Profile Projector Dealers

Presto’s Profile projector is a cost effective solution for angular measurements and for Digital linear. The machine also has a built-in DRO. The basic use of Profile Projector in PET & Preform Industry is to identify an edge or point of the shadow of the PET Bottles in order to measure the length of the PET or Preform from this particular point. By expanding the image via profile projector, the operator can easily decide that from where the edge or the point of the shadow starts.  Profile images are also used to take important decisions to fulfill various measurement purposes like it matches the size of the bottles with standard size to evaluate whether a part of the bottle is designed correctly or not.   FEATURES   The profile projector offers standard magnification of 10x. The diameter size of the screen is 300 mm Projector view of the field is 30 mm It provides a working distance of 65 mm X-Y Range of the profile projector is 50 x 50mm* (*with Use of Gauge Blocks) The measuring unit of the instrument is Micrometer Heads (0 – 25 mm Imported) It provides the resolution/ least count of 0.01 mm It offers a rotary measuring stage. The stage glass diameter is 70 mm The maximum height of Test piece can be 125 mm The projector provides Contour Illuminator type illumination of 24V/ 150W and Surface Illumination of 12V/ 100W, Halogen brightness adaptable via solid-state variable control bulge that operates on the power supply of 220V/ 50 Hz. The machine provides cooling with the help of in- built noiseless and vibration free fan motors. The instrument is incorporated with some furnished accessories like silicon cloth, Power supply cord-vinyl, cover-fuse bulbs and operating manual.

• Country of Origin: India
• Voltage: 110V
• Condition: New

Specification: Travel X-Y Movement:50x50mm(standard) Travel Z(Up and Down):25 mm (Under 10x) Travel Z(Up and Down):50mm (Under 20x50x$100x) Micrometers (50mm Dia):25mm(L.c 0.005) x-y Bed size : 150mm x 150mm Having both Countour (12v/100w) lamp and two surface (6v/20W)lamps

• Type: Horizontal profile projector
• Feature: High Performance, High Quality, Quality Assured, Reliability
• Voltage: 220V
• Condition: New
• Frequency: 50Hz
• Power: 750W
• Warranty: 1year
• Brand Name: Meera Metzer
• Country of Origin: India
• Product Name OPTRUE 300: Magnification 10x. 20x. 50x
• Travel 300x150mm: Least count 1 micron

• Applications: Plastic Manufacturing, Metal Manufacturing, Cracks & Failure Analysis
•  Key Features: Large Stage Mountable ,Adjustable Base Feet ,Erect Images ,Projection Lenses on a Turrent ,Built in Projector ,360 degree Swiveling Screen ,Multiple scrren size available ,Four Step Zooming Condenser Lens-
• Maximum Load Capacity: 20.00/22.00 Kilograms
• Power Source: 110 VAC (50/60HZ) ; 220VAC (50/60HZ)
• Lenses: 5X, 10X (Standard), 20X, 25X, 50X, 100X, 200X
• Software: Compatible With Metrologik 2D, CAD Transfer Compatible
• Screen Size: 400mm/600mm Standard, Customization available on request
• Accuracy: +-0.1% in contour illumination, +-0.15% in surface illumination
• Motorized Traverse: Optional
• Digital Read-Out: Optional
• Linear Encoders: Resolution 0.001mm/0.005mm/0.0005mm Options Available with DRO
• Lens Axis: Horizontal/Vertical

• Type: TABLE TYPE PP
• Application: DEFENCE,AUTOMOBILE,PLASTIC,RUBBER,DIE MAKING INDUSTRIES
• Feature: High Performance, Low Maintenance
• Voltage: 220V
• Condition: New
• Display Type: LED
• Frequency: 50Hz
• Power: 100W
• Brightness: 0-2000Lms
• Warranty: 1year
• Aspect Ratio: 4:3
• lamp life: 200-400Days
• Brand Name: BUOYANT TECH ENGINEERS
• Country of Origin: India

• Country of Origin: India
• Brand Name: Dynascan
• Resolution: 0.001 Mm
• Focusing: 100mm
• Accuracy: 0.05% on Profile & Surface
• Profile Lamp: One,250 W,24 V
• Surface Lamp: Two,250 W,24 V
• Mass: 800 Kg approx

Customers should stay rest assured with us for the payment procedures. They can pay us conveniently through wide-ranging payment mediums. Available with us in different grades and specifications, our products stand high on the counts of quality. Details : VPP 41 0/510/610 have vertical illumination system. Cooling fan provided to avoid overheating. Screen diameterfrom 400mm to 600mm. Lens magnification range from 10x, 20x, 25x, 50x, 100x. Useful forchecking parts between centre. Heavy parts can be placed on work-stage easily. Erect unreversed image, movement of the specimen corresponds.

Only under the strict supervision and management of our team members, we make certain that the products are packed as per the set standards; by this we are capable of delivering the range safely. If you are seeking high quality products in Bangalore(India), then ours is the name to reckon with.   Product features : 16"(400mm) Vertical screen for optimum viewing Erect profile image with surface reflection image High resolution ground glass screen with 90 degree cross lines Electronic rotary screen protractor with selectable 1 minute or 1/100 of a degree resolution Coated telecentric parfocal optics Superlative Surface Illumination Nickel plated, completely cast iron work stage Solid crossed roller stage system Medium Duty Milling Machine type Work Stage of 450mm X 180mm, with Helix Angle Tilt / Setting of 20 Degree (+/-) 320mm X Axis travel with glide release 150mm Y Axis travel (UP & DOWN) 110 lbs. Capacity Contour Illumination-150W, 24V with Fan cooled system Surface Illumination-150W, 24V 2 nos. with Fan cooled system Available with external edge sensing Standard swing away lamp house arm Optional motorized Work stage and Computer controlled Readout Systems 10X Lens system included NIST / NABL traceable calibration certificate 1 Year warranty Technical description : Light Path  -  Horizontal Ground Glass Screen with cross-lines  -  Dia400mm Rotating range  -  0-360diameter Rotating angle scale  -  1' Accuracy of X,Y Coordinate  -  (3+L/55)um Magnifications - Standard, Coated Telecentric Lens -  10x mounted on indexing turret designed for 3 Optics Optional Coated Telecentric Lenses  -  20x, 25x,50x,100x Work Stage Size (mm)  -  450X180 Measuring range (mm)  -  320 X 150 Linear scale resolution Standard  -  0.001mm/.00005 Z axis (Focusing)  -  Manual; Optional  -  Motorized Contour Illumination Accuracy  -  < 0.05% on screen Surface Illumination Accuracy  -  < 0.075% on screen Illumination System  -  Dual Beam Split Light source with Light Control Intensifiers system to adjust bright surface Illumination Contrast for clear and sharp display on Screen, All bulbs are individually fan cooled for minimum heat Standard Measuring System  -  Digital Read Out to measure X, Y, Angle and Radius Optional Advance Measuring System  -  Metronics USA Quadrachek 221 Micro Processor Data Processor.

• Type: Portable Projector
• Feature: High Performance, High Quality, Low Maintenance, Quality Assured, Reliability
• Voltage: 110V, 220V
• Condition: New
• Display Type: DLP, LED
• Frequency: 50Hz
• Power: Based on Discussion
• lamp life: Based on Discussion

Profile Projector: The Baty SM20 is a vertical light path floor standing profile projector with a 500mm / 20″ screen which features a large heavy duty high precision work stage with 250mm x 125mm measuring range and a 0.5 micron resolution. To know more about the product visit

• Country of Origin: India
• Type: Profile Projector
• Application: QC, Inspection
• Feature: High Performance, High Quality, Low Maintenance, Quality Assured, Reliability
• Voltage: 220V
• Display Type: Industrial Optical Profile Projector
• Frequency: 50Hz
• Power: 200W
• Brightness: NA
• Resolution: NA
• Warranty: 1year
• Aspect Ratio: NA
• lamp life: NA
• Connectivity Type: NA
• Basic Input: NA
• Brand Name: Opel
• Color Programming: NA
• Color: White, Blue
• Product: Profile Projector

• Type: VIDEO PROFILE PROJECTOR
• Brand Name: OPTOMECH
• Model Number: VPPMAZ2515

Precision X Y stage movement on cross roller guides with screwless drive. High resolution CCD Camera. Motorized zoom Lens with magnification upto 120x. LED profile illumination system. 4 Quad LED surface illumination system. Programmable LED surface and profile illumination system. Z axis with autofocus detection facility. Latest configuration computer with monitor. Advanced metrology software with user friendly graphical user interface. Equipment is capable of: a. Generating and storing imaginary points such as centre of a circlearc and intersection of two lines. b. Finding the distance between two imaginary points like the center distance between two circles, within an accuracy of 5 microns. c. Create components drawing, using the measured coordinates and store in .Dxf d. 3D non-contact measurement by auto focus. e. 3D measurement with touch probe option SPECIFICATIONS : S.No Description VPPMAZ2515 1.0 Structure Granite base and column 2.0 X Y Work Stage Manual 2.1 Size of top plate(mm) 420 x 250 2.2 Traverse: X & Y axis(mm) 250 x 150 2.3 Load capacity 25 Kg 3.0 Z axis Travel(mm) Motorized with auto focus 150 4.0 Video System 4.1 Lens High resolution motorized automatic telecentric zoom lens 4.2 Magnification range Optical magnification 0.7 to 4.5x, Can do measurement at 20x to 140x 5.0 Illumination System 5.1 Profile LED profile illumination, software controlled 5.2 Surface LED ring light, PC controlled 6 ring 8 zone light 6.0 Measurement System 6.1 Linear measurement X Y Z axis Linear encoders 0.1 u least count 6.2 Measurement software 3D geometric measurement software with programming and autofocus 7.0 SPC Advanced SPC software in built 8.0 Measuring Accuracy (2.5 + L100) u 9.0 Computer Latest computer with 19" LCD monitor, Windows 7 OS

Floor Model Horizontal Profile Projector that we manufacture, export and supply is widely in demand amongst buyers. Our Floor Model Horizontal Profile Projector is fabricated as per the international standards. We make it available in the screen diameter of 50/60/80/100 cm. The rotating range of our Floor Model Horizontal Profile Projector is 0-360 Degrees. Our Floor Model Horizontal Profile Projector is widely in demand owing to its accuracy, easy usage and longer operational life. Angular Measurements : Digital angular protractor with 0.01 degree L.C.

It is a compact model (Bench Type) profile projector suitable for all types of measurements and inspections at industries and engineering colleges. Antiglare hard glass Screen 200mm DIA with cross rotatable through 360 degree with least count 1 minutes an arc. Provided with X-Y movement of 120mm x 120mm measuring stage, travel 50 x 50 mm with the elp of a slip gauge, equipped with zero adjustment Micrometers of 25mm graduation having least count 0.001 mm. Supplied with high resolution 10x objective as standard and 20x or 50x or 100x as optional at extra cost. Equipped with built in counter illumination of 24 V 150 W halogen lamp and surface illumination system is a set of two halogen lamps (6V/20W) with a clamping device.

Model 300TE Screen Glass screen - Glass screen Ø 400mm with crosslines   Magnification 5x,10x,20x,50x,100x Telecentric Lenses   Workstage Size of Top Plate - 350mm x 210mm Measuring Traverse - X:200mm, Y: 100mm Working Area - 205mm x 105mm Load Capacity - 20 kgs Max Diameter - 150mm Digital Measuring Systems Linear - 3 axis DRO with Linear Encoders 0.005mm LC Angular - 360º rotary encoder LC of 1' of an arc. With digital display Tungsten Halogen lamps Illumination Systems Profile - 24V, 150W Surface Illumination - 24V, 150W - 2 Nos Weight 100 kg ( Unpacked)   Dim (LxWxH) 700 x 480 x 1025

• Screen: 200mm. fine ground screen with cross line
• Brand: Metzer
• Magnification: 10x.
• Magnification Accuracy: ± 0.1% for contour and ± 0.15% for surface
• Surface Illumination: 12V – 50W Halogen lamp with reflector
• Power Supply: 220 / 240V AC., 50 / 60Hz., Fuse 5A
• Cooling System: Built in noiseless and vibration free blower for powerful cooling system

For accurate magnification, maximum luminosity, great contrast, uniform resolution to the edge of the screen, freedom from distortion of the images. It is supplied with standard lenses with magnification 25x and 50x for contour projection. The maximum visible part of the object on the screen are 11.2mm and 5.6mm respectively. The screen size is 330mmx380mm (13"x15"). The maximum diameter and length of work accommodated on the stage are 40mm x 150mm respectively. It is having wooden storing cabinet with lock and key for safe custody of lenses etc. The height and weight of the instrument is approximately 1448mm (4'-9") and 68 kg respectively optional available magnification 10x.
