Semikron Thyristor Module Dealers

• Frequency: 50- 60 Hz
• Voltage: 220- 240 V
• Power: 2000 W
• Brand: Semicron
• Mounting Type: SMD
• Package Type: Box
• Usage/Application: Industrial
• Current Rating: 20- 400 A

• Brand: IXYS
• Model Name/Number: MCC501-16io2
• Maximum Operating Temperature: 500 Degree C
• Package Type: BOX
• Surge Current Rating: 500 A
• Current Rating: 160 A

• Type: Thyristor Module
• Application: Electrical Use, Electronic Use, Machinery Use
• Brand Name: SEMIKRON

A thyristor is one of the several controllable semi conductor devices that can act either like a switch, rectifier or as a voltage regulator. The thyristor is a solid-state analogue of the thyratron vacuum tube. The name ‘thyristor’ is a combination of two words – the thyratron and the transistor. A thyristor functions a little like a transistor. It consists of three electrodes: the gate, the anode and the cathode. The gate acts as the controlling electrode. When a small current flows into the gate, it allows a larger current to flow from the anode to the cathode. A thyristor can be switched from a blocking state (high voltage, low current) to a conducting state (low voltage, high current) by a suitable gate pulse. Forward conduction is blocked until an external positive pulse is applied to the gate terminal. A thyristor cannot be turned off from the gate.

• Features: High strength, Durability, Heat resistance

• Brand Name: Shreem
• Country of Origin: Made in India
• Maximum Operating Temperature: -10 DegreeC to 50 DegreeC
• Mounting Type: Panel Mount
• Package Type: Box packaging
• Repetitive Peak Reverse Voltage: 1800V

• Part Number: SKKT 273/22 E
• Maximum Operating Temperature: 130 Degree C
• Country of Origin: Made in India
• Brand: Semikron
• Mounting Type: DIN
• Repetitive Peak Reverse Voltage: 1.2 kV

Thyristor modules feature combinations of SCR and Diode configurations in an electrically-isolated base- plate construction that allows for mounting with other components on a common heat-sink without additional clamping or insulation components being required. Thyristor modules are designed for medium and high current power control applications. Featuring electrically isolated package that simplifies system packaging, installation and cooling..

• Part Number: SKKD101/16
• Current: 101 A
• Brand: Semikron
• Mounting Type: DIP
• Repetitive Peak Reverse Voltage: 1600 V

• Voltage: 400V
• Weight: 170g
• Brand: Sun Rex
• Maximum Operating Temperature: 150 Degree C (Max)
• Model Number: PWB130A40

• Part Number: SKKT92/16E
• Maximum Operating Temperature: 85 Degree C
• Brand: Semikron
• Mounting Type: Screw Mount
• Surge Current Rating: 1600 A
• Rated Average On-State Current: 92 A
• Repetitive Peak Forward Blocking Voltage: 1600 V

• Rated Voltage: 415V, 3ph, 50Hz.Z
• Operating voltage: 110 V -500 V [L-L]
• Controller Current: IN/5 Amp or IN/1 Amp.
• Display: Single Line 16 char./4 Line 20char.alphanumeric LCD
• Weight: 900 gms. (Appox.)
• Mechanical arrangement: IP 54
• Mounting Orientation: Vertical with attachable clamping screw terminals.

Main Features : Highly Sensitive. Accuracy Class I. Auto CT Synchronization. Intelligent Multi Method Switching (MMS)Algorithm. Four Quadrant Measurement. Data memory-45 days on hourly basis. Communication port RS-232/485. 2 / 4 Line LCD Display with backlit. Energy Pulse Output. Plug & Play Operation. Computerized Test & Calibration Report. Payment Lock Facility. Plug in Terminal. IP-54 Degree of Protection   LT APFC RELAY- An inteligent high speed DSP + Microprocessor Based device to measure, calculate, display and store all electrical network parameters. In built Intelligent Multi Method Switching (MMS) Algorithm enables user to get close control on network reactive power requirement. Multi Method Switching (MMS) Algorithm allows user to set different target power factor for Diesel Generators and Windmill Stations. A built in self test facility provided for checking calibration and operation of the relay without external load. The control functions even at low operating loads with great accuracy   GB Control’s APFC controller find usage and applications in all segments of industry viz Automobile Factories, Cement Plants, Chemical & Fertilizer Plants, Metal Industries, Hospitals, Windmill Power Stations, D .G. Stations etc.   The other built in features viz Over Voltage Protection, Low Voltage Protection, Under Load Protection, Over Load Protection High Temprature etc. provides nonstop operation of APFC System.   Display Parameters : Voltage, Current, Power Factor, Active Power (KW), Apparent Power (KVA) Reactive Power (KVAR), Capacitive Reactive Power (CKVAR) Active Energy (KWH), Apparent Energy (KVAH), Reactive Energy (KVARH) Real Time, Date, Network fault message display Capacitor bank status display, Load side Parameters viz. Current, P.F. & KVA.   Protections :              Controller offers protections in the following situations. High voltage, Low voltage,            Over-load,Under-load,Voltage Imbalance, Load Current Imbalance, Over Capacitor            Current, Capacitor Current. Imbalance, Over Temperature.   Programmable Parameters : Target Power Factor - 0.90 lead to 0.85 lag. Time Delay (TD) – 0.1 Sec. to 255 Sec. CT Ratio – Current Transformer ratio to observe actual load current. PT Ratio – Potential Transformer ratio to observe actual Line Voltage. No. of Steps – 1 to 16 Capacitor steps. Capacitor Step Rating. Display Scroll time delay. Capacitor’s discharge time.   Operating Mode : Automode / Manual Mode / Programme Mode / Standard Mode. Compensation Mode : Average / Maximum / Minimum of Load Kvar Basis. Memory Storage : 45 Days on hourly basis.

• Type: Thyristor Module
• Certification: CE Certified
• Application: Electrical Use
• Voltage: 440V
• Condition: New
• Phase: Three Phase

all kinds of igbt thyristor , igbt driver card.

• Brand Name: Semikron
• Part Number: SKKH 42
• Switches: 2
• VRRM / VDRM in V: 800-1800
• ITAV / IFAV in A: 40
• IFSM / ITSM in A: 850
• Features: Heat transfer through aluminium oxide ceramic isolated metal baseplate,Hard soldered joints for high reliability,UL recognized, file no. E 63 532

• Voltage: 230 V
• Country of Origin: Made in India
• Mounting Type: SMD
• Model Name/Number: SKKD
• Brand: Semikron
• Usage/Application: AC Inverter Drives
• Packaging Details: BOX

• Brand Name: Semikron
• Weight: 120 g
• Part Number: SKKH33016
• Maximum Operating Temperature: 50 Degree Celsius
• Repetitive Peak Reverse Voltage: 2600 V
• Surge Current Rating: 1200 Amp
• Dimention: 115 x 49 x 50 mm

• Power: 1.7kW
• Part Number: SKKD81/16
• Maximum Operating Temperature: 62 Degree Celsius
• Brand Name: Semikron
• Application: Industrial
• Voltage: 1.55 V
• Current: 140A

• Type: Thyristor Module
• Application: Electrical Use, Electronic Use, Machinery Use
• Weight: 0-50gm, 100-150g, 150-200gm, 200-250gm, 250-300gm, 300-350gm, 350-400gm, 400-450gm, 450-500gm, 50-100gm
• Color: Blue, Grey, Light White, Metallic, Silver, White
• Voltage: 110V, 220V, 380V, 440V, 525V
• Condition: New, Old
• Power Type: AC, DC
• Operating Temperature: -25 +85deg C, -40 +70deg C, -45 +55deg C, -70 +40deg C
• Frequency: 50Hz, 60Hz, 90Hz
• Driven Type: Battery, Electric
• Feature: Auto Controller, Dipped In Epoxy Resin, Durable, High Performance, Stable Performance

The converter grade thyristor range extends upto 4350Amps with PIV upto 2800V incorporating standard packages of 14" unf stud in to hat range to 3"in capsule type. The inverter range is divided into two distinct types. One meant for standard low frequency inverter upto 4350 amps and 2800 volts and the other for high frequency applications such as induction heating and high frequency welding. The high frequency range has thyristors upto 1200 amps with voltages upto 2000 volts., 'turn off' times as low as 10 microsecs.

INSEL Rectifiers India Thyristors may also be necessary to act in the opening switch mode as well. Such applications may contain those where voltage is reapplied to the pulse power switch shortly after closing and the switch needs to have improved blocking capability or the transfer energy needs to be controlled. In these applications, the switch needs to have turn-off capability to decrease the natural turn-off time (tq) of the device. The device is operated in GTO mode with the suitable commutating gate drive. Thyristors may be used to bond a source of stored energy, such as a capacitor to a load, or to bypass and protect the load in the case of a crowbar circuit. In these pulsed power applications where the rate of rise of current is very fast, the pulse power switch is acting as a closing switch and ordinary phase control thyristors (SCRS) are probable to fail due to the high didt experienced?

• Capacitor: 5 to 100KVAR
• Dc Signal: 12/24 VDC
• Weight: 5.5 KG
• Thyristor Type: Switch
• Minimum Order Quantity: 1 Unit
