Radiographic Testing Services

RT (Radiographic Testing) Industrial radiography is used for a variety of applications but is commonly performed using two different sources of radiation, X-Ray and Gamma ray sources. The choice of radiation sources and their strength depends on a variety of factors including size of the component and the material thickness. Within the broad group of X-Ray and Gamma ray sources are a variety of camera choices with varying radiation strengths. CR Services X-Ray capabilities run the gamut from 4 MEV units utilized to radiograph extremely large and thick castings and forgings, to portable X-Ray cameras used for field weld applications and thin wall material inspection. Gamma sources vary from very low level fluoroscopic units to perform real time corrosion under insulation surveys, to Iridium (Ir192) and Selenium (Se 75) sources used for a variety of weld inspections, to Cobalt (Co 60) inspections for thick component testing. There are many advantages to radiography including: inspection of a wide variety of material types with varying density, ability to inspect assembled components, minimum surface preparation required, sensitivity to changes in thickness corrosion, voids, cracks and material density changes, the ability to detect both surface and subsurface defects and the ability to provide a permanent record of the inspection. The disadvantages of radiography are: safety precautions are required for the safe use of radiation, access to both sides of the specimen are required, orientation of the sample is critical, and determining flaw depth is impossible without additional angled exposures. Radiographic testing is used extensively on castings and weldments. Radiography is well suited to the testing of semiconductor devices for cracks, broken wires, unsoldered connections, foreign material and misplaced components. Sensitivity of radiography to various types of flaws depends on many factors, including type of material, type of flaw and product form.

Being a prominent firm in this domain, we are engaged in offering Radiography Testing Services.Offered service is performed under the strict supervision of our experts using optimum grade tools and latest technology. Our professionals perform this service as per the requirements of our clients. Moreover, this service can be availed by our clients at most reasonable price.

• RT: 100

this ndt method involves the use of penetrating x or gamma radiation to examine parts and products for imperfections. An x-ray machine or radioactive isotope is used as a source of radiation. Radiation is directed through a part and onto film. When the film is developed, a shadowgraph is obtained that shows the internal soundness of a part. Possible imperfections show up as density changes in the film. Radiography testing

Industrial radiography is the use of ionizing radiation to view objects in a way that cannot be seen otherwise. It is not to be confused with the use of ionizing radiation to change or modify objects; radiography's purpose is strictly viewing. Industrial radiography has grown out of engineering, and is a major element of nondestructive testing. It is a method of inspecting materials for hidden flaws by using the ability of short X-rays and gamma rays to penetrate various materials. Two ways to inspect materials for flaws is to utilize X-ray computed tomography or Industrial computed tomography scanning.

Radiographic Testing (RT) is a method of non-destructive testing where many types of manufactured components can be examined to verify the internal structure and integrity of the specimen. Industrial Radiography can be performed utilizing either X-rays or gamma rays. Both are forms of electromagnetic radiation. The difference between various forms of electromagnetic energy is related to the wavelength. X and gamma rays have the shortest wavelength and this property leads to the ability to penetrate, travel through, and exit various materials such as carbon steel and other metals.

• Testing Type: Cracks & Internal Flaws
• Test Location: Customer Place, Laboratory
• Testing Result Duration: 6 to 12 Hours
• Testimonials Format: Hardcopy
• Standard Certification Required: No
• Usage/Application: Manufacturer
• Process Type: Casting, Forging, Welding

abhishek technical services, approvced by barc for industrial radiography testing. we are pinnor servise provider in maharasgtra . we serve in boiler radiography , pipeline testing , tank testing , casting valaves

Radiographic testing can detect internal discontinuities such as voids, porosity, inclusions and cracks in piping & structural weldments , pipeline weldments , castings, valves & tubes in a wide range of materials, sizes and shapes. The interpretation of radiographic film of welds requires knowledge of not only welding and welding discontinuities, but also the exercise of good judgment as to whether the discontinuities are actually defects. Radiography technicians have extensive experience in film interpretation at both asnt level ii, asnt level iii benefits at a view: inspection of a wide variety of material types with varying density ability to inspect assembled components minimum surface preparation required sensitivity to changes in thickness corrosion voids cracks and material density changes the ability to detect both surface and subsurface defects and the ability to provide a permanent record of the inspection. Metus ndt services provide complete radiographic services for field applications. The trained certified inspector is able to read and grade the films and then determine if parts are acceptable or rejectable.

Industrial radiography is used for a variety of applications but is commonly performed using two different sources of radiation, X-Ray and Gamma ray sources. The choice of radiation sources and their strength depends on a variety of factors including size of the component and the material thickness. Within the broad group of X-Ray and Gamma ray sources are a variety of camera choices with varying radiation strengths.
