Advance Power Electronics Trainer Salient Features Each of following advance PE trainer may need a few set of associated panels (4 nos. typically) which are mounted in a light weight sturdy aluminum flat demo panel system. Facilitates easy and safe wiring by students due to 4mm sturdy shrouded banana patch cords and shrouded socket arrangement for high voltage circuits. Each panel has ABS molded plastic sturdy enclosure, and colorful screw less overlays showing circuit diagram & its connection tag numbers for easy understanding and connections. Set of Instructor Guide & Student Workbook. Mechanical specifications:1. Auminum rack: of 1* 4 matrix used as flat panel demo panel system to house 4 panels needed for the trainer ordered.2. Dimensions :500(H)*910(L)*300(D)mm

Objective      : To study Char. & applications of  Diac, Triac, UJT & SCR   Applications :           1.   Characteistics of   Diac                                      2.   Characteistics of   Triac                                      3.   Characteistics of  UJT                                       4.   Characteistics of  SCR                                      5.   Characteistics of  Diode                                      6.   Study of  UJT as  Relaxation Oscillator.                                      7.   Light Intensity control using SCR                                      8.   Light Intensity control using TRIAC                                      9.   Study of SCR Triggering Circuits.                Features       :  It has built in two dual dc regulated power supplies 0-5/15 volts and                                  0-20/40 volts dc., four analogue meters are provided on front panel                                  to measure the DC voltage and current,  AC supply of  0-17-34 V                                  volts are also provided, Electric bulb of 12 volts 18 watt., Load                                  resistance 100 ohms to 1000 ohms, Fixed resistance R1 = 1K W,                                    R2 = 2.2K W , R3 = 10K W  are provided for different uses,                                  Potentiometer of 22 K ohms are is provided for intensity control                                  applications.

• SCR Assembly :: 4 SCRs 2P4M, 400V/2A
• Frequency range :: 30Hz to 900Hz variable
• Amplitude :: 12V

Power Electronics Lab Scientech 2712 is a universal learning platform which is very useful for Students to understand the concept of power electronics. Students can perform experiments like VI characteristics of the power electronic devices, single phase controlled rectifiers, DCDC choppers etc. This Lab is provided with a bread board for testing their own circuits. Power Electronics Lab is provided with built-in AC & DC power supplies and exhaustive learning material.

• STANDARD ACCESSORIES: 1. Detailed Instruction Manual. 2. Set of Patch cords.

Power Electronics trainer is modular type circuits on glass epoxy PCB as front panel. The circuit layout is printed on the glass epoxy PCB with high quality printing. Test tags are provided to observe the waveforms and voltages. LED indicators are provided on each input and output of logic blocks to observe the instantaneous logic level. 2 mm holes test points ( multimeter cord compatible ) are provided at all the points where voltages has to be measured. Built in DC regulated power supply is provided making the kits suitable for operation at 230V AC. The trainer is housed in wooden cabinet with cover for safe keeping of trainer. Necessary connecting leads ( patch cords ), jumper link, detail operating & servicing manual with theory and waveform to be provided.

• Brand Name: Mechanics Optics & Digital Instruments Pvt. Ltd.
• Application: Laboratory
• Is It Portable: Portable
• Model: TK 14
• Condition: New
• Power Source: Electrical
• Warranty: 1 Year
• Feature: Durable

• Usage: Engineering Laboratory Trainer Kit, Laboratory
• Model: XPO-PE
• Features: DC Power Supply, AC Power Supply,

Salient Features   Each of following advance PE trainer may need a few set of associated panels (4 nos. typically) which are mounted in a light weight sturdy aluminum flat demo panel system. Facilitates easy and safe wiring by students due to 4mm sturdy shrouded banana patch cords and shrouded socket arrangement for high voltage circuits. Each panel has ABS molded plastic sturdy enclosure, and colorful screw less overlays showing circuit diagram & its connection tag numbers for easy understanding and connections. Set of Instructor Guide & Student Workbook.   Mechanical specifications: 1. Auminum rack: of 1* 4 matrix used as flat panel demo panel system to house 4 panels needed for the trainer ordered.2. Dimensions :500(H)*910(L)*300(D)mm

Our assurance towards providing damage-free products to the clients is achieved through our use of quality packing material. In addition, we maintain streamlined packaging system supervised by experts. Our procedures of payment are lawful, simple, and secure. We do not levy concealed charges while presenting the invoice and make sure payment is carried out securely from you to us.

Power Electronics Lab is used to perform power electronics circuit experiments. It is very useful in power electronics laboratories for performing power experiments in colleges and universities. It is very for student to know about the characteristics of power electronics devices and the applications of power devices. The applications or power devices are in alarm circuit, lamp flasher, rectifiers, choppers, inverters. It is also used for commutation circuits.

AnalogLinear IC Trainer Kit: Breadboard, 555, 741, 723, 565 & allied components Digital IC Trainer Kit: 16 pin, 20 pin, 28 pin, 40 pin ZIF sockets, Breadboards with 2mm sockets, 4mm terminals & BTI-15 terminals Decade Resistance Box-4, 5 & 6 dials with 1% and 3-5% tolerances Decade Inductance Box-4, 5 & 6 dials with 1% and 3-5% tolerances Decade Capacitance Box-4, 5 & 6 dials with 1% and 3-5% tolerances

features: trainer having control panel should provided in 40x40mm aluminum profile rack with sturdy table top flat panel. should have 3phase dol starter 4pole mcb, contractor & relay panel should have 3 phase multifunction meter panel . should have circuit breaker panel, switch panel, bus bar panel, fuse panel. should have industrial socket panel, analog voltmeter & ammeter panel. should have kwh meter 1 phase kwh meter, 3 phase kwh meter. should have lamp load panel. ..

• Type: Power Electronic Trainer
• Application: Electronic Lab Use
• Color: Blue, Grey, Light White, Metallic, Silver, White
• Voltage: 110V, 220V, 380V, 440V, 525V
• Condition: New, Old
• Power Type: AC, DC
• Operating Temperature: -25 +85deg C, -40 +70deg C, -45 +55deg C, -70 +40deg C
• Frequency: 50Hz, 60Hz
• Driven Type: Battery, Electric
• Feature: Dipped In Epoxy Resin, Durable, High Performance
• Warranty: 1Year, 2Years

Power electronics is the branch of electronics which deals in equipment integrated by switching circuits used to control both alternating and direct currents. This domain of electronics and electrical engineering is directly involved in research, design and implementation of non liner, time-varying, energy-processing electronic systems. The family of discrete components used in semiconductor switching devices in power electronics can be listed as diodes, transistors and thyristors (Silicon Controlled Rectifier (SCR), Gate Turn-Off Thyristors, Insulated Gate Bipolar Transistors (IGBT), Gate-Commutated Thyristors). Our power electronics lab equipment and training kits are specifically designed while keeping in mind all these pre-discussed basic components.

• Brand Name: UNICON
• Model Number: UI-404

We are offering power electronics trainer (pet) power electronics lab is used to perform power electronics circuit experiments. It is very useful in power electronics laboratories for performing power experiments in colleges and universities. It is very for student to know about the characteristics of power electronics devices and the applications of power devices. The applications or power devices are in alarm circuit, lamp flasher, rectifiers, choppers, inverters. It is also used for commutation circuits. Technical specifications dc power supply on board: â± 5v at 150ma : â± 15v at 150ma : 0-15v at 150ma : 0-25v at 150ma ac power supply on board : 18v - 0v - 18v at 150ma : 12v - 0v - 12v at 150ma ujt triggering circuit using scr (2 channel) on board digital firing circuit on board : with pwm control, firing angle control. Scr assembly : 4 scrs 2p4m, 600v,2a power devices : igbt-g4bc20s, mosfet-irf540, ujt-2n2646, diac-db3, triac-bt136, scr-tyn604, power transistor 2n3055 tip type and power diode 16a on board. Circuit components on board: capacitor 0.01uf, 0.047uf , 0.1uf, 0.33uf, 1uf63v(4nos.) 2.2uf50v diode 1n4007 (8nos.) zener diode 9v (1nos. ) inductors 10mh, (1nos.), 50mh (2nos.) load resistance 100e, 220e, 500e, 1k, 2k2, each 5w resistance on board 22e5w, 100e2w, 220e2w resistance on board(14w) 10k (3nos.), 22k, 47k diode on board: 1n4007 (4nos), zener 9v 1nos. Potentiometer 1k(1nos.), 10k(1nos.) pulse transformer on board : 2 nos. Is pt4503 1:1:1 power requirements: 220v â±10%, 50hz

Covers different power electronics devices i.e Thyristors, On-board passive and active components, External AC DC Power supply, On board variable DC SUPPLY.

Power Electronics trainer is modular type circuits on glass epoxy PCB as front panel. The circuit layout is printed on the glass epoxy PCB with high quality printing. Test tags are provided to observe the waveforms and voltages. LED indicators are provided on each input and output of logic blocks to observe the instantaneous logic level. 2 mm holes test points ( multimeter cord compatible ) are provided at all the points where voltages has to be measured. Built in DC regulated power supply is provided making the kits suitable for operation at 230V AC.
