Roll Bending Machine Dealers

• Material: Cast Iron
• Driven Type: Electric
• Finishing: Polished
• Operating Type: Automatic
• Voltage: 220 V
• Country of Origin: India
• Max Bending Radius: 0-50 mm
• Frequency: 50 Hz
• Brand Name: Sandeep

The PBM Series 3 Roll Pyramid Type Hydro Mechanical Plate Bending Machines are designed with top roll UP & DOWN movement by hydraulic cylinder. This saves time & labor to adjust top roll. This feature makes the machine more productive and suitable for handling heavy jobs. Dropper end movement is done by hydraulic cylinder.

• Type: Automatic
• Certification: CE Certified
• Weight: 100-1000kg
• Voltage: 220V
• Power: 3-6kw
• Warranty: 2 Years
• After-Sales Service Provided: Spare Parts
• Driven: Electric

Jayson Machine's (Impex) is acknowledged amongst reliable Manufacturers & Suppliers of Pyramid Roll Bending Machine. We manufacture Pyramid Roll Bending Machine using premium grade materials and component as per specified technical parameters. Our Pyramid Roll Bending Machine is low in maintenance and high in performance. Due to it less wear and tear quality, our Pyramid Roll Bending Machine is highly demanded by nationwide customers. We are committed to provide Pyramid Roll Bending Machine at very reasonable price.

• Sheet Bending Roller: Plate Bending Roller

We can offer you our best quality, heavy duty steel fabricated body three roll pyramid type plate bending machines as per your requirements. We can supply you both mechanical and hand operated plate bending machine. Machine is supplied with centralized lubrication system. Heavy duty steel fabricated housing amply proportioned to withstand maximum strain. Rolls are of forged EN-8 material and run in collar type gun metal bushes. Base is of heavy duty girders. Drive through a series of hob cut steel gears and worm reduction gear box. Screw jack is provided to keep the top roll in horizontal position when trunion is retracted to facilitate removal of formed shells. The photo shows our standard 2500mm x 25mm capacity bending roller fitted with 30.0 HP three phase AC electric motor, Siemens make ONOFF Push Button Starter with Siemens make ReverseForward switch. We can supply you machine to bend sheets upto 32mm Plate. We also offer manually driven plate bending roller machines as well. Kindly ask for more details.

• Brand Name: INFORCE
• Raw Material: C45
• Color: Grey
• Condition: New
• Automatic Grade: Fully Automatic
• Power: 10 HP
• Usage/Application: Plate Rolling
• Certification: ISO 9001:2008 Certified

Hydraulic Plate Bending Machine (2 Roller Sheet Rolling Machine) Hydraulic Plate Bending Machine is a specially designed compact Hydraulic Sheet Rolling Machine with 2 Rolls. This Sheet Rolling machine is also known as Hydraulic Plate Roller, Hydraulic Plate Bender. This 2 roll plate bending machine is ideal solution for mass production of a similar type of components. 2 Roll Hydraulic Plate Rolling Machine is mainly used to bend lower thickness metal sheets. This is a hydraulic sheet bending machine with 2 rolls. Top roll is static with small diameter and bottom roll is coated with polyurethane to avoid plate slippage during bending process. In this type of hydraulic plate roller Polyurethane coated plate roller avoid bending marks on sheets and give the smooth bending surface This machine is probably the quickest machine with very high production rates. It can produce around 800 components per day. Features of Sheet Bending Machine 2 Roll - Hydraulic Plate Bending Machine standard features INFORCE make 2 Roll Hydraulic Plate Bending Machine is fabricated with electro welded frame. It is accurately machined on high precision boring machines. This machine is supplied with wide range of optional accessories as per client's requirement.   Feed table with two adjustable guides for squaring of blanks. Two hydraulic cylinders for movement of bottom urethane roll. Swing bearing: hydraulically controlled. Hydraulic drop end. Hydraulic Plate Bending Machine Accessories Optional Accessories can be supplied with 2 Roll Sheet Bending Machine INFORCE can supply 2 Roll Plate Rolling machine with advance automation and additional following optional accessories as per your requirements.  Automatic feed table with two adjustable guides for squaring of blanks. Auto Ejection of components after rolling PLC controller with operating desk HMI display Hydraulic Sheet Rolling Machine 2 Roll - Hydraulic Plate Bending Machine Applications INFORCE make 2 Roll Hydraulic Plate Bending machine is suitable for variety of applications like, Submersible Pump Body Stainless Steel body cover Automobile Silencers Automotive Tanks Exhaust Pipes Catalytic Converters Air Tanks for Truck Air brakes Air Compressors Small Water Heater Chimney Flues LPG Cylinders Fire Extinguishers Pharmaceutical Machinery Food & Beverages Machinery The main advantage of 2 Roll Hydraulic Plate Bending Machine is its very high production rate. This is the fastest machine among all other versions of Sheet Bending Machine

• Max Bending Radius: 50 mm
• Usage/Application: Industrial
• Roll Material: Steel
• Automation Grade: Manual
• Brand: AK Engineering

• Range: 16mm to 100mm and length of 2500mm to 5000mm Electromechanical or PLC based balancing & parallelism system

Pyramid base principle 3 & 4 Roll Hydraulic Plate Bending Machine Used for roll bending of plates with pre-pinching. Product like Vessel & Tanks, Cone, Silos, Over & Under Storage Tanks, Heavy Transmission Pipe, etc.

• Brand Name: ANASUYA
• WHITE: YELLOW

We are offering roll plate bending machine. Plate rolling machine ’anasuya’ presents to you a range of most technically advanced 3-roll plate bending machine with all latest features as per international standards. standard features/accessories: » main drive motor » frame built of laser cut high strength steel, welded, stress relieved and sand blasted. » hydraulic pressing system on top roll. » hydraulic unit by rexroth and valves by aron. » screw jeck drop-end. » mechanical rolls parallelism . » bending rolls assembled on heavy duty skf bearings. » centralized lubrication by means of a hand pump. » separate controls on control panel. » movable work station with pair of foot switch » pair of lifting links » safety devices and operating manual according to ce norms.

'Tee' Electro Mechanical Pyramid Type Plate Bending Machines Are The Most Popular Plate Bending Machines Working In India With Over A Thousand Machines In Use.   They Are Designed For Production Of Cylindrial Shells Used For Pipes, Storage Tanks, Chimneys, Pressure Vessels, Etc.    These Heavy Duty Plate Bending Machines Employ The Orthodox Three Roller Pyramid Principle. Bottom Rolls Are Fixed And Are Driven By A System Of Gears And Worm Reduction Gear Box Whereas The Top Roll Has A Vertical Up And Down Movement Through   (A) Screws Adjusted Manually In Model Tph.   (B) Separate Motor In Model Tpvp.    The Housings Are Steel Fabricated With Large Bearing Surface Area. The Rolls Are Of Wear Resistant Forged Steel And Are. Amply Dimensioned To Keep The Top Roll Horizontal When The Formrd Shell Is To Be Extracted By Retracting The Trunion. Horizontal Grooves Are Provided Throughout The Length, Of Rolls For Additional Gripping And Correct Feeding. Indicators Are Provided At Both Ends Correct Feeding. Indicators Are Provided At Both Ends For Correct Top Roll Pressure. (For Model Tpvp) For Conical Bending The Top Roll Can Be Inclined Disengaging The Clutch At One End Of The Worm Gears.

• Warranty: 1year
• Voltage: 110V, 220V
• Weight: 100-1000kg
• Type: Plate Bending Machine
• Automatic Grade: Automatic, Fully Automatic
• Driven: Electric

With the support of our engineers, we are able to provide high performing Roll Plate Bending Machine to the clients. Roll Plate Bending Machine is assembled by making use of sophisticated components that ensure efficient performance, subsequently increases production capacity. Conical bending without any extra attachments can be done by Roll Plate Bending Machine. The two bottom rolls are inclined by disengaging the dog clutch by lever fitted on the machine. Even pre-pinching of cones can be done. Highlights Robust construction Smooth working Efficient design Longer service life Specifications The Pinch Cum Puramid Principle The machine based on this principle combine the advantages of three roll pyramid type, three roll initial pinch type and four roll pinch type machines. Highest degree of pre-bending can be achieved and only the smallest possible width of flat remains. An error in pre pinching can be corrected even after the shell is completed. It can pre-pinch and roll the plate without removing the plate from machine after first insertion. Inclined movement of bottom rolls provides wider bending span as the plate thickness increases, and better grip in thinner plates. Cone Bending : The Machine has inherent feature for conical bending without any extra attachments. The two bottom rolls are inclined by disengaging the dog clutch by lever fitted on the machine. Even pre-pinching of cones can be done. Features Top roll drive for rolling thin plates. Highest degree of pre-bending can be achieved and only the smallest possible width of flat remains. Plate Squaring(aligning) arrangement. Small dia. Top roll for small shell rolling (for reduced capacity). The Symmetrical Three Roll Principle of Plate Pre-Prinching & Rolling The plate is first lightly rolled over its full length. One of the bottom roll is brought near the top roll and plate edge is brought close to the tangent point. By lifting the other bottom roll, plate edge is pre-bent (pre-pinched) The Positions of bottom rolls are reversed (interchanged) for pre-bending second edge of the plate. Note that both the edges are pre-bent without turning the plate around. The rolls are brought in pyramid formation and cylinder is completed. Note that an error in pre-pinching can be corrected even at this stage.

Offering international quality international quality 3 Roll Pyramid Mechanical Plate Rolling Machine. We have earned great accolades in the industry by exhibiting unmatched manufacturing technology and product quality.The job is fed from one end to carry out pre-pinching & entire shell is rolled to desired bend radius. Other end pre-pinching is carried out by second bottom roll to complete shell .the complete shell is prepared in single operation.

This is our heavy duty three roll pyramid type power operated plate bending machine in model TPH having capacity to bend 2500 x 25 mm in mild steel. The machine weighs about 6700 kgs and is equipped with 30 HP motor, siemens make on/off starter and reverse/forward switch complete with lubricaton system. Some of the salient features of our three roll pyramid type plate bending machines are as under: Heavy duty steel fabricated housing amply proportioned to withstand maximum strain. Rollers are of forged EN-8 material and run in collar type gun metal bushes. Base is of heavy duty girders. Centralized lubrication system Drive through a series of hob cut properly hardened steel gears and worm reduction gear box. Screw jack is provided to keep the top roll in horizontal position when trunion is retracted to facilitate removal of formed shells. The machine is supplied complete with : - Elicon / Redicon make Reduction gear box- Electric motor 3 phase /440 volts / 50 cycles AC- Reversible switch (Upto 5 HP)- Reversible starter (Above 5 HP)  These Three Roll Pyramid Type Plate Bending Roller Machines are available in a wide range of capacities from 1250 x 3 mm in mild steel up to 3000 x 42 mm. Kindly ask for details.

We are ranked amongst the prominent Manufacturers, Suppliers, and Exporters of Hydraulic 4 Roll Double Pinch Type Plate Bending Machine. We are based in India. Our bending machine is available in SIX different models, each of which has a different mechanism, specification, and system for the suitable applications and production rate. These models are J4RHH, J4RHM, J3RHH, J3RHM, J3RMM, and J3RML. We offer our machine in varied sizes and thickness, in accordance with the requirements of our client. Features : Jayshree plate bending machines are available in SIX different ranges, All range of machine has a different mechanism, specifications and systems for suitable applications and production rate. Type J4RHH / J4RHM/J3RHH/J3RHM/J3RMM/J3RML Model J4RHH is very suitable for medium and heavy plates or stainless steel, Model J4RHM is very suitable for light and medium plates.  Technical Specifications and Standard Accessories Pipes in full circle or varying radius can be done easily Bottom roll and side rolls move with hydraulic cylinders Overload protection Top roll and bottom rolls are drives by hydraulic motor and planetary gearbox. Hydraulic drop-end for easy removal of finished pipes Easy operation with mobile control panel Welded steel frames Forged or rolled steel rolls Manual central lubrication system Hydraulic and electrical balancing system Users manual  Optional Equipments Cone bending device Double speed working system Hydraulic lateral supports for large diameters Extended rolls Profile rollers Automatic centralized lubrication system Material feed table Digital readout display NC control system Range - To 5000mm, Thickness - 4 to 100mm

Quality packing material and advanced machines are responsible for the safe packaging of the orders from our end. Moreover, our experts keep a strict vigil on the entire procedure. Striving hard to provide the best in class range, we are a Rajkot(India) based company.

• Brand Name: Ramani
• Type: Bending Machine,Roll Bending Machines
• Country of Origin: Dera Bassi
• Quality: High

We are a quality-driven firm and dedicatedly work towards attaining maximum client satisfaction. And, for this, we have adopted several measures for ensuring high quality of our products. We have captured the market with the wide array of products; we make available the same from Dera Bassi(India).

  Features: 3 Roll Are Made From Alloy Gear Box. Bending Rolls Are made Top Roll Adjustment is manually Set By Screw Jack The Robust welded Structure is Made From Mild Steel Plates High Quality Durble Worm Gear Box. Bottom Rolls Are Power Driven Manual end Dropper Arrangement Standard Accessories: Main Motor Drive Elecric Control Panel with Movable Operation Console(Not Included In Some basic Models Ruler for Top Roll Movement & Leval Manual Centralized Lubrication System 2 Nos. Screw Drive Road Nut Spanner Operation Accessories: Automatic Lubrication System Hardended Roll hydraulic Readout System Digital Readout System Extended Roll Shafts for Profile Bending Conical Bending Arrangement Useful Links Home About Us Inquiry Contact Our Products   C & Pillar Power Press Hydraulic Press Brake Hydraulic Sharing Machine Over Crank Mechanical Sharing Machine Pyramid Type 3 Roll Plate Bending_Machine Hand Press Brake Quick Contact
