Pneumatic Trainer Kit Dealers

• Application: Training Center
• Color: White
• Place of Origin: Rajasthan, India
• Category: Pneumatic
• Material: Aluminum
• Supply Ability: 100 Piece/Pieces per Month
• Product name: Basic Electro Pneumatic Trainer Kit PLC
• Usage: Training
• Certificate: ISO9001 2008

• Service Required: 230 V. AC. Supply.Air Supply from 7.5 HP Compressor.

This includes following components : Double Acting Pneumatic Cylinders  -  2 Nos. Single Acting Pneumatic Cylinders  -  1 No. Five Port Double Pilot Valve  -  2 Nos. Five Port Single Pilot Valve spring return  -  2 Nos. Five Port Hand Level operated spring centered three position valve.  -  1 No. Three Port two position palm operated NO valve -  1 No. Three Port two position palm operated NC valve -  1 No. Three Port Single pilot Spring Return valve  -  1 No. Three Port Roller lever operated Return valve  -  4 Nos. Quick Exhaust valve.  -  1 No. Flow Control Valve.  -  1 No. Roller operated Electrical Limit Switches.  -  4 Nos. Three Port Double operated 230 V AC. solenoid Valve.  -  2 Nos. Work Bench operated components mounted on board & brass fittings fitted on all components. 15. Nylon Tubings. 500 mm.  -  10 Nos. 1000 mm.  -  1 Nos. Instruction Manual 1 Copy.

Sinewave Engineering Pvt. Ltd. various models of Pneumatic Trainers from Basic Pneumatic Trainer to Advance PC Based Pneumatic Trainer.   Specification :   Brand: Sinewave Engineering Pvt. Ltd.       Detailed Description   Sinewave Offers 4 model for Pneumatic Trainers. • Basic Pneumatic Trainer which can take care of basic 15 Experiments.• Electro- Pneumatic Trainer which can take care of 30 Experiments.• PLC Based Pneumatic Trainer which can take care of 40 Experiments.• Advance PC Based Pneumatic Trainer which can take care of More than 40 Experiments. For Detiled Specification please contact us on info@sinewaveengineering.com All the Penumatic Trainers can be customised as per the requirment

• Electric Supply: 230 V AC, 50 Hz
• Dry, Compressed, Clean Air Supply: 4-5 Kg/cm3

We make available the product range that is as per the customers; exact requirement and needs. By keeping records of the ever-evolving requirements of the clients, we have adopted a system that facilitate them to make transaction in both online and offline modes.   Features : Ergonomic design Relay board logic circuit operation Inbuilt safety measures M.S powder coated cubical plant Equipped with training manuals Enhanced electrical safety measures Easy to operate Self explanatory systems

We are offering pneumatic trainer kit. Technical specifications: pressure gauge : 0-10 kg/cm2and 0-150 psi input supply : 230 volts ac 50 hz single acting cylinder : stroke length of 54 cm diameter 32mm ,port size 1/8 inch operating pressure 0.5-8 kg/cm2 the board consists of the following built-in parts: 1) double acting cylinder stroke length of 100 cm 2) frl 5/2 hand lever valve 3) 3/2 push button valve ,diameter 32mm, port size 1/4 inch, operating pressure 0.5-8 kg/cm2 4) single solenoid valve,5/2 way valve, direct acting, 5) pressure 1.5 -8 kgf/cm2, 6) operating voltage 220 v ac at 50 hz 7) indicator light neon light red 8) pilot valve 9) roller lever valve 10) timer solenoid valve 5/2 way valve direct acting, pressure 1.5 -8 kgf/cm 2, operating voltage 220 v ac at 50 hz, timer spec 11) on timer 0 -10 sec 12)air filter, regulator & lubricator unit (frl unit) 0-10 kg/cm2 13)hand lever operated valves 5/2 way valve 14) pilot operated valve 5/2 way valve 15)port size 1/4’’ bsp f pressure 0-10 bar 16) roller lever valve 3/2 way valve design spool type port size 1/4’’ bsp f flow / speed control valve pressure 0-10 bar.

The basic principle of Electro Pneumatic Trainer is to study about pneumatic control used in various industrial applications. With the help of this system, a user can give details about the components of pneumatic control systems. Our team has engrossed it with premium quality material and checked it at every point.

• Material: Stainless Steel
• Driven Type: Pneumatic
• Shape: Square
• Operating Type: Semi Automatic
• Packaging Type: Wooden Box
• Specialities: Easy Maintenance, Easy To Operate
• Country of Origin: India

Pneumatic kits Pneumatic kits commonly refer to a set or even a collection of pneumatic components, tools, and accessories used in pneumatic systems. These advanced systems utilise compressed air to move force and energy, normally found in different industries and applications, which include manufacturing, construction, automotive, and aerospace. We at Shantek Instruments are here with the best quality pneumatic kits available at the best price. Our products can be used for hands-on training of all sorts of end-use. Using this trainer kit, one can simply and quickly assemble different circuits. The approach supports the training needs for design, maintenance, operation, and troubleshooting of different pneumatic applications. Our trainer kits can be quickly and easily personalised to suit your special training demands. We can add pneumatic trainer kit components that suit your special training needs. If you have more queries in mind related to pneumatic kits, just contact us now.

• Type: Electro Pneumatic Trainer Kit
• Color: Grey
• Voltage: 220V
• Condition: New
• Power Type: AC, DC
• Driven Type: Electric
• Warranty: 1Year
• Brand Name: ENERZIO
• Application: FOR STUDENT TRAINIG

  The Platform Pneumatic Training Platform has pneumatic components which can be used for the study of Pneumatics. There is a wide range of experiments which can be performed on the Platform.   ·         Function and identification of pneumatic components ·         All components fitted on aluminum profile stand & panel.   .

• Power Supply: AC 220 V
• Power Consumption: ≤0.3 kVA
• Dimensions: 500 mm x 300 mm x 140 mm
• Product Code: ELSHADDAI MECH - 001

• Country of Origin: India
• Shape: Rectangular
• Driven Type: Pneumatic
• Corrosion Resistance: Yes
• Operating Type: Semi Automatic

Is a fully equipped training system with all necessary components and aids to conduct a comprehensive training course in the fundamentals of Pneumatic controls. The didactic structure of the course is based on the long-established concept of training in hydraulic drive engineering. The central element of the unit is the large assembly panel. Here, two different circuits can be easily constructed using items from the kit of modern standard industrial components and connecting hoses. A special quick-clamping system ensures all components are securely attached. The component connections face outward to allow easy interconnection by means of quick-couplers. There is generous space for all the system components to be accommodated in drawers and cabinets

• Brand Name: ITC
• Material: ALMUNIUM
• Certification: CE Certified
• Color: Silver
• Finishing: Polished
• Power: Pneumatic
• Packaging Type: Carton Box
• Pressure: Low Pressure
• Warranty: 1 Year
• Country of Origin: India
• Corrosion Resistance: Yes
• Operating Type: Manual
• Cartridge Heater Voltage V: 220V
• 220 V: 220 V
• Pressure Gauge: 70 bar

The Pneumatic trainer kit is designed with capability to demonstrate the design, construction and application of pneumatic components and circuits. The kit is capable of demonstrating the following: Design and function of a Pneumatic system – Basic. Function and identification of Pneumatic components and their symbols. Direct and indirect manual controls, stroke dependent controls. Logic AND OR function with start stop signals. Functional diagrams. Sequence controls.

• Air Compressor Pressure Range :: 0 to 150 psi and 0 to 10 Kg/cm2
• Supply :: 230 V AC
• Motor Type :: Single Phase
• Motor Power :: 0.5 HP
• RPM :: 1440
• Tank capacity :: 5 Liters
• Single Acting Cylinder :: Stroke length of 54 mm
• Double Acting Cylinder :: Stroke length of 100 mm
• FRL Unit :: Operating Pressure 115 psi, Filter size 25 micron
• Solenoid Valves :: 3/2 type, Operating Pressure range (1.5 - 8 Kg /cm2), Operating voltage +24V DC
• Pressure Gauge :: Reads (0 - 150 psi and 0 - 10 Kg/ cm2)
• Manifold :: 8 ports

Simulation Mode, Software from IRAI France,Dynamic Ladder Diagram Updation,Complete Flexibility in PLC operation,Online Simulation of Pneumatic circuits,Online simulation and updation of PLC Programs,Completely controlled through computer software,Compatible with Siemens Allen Bradley Mitsubishi PLC,Aluminium Alloy mounting panel for quick mounting and dismounting,Pneumatic circuits can be designed in software and the same can be demonstrated on training kit.

electro pneumatic trainer kit, We also manufacture the equipments and control systems for sugar industries mainly mill automation, boiler instrumentation, prd stations and embibition water control system.

Nvis 3020 Pneumatic Training Platform explores students & industry professionals to the principles of pneumatics and compressed air devices. It tells, how components manage, command, direct or regulates pneumatically. All types of pneumatic controls are explained in the Platform. Nvis 3020 Pneumatic Training Platform has pneumatic components which can be used for the study of Pneumatics. There is a wide range of experiments which can be performed on the Platform.

• Hydraulic Hoses: 10nos
• Indicator: 24 VDC Operated.

Electro Hydraulic Circuit Trainer outlines the basic Principle of Hydraulic Control System, Hydraulic Control System Components & its applications using electronic proximity position sensor & electro-mechanical actuators (solenoid valves). • Relay Module: - 4 Relays, 24V DC supply, 2 NONC contacts, panel mounting type. • Single Acting Cylinder: - Bore: 40 mm, Stroke: 75mm100mm, Mounting: Foot. • Double Acting Cylinder: - Bore: 40 mm, Stroke: 75mm100mm, Mounting: Foot • Solenoid Valve: - 2 Nos, 43 way, ¼", 230VAC & 42 way, ¼", 230 VAC. • Meter-in Circuit & Meter Out Circuit

Advanced customized electro-pneumatic trainer kit is capable of being used to demonstrate the design, construction and application of electro-pneumatic components and circuits. The Kit is designed to satisfy following objectives: • Function & identification of Electro-pneumatic components & their symbols. • Direct and indirect manual controls, stroke dependant controls, time dependant   and pressure dependant  Controls with time delay, pressure sequence valves. • Design & function of an electro-pneumatic System. • Functional diagrams. • Logic AND/OR function to start signals. • Application and fault findings of Electro Pneumatic controls. • Pneumatic power section – Electric control section. • To empower students to design their own circuits. • The kit is modular and upgradeable. • Training Manuals provided for Operation with Ease. The components are capable of being mounted on an appropriate profile plate with grooves for secure and flexible positioning so that the components can be clamped firmly, quickly and safely through quick fix adaptors. Industrial components are used in the kit so that the students get hands on practical training in using industrial components. TECHNICAL SPECIFICATIONS 1] Profile Plates & Stand: The anodized Aluminium profile plate is the basis for training. All components fit securely & safely onto the profile plate with safe fixing arrangement. Grid Dimensions: 50mm, Size: 1000 ×700mm. 2] Shuttle Valve (OR): 1 No. : The Shuttle Valve is switched through to the output by applying compressed air to one of the inputs (OR) function. Design type is OR gate (shuttle valve). Pressure range: (1-10 Bar) 3] Dual Pressure Valve (AND): 1 No. : The dual-pressure Valve is switched through to the output by applying compressed air to both the inputs (AND) Function. Design type is AND Gate (Dual Pressure Valve).Pressure Range: (1-10 Bar) 4] One way flow Control Valve Assembly: 1 No. : - The One – way flow control valve is a combination of flow control valve & a non-return valve. The cross section of the restrictor can be set by means of a Knurled screw. Design type is combined flow control Valve. Pressure range – (0.5-10 Bar) 5] Pressure Sequence Valve assembly: 1 No.:- The pressure of the control signal can be set by means of the pressure setting screw (variable). Design type is Poppet Valve with return spring. Operating Pressure range – (1.8 – 8 bar). Control Pressure range - (1 – 8 bar). 6] Single Acting Cylinder: 1 No. : Design type is Piston Cylinder. Operating Pressure 10 bar. Stroke length – Max. 100mm. 7] Double Acting Cylinder: 1 No. : Design – Piston Cylinder. Operating Pressure – 10 bar Stroke Length – Maximum 100 mm 8] Manifold Assembly: 1 No. : - Manifold with 6 (2 ×3) Hex-Ball Valve. A common manifold for plastic tubing allows supply of compressed air to the control via six individual ports (for plastic tubing PUN 4×0.75) 9] Filter regulator with Gauge: Filter control valve with pressure gauge, gate valve, quick push-pull connectors & quick couplings mounted on a swivel support. The filter with water separator removes dirt, pipe sinter, rust & condensed water. The pressure control valve regulates the supply. Air pressure to the set operating pressure & compensates pressure fluctuations. The filter bowl has a condensate drain valve. The shutoff valve ventilates & vents entire control. Input pressure –Maximum (16 bar), Output pressure – Max 12 bar, grade of filtration– 40 mm approx., Connector – G 1/8 , / PU 4 10] Relay, Three fold: 2 No. : The device has three relays with terminals and two buses for power supply. Contact set – 4 change-over switches, Contact load – maximum 5 A., 11] Signal Input, Electrical: 1 No. : The device contains an illuminated push-button switch (control switch) & two illuminated push buttons (momentary contact switches) with terminals and two buses for power supply. Contact set – 2 makes, 2 breaks, and Contact load – maximum 1A. 12] Indicator & Distributor Unit, electrical –: 1 No. : The device contains an acoustic indicator and four lamps with terminals and three buses for power supply. Through-contact socket pairs per lamp allow the element to also be used as a Distributor. 13] Proximity switch with attachment: -2 No. : The Proximity switch consists of a sensor, the mounting kit and the cable. This proximity switch gives a signal when it detects a metal. The status is indicated by an LED. Switching Voltage – 24 VDC, Switching current – max. 200 mA, Switching Power – 6 W approx, switching accuracy - ±0.1mm 14] 3/2 Solenoid Valve, Single with LED,– 1No. : The status is indicated by an LED on the housing. The valve is equipped with a manual override. Pneumatic Technical data: Design type is spool valve, pilot controlled with return spring, Pressure range: 250-800 kPa (2.5-8 bar), Electrical Technical data: Power consumption – 1.5 W 15] 5/2 way single Solenoid Valve with LED: 1No. : The status is indicated by an LED on the housing. The valve is equipped with a manual override. Pneumatic Technical data: Design type is spool valve, pilot controlled with return spring, Pressure range: 250-800 KPa (2.5-8 bar), Electrical Technical data: Power consumption – 1.5 W 16] 5/2 Solenoid Valve, Double with LED: 1 No. : The statuses are indicated by LEDs on the housings. The valve is equipped with two manual overrides. Pneumatic Technical Data: Design-spool valve with pilot control, Pressure range – 150-800KPa (1.5-8 bar) Electrical Technical Data: Power Consumption – 1.5 W 17] Pneumatic – Electric convertor:-1 No.: The pneumatic – electric convertor can fulfil 3 functions: Pressure Switch, Vacuum Switch and Differential Pressure Switch. Pneumatic Technical Data: Pressure Ranges: Pressure Switch connector P1 - 0.25 – 3.5bar, Vacuum Switch- -0.2- -0.8 bar Differential Pressure Switch: Connectors P1….P2 - (-0.95 – 3.5 bar), Switching Current: - 400 mA. 18] Limit Switch, Left Actuated – 1 No. : The electrical limit switch comprises a mechanically operated micro switch. When the roller lever is pressed, for example, by control cam of a cylinder, the micro-switch is actuated. The circuit is closed or opened via the contacts. The micro-switch can be wired as a normally open or normally closed or changeover contact. Contact load: maximum 5A, switching frequency – maximum 200Hz, Reproducible accuracy – 0.2mm, Switch travel – 2.7 mm, Actuator force – 5N 19] Limit Switch, Right actuated – 1 No. : The electrical limit switch comprises a mechanically operated micro switch. When the roller lever is pressed, for example, by control cam of a cylinder, the micro-switch is actuated. The circuit is closed or opened via the contacts. The micro-switch can be wired as a normally open or normally closed or changeover contact. Contact load: maximum 5A, switching frequency – maximum 200Hz, Reproducible accuracy – 0.2mm, Switch travel – 2.7 mm, Actuator force – 5N 20] Equipment Tray – 1 No. : MS powder coated tray with slots for placing components to be supplied with Electro-pneumatic supplementary kit. 21] Power Supply Unit – 1 No.: Input Voltage - 230/115 V Ac (47-63 Hz.), Output Voltage – 24 V DC, short circuit proof, output current – Max. 4.5 A, Connection Cable – 3m 22] Plug in adapter: For mounting components with plug-in foot on the aluminium profile plate. 23] Quick Push-Pull connectors: Sufficient shall be supplied for branching of the tubing for making of the circuitry. 24] Plastic Tubing: PUN 4×0.75, Exterior Diameter-6mm, Interior Diameter- 4mm, Transparent – 10mtrs, Blue-10mtrs. 25] Set of moulded Cables: 1.5 Meter (2 core) ________________6 No. 1 Meter (3 core) _________________ 3 No. 300 mm Red: - 06 No. 300 mm Black: - 06 No. Range Of Experiments: Study of Advanced Electro – Pneumatic Trainer Study of various Pneumatic Components Study of Pneumatic & Electro-pneumatic Circuits Services Required: 230 V AC, 50 Hz Power Supply. Dry, Compressed, Clean Air supply at 4-5 Kg/Cm². Note: All descriptive matter and illustrations are intended to give only a general idea of the equipment. Detailed specifications may be altered at the company’s discretion without any notice.
