Rigid Stranding Machine Dealers

• Type: Rigid / Planetary
• Condition: New
• Configuration: 1+6+12+18+24+30+36
• Fork: 4 sectional fabricated robust forks
• Machine Base: Machined Heavy Duty
• Bobbin Size: 400 mm – 630 mm

Armouring cum core laying machine / Rigid Stranding Machine (Tubular Stranding) and all Wire and Cable making machines are provided with under rollers with double ball bearings with each carriage, main hallow shaft supported. zoom The Armouring cum core laying machine / Rigid Stranding Machine (Tubular Stranding) and all Wire and Cable making machines have self aligned spherical roller bearings on ends, fine locking and tension device that provide on cradle pintle

Main features : self supporting rigid rotor design with 1+6+12+18+24+30+36 bobbin cage high efficiency and speed line drive by a.c. Or d.c. Motors with electronic or mechanical synchronization between line components. Different braking device for bobbins centralized lubricating system for bearing disk type pneumatic brake for cage. Machines with or without back twist mmi /plc equipped, optional easy lay setting

We are offering rigid stranding machine the machine is used for stranding cu, al wires and conductors. Stranding unilay and reverse concentric, round, compressed, compacted or sector shaped ( straight or prespiralled ) as per customer requirements sarvasv industrial corporation main features self supporting rigid rotor design with 1+6+12+18+24+30+36 bobbin cage high efficiency and speed bobbins mounted on pintles line drive by a.c. Or d.c. Motors with electronic or mechanical synchronization between line components. different braking device for bobbins centralized lubricating system for bearing disk type pneumatic brake for cage. machines with or without back twist mmi plc equipped, optional easy lay setting

• Wire range: 1.5mm to 4.5mm

Rigid cage stranding machines are another very high speed machine with the ability to produce multiple wire combination strands of Copper or Aluminum in one pass.The machine is constructed with a line of independently geared and reversible rotating cages or sections that rigidly hold the bobbins in multiples of 6 and pay-off while rotating.

We provide technically advanced Rigid Stranding Machine which is suitable for stranding long length and section bare aluminum, copper, aluminum alloy. These are widely used for the producing of aluminum cable steel reinforcing wires and the various power cables sector shaped conductors, round compacted and single core presidential.
