Ring Type Joint Gaskets
Get Price Quote
50000 Piece (MOQ)
Ring Joint Gaskets
Get Price Quote
We have come up with the finest range of Ring Joint Gaskets for our clients. WFY RJ3200 is machined from solid metal in a variety of shapes and designed for high pressure, high temperature or highly corrosive applications by selecting the most suitable material and shape. Our Ring Joint Gasket is designed to withstand exceptionally high assembly loads over a small area, thus producing high seating stresses. Ring Joint Gaskets are obtained by mechanical working from forged or laminated metals. These Ring Joint Gaskets are employed in the production and refining process of oil and chemical industries. These gaskets are designed in oval/octagonal shapes confirming to R, Bx and Rx series of API STD 6A. Types 3300 PL Plain type RJG 3300 OV Oval type RJG 3300 OC Octagonal type RJG 3300 RX RX type RJG 3300 BX BX type RJG 3300 S Special type RJG Applications Steel Mining Petrochemical Refining Fertilizer industries
Best Deals from Ring Gaskets
Ring Type Joint Gasket
Get Price Quote
We are offering ring type joint gasket. Ring type joints are primarily used by the oil, gas, petrochemical and offshore industries, they are also commonly used on valve, pipe work assemblies and with some integrity vessel joints. Ring type are use to seal flanged connections subject to high pressures and temperatures. These precision made solid metal gaskets form a metal to metal seal with the flanges. The gasket cross-sections are designed to concentrate the bolt load over a small area to produce a high seating stress. The gasket metal should always be softer than the mating flanges. The high seating stress causes 'plastic-flow' of the gasket into the flange faces to create seal. The 'rx' and 'bx' gaskets are designed to be pressure activated by the sealed media which improves the efficency of the seal as the internal pressure of the system increases. 'r' series ring type joints can contain pressure up to 10,000 psi 'rx' and 'bx' series ring type joints can contain pressure up to 20,000 psi the gasket and flanges must be manufactured to precision dimensions, surface and hardness.
metal ring joint gasket
200 Per Piece
100 Piece (MOQ)
Ring Type Joint Gasket
Get Price Quote
200 Piece (MOQ)
Teflon Ring Gasket
Get Price Quote
Ptfe Ring Gaskets
Get Price Quote
Our specially manufactured PTFE Ring Gaskets are widely used in chemical plant, glass lined equipments, etc. due to their high temperature, corrosion and ageing resistant qualities. We are one of the leading exporters of PTFE O Ring Gaskets Exporters. Our company has been renowned widely as one of the leading Suppliers of Solid PTFE Ring Gaskets. Description : These gaskets are successfully used in chemical plants, glass/glass lined equipment due to their high temperature, corrosion and ageing resistance. Envelope Gaskets are produced in two forms: - Milled & Slit forms. Milled type envelope is perhaps the better of the two since it is made it fit the insert and present a flat face to the flange. The slit type is perfectly arrogated for many applications where cost is a major consideration. The envelope in this variety does not present a full face to the flange. Solid gaskets can be made to order in different types of shapes and sizes. Size : PTFE Envelope is available in 12mm onwards and the 0.5mm flap thickness.PTFE Solid gaskets are available from 12mm on wards and 1mm, 2mm & 3mm in thickness.
Printer Ring Gasket
1,500 Per Piece
10 Piece (MOQ)
Ring Joint Gaskets
Get Price Quote
Rubber Ring Joint Gasket
16 Per Piece
10000 Piece (MOQ)
0.0
Website
Ring Gaskets
5,000 Per Piece
10 piece (MOQ)
We offer Ring Gaskets of different sizes for I/R & KPC compressors with MOC, Asbestos, Non Asbestos, Spiral steel, Ring Gasket of solid copper / solid aluminum, copper asbestos, aluminum asbestos with proper standard thickness and roundness. Ring Gaskets come with standard oil seals with S.S. Spring for grip with different sizes of compressors of I/R & KPC.
Octagonal Ring Gasket
Get Price Quote
Ring Joint Gaskets
Get Price Quote
We are well-reckoned Manufacturer, Exporter and Supplier of a wide range of Ring Joint Gaskets. The gaskets are suitable for high temperature and pressure industrial applications. We offer Ring Joint Gaskets in R, RX, BX styles and in oval/octagonal profiles. Our company fabricates them in compliance with specific tolerances as per API spec 6A and ASME B16. 20 standard (where applicable) on CNC machines. Buyers can purchase Ring Joint Gaskets form us at market lading prices. Our Ring Joint Gaskets are monogramed as per API- 6A (PSL4). Prime Feature : R – Type ( Oval and Actagonal ) : API R- Type Ring Joint Gaskets come in two basic types, an oval cross section and an octagonal cross section. These basic shapes are used in pressures up to 10,000 psi. The dimensions are standardized and require specially grooved flanges. The octagonal cross section has a higher sealing efficiency than the oval and would be the preferred gasket. The sealing surfaces on the ring joint grooves must be smoothly finished to 63 Micro inches and be free of objectionable ridges, tool or chatter marks. They seal by an initial line contact or a wedging action as the compressive forces are applied. The hardness of the ring should always be less than the hardness of the flanges. BX and RX Ring Gaskets : The BX ring gasket differs from the standard oval or octagonal shape in that it is square in cross section and tapers in each corner. BX can only be used in API 6BX flanges. RX ring gaskets are similar in shape to the standard octagonal ring joint gasket but their cross section is designed to take advantage of the contained fluid pressure is effecting a seal. Materials Standard: Soft iron, low carbon steel, alloy steels F5 and 410; stainless steels 304, 304L, 316, 316L, 321 and 347. Non-standard: high nickel alloys, super alloy steels and other stainless grades. Rubber coated ring joint gaskets - soft iron metal ring joint gaskets are coated with nitride rubber for testing wellhead assemblies and valves. Rings can be reused and do not damage flange grooves.
Ring Joint Gasket
Get Price Quote
Metallic Ring Joint Gaskets are suitable for high pressure and high temperature applications. The Ring Joint Gaskets are available in R, RX, BX styles and in oval/octagonal profiles. SEW manufacture Ring Joint Gasket in accordance with specific tolerances on CNC machines. These Ring Joint Gaskets fully comply with the ASME B16.20 standard and the API spec 6A requirements (where applicable). Prime Features R-type (oval & octagonal) solid sections to fit standard ring joint flanges with trapezoidal grooves Type RX and BX with complex beveled edge sections for wellhead pressure above 700 bars Combination Gaskets � Used where two flanges of different sizes are to be joined together Split Gaskets � Used where an API flanges is to be joined with a low pressure ANSI Flanges where a spiral wound gasket is used Special metal gaskets made to customer specifications Materials Standard : Soft iron, low carbon steel, Alloy steels F5 and 410: stainless steels 304, 304L, 316, 316L, 321 and 347 Non-standard : high nickel alloys, super alloy steels, and other stainless grades Rubber coated ring joint gaskets : soft iron metal ring joint gaskets are coated with nitrile rubber for testing wellhead assemblies and valves. Rings can be reused and do not damage flange grooves
Copper O Ring Gasket
Get Price Quote
Be it online or cash deposit, the financial operations are carried out only under the stern management, supervision of professionals. To make our payment procedures highly secured, we make use of the leading technologies to avoid any fraud. Using premium packaging materials, we secure our products properly for transportation and label it properly to provide information such as address of manufacturer/distributors, MRP, quantity, etc.
Ring Joint Gaskets
250 Per Unit
10 Piece (MOQ)
Rubber O Rings Gasket
20 - 100 Per Piece
1000 Piece (MOQ)
D I PIPE JOINT RUBBER RING (GASCKET)
Get Price Quote
T Type Rubber Ring for Ductile Iron Pipe size: 80mm to 700mm Rubber type:SBR/EPDM/NBR/NR Application:Ductile Iron Pipe Joint Sealing Standard: IS 5382 Also available as per buyer's sample or drawing
PTFE Ring & Envelopes Gaskets
Get Price Quote
Solitaire Enterprises are the leading manufacturers of PTFE ring, PTFE solid ring gaskets and PTFE envelopes as well. Made using special materials, the PTFE rings guarantee minimal friction and therefore promise optimum efficiency. The malleability of these PTFE rings ensures that they can be machined into various dynamic processes. The PTFE rings are manufactured in various sizes to ensure that it can support various industrial processes. The free running ability of this ring makes them an important part of manufacturing and industrial processes.In addition to its reputation as a reliable partner for manufacturers in India, Solitaire is also a leading supplier & exporter to various other countries across the globe. Currently, Solitaire has the technical expertise and experience that allows them to manufacture various kinds of engineering polymers. We deal in PTFE Thread Sealing Tape, Polytetrafluoroethylene and Nylon Products. Our company is known as one of the most reliable PTFE Ring manufacturer in India. Having worked with leading names like Bharat Heavy Electrical Ltd (BHEL), Indian Oil Tanking, Crompton Greaves, Grasim Industries Ltd. (Chemical Division) and many more, Solitaire specialises in understanding the needs and accordingly developing solutions to address them. These PTFE ring gaskets are successfully used in chemical plants, glass lined equipment due to their high temperature, corrosion and ageing resistance. PTFE Envelope Gaskets are produced in two forms : - Milled and Slit forms. Milled type PTFE envelope is perhaps the better of the two since it is made it fit the insert and present a flat face to the flange. The slit type PTFE envelope is perfectly arrogated for many applications where cost is a major consideration. The PTFE envelope in this variety does not present a full face to the flange. PTFE solid gaskets can be made to order in different types of shapes and sizes.The export network of Solitaire extends to Kenya, Nigeria, Mauritius, Sri Lanka, Bangladesh, Indonesia, Philippines and so on. In the coming years, Solitaire is confident of strengthening its presence across various domains emerging as one of the most recommended service providers in its category. Adhering to values like reliable customer service, on time delivery and complete after sales support, we ensure the best possible deliverables for our client.We are located in Mumbai, India. Feel free to Contact Us for further information about our PTFE Ring & Envelope and it's pricing.
0.0
View Profile
Ring Joint Gaskets
Get Price Quote
We manufacture Ring Joint Gaskets conforming to R series in Octagonal / Oval shape, Bx and Rx series of API std 6A and ASME B 16.20. They are used in the production and refining process pipelines of oil and Gas Industries.Made from solid metal types like : Soft Iron/LCS - Low Carbon Steel – Electroplated as per your specs zinc electroplated (By Default); Yellow Pacification; Cadamium Plated and Hot Dip Galvainsed. Stainless Steel AISI 304/316/321 Income and other Alloy grades.
