Salt Spray Test Chamber Dealers

• FEATURES & ADVANTAGES: Easy loading and unloading of large samples, Digital microprocessor based control, Auto water refill system, Auto Fog Collection System, Over temperature alarm .
• Temperature range: 35°C±1°C / 50°C ±1°C
• Temperature of pressure barrel: 47°C±1°C / 63°C ±1°C
• Temperature uniformity: ±2°C
• Temperature fluctuation: ±0.5°C
• Temperature sensor: PT100
• Humidity range: ≥93% (No Controlled / Display)
• Controller type: 02 No. PID temperature controllers for chamber and pressure vessel
• Timer: Digital timer 9999 hours
• Canopy: Made of Acrylic Manual lifting
• Chamber construction: PVC reinforced hard plastic sheets for complete corrosion proof construction
• Brine tank (reservoir): 25 liters inbuilt brine tank,  Low water level indicator .
• Salt fog fallout rate: 1
• Spray mode: Continuous or intermittent spray
• Compressed Air pressure: 1.00 ±0.01kgf/cm²
• Sample rackes: 08 Nos. V type racks,12 Nos. support rods .
• Fog accessories: 01. No. Spray tower 02 Nos. cup collectors
• Standard fittings: Mains ON/OFF, Pressure regulator, Dial type pressure gauge,  Drain system, Spray solenoid valve .
• Safety features: Over temperature protection, Low water protection
• Power supply: 220 Volts 50 Hz

The updated models of Salt/Cass Fog Test Chamber specially designed for evaluating the corrosion resistance of the surface treatment of metallic materials by Copper Accelerated Acetic Acid Salt Spray Test Method. It consists of following parts. Test Chamber :It consists of Cabinet and Lid and is constructed with insulated double structure made of FRP Moulded Sheet. The upper part (triangular shaped lid made of FRP with acrylic glass window) has sufficient space for the mist to accumulate naturally on it and is so shaped that drops so accumulated do not fall on specimen being tested. Air-Saturator :It is provided to supply heated and humidified clean air, over 90% RH, for Atomization of the solution. It consists of Body (made of stainless steel), Heater, Bubbling Nozzle, Air Cleaner & Pressure Regulator. Air Regulator :The Air Regulator will maintain a constant pressure of Air at 70 to 170 Kpa.Air Filter :The compressed air will be passed through a Filter Arrangement to remove all traces of oil and solid matters before sent to the saturation tower.Lid Sealing :Lid Sealing through Water Seal Method.Mist Dispersion Atomizer :Atomizer made of Acrylic Glass will be equipped in the Chamber having property of non-choking. It produces a mist of atomized solution, which is distributed uniformly throughout the exposure zone by means of Mist Dispersion Atomizer incorporated with a baffle to prevent dispersion of large liquid droplets. Compressed Air and Gravity Process will help for creation Fog through Atomizer.Heating System :The Temperature within the Chamber maintained by Heater with Blower System, which provided in-between the Exterior and Interior walls.Solution Supply Tank :Solution Supply Tank will be provided to supply solution to Mist Dispersion Tower and will be made of FRP Moulded Sheet.Mist Collector :Two Mist Cylinders are provided for measurement mist quantity. Each has 80 cm² of horizontal area. The condensate is collected in individual graduated cylinders.pH Indicator :pH Indicator is inbuilt in Control Panel.Control Panel :Separate Control Panel will be provided located on the Trolley. The Control Panel will house : RH and Temperature Controllers-cum-Indicator for Main Chamber. PID Temperature Controller-cum-Indicator for Air Saturating Tower. PID Temperature Controller-cum-Indicator for Solution Tank. Weekly Programmable Timer, Hour Meter, ON/OFF Switches, Fuses, Electronic Relays and Indicating.Lamps. pH Indicator. Material :Control Panel, Stand and the Chamber containing other accessories of the Equipment will be made of Stainless Steel 304 grade. Wiring :All wiring will be as IS code. Channel type wiring will be done with suitable current rated copper wires.Power Supply : 220/240 V, 50 Hz, Single Phase, AC Mains.Safety Device : Cut-out at the time of water shortage in air saturator. Cut-out at the time of over current in control devices. Low Water Level Controller with Mechanical Floats type-Refilling Arrangement. Pre Installation Facilities to be required at user’s premises : Power Supply – Single Phase or Three Phases. Drainage System. Compressed Air. Distilled Water Reservoir or R.O. Reservoir as per user’s Test Requirement.

• Brand Name: Water Spray
• Material: SS
• Driven Type: Electric

Salt Spray Test Chamber

Our Salt Spray Chambers are manufactured in compliance to various standards like IS 2074 8168 IS 6910. These are mainly used to test the effect of salt on products by spraying it on them. Salt Spray Chambers are fabricated using rust-resistant material to ensure durability and strength. We are engaged in manufacturing and supplying a high quality range of Salt Spray Chambers. Designed and developed in compliance with the IS 2074, 8168, and 6910 standards, these Salt Spray Test Apparatus are widely acknowledged for features like high durability, strength, and rust resistance. This equipment is used to measure the effect of salt on different specimen products under test.

• Brand Name: TSI
• Temperature Range: Ambient to +50 Deg C
• Capacity: 300, 600,900,1500 liters
• Humidity Range: 60% to 95%RH
• Saturated Temperature: Ambient to +65 Deg C
• Salt Spray Fall Out Rate: Adjustable from 0.5 to2.5ml per 80cm2 per hr

• Type: Corrosion Test Chamber
• Certification: CE Certified, ISO 9001:2008
• Application: Industrial Use
• Color: Grey
• Voltage: 220V, 380V
• Condition: New
• Power: 1-3kw, 3-6kw, 6-9kw
• Driven Type: Electric
• Phase: Single Phase, Three Phase
• Warranty: 1year
• Country of Origin: CHINA
• Automation Grade: Automatic, Fully Automatic
• Brand Name: ASLI
• Material: PVC
• Standard: ASTM, ISO, IEC,
• Certificate: Ce, Iso , Sgs, Tuv, Bv

Touch Tone Salt Spray Fog Tester is used to test the corrosive resistance of products  whose the surface was treated with paint, electroplating, inorganic and organic film, anode handling, anti-rust oil.

• Country of Origin: India
• Type: Salt Spray Test Chamber
• Application: Industrial Use
• Features: 7'' Colorful Programmable touch screen controller, user-friendly, can remoto-control, Imported reinforced hard PP plates with smooth and flat surface, Power failure protection function, Self-diagnosis
• Model: 101L/270L/412L/663L/816L/1080L

 Salt Spray Test Chamber could evaluate the anti-corrosion ability of material and material coating, make a comparsion about the product techniques and quality of similar coating and products, It be used to test the electronic elements, and metal materials and industrial products.

Effective Lab India is a Leading Manufacturer and Exporter of a highly commendable and diverse range of Lab Testing Instruments like Cass Test Chamber, Salt Spray Lab Chambers, Laboratory melt flow indexers, Bursting strength tester, Xenon Arc Test Chamber, Ozone Aging Test Chamber and UV Light Accelerated Weathering Tester.

The Salt water spraying/corrosive resistant machine are specialized to test the performance of the products for its surfaces of various materials after treatment of corrosive protection by means of painting, coating, galvanizing, anodizing and of lubricant.   WEIBER Salt Spray Test Chambers allows selective and reproducible accelerated corrosion testing complying with the requirements of relevant national and international standards such asDIN, ISO, ASTM, DEF, MIL-STD, etc. Standard as well as customizable sizes are available. This Chamber also called Corrosion resistance test chamber, Cyclic Corrosion Test Chamber and Salt Spray Chamber. Choice of capacities – 108Lt,270Lt, 480Lt, 800Lt and as per requirement. Easy to clean, smooth, non-corrosive surfaces It has the function to refill water automatically when water level is insufficient. With accurate glass made nozzle (Pyrex) no sediment of crystallization blocked in 4000hours. The control instruments are mounted in one panel so it easy to operate and clear at a glance. Equipped with dual protection for over temperature and an alarming device for insufficient water level so as to ensure the safe operation. The test tank is heated directly by vapor so that the temperature rises fast and the stand by time shortened. The water spraying column equipped with the disperser has the functions to lead and adjust the reek and also has the function to make the falling reek even (the control instrument and the nozzles adopt the systems of Europe, America and Japan. The relevant materials adopt Taiwan system to assemble). Colour touch panel. HMI+PLC in one unit Door open and Door close alarm system. Inbuilt calibration system. Less use of Electrical and Mechanical Components on the Top and Bottom of Chamber - Provides easy maintenance of chamber, increases durability because of proper air circulation; cooling systems kept at bottom of the chamber to provide proper environment for compressor. Circulation Fan with Variable Speed Electrical efficiencyVariable speed motor saves money by reducing energy bills, as it consumes less electricity than conventional motor. Cooling EfficiencyVariable speed enables gaining air conditioning efficiency or SEER. Air QualityVariable speed motor helps clean the air efficiently. When the fan is in constant operation (indicated by the "Fan" setting on thermostat), the motor continues to slowly circulate air, allowing filters to capture more contaminants. Humidity ControlVariable speed motor combined with a Thermostat allows controlling the amount of humidity. Quieter OperationVariable speed blower motor are significantly quieter thanits single-speed counterpart. Digital Output – Target and Performance Output of the chamber operations are in digital format(digits) giving precise reading. Pre - Attached Data Logger with Data Analysis Software - Primary benefits of using data loggers is to automatically collect data 24-hour basis.Graph and table format of results can be produced automatically by the data logging software. Self - Calibration System - WEIBER incorporate a self-calibration system, in each chamber,that is completely automatic to prevent errors that could result from failure to calibrate. The system continuously monitors the environment, sensing changes that could affect analysis, and re-calibrates accordingly using a built-in long-life calibrator The process takes just a few seconds, without operator intervention or additional supplies, quickly optimizing system parameters for the current conditions. Open and Close Updates Through Mobile Network - Mobile technology has the potential to make services more flexible and keep informed, information anywhere at any time from mobile device, and can set alert system to know whether or not the chamber is being used. Reliable – Construction, performance mechanism, controls and information system integration makes the equipment reliable. Precise Control of Environmental Parameters - The set/ programmable parameters of the chamber are precise or have less deviation from original value,thus ensuring correct measurement. Micro - Processor Based Controller – Microprocessor based controller enablesprecise control of temperature, humidity, pressure and other values. Benefits: Processing speed is high Provides flexibility to alter the system by changing software. Compact in size. Operation and maintenance easier. Maintain precise values Aesthetically designed - Designed according to the standards and principles underlining industry’s aesthetic values. Corrosion Resistant interior and exteriors - Corrosion resistant coatings like epoy coatings are applied inside and outside the chamber to prevent against degradation due to moisture, salt spray, oxidation or exposure to a variety of environmental or industrial chemicals/ corrosive agents. Energy Efficient – WEIBER chamber uses less energy to provide the same level of performance, comfort and convenience, thus making it energy conserving chamber. Sturdy Construction - WEIBER chambers are built with robustness to withstand stress and strain, giving the chamber long life and ability to perform in extreme stress environments. Low Maintenance - WEIBER systems benefit inretaining proper functionality over long period of time. Light Weight: Compact and superior materials ensure the chamber be light weight

• Material: FRP/PVC
• Phase: Three Phase
• Voltage: 415 V
• Usage/Application: Laboratory
• Temperature Range: +5 Degree C Above Ambient to +35 Degree C
• Accuracy: +/-0.5
• Surface Treatment: Powder Coated
• Humidity Range: Sacurated Condition

• Brine tank capacity: 15 Liters
• Temperature Fluctuations: ≤ ± 0.5°C
• Temperature Precision: ± 1°C

Whether you are new to corrosion atmosphere testing or have been conducting testing for years, we present Salt spray chambers or Salt Fog Chambers that are not only easy to use and maintain but also provide the accuracy and flexibility necessary to meet today's demanding corrosion test procedures including Salt Spray Test, Condensation Water Test and Cyclic Corrosion Test. These machines create three types of manually adjusted environment; salt spray, high humidity and air drying at any given temperature within the chamber. Any combination of these environments can be programmed, in any order, to form a corrosion cycle. Such a corrosion cycle can be automatically repeated a predetermined number of times. Our models meet the requirements of basic, continuous salt spray tests conducted at a single temperature only, such as ASTM B117 and similar international test standards, and may be used with pH neutral salt solutions (NSS) or those acidified by the addition of Acetic Acid (ASS), Seawater Acidified Test (SWAAT) or Cupric Acid (CASS). Models above 480 Liters of capacity are ideal for Cyclic Corrosion Cabinet (Cyclic Corrosion Chamber). In Laboratories corrosion tests are used extensively for selection of materials and their surface protection. Our Corrosion box chambers are what you need to predict corrosion resistance of materials such as paints and coatings and are designed and developed to meet the widest possible range of industry standards: • Salt fog testing as specified in DIN 50021 • Condensed water test as specified in DIN 50017 and EN ISO 6988 • Standard climates as specified by DIN 50015

• TEMP: 70ºC

Innovative Salt Spray Test Chamber has been designed strictly as per the relevant standard to assess the ability of rust proofed components to withstand corrosion due to atmosphere conditions. It is Double Walled. (Stainless Steel 316 inside and Outside also Stainless Steel) with glasswool insulation. Salt Spray Test chamber can also be fabricated out of thick acrylic sheet, Salt solution is kept at the bottom of the test chamber, Overhead tank one side of the test chamber and is provided with a valve to maintain constant water level in the tank, Air atomizer is used to create salt fog conditions in the chamber, Air pressure is maintained at 0.2 to 0.8Kgcm2 to achieve desired density of fog in the test area,

• Temperature Accuracy: +/- 2oC
• Dimensions: 250 – 800 x 500 x 550mm

The Presto salt spray chamber is the most reliable equipment for checking the corrosion resistance of surface coatings when exposed to a salt laden environment. This time-tested product has been specifically designed to assess the rust-proof ability of components to withstand corrosion due to atmospheric conditions. It provides complete flexibility in simulation of real life weathering conditions. The test temperature in the chamber is user adjustable from ambient to +45°C and is controlled by a PLC controlled PID. The touch screen installed in the Presto salt spray chamber is a powerful tool that eases the analysis of corrosion resistance for a wide variety of sample types. A special zero corrosion PT 100 sensor is incorporated in the touch screen. It also has 8 function keys, a 3M flash memory and provides a USB host for a USB flash drive. The Presto salt spray chamber is double walled and is fitted with a glass wool insulation, which ensures that the results are accurate and reliable enough to meet the international standard of testing. The chamber incorporates the latest technology including an Air Flow Meter which regulates the air flow from 0 to 30 psi. It is also equipped with an air jacket heating system which ensures uniformity and reliability. This testing equipment is particularly useful in quality control laboratories, where they are used for comparative sea salt spray test. A see-through cover optimizes test observation by providing continuous direct visual observation of the test item. Further, the Presto salt spray chamber is fully tested before shipment and comes with an instruction manual & a calibration certificate. It strictly adheres to ISO, ASTM, JIS, IS and DIN standards.

Constant deposition amount through dosage pump, Salt Spray Chambers have high value spray nozzle made of PMMA or PVDF, Testing chamber made of polypropylene, Air humidifier made of stainless steel, Frame and extension components consisting of stainless steel, Transparent cover, Computer control using a graphic screen

Composite Salt Spray Test Chamber stimulate the actual natural conditions to do accelerated corrosion test, all the testing are based on common states on the natural environmental: such as combine with salt spray, hot air drying, humidity, low temperature and so on. The test samples are widely used on the intense changes in the environment, like automobile parts, aviation equipment, building materials, coating, electric and electrical machinery so on. YWXQ-150X series is full compliance with ASTM D4728I, EC 60068-2-1, IEC 60068-2-14 and EIAJEDEC JESD22-110-B standard requirements etc.

• Capacity: 100, 200, 400 and 600 Litres.
• Power supply: 230 V, 1 Phase, 50 Hz.

Cabinet constructed from non-corrodible high temperature resistant glass reinforced plastic. Acrylic cover is provided. Constructed in fiber-reinforced plastic, 10 mm thick with stiffners at the bottom to take heavy load. The FOG Chamber conforms to ASTM B 117 specification. The volume is of sufficient size to test adequately the desired number of parts without overcrowding. The apparatus consists of a fog chamber, a salt solution reservoir, a supply of moisture free compressed air, atomizing nozzles, specimen supports, provision for heating the chamber, humidifying chamber and control system. The fog chamber is provided with digital temperature controller, pressure gauge, provision for controlling the mist, humidity indicator and solenoid valve to regulate these conditions.
