Projection Microscope Dealers

• Country of Origin: India
• Application: Forensic Lab, Science Lab
• Weight: 1-3kg
• Feature: Durable, Easy To Use, Good Griping
• Voltage: 110V
• Condition: New
• Eyepieces: WF10X
• Focus: 2-4mmRevolution
• Vision Angle: 0-5Degree
• Magnification Range: 50- 250X

• Packaging Type: plywood box

Microscope Body is heavy duty, inclined monocular type with sturdy base. Equipped with Coarse & Fine Focusing systems with Quadruple revolving Nose Piece. Plain stage (120x120mm) with graduated Mechanical Stage for X-Y movements of specimen slide. Built in light by 6V-20W halogen lamp with continuously variable light intensity control. The whole system of condenser & light arrangement is moveable up & down by rack & pinion to get the optimum results. Projection Doom of screen size 150 mm is Rotatable through 360°. Objectives: Achromatic 10x & 20x/40x (SL) Projection Eye Piece: 10x (Huy) Packed in a thick and attractive plywood box.

• Condition: New
• Power Source: Electric
• Usage: Household, industrial, Laboratory
• Material: Steel
• Finish: Polished

Projection Microscope use to check Spinneret holes measurement or any object to be measure accurately on projection screen. Range: 10x lense Focus: Adjustable Lights: Yellow Lower Supply: 240 Volt AC Supply Total Size: 520 mm (L) x 350 mm (W) x 700 mm (H) Weight: 45 Kg Dispatch Time :

• Color: White
• Brand Name: Radical
• Name: Projection Microscope

Projection Microscope PRM-18TP A most advanced and latest model of projection microscope, permitting accurate measurement of microstructures, incorporating trinocular head with switch cover system, facilitating observation of the specimen through trinocular head as well as on the screen. The instrument is equipped with quadruple revolving nose-piece, approximate 200 mm dia graduated screen rotatable on ball bearing system through 360°, best quality built-in solid state variable light control transformer, electronic fuse system, loop & arrow arrangements and built-in compensating eyepiece connected with magnification correction knob to provide magnification from 125x to 1000x. On screen. Supplied with stage micrometer, halogen lamp, fuse & maintenance kit. With following optical combination in a card board box. objectives : 5x, 10x, 20x & 40x.

• Application: Forensic Lab, Science Lab

We are offering projection microscope. Specially design for sugar factories for measuring the size of sugar crystal. From : 0.2mm to .001mm supplied with calculation chart. Salient features screen : antiglare hard glass 200mm dia screen. Focusing mechanism : coarse motion nose piece : a reverse type nose piece running on ball bearing balls ensures smooths motion. Objective : objective 5x, 10x, 40x, 60x imported hard control & anti fungal treatment lenses. Mechanical stage : co-axial mechanical stage. Light source : 12v 100watt halogen bulb with solid state variable light control.

Our projection microscope has heavy duty body, coarse & fine focusing system &triple revolving nosepiece. A plain stage 1 20x1 20mm with two spring clips to hold the slide can be provided with attachable graduated mechanical stage (optional accessories) For the clear observation of slides, a 150mm diameter screen attached to the microscope tube.

• Brand Name: Paramount
• Certification: ISO 9001:2008 Certified
• Color: Blue and Grey
• Condition: New
• Warranty: Lifetime Buyback Warranty
• Country of Origin: India

PROJECTINO is a latest model Polarizing Projection Microscope which is extremely useful for Textile laboratories for analysis of textile fibre & yarns. Special Polarized light increases the clarity & sharpness of the specimen. Paramount Projectino i9™ is a specially designed Polarizing Projection Microscope with Polarized light effects to increase the clarity & sharpness of the specimen. Four objectives of different resolutions are provided to change the power of magnification according to the requirement. Wide screen to project the magnified sample for proper viewing & flawless analysis. The screen has a scale graduated on it for the measurement of fibre length & dia .Specially designed mechanical stage is provided for mounting the sample, which can be moved Up, Down, Forward & Backward. Light intensity controller knob is provided to adjust the light intensity. Fine & coarse focus adjustment knob helps in focusing the sample easily. The unit is meticulously finished in cream paint.

• Condenser: A High Quality Glass Condenser in Front of Screen
• Mechanical Tube: Length 160mm
• Optics: Eyepieces: 10x Huygenian
• Objective Achromatic: 5x, 10x, and 40, Spring Loaded
• Nose Piece: Triple Revolving Nose Piece
• Transformer: Workable by 12 v 21 Watts, Built in the base
• Mechanical Stage: Brass

The microscope is most suitable for group discussion as well as for teaching .  Screen: Grainless Optical true 150mm outer circular dome, 360º rotatable for mounting on microscope  Condenser: A high quality glass condenser in front of screen  Mechanical Tube: Length 160mm  Optics: Eyepieces: 10x Huygenian  Objective Achromatic : 5x, 10x, and 40, spring loaded  Nose Piece: Triple revolving nose piece.  Movement : Coarse motion through rack and pinion with precise and accurate fine movement. Fixed square stage 102 x 102 mm.  Transformer: Workable by 12 v 21 Watts, Built in the base.  Mechanical Stage:  Brass  Lamp Assembly: Fixed lamp, built in base of high illumination with high power condenser and screen it will work as micro view projector. With lamp, transformer, but without it work as microscope. The viewing of biological microscope slide is distinct and enlarged. Sharp, clear and evenly illuminated image in full colours, visible to the whole class free of distortion.    Spare for above:   Lamp 12 Volts 21 watts Graduated Mechanical Stage.

We are offering laboratory microscope.

• Objective: 5x, 10x & 45x
• Brand Name: Radicon
• Magnification: 50x – 450x
• Focusing: Focusing by rack and pinion Mechanism
• Stage: Fixed square stage size 120 x 120 mm. with co-axial graduated Mechanical stage for X & Y movements u
• Doom Screen: 8 Inch dia Doom Projection Screen.
• Illumination: The Illuminator Incorporated 3w Led / 6v-20w Halogen Bulb Has Adjustable Brightness
• Model: RPM - 58

Stage: Fixed square stage size 120 x 120 mm. with co-axial graduated Mechanical stage for X & Y movements up to 55mm to 75mm.

The Projection Microscopes that we offer have an excellent design that enables accurate and clear results. these projection microscopes that we offer are easy to use and light in weight. our range of projection microscopes has made us a favored name in the market. the microscopes are used in several applications. used in schools laboratories medical institutions salient features screen : antiglare hard glass 200mm dia screen focusing mechanism : coarse motionnose piece : a reverse type nose piece running on ball bearing balls ensures smooths motion objective : objective 5x, 10x, 40x, 60x imported hard control & anti fungal treatment lenses mechanical stage : co-axial mechanical stage light source : 12v 100watt halogen bulb with solid state variable light control.

We provide to the esteemed clients precisely engineered Projection Microscope, which is at par with international quality accepted standards. These Projection Microscopes find wide application in research labs and college and school laboratories. Our Projection Microscopes are categorized by various special features like portability, light in weight and for providing eye comfort to the user. TECHNICAL SPECIFICATIONSObservation Body : Monocular Fixed Straight Tube, length 160mmNosepiece : Triple revolving nosepiece with accurate centering and positive click stopsStage : Mechanical stage of 135x120mm. Low co-axial drive controls for X-Y movement and cross movement 50X75mm, fully graduated vernier scaleIllumination : 20W halogen lamp, 220/110Volts. Lamp slots provided for natural cooling of the illuminatorObjectives : Achromatic 4X - 10X- 40XSLEyepieces : Huygenian 10X and 15XScreen : 150mm diameter Glass Projection Screen is provided can be rotated over 360-degrees on Microscope tube

• Body: Monocular fixed straight tube (Length – 160mm)
• Stage: 110 x 110mm square stage is provided with stage clips to hold the slide (optional Mechanical Stage).
• Illumination: LED Lamp
• Objectives: Achromatic 4x, 10x & 40x
• Eyepiece: Hyugenian 10x
• Packing: Securely packed in Cardboard & Styrofoam box.

Body Monocular Fixed Straight Tube, length 160mm. Nosepiece Triple revolving nosepiece with accurate centering and positiveclick stops Stage Detachable Mechanical stage for X-Y cross movement 50X75mm, fullygraduated vernier scale. Illumination 20W halogen lamp, 220/110Volts. Lamp slots provided for naturalcooling of the illuminator. Objectives Achromatic 4X - 10X- 40XSL. Eyepieces Huygenian 10X and 15X Screen 150mm diameter Glass Projection Screen is provided, can be rotatedover 360-degrees on Microscope tube. Model PRM-11 All specifications are as per PRM-11A but has only 2 Objectives10X & 40X. Screen size 100mm and without mechanical stage.

• Brand Name: ALPHA CHEM
• Model Number: ALPHA CHEM-1025

Advance projection microscope : this microscope is very useful for routine observation and complex type measurements of specimen magnified on screen, group observations, discussions and teaching. Specifications:- equipped with a 195 mm diameter special material graduated screen built-in base illuminator & diaphragm which is directed to the condenser which again is reflected through a mirror to the objective and compensating eyepiece for projection on to the screen again by a reflector graduated mechanical stage is also provided on the large stage for backward and forward movements within 30mm& 40mm scales read by verniers to 0.1mm screen-head is rotatable through 360o with cross scales vertically and horizontally within 140mm a quadruple nose-piece carries has four objectives : 5x, 10x, 20x & 40x giving magnification from 125x to 1000x. A: magnification from 125x to 1500x. B : incorporated with binocular head. C : screen of 150 mm diameter.

• Material: Metal
• Color: Blue

150mm Dia screen Projection Microscope. Objectives: 10x, 20x. Eyepiece: 10x. Magnification: 100x - 200x Plain stage with slide holding clips. Rack  Pinion coarse focus. 12V Halogen projection bulb.

Magnification            :    125x - 1000x. Stand                             :    compact dust proof in construction. Projection screen    :    195mm dia graduated screen rotatable 360°. Focussing                    :    focusable condenser with rack & pinion is fitted under the stage and fine focusing                                               knobs placed separately in convenient position. Stage                             :    co - axial mechanical stage is attached for comfortable and convenient manipulation. Illumination               :    12v - 100w super bright halogen lamp controlled by variable solid state arrangements. Objectives                  :    5x, 10x, 20x & 45x.   metz 402 all specification same 401 but microscope equipped with binocular head.

• Brand Name: Amesys India,amesys india,amesys india
• Driven Type: Battery, Electricity
• Color: White,white,white
• Condition: New
• Power: 100W
• Application: Science Lab
• Size: 150mmx200mm
• Feature: Durable, Good Griping
• Voltage: 110V
• Packaging Type: AMESYS INDIA
• Portable Style: Portable
• Type: Projection Microscope,Projection Microscope,Projection Microscope
• Weight: 1-3kg
• Warranty: 1yrs
• Country of Origin: India
• Eyepieces: WF10X
• Focus: 0-2mm/Revolution
• Objective: M10x
• Magnification Changer: Positive Precision Click Stops
• Vision Angle: 0-5Degree
• Magnification Range: 50- 250X
• Battery Backup: 4-6hr/1 Time Charging
• Warranty: 1year
• Warranty: 1year
• Country of Origin: made in india

• Objective: 4x, 10x & 40x
• Eye Piece: H10x & H15X

A group of students, can observe the specimens in one time through a 150mm Diameter Projection screen / doom, which is fixed on a microscope head with the following specifications:Simple type Microscope body fixed on a base,- having coarse and fine focusing system,- Triple revolving nose pice,- Fixed square stage size 120 x 120 with mechanical stage for X & Y movement of slide.- With attachable lamp having 220V-15W tungston lamp mains operated.- duly packed in wooden cabinet with the following optical combination: Optional Accessories: a) Microscope with attchable illumination system.b) Microscope with Built in Illumination system.

• Application: Forensic Lab
• Weight: 1-3kg
• Color: White
• Voltage: 110V
• Driven Type: Battery, Electricity
• Feature: Contemporary Styling, Easy To Use
• Warranty: 12 Months
• Objective: M10x, M20x, M40x
• Portable Style: Portable

With screen diameter 195m, graduated 360o, rotateable screen, solid state intensity control system, mechanical stage, objectives 5x, 10x, 20x, 40x, or 60x magnification 125x to 1000x complete in cardboard box.

We are a leading manufacturer and supplier of Projection Microscope based in Ambala, Haryana, India. We supply this Projection Microscope to colleges and different types of research laboratories. This Projection Microscope is especially designed with good focusing range. For packaging we use shock absorbing material which is suitable for various mode of transport. We are also capable of handling bulk orders with an assured delivery within stipulated time.

• Type: Junior Projection
• Application: Science Lab
• Voltage: 220V
• Driven Type: Electric
• Warranty: 1 Year
• Eyepieces: 10X & 15X
• Objective: 10X & 45X
