50 Hz

• Features: Easy to use, Good Quality, Fine finish

• Speed: 2850 rpm
• Application: Industrial
• Features: Advanced radial blades designed for higher efficiency, Cost effective economic design, CE approved, Light to handle
• Frequency: 50 Hz
• Single Phase Voltage: 220 V
• Protection Class: IP 55
• Motor Case: Aluminium Alloy

• Type: Booster Pump
• Application: Industrial
• Weight: 10-20kg, 20-300kg, 30-40kg, 40-50kg
• Voltage: 110V, 220V, 380V, 440V
• Condition: New, Used
• Power: 10hp, 1hp, 2hp, 3hp, 5hp, 7hp
• Driven Type: Electric, Hydraulic
• Pressure: High Pressure, Low Pressure, Medium Pressure
• Warranty: 1year, 2years

The characteristics of the peripheral pump make them suitable for use in a wide range of industrial sectors where small volumes are to be pumped against high pressures. They can also be installed in applications at a low intake head without creating cavitation problems. A peripheral pump is a niche product in-between a displacement pump and a centrifugal pump, in which the medium is pumped into a peripheral channel Peripheral pumps have the following characteristics: The ability to transport gas without interrupting the fluid flow or damaging the bearings due to dry running. Maximum power consumption at their highest head and lowest flow rate. Steep capacity-head (Q-H) curves ideal for pressure-dependent system regulation. Insensitive to reverse rotation. Very low suction head (NPSH) required. Narrow columns (peripheral channels) not suitable for abrasive particles in the fluids.   Application Domestic Water Supply Home Pressure Boosting Garden / Fountains Over Head Tanks Construction Site  Features Cast Iron Casing and Bracket with Brass Inserts Brass Impeller Stainless Steel Shaft Super Enamelled Winding Wires Insulation Class F / B Flow Max 50 lpm Head Max 55 m Suction lift Max 7 m Liquid Temp upto 50° C Motor 2 pole Induction motor, 50 Hz, 2900 rpm, single phase 230 v +5% -15% Ball bearings

• Fluid temperature: up to 60°C
• Maximum ambient temperature: 40°C

Peripheral Booster Pump are designed to automatically start and stop the pump on opening and closing of taps. pumps are able to offer high performance, consuming low power, reliable, economical, and simple to use which have particularly steady operating curves. For the correct functioning of the pump, use clean water. Pump is coupled with a Compact designed composed pump, a manometer, a Pressure diaphragm tank, a pressure adjustable switch, and a 3 or 5 ways connection in stamped brass. These pumps should be installed in a covered area, protected against the weather.

• Color: Blue
• Pump Type: Peripheral Pump
• Brand Name: Megatech
• Model Name/Number: MSP Series
• Motor Horsepower: Up To 10 HP
• Material: CI, SS, MS
• Discharge Pressure: Up To 3.5 Kg/cm2
• Power Source: Electric
• Phase: Three Phase

• Flow: Max 50 lpm
• Head: Max 55 m
• Suction Lift: up to 7 m
• Liquid Temp: upto 50° C
• upto 50° C: 2 pole Induction motor 50 Hz, 2900 rpm
• single phase: 230 v +5% -15%

Application:   Domestic Water SupplyHome Pressure BoostingGarden / FountainsOver Head TanksConstruction SiteFeatures and Benefits:   Cast Iron Casing and Braket with Brass InsertsBrass ImpellerStainless Steel ShafBuilt in Winding ProtectorInsulation Class F / B

• Color: Green
• Power: 240 V
• Pump Type: Centrifugal Pump
• Brand Name: Leo
• Model Name/Number: LKSM350A LEO
• Motor Horsepower: 0.47 Hp
• Material: Iron
• Discharge Pressure: booster
• Power Source: Electric
• Motor Phase: Single Phase

• Speed: 2880 rpm.
• Power Range: 0.5 HP. & 1.1 HP
• Version: 220-240V, 50 Hz, A.C-1 Ph. Permanent Split Capacitor (PSC) Incorporated with Thermal Overload Protector.
• Duty: S1 (Continuous)
• Degree of Protection: IP 54
• Insulation: Class B
• Discharge range: 580 - 1620 lph
• Head upto: 12 - 40 mtrs.
• Suction lift upto: 8 ft.
• Suction x delivery size: 25 x 25
• Material of Construction: Pump Casing
• Cast Iron: Motor Frame
• Alluminium Alloy / Cast Iron: Impeller
• Bronze: Shaft
• EN 8: Sealing
• Mechanical Seal (Carbon V/s Ceramic):

• Power Rating: 0.37 kW / 0.75 kW:
• Head Range: 6 – 60 m
• Capacity: 3200 – 300 LPH
• Voltage: 160-240V (1PH)
• Liquid / Opr.Temp: Clear Water / 40°c
• Motor Body: Aluminum Extruded
• Impeller: Forged Brass
• Delivery Casing: Cast Iron
• Bracket, E.Cover: Cast Iron
• Shaft: Carbon / Stainless Steel
• :: Carbon / Stainless Steel

• Motor Horsepower: 1 HP
• Material: Aluminum Extruded
• Model Name/Number: ELITE - I
• Power Source: Electric
• Motor Speed: 1200-1500 RPM
• Capacity: 3200 - 300 LPH
• Liquid Operating Temp: Clear Water / 40 Degree c
• Voltage: 160-240V
• Pipe Size: 25x25 mm
• Head Range: 6 - 60 m

• Brand Name: LEO
• Material: Cast Iron
• Max. Liquid Temperature: 60 Degree C
• Max. Suction: 8 m

Salient Features: Cast iron casting Cast iron bracket with brass insert Forged brass impeller Stainless steel shaft SS410 Thermal overload protection Ceramic and graphite mechanical seal Non Corrosive Power Coating

• Features: Optimum functionality, Low maintenance, Enhanced working
• Used for: Water & light fuel transfer
