Self Aligning Rotator Dealers

• Type: Self Aligning Rotator
• Application: Industrial
• Weight: 800-1000kg
• Color: APPLE GREEN
• Condition: New
• Automatic Grade: Semi Automatic
• Driven Type: Electric, Mechanical
• Warranty: 1year
• Country of Origin: India
• Brand Name: FOHMICS
• After-Sales Service Provided: PROVIDED
• Certification: PU WHEEL TEST CERTIFICATE

Our company is the major company known for providing Self –Aligning Rotator to the clients. Offered range is widely used for manipulation of shells or cylindrical component for processing or positioning. This product is manufactured using supreme grade basic components and pioneering techniques in tandem with market standards.

Leveraging on our vast infrastructure, we offer our clients an unmatched range of Self Aligning Rotator. Manufactured with extreme care and quality scrutinized methods, our Self Aligning Rotator is widely appreciated for its high functioning. We are also reckoned for providing our range of Self Aligning Rotator in a customized manner as per the requirement of our clients. Our clients can avail this fine range at very economical price. Attributes : Robust constructionExtremely DurableOptimum load bearing capacityHigh mechanical efficiency Specifications : Roller Surface Speed : 75 mm / min to 1500 mm / minDrive : Variable Speed A.C. Motor (A.C. VFD) For Job Diameter : 500 mm � min and 8000 mm � max (The Job diameter varies according to load conditions) Note : Customised Self Centering Rotators May also Be Provided Apart from Our Standards. Technical Specifications ModelCapacity (Drive + Idler ) (Tones)Roller Dia. (D) (MM)Roller Width (W) (MM)Roller Material SRT-SAR- 01130090POLYUR ETHANESRT-SAR- 055300100SRT-SAR- 1010400100SRT-SAR- 1515400120SRT-SAR- 2020400120SRT-SAR- 3030400120SRT-SAR- 4040400120SRT-SAR- 5050400145SRT-SAR- 6060500145SRT-SAR- 8080500150SRT-SAR- 100100550160SRT-SAR- 150150550290SRT-SAR- 200200550340

The design of the AMIN Self - aligning Rotators incorporates many hidden features, which are unknown to our competitors.With the AMIN Self-aligning construction the trunnion brackets which support the rubber typed wheels automatically align themselves when changing from one diameter to another, no manual adjustment whatsoever is required.Each section supports the vessel on four points ensuring better traction, and on machines of 3 T to 500 T capacity and upwards all four wheels of the drive section are positively driven. This four point suspension is an added advantage when on handling thin walled vessels.The two top leading wheels of the drive section incorporate clutches which are loosened prior to  loading the vessel and the top wheels can rotate freely when the vessel is loaded; thus  regardless of weight if the vessel is lowered centrally between the frames, or firstly on to one  wheel only, no damage can be sustained by the transmission.One problem in the welding of large diameter heavy vessels is the lining up of the  strakes. To facilitate this problem of lining up, the AMIN Self-Aligning Rotators can be supplied with an arrangement whereby the trunnion brackets which support the rubber typed wheels can be moved across the frame by lead screw so that the vessel can raised or lowered by widening the trunnion centers or bring them closer together and in addition a secondary screw adjustment can be provided to move both the trunnion brackets either side of the center line approximately 38 mm. In order to ensure that the four wheel point support can be maintained over an extended range of diameters the SAR. Frames can be supplied so that a spacer can be inserted in the main frame between the trunnion centres so that they are capable of handling vessels upto 11 metres or more in diameter.

Self Aligning Rotators automatically adjust the roller Housings to accept any job diameters with in the specified diameter range. This type of machines are generally used to cope with the change in shell diameter, Job to job. The roller housings of this type of machine are hinged ot the beds and to cope with the change in shell diameter job is introduced. In this type of rotator. each roller brackets assembly have two separater roller assemblies, and thus supports the job on a wider area. The final drives is given to both the 2-sets of rollers of the Drive Unit, provide better traction ot the job. However, in this case a declutching arrangement is provided to the top rollers, in order to protect the gear boxes, as when the job hits the top rollers first while loading, there is a tendency of rotating the top rollers where as it locked by the gear boxes.

self aligning rotator The Rollers of these machines automatically adjust themselves when loading to suit the diameter of vessel. Thus a large range of diameters can be accommodated without need for any adjustment.

Self Aligning Rotator: The self aligning rotator are having one power unit and one idler unit with combined load capacity of set, as per the rated load of set. The vessel or job supported on four rollers and due to self aligning design, the rollers will adjust automatically with respect to job diameter and irrespective job ovality. Self Aligning more suitable for thin vessel. Application: Pressure Vessels, Heat Exchanges, Boilers, Tanks, Pipe welding, Generators etc. Benefits of self aligning welding rotator: Fast production and quality improvements Reduce fatigue for welder No need to use crane of job handling No setting of job required, machine accept the job automatically Useful for thin vessel and busy workshop having frequently job changes. Self Aligning rotator range includes upto 800 Tons.

• Material: Mild Steel
• Max loading: 20 Ton
• Roller distance: 2000 to 2200 mm
• Linear guide: 60 m/hr
• Motor power: 1.5 KW

COMMON SPECIFICATIONS SAR : - • ROLLER SURFACE SPEED : - 75 mm min to 1500 mm min • DRIVE : - Variable Speed A. C. Motor (A.C. VFD) • FOR JOB DIAMETER : - 500 mm – min. 8000 mm – max. JOB DIAMETER VARIES ACCORRDING TO LOAD CONDITIONS. NOTE : - CUSTOMISED SELF CENTERING ROTATORS MAY ALSO BE PROVIDED APART FROM OUR STANDARDS.

  Salient Features:   Rotators mainly consist of drive, idler, electrical controls Rotators are used for the inside and outside circumferential and longitudinal welding The distance of rollers can be adjusted automatically according to the diameter of workpiece VFS speed control, or a simple gear box drive, as per customer choice. It is stable and precise Rubber, steel or PU wheels customers choice The roller wheel consists of specialized heavy duty tyres made up of 650 dural hardness AC or DC Motor – Ensures constant speed with outer balance loads of 15% Drive system with hi-stress rubber cushion mounts to absorb shock loads and prevent gear box damage.

Hurliman Casters Corp. offers wheels casters castors made from Hard-rubber, Neoprene, Advanced Elastomers, Mold-on rubber and Polyurethane, Thermoplastic rubber, Phenolic, Polyolefin, and cast iron semi steel materials.Our custom formulated Neoprene outlasts and outperforms ordinary rubber wheels. Available in all sizes, either in black or non-marking gray, and combined with either ball bearings, roller bearings, or self-lube bushings.Hurliman Casters Corp. an ISO 9001:2000 certified company :is a specialized manufacturer and exporter of high quality Self Rotator Wheel. Also known by the names of Self Rotator Wheel , Self Aligning Rotator Wheel, Self Rotatory Wheel, Wheel Rotator,PU wheels self-alignment welding rotators,Welding Rotators wheel.

AMIN’s Traversing Rotators (Conventional / Self Aligning) follow the well established reputation of their static counter-parts for ease of use and reliability. We are providing an economical and practical platform for all cylindrical vessel rotating problems. The Traversing Rotator ranges are all bogie mounted to carry vessels of various lengths, and to allow for traversing, in addition to rotation at the work site. Traversing Rotators are built to the highest standards with quality materials and components : - Robust, all-steel construction- Inverter controlled traversing and rotation at welding speeds.- All rollers of the Drive Section positively driven. Whatever your requirement – large or small, short or long – you will find that AMIN has the solution in Stationary or Traversing Rotators.

Self Aligning Rotators automatically adjust the Roller Housings to accept any job diameters within the specified diameter range. These types of machines are generally used to cope with the increased production demands. The roller housings of this type of machine are hinged to the beds and open up automatically when a larger diameter job is introduced. In this type of rotator, each Roller bracket assembly has two separate roller assemblies, and this supports the job on a wider area. The final drive is given to all the 4-sets of rollers of the Drive Unit in special models, providing better traction to the job. However, in that case a de-clutching arrangement is provided to the top rollers, in order to protect the gear boxes, as when the job hits the top rollers first while loading, forcing it to rotate via. the self locking gear box. Both the rollers automatically get adjusted for all job diameters. Accepts complete range of job diameters in one setting. Center axis of job remain stable for all job diameters. Wide range of Job diameters and Load capacities. Most suitable for 'thin walled' shells of large diameters. 'Four roller' contacts gives superior 'slip free' traction for thin walled vessels. Proven reliability and higher productivity. Most accepted design for very busy fabrication shops. Ideal design for using in conjunction with Column & Boom. Better acceptability to ovality of vessels compared to other models.

• Model: SAR 005
• Load Capacity:: 2.5 Metric Ton (1 power & 1 idler)
• Rotation Capacity: 5 Metric Ton (1 power)
• Rotation Speed: 100 to 1000 mm/min

In order to ensure that both the tyres are driven together by an AC gear fitted with inverter control box, Thakur Industries has designed Self Aligning Rotators. The operator has full control of the rotator i.e. a potentiometer for varying the speed, start or stop, forward or reverse and stop in case of emergency by a hand held low voltage control pendent on a 10-meter cable.
