Rotary Feeders Dealers

• Application: Industrial
• Weight: 10-100kg
• Color: Silver
• Capacity: 100kg/hr
• Frequency: 50Hz
• Warranty: 1yrs
• Surface: Polished

Rotary Table Feeder will consist of a power driven circulated plate rotating directly below a hopper / bunker.  A feed collar located immediately above rotating table used in conjunction with an adjustable plough, determines the volume of material discharged.   The lower edge of the feed collar will be parallel to the table with a predetermined gap from table top.  This arrangement permits equal quality of material to flow under the collar and spread over the table as it resolves.  The material is then ploughed off into the discharge chute.   Rotary table feeders are most useful for handling materials that are sluggish, tend to interlock or mat and thereby arch over restricted openings.

With immense knowledge and expertise in this domain, we have made our position in the domestic market by providing ROTARY FEEDER. As we give utmost importance to the quality of the products, we produce them in accordance to the quality standards.

• Brand Name: Delite Make
• Material: Cast Iron Body and SS 304 Rotor
• Color: Green
• Condition: New
• Application: Coal Feeding
• Certification: ISO 9001: 2015
• Country of Origin: India

Other Details :We are one of the Well-Known Manufacturers and Suppliers of a Wide Variety of Rotary Pocket Feeder. We Ascertain the Quality and Efficiency of Our Pocket Feeder and Therefore Latest Technology is Used Features: Higher Efficiency Durable Easy to Operate Specification: Material CI Grade 20 & S.S. Rotor Size: 4″( 200 Diameter Rotor) and 6″ ( 250 Diameter Rotor) to Avoid the Fuel Passing Through. Features: Model – Pocket Feeder Material – CI Grade & SS Rotor Size – 4″ to 6″

Our Rotary airlock are designed for rugged applications that require an outboard bearing style unit where contamination and /or an abrasive product cannot be handled with an inboard bearing style RAL. The HEM Technologies is Designed for use in high pressure pneumatic conveying systems, with 4000F application temperatures where more of an effective seal is required due to high or excessive wear that is experienced with a simple dust collector RAL   Benefits Superior seal design for prolonged life. Select from five sizes to fit most applications. Suitable for all dust collection applications. Operating temperatures to 400°F. Used in positive pressure pneumatic conveying systems.   Features  Outboard bearings Multi-Seal Round or square flange available Heavy duty oversized shaft Pressure differentials to 12 PSI Housing: Cast Iron / Fabricated Rotor: 8 Vane, open end Close

• Power: 2.5-5 kW
• Type: Gravimetric Feeders
• Lifting Capacity: 0-2 Tons
• Feeding Speed: 3 dm3/h - 4000 dm3/h
• Usage/Application: Industrial
• Body Material: Mild Steel and C.I

• Brand Name: HRI
• Capacity: 4-6 Tons
• Power: 2 HP
• Voltage: 220/240 Volt
• Warranty: 12 months
• Power Source: AC

As a renowned Vibratory Feeder Manufacturer, the company offers excellent performing Rotary Feeders. These Rotary Feeders do not require any type of controller or a vibrating electro-magnetic coil. Our Centrifugal Rotary Feeders are fitted with a Gear Box & Motor with a Rotating Disc, which rotates the components and places them in the provided oriented chute. CentrifugalRotary Motorized Feeders are speedier in output then the Vibratory Bowl Feeders.

HI-TECH Rotary Table Feeder consists of a power circular plate, rotating directly below the bin opening. An adjustable feed collar, located above the rotating table, determines the volume of material delivered. These feeders are used generally with round, vertical bins and for handling materials which have a tendency to arch ; such a dump sand, wood chips, and fine salt. The opening in the bottom of the round , vertical bin is large, so that material cannot arch over it.

• size: 8 mm x 41 mm

These can help achieve speeds of upto 50 meters per minute. Secondly, there being no vibrations and only mechanical items, rotary feeders are more acceptable to a lot of customers who are afraid of the reliability of vibratory bowl feeders in the long run (however, using a vibratory bowl feeder from a reliable supplier like Elscint can reduce this inhibition).

Rotary Air Valves regulate the flow of material from one chamber to another while maintaining a good airlock condition. Common uses of Rotary Air Valves include discharge of powdery materials at dust collector, storage bins and pneumatic conveying application. Our Rotary Feeder & Rotary Airlock Valve is available in various rotation speeds ranging from 20-50 rpm.

Rotary Table Feeders are used in industries, which require the moving or feeding of powder or granular substances. Table feeders are particularly helpful in moving sticky or hard to feed materials. They are also very useful in converting an intermittent batch process into a continuous material feeding process.The amount of material leaving the rotary feeder can be controlled by changing the angle of the discharge plow via a hand wheel or by motor.

Features: Cast body for rigidity Air purging for shaft sealing (Optional) Affordable Additional Information: Item Code: 02
