Resistance Temperature Detectors Dealers

Canopus Instruments provides multi-channel temperature scanners designed to interface with 8 12 16 channels of 3-Wire RTD PT-100 inputs as per the user requirement.

We do not have to worry about stock-out situations and undertaking bulk orders, as are facilitated by a large storage facility. It has the latest inventory management software that helps us to maintain year around availability of the products. Buyers can rely on us for on-time and safe delivery as we are aided by modern transit facilities.   Specifications : 2, 3 or 4-wire platinum element in simplex or duplex assembly Temperatue range -  -50 to 250oC Triple element assembly in 6 mm diameter on request Standard lengths  -  100mm, 150mm and 300mm( Longer assemblies not recommended) Standard 6mm sheath diameter, other sheath diameter available on request Termination  -  Weatherproof Die cast aluminum head with threaded cap and chain 1/2"BSP (F) single cable entry with single compression gland Different types of terminal heads available SS316 sheath material as standard

• Power: 1.5 KV AC

Linearized RTD TC Field Interface Board have 8 nos of independent Thermocouple or Pt-100 RTD (3W) input channels. All 8 channels have factory set either Current or Voltage Output signal. Optionally offered Windows based User friendly mTRAN configuration software allows user to configure each channel for different type of TCRTD input. Field interface Board has channel wise open sensor indication that allows user to identify channel wise faults. The interface boards are built using the latest Technology to deliver high performance in Accuracy, Resolution, Stability and Isolation.

• Application: Used in Pulp & Paper Industries,vessels,Machine & Apparatus construction,furnaces,plastic industry.
• Brand Name: Tempcon Components
• Condition: Good
• Type: PT-50,PT-100,PT 500,PT-1000,NI-100
• Country of Origin: Delhi
• Product Name: Resistance Temperature Detectors
• Feature: High durability, easy operation, tensile strength, and low maintenance cost
• Min. Order Quantity: As Per Client Requirement

We have made our mark as Manufacturer and Supplier of Resistance Temperature Detectors from Delhi, India. We make use of cutting-edge technology for their production in order to infuse significant features such as accurate result, high durability, easy operation, tensile strength, and low maintenance cost.  The Detectors are widely used in Pulp & Paper Industries, vessels, Machine & Apparatus construction, furnaces, plastic industries, Chemical & Petrochemical Industries, Food & Beverage Industries.Types of resistance temperature detectors : PT-50 PT-100 PT 500 PT-1000 NI-100

• Feature: The Sheath Would Be Flexible and Filled with Mgo.
• RTD Types: PT-50,PT-100,PT-200, PT-500, PT-1000
• Temperature Range: -200 to +600 ° C
• Elements: Platinum Thin Film Rtd, Ceramic Wire Wound
• Class of Tolerance (Reference din En 60751): 1/3,1/10, CLASS A,CLASS B,CLASS C,CLASS Y & K
• Standard RTD MI PROBE Sizes: 0 3,4.5,6,8 mm
• Configurations: Simplex, Duplex
• Grade of Protection: IP 55,IP 65,IP 67, Atex, Ccoe, Flame Proof
• Type of Termination: Plug and Socket,Ip Rated Head,Din and Explosion-proof Connection Head
• Connectors: Mil Std, Nylon, Plastic, Ceramic
• Type of Measurement: Air,Gas,Liquid Immersion,Contact,Surface
• Sheaths: SS 304,00 316,55 310,00 446, Inconel 600,Inconel 800,Incoly Titanium, Inconel, Ceramic, APM

• Brand Name: ABB
• Color: Black, Green
• Power Source: Electric
• Application: Industrial Use
• Certification: CE Certified
• Voltage: 220V
• Warranty: 1 Year
• Country of Origin: India

We are offering our entire range of products in excellent quality packaging to guarantee zero damage during transit. For this, we have hired only professional packing personnel to ensure the same. With our up-to-date transit facilities and speedy services, timely and safe deliveries are guaranteed.

• Type: Pt-100 (PRT) / Cu-53 (CRT), Simplex / Duplex, 2 /3/4 / 6 wire.
• Calibration: As per DIN 43760
• Head: With / Without head
• Sheath Material: S.S. 304 / 316/ 310/ Inconel / Incolloy
• Sheath Dia: 3/6/8 mm. (MI type) . 6/8/10/12 mm ( Beads type)
• Sheath length below head: As per clients’ requirement
• Process Connection: 1/4"/ 3/8”/1/2” BSP(M) /NPT(M) adjustable/ Flanged/ Clients’ specn.
• Temperature Range: -100 deg to 400 deg C.
• If without head: Terminal block on flange / Plug-Socket
• Thermowell type: Bar stock - Tapered / Straight. Others
• Thermowell Matl. & Length: SS 316, 310, Inconel, or as per clients’ requirement

We offer resistance temperature detectors. Manstronic’s platinum resistance elements are specially designed to ensure precise and repeatable temperature versus resistance characteristics. The sensors are made with controlled purity platinum, have high purity ceramic components and constructed in a unique strain-free manner. Rtds are best for most industrial measurements over a wide temperature range, especially when sensor stability is essential for proper control. Generally speaking, if accuracy is your most important concern and the application temperature is between 140°c and 650°c rtds are probably the best choice. Three-wire is the most common but four-wire provides higher system accuracy.

• Feature: High durability
• Calibration: As per DIN 43760
• Head: With / Without head
• Sheath Material: S.S. 304 / 316/ 310/ Inconel / Incolloy
• Sheath Dia: 3/6/8 mm. (MI type) . 6/8/10/12 mm ( Beads type)
• Configuration:: Simplex/Duplex/Others

Resistance Temperature Detectors (RTDs) are sensors that measure tem-perature by correlating the resistance of the RTD element with tempera-ture. Most RTD elements consist of a length of fine coiled wire wrapped around a ceramic or glass core. The element is typically relatively fragile, so it is generally installed inside a sheath to protect it. The RTD element is con-structed from a pure material, the resistance of which, at various tempera-tures, has been documented by various international standards institutes. The material has a predictable change in resistance as the tem-perature varies; it is this change that is used to determine temperature. RTDs are generally considered to be among the most accurate temperature sensors available. In addition to offering very good accuracy, they pro-vide excellent stability and repeatability. RTDs also feature high immunity to electrical noise and are, therefore, well suited for applications in process and industrial automation environments, especially around motors.

• Material: SS
• Diameter: 310 mm
• Temperature Range: 200-420 Degree C
• Packaging Type: Packaging Type
• Features: Precisely Designed, Compact Size, Durability
• MOQ: As per Requirment
• Quality: Optimum Quality

1.rtd sensor, make - tempix, length -12"below head , od - 8mm , 12 "bsp connection, temperature range 400 deg. and 2.thermocouple , type - k , length 12" below head , od - 8 mm , connection - 12 bsp , temperature range - 800 deg.
