Rebound Hammer Dealers

Concrete rebound Schmidt hammer (sclerometer) – is a device for strength testing of concrete and other building materials. The most common in the world instrument for measuring the strength of concrete is the Schmidt Hammer. The device is called by the name of the engineer Ernst Schmidt, who invented the construction of the sclerometer.The method of strength testing of concrete with using the Schmidt hammer is based on the impacting the striker on the concrete surface with predetermined (normed) impacting energy and after measuring the height of the striker rebounding. The height of the striker rebounding will be proportional to the strength of concrete. The strength of concrete is determined by the calibration charts which is supplied with the instrument. Concrete Rebound Schmidt Hammer NOVOTEST SH is very ease in operation, has good reliability of design and high measurement accuracy, so that this method is the most common method of measuring the strength of concrete in the world. The strength testing with the Schmidt hammer is correspond with ASTM C 805; ASTM D 5873 (for rock); DIN 1048, p. 2; ENV 206; EN 12 504-2; ISO / DIS 8045. There are several versions of the measuring methods, which are different in impacting energy. The most “powerful” Schmidt hammer is designed to measure the strength of concrete with a thickness of 70-100mm and more, also for the strength testing of massive rocks with impact energy – 2,207J (Nm). This is the base and the most common model of Schmidt hammer, about 90% of the Schmidt hammers in the world have the same impact energy. Average “powerful” Schmidt hammer has the 735J (735 Nm) impacting energy. The impact energy is reduced threefold in compared with the base model. The main application of this instrument is measuring the strength of bricks and concrete products with a wall thickness less than 100 mm and small sizes of sample, also it used for testing the less strength stones and rocks. The least “powerful” Schmidt hammer has 196J (196Nm) impact energy. The main purpose is the strength testing the mortar of brick masonry.  Depending on requerments tasks user always need to select the correct model of Schmidt hammer. All models, independently of impact energy, are devices for non-destructive testing, so that they are not destroying the object of testing. To verify the accuracy of Schmidt hammer, is used a special calibrated anvil. Correctly functioning instrument have to display the certain value when it testing the standard anvil.Advantages Concrete Rebound Schmidt Hammer NOVOTEST SH has 3 modifications with different impacting energy, so that user can test all kinds of concrete and other building materials.

• Brand Name: TEI
• Application: Concrete testing
• Application: Concrete Test
• Rede: Blue

Rebound Hammer TestRebound hammer test is done to find out the compressive strength of concrete by using rebound hammer as per IS: 13311 (Part 2) - 1992. The underlying principle of the rebound hammer test is : The rebound of an elastic mass dRebound hammer test is done to find out the compressive strength of concrete by using rebound hammer as per IS: 13311 (Part 2) - 1992. The underlying principle of the rebound hammer test  Concrete Rebound Hammer Manufacture in Tamilnadu,  Concrete Rebound HammerManufacture in Chennai, Concrete Rebound HammerManufacture in Kanchipuram,  Concrete Rebound HammerManufacture in Tiruvallur, Concrete Rebound HammerManufacture in Cuddalore, Concrete Rebound HammerManufacture in  Villupuram, Concrete Rebound HammerManufacture in Vellore,  Concrete Rebound HammerManufacture in Tiruvannamalai, Concrete Rebound HammerManufacture in Salem,  Concrete Rebound HammerManufacture in Namakkal, Concrete Rebound HammerManufacture in Dharmapuri, Concrete Rebound HammerManufacture in Erode, Concrete Rebound HammerManufacture in Coimbatore, Concrete Rebound HammerManufacture in The Nilgiris, Concrete Rebound HammerManufacture in Thanjavur, Concrete Rebound HammerManufacture in Nagapattinam, Concrete Rebound HammerManufacture in Tiruvarur,  Concrete Rebound HammerManufacture in Tiruchirappalli, Concrete Rebound HammerManufacture in Karur, Concrete Rebound HammerManufacture in Perambalur, Concrete Rebound HammerManufacture in Pudukkottai, Concrete Rebound HammerManufacture in Madurai, Concrete Rebound HammerManufacture in Theni, Concrete Rebound HammerManufacture in Dindigul, Concrete Rebound HammerManufacture in Ramanathapuram, Concrete Rebound HammerManufacture in Virudhunagar,

• Features: Concrete Rebound Schmidt Hammer NOVOTEST SH has 3 modifications with different impacting energy, so that user can test all kinds of concrete and other building materials
• Measurement accuracy, %: 10
• Hardness value of impact plunger working surface, HRC, no less: 60
• Surface roughness of testing object, Ra um, no worse: 40
• Radius of impact plunger, mm: 25
• Operating temperature range, oC: -20 … +50
• Weight of the device, kg, no more: 1
• Gross weight of package, kg: 1.7

• Brand Name: Geo Star
• Application: Construction
• Finishing: Polished
• Handle Material: Metal
• Warranty: 1Yrs
• Use: Concrete Testing

• Warranty: 1 Year
• Country of Origin: Made in India
• Application: NDT testing
• Brand Name: Proceq
• Material: Mild Steel
• Is It Portable: Portable

The SilverSchmidt STPC is the first integrated concrete test hammer featuring true rebound value and unmatched repeatability.Independent validation testing by BAM (Federal Institute for Materials Research and Testing, Germany) has shown the SilverSchmidt STPC to have less dispersion than the classical concrete test hammer over the entire range. The unique design and high quality construction of the concrete test hammer SilverSchmidt STPC makes rebound hammer testing quicker and more accurate than ever before.

• Application: Laboratory Use, Construction sites
• Type: Concrete Test Hammer
• Country of Origin: India
• Temperature: -40- +60 Degree C

Vijay Scientific Supplies was established in the year 1996. We are Manufacturer and Wholesale Trader of Laboratory Microscope, Survey Instruments, Ceiling Fan, Medical Instruments, TDS Meter, Pedestal Fan, Wall Mount Fan etc.

• Brand Name: Subi Tek
• Model Number: Subi Tek
• Place of Origin: Covai
• Red: Blue

Concrete Test Hammer Specifications : Consists of a barrel in which is housed a hammer mass attached to an impact spring which slides on a guide bar. A plunger is attached to the guide bar which is pressed against the surface to be tested. As the piston is pressed against the surface to be tested. As the piston is pressed against the surface to be tested, on reaching the compressive strength, the hammer mass is released and rebounds to a certain extent (according to the strength of the surface) which is indicated by a rider on a calibrated scale. A lock button fixed on the body of the hammer locks the rider in place and the rider can be recared to zero position by using the same button. The equivalent compressive strength can be computed from the chart supplied. Each hammer is calibrated against at standard test hammer, and is suitable for specimen of compressive strengths 100 - 700 kg/cm. The instrument, complete with a grinding stone for polishing the test surface, is supplied in carrying case. Taag: Concrete Test Hammer Dealer in Chennai, Concrete Test Hammer Supplier in Chennai, Concrete Test Hammer Manufacture in Tamilnadu

• Application: Laboratory
• Weight: 450 Gm
• Finishing: Portable
• Warranty: 6months
• Brand Name: Steco
• Material: Steel
• Use: Impact Testing
• Spring Extension: 75 mm

Rebound Hammer is a device for measuring elastic properties/strength of concrete/rock and helps in testing mainly surface hardness and penetration resistance properties. Specification: · Usage: Concrete Rebound Hammer · Testing instrument: Concrete Rebound Hammer · Color : CustomizedFeatures: · Portable and flexible· Simple and convenient to use· Adjustable friction of pointer· Particularly used on the site to carry out non-destructive NDT test

Product Description   Concrete Rebound Hammer is used for estimating the concrete strength and non destructive test on concrete. These are very durable and ensure error free performance for a long duration. These are manufactured using qualitative grades of MOC and are promised for on time performance.   Operation:   It consists of a barrel in which is housed a hammer mass attached to an impact spring which slides on a guide bar. A plunger is attached to the guide bar which is pressed against the surface to be tested. As the piston is pressed against the surface to be tested, on reaching the compressive strength, the hammer mass is released and rebounds to a certain extent (according to the strength of the surface) which is indicated by a rider on a calibrated scale. A lock button fixed on the body of the hammer locks the rider in place and the rider can be recurred to zero position by using the same button. The equivalent compressive strength can be computed from the chart supplied. Each hammer is calibrated against at standard test hammer, and is suitable for specimen of compressive strengths 100 – 700 kg/cm. The instrument, complete with a grinding stone for polishing the test surface, is supplied in carrying case.

• Warranty: 1 year
• Pointer length: 20.0 ± 0. 2mm.
• Is It Portable: Portable
• Model Name/Number: Langry
• Material: Ms
• Usage/Application: Laboratory

Rebound hammer test is conducted to find out the compressive strength of concrete by using rebound hammer. The rebound of an elastic mass depends upon the hardness of the surface when it strikes. When the plunger of rebound hammer is pressed against the surface of the concrete, the pring controlled mass rebounds and the extent of such a rebound depends upon the surface hardness of the concrete.

• Weight: 1.5 Kg
• Conforms to BS 1881: Part 202.IS 13311 Part 1, ASTM C-805
• Accuracy: Better than + 2 Rebound Numbers when tested on Calibration Anvil
• Impact Energy: 2.207 Nm
• Resolution: 2 Rebound Number(s)
• Range: 10 to 100 Rebound Number
• Features: Economical, Travel Carry case

The Schmidt Hammer Digi-Schmidt was developed for the non destructive measurement of the concrete compressive strength and controlling the uniform concrete quality.

• Weight: 1.4 Kgs.
• Voltage: 440 V
• Impact Energy: 2.207 J or N-m / 1.6278 ft-lb
• Radius of spherical tip: 25 +/-1 mm / 0.99 +/- 0.04 in
• Impact stroke: 75 +/- 0.3 mm / 2.95 +/- 0.012 in
• Test range: 10 -60 MPa

We are offering rebound hammer. key features: 1. high contrast oled display 2. all setup can be made on site 3. automatic calculating compressive strength 4. all data will be stored in memory 5. all data can be transferred to pc usb or blue tooth (optional) 6. dual display for analog ruler and digital value

• Standard impact energy: 2.207 J
• Pointer length: 20.0 ± 0. 2mm
• Friction of pointer: 0.65 ± 0. 15N
• Spherical radius of bouncing rod: 25±1.0mm

• Usage/Application: Industrial
• Packaging Type: Plastic Case
• Impact Energy: 2.207Nm (1.63ft-lbf)
• Compressive Strength: Max. 10,152psi (Max. 70MPa)
• Product Dimensions: 2.1 x 14in (53 x 356mm), Dia.xH
• Estimated Shipping Weight: 5.0lb (2.27kg)
