Position Transmitter Dealers

Bringing you top quality Position Transmitters manufactured using the superior grade material and the most advanced technology available. Our products are known for their durability and longer equipment life. We are one of the best known and trusted manufacturers, exporters and suppliers of Position Transmitter all over the country. These Position Transmitters can be ordered with us at competitive rates. Hassle free delivery options are available for bulk orders.

• Type: Wired
• Application: Tap Position Transmitter
• Surface Treatment: Polished
• Screen Size: 2.5 -3 inch
• Supply Voltage: 9-28V DC
• Input Signal: 0-30 Deg C

We are offering position transmitters which can be used to monitorcontrol the position of damper gate reclaimer position length of wire rope woundunwound by winch hoist position grab bucket opening etc. Position transmitter gives out 0- 10 volt4 – 20 ma current signal depending upon position of shaft. Digital pulses can also be provided. Position accuracy +- 0.1 %. It also provides two settable alarmsprovides potential free relay contacts. The position transmitters are manufactured in ip 65 protection class. Many of position transmitters are working in cement industry, crane industry, winch manufacturers and engineering industries.

The TZIDC represents the digital, intelligent positioner for communication via HART within the positioner family. Unmatched shock and vibration immunity of 10g up to 80 Hz distinguishes the TZIDC from other‘s and guarantee reliable operation in almost all areas under harshest environmental conditions.

Our company holds expertise in importing and supplying highly efficient SC/V Series Position Transmitter. Specifically designed to meet all the requirements of various industries, our SC/V Series Position Transmitter is suitable to be directly mounted on STI pneumatic or electro-pneumatic positioners. Compact in size, SC/V Series Position Transmitter facilitates easy installation and calibration. Moreover, SC/V Series Position Transmitter is greatly applauded for high precision and reliability. We offer transmitter in pneumatic and electronic potentiometric type models. Pneumatic type (mod. 85) Output 3 15 psi - supply 20 psi Ideal for installation in very hazardous areas Electronic potentiometric type (mod. 10031) Output 420 ma - supply 1933vdc Suitable for general purpose applications Electronic inductive type (mod 2020) Output 420ma - supply 1236vdc

We are offering Position Transmitter FEATURES : - Explosion proof and weather proof position transmitter - Accuracy 0.3% FS - Repeatability 0.2% FS - Hysterises 0.3% FS - Field adjustment available - Zero and span adjustable - 2 wire system - Spring loaded resistive feed back - Visual percentage indicator provided - NAMUR mounting dimensions.

• Accuracy: 0.3% FS
• Repeatability: 0.2% FS
• Hysteresis: 0.3% FS

Weather ProofExplosion ProofExplosion proof and weather proof position transmitter

Weather Proof Explosion Proof Explosion proof and weather proof position transmitter Accuracy 0.3% FS Repeatability 0.2% FS Hysteresis 0.3% FS

Position Transmitter: Cylinders : Miniature series (12 mm dia to 25 mm dia ) Cylinders : Standard series ( 32 mm dia to 160 mm dia) Cylinders : Heavy duty series ( 200 mm dia to 1100 mm dia ). Stokes upto 2000 mm available . Spool valves : 2 – way, 3 – way, 5 – way, Hand leaver, Push Button.

• Type: Automation System
• Brand Name: BENTLY NEVADA
• Type: THRUST POSITION TRANSMITTER
• Condition: USED
• MODEL: 1800/2
• PART NO: 1800/2-02-90-02-01

bently nevada thrust position transmitter 1800/2 part no: 1800/2-02-90-02-01 condition: used & working qty: 1 pc available  ref: mm.

• Weatherproof/ Flameproof: Auto calibration with stroke settings
• 21 freely configurable set points: Contactless
• LCD display – Current (mA) and Position (%): Push button on device
• ½” NPT (F) or M20: -20 °C to +60 °C (Standard) -40 C to +80 °C (On Request)
• 0.3% of full scale: 0.2% of full scale
• 0.3% of full scale: 0.2% of full scale
• 24V DC + / – 10% (Loop Feedback): Screw Terminal (standard), M8 socket 3/4 pin (M) (optional)
• 3.6 – 21mA: 0.35% / 10 °K
• < 0.3%: CE, directive EMC 89 / 336 / EEC Compatibility

• Feature: Accepts a wide supply voltage Range.
• rang: 0°-15° to 0°-90°

RMG-UPT-0501 is a 2 wire Position Transmitter, widely used to transmit the position of a Control Valve in a variety of process control applications. The Contactless Inductive Position Transmitter is a 24V DC operated 2Wire System, which accepts angular movements ranging from 0°-15° to 0°-90° and converts into a 4.00 to 20.00mA signal when suitable back lever and linkages are used. Minimal effect of ambient temperature variance on accuracy. Encapsulated electronics – to protect from moisture, vibration and tampering of the circuitry.

When using Auma actuators for regulating duty with demand of high accuracy, an inductive position transmitter can be fitted to give precise read out of position. The output signal is used as feed back to electronic positioner or for position indicator. The system consists of two parts, a linear variable differential transformer (LVDT) and an electronic unit. The smallest change of magnetic core in the measuring coil is transformed into proportional signal. The transmitter has no moving contacts. This device requires 24 V DC power supply regulated within + 15%. Auma power supply unit PS01 is recommended for this purpose. The linearity of the unit is less than 0.3%.

Weather ProofExplosion ProofExplosion proof and weather proof position transmitterAccuracy 0.3% FSRepeatability 0.2% FSHysteresis 0.3% FSField adjustment availa

• Brand: Marsh Make
• Accuracy: 0.2% +/- ,1 Digit F.S.R.
• Type: Wired
• Usage/Application: It is used for display purpose with Electrical actuator .
• Model Name/Number: PP503
• Voltage: 230 VAC-110 VAC ,50 Hz
• Operating Range: 0-100.0 %
• Screen Size: 96X96X125mm

Resistance transmitter of 100-235 (alternative values are also available) or a current transmitter with a unified signal of 4-20 mA. The maximum load resistance is 500 W. The supply voltage of the transmitter is 12 to 36 V D.C. Also available with non contact type position transmitter.

Today's modern process control systems need Position Transmitters and Limit Switches that deliver a high level of accurate position feedback. The infinite resolution potentiometer in the XFlo Position Transmitter senses the exact position of a valve coupled with a two-wire transmitter and sends a continuous 4-20mA signal to a remote indicating device. The XFlo Limit Switch Box houses two to four Micro-switches or Inductive Proximity Switches to indicate Open, Intermediate or Close position with redundant signal options. The Position Transmitter and Limit Switch Box can be combined in a XFlo PTLS2 box to provide accurate 4 – 20 mA feedback as well as two positions (Open, Intermediate or Close) via its two auxiliary switches. The Aluminium housing is compact and explosion proof, weather proof and dust proof.
