Sensor Pavers Dealers

ESP-045 is a wheel mounted sensor paver finisher for those who want better performance compare to mechanical pavers at a very economical rate. ESP-045 offers ease of operating and maintaining it.Smaller, stronger, and economical sensor paver finisher model ESP-045 comes with hydrostatic transmission, hydraulic drive for conveyor, sliding type control panel, dual operator seats, 2 nos. rear wheels, hydraulically extendable screed with vibration and heating facility, and MOBA (Germany) make sensor device.ESP-045 has basic screed of 2.5 meters width and it is hydraulically extendable up to 4.5 meters.

We offer Electronic Sensor Paver. Material Laying Capacity: 300 TPH Engine Power: 125 hp Screed size: 2.5m to 5.5m Wheels on rear axle: Two on each side Electronic Sensor: MOBA, Germany Opertor Seat: Double For more details visit our website: http:www.uniter.inpavermachinesvp-05

• Country of Origin: Made in India
• Weight: 15240 kg
• Capacity: 5.5 METER
• Brand: FABHIND
• Usage/Application: Road Construction Work
• Model Name/Number: FAB-550 W
• Automation Grade: Automatic
• Operating Height: 3430 mm
• Shipping Height: 2520 mm
• Total Length: 6610 mm
• Operating Width: 3140 mm
• Shipping Width: 2540 mm
• Tyre Centre Line: 2080 mm
• Truck DumpingClearance: 485 mm
• Wheel Base: 2610 mm
• Screed Type: FH4500
• Screed Basic Width: 2500 mm
• In???nite Variable Extension: 2500-4500 mm
• Bolton Extension: 5750 mm (max)
• Screed Weight [main]: 2890 mm
• Bolton Extension Weight: 210 kg [625mm]
• Crown: -1.0 to + 4.5 %
• Gradient Slope: 10% gradient slope
• Screed Vibration: 30-50 Hz
• Tamping Stroke 5 mm: 18-27 Hz
• Screed Plate: 320 x 12 [wear resistant]
• Screed Heating: Diesel operated burner

Offering you a complete choice of products which include SENSOR PAVER FINISHER IN INDIA such as Bottom Plate, Conveyor Sprocket Assembly, Screed Plate, Tempar Bar, Chain Guard, Conveyor Chain and many more items in Sensor Paver Finisher

• Condition: New
• Application: Road Construction Work
• Country of Origin: Made in India
• Engine Output: 125 HP, 2300 RPM
• Power Steering: Yes
• Machine Type: Fully Automatic

High precision cylinder finisher for concrete slabs such as Streets, Parking, Factory floors, Bridges, Airports, Tennis Courts, Canal, Reservoir etc. It can finish a width from 3.5 mtrs. To 20 mtrs. ( It is a custom design paver ) Machine can finish a width up to 180 Sq. Meter/hour at suitable site condition. The special under carriage consists of a spreader extra length auger to spread the concrete to level, the finishing cylinder to compact and finish the concrete to the grade. Finishing roll bracket is equipped with Electric vibrator. Heavy Duty Track Chain, Heavy Duty Hydraulic Jacks & Moba Make Electronic Sensor Technical Specification PRIME MOVER (With Needle Vibrator) 15HP 1440-RPM for Fix Console.20HP 1440-RPM for under carriage PRIME MOVER (Without Needle Vibrator) 15HP 1440-RPM for Fix Console.7.5HP 1440-RPM for under carriage Fix Console This hydraulic console controls the forward and reverse movement of the under carriage and the travel track chain by means of hydraulic motors. Under Carriage/Finisher Assembly Under Carriage accommodates the most critical components of the machine. It encompasses the vibratory finishing drum, Spreader AugerHydraulic Needle Vibrators(Optional) The Under Carriage travels with a speed 30 meters/ minute. Vibratory Finishing Drum The finishing drum is 4 feet length and 10.7 inches (272mm) in diameter. It rotates at a speed of 195 rpm. The finishing drum vibrates at 1500 vpm. This drum is precisely balance with the help of computerized balancing system to obtain quality finish. Spreader Auger The Auger is welded with hard faced welding to obtain maximum life. The auger is designed to work in the direction of travel movement to the machine. Traction System Heavy duty hydraulically driven Track Chain. Sensor Gradation Moba ( Germany) Make Electronic Sensor system to obtain maximum accuracy. Jack System Heavy duty hydraulic jack system. Hydraulic Oil Capacities Fix console: 110 Liters.Under carriage: 140 Liters.

Electronic Over Hydraulic control system for steering and remote grade sensor (Moba-Germany). Control panel with monitor gauges and Heavy Duty Hydraulic elevation Jacks.MACHINE is equipped with crawler tracks or foam-filled rubber flotation tyres provided to increase the efficiency on any project where the surface of the concrete requires texturing and application of curing compound.Our product range includes a wide range of Sensor Texturing Machine and Electronic Concrete Sensor Paver.

• Country of Origin: Made in India
• Features: Durable , Optimal performance , Easy to install.
• Usage/Application: Road Construction Work
• Automation Grade: Automatic

• Condition: New
• Brand Name: Dhwani
• Application: Road Construction Work
• Model/Type: Sensor Paver

• Weight: 12000 KGS
• Brand: VOLVO
• Usage/Application: Road Construction Work
• Model Name/Number: P4370
• Automation Grade: Automatic
• Voltage: 24V
• Driven Type: SELF
• Operating Width: 12M
• Engine Make: D5 VOLVO
• Engine Output: 118 HP
• Paving Thickness: 300 MM
• Paving Speed: 45 M/ MIN MAX
• Travel Speed: 14 KMPH
• Hopper Capacity: 12000 KG

• size: 480 mm

Paver Chains are widely used in all paving applications of Road Industry in different models of Pavers where all the brands of Pavers have their own unique sizes and designs. "Tripcon" brand paver chains are available for all kinds of Pavers.

• Weight: 1000-2000kg,2000-3000kg,3000-4000kg,4000-5000kg
• Condition: New,Used
• Warranty: 1year,2years,5years
• Certification: CE Certified,ISO 9001:2008
• Color: Grey,Light White,Blue,Light Green
• Application: Constructional
• Voltage: 110V,220V,380V,440V
• Power: 1-3kw,3-6kw,6-9kw,9-12kw,12-15kw
• Automatic Grade: Automatic,Fully Automatic,Manual,Semi Automatic
• Driven Type: Mechanical

Hydrostatic paver finisher with eectronic sensor device and backed with proven technology.Variable displacement motor and pump for infinity paving and travel speeds. No mechanical shifting either in the pave or travel mode-effortless selectio through finger tip control. limiteeee mechanical parts,hense very low maintence and service needs.Hydrolically extendable screed is from 2.5 mtr. to 4.5 mtrs. in standerd supply,and optional mechanical extention for higher widths.tamping and vibration in line with M.O.S.T, specification. heating arrangement ( LPG HEATING OPTIONAL) to avoid sticking of bituman on the screed surface at start up time.

Smooth operations.High performance. High efficiency through lubricating process. Easy and low cost maintenance. Simple and time saving installation. Hydrostatic Transmission Engine Power 76 HP @ 1800 rpm Laying Capacity 180 TPH Hopper Capacity 4.5 M3 Paving Width 2.5 to 4.5 mtr. Weight 10 Ton kg Tyre Front Solid Rubber 4 No. Four Wheels on Rear Axle Brake System : Earth moving Heavy Duty Calliper Disc Brake Innovatively designed Conveyor Chain Drive Sprocket (EN8620 grade) Conveyor & Augur Drive HRC Belt, Hydraulic Scree Leveling Hydraulic Operated All Chain Drive Gear Box Oil Bath Double Operator Seat (Optional) This Paver comprises of : FINOLEX Cables, REXROTH Hydraulics, LUCAS Lamps Manufactured with AUTOMOTIVE parts, AVAILABLE Pan India. Layer of wearing courses, binder and special asphalts. National Roads Country Roads Municipal Roads Building lots Big squares and courtyards Motor ways Air Fields Port area Cities’ streetss Gravel Footpath Cycling Track Narrow Roads Parking Lots Property Entrance

Due to our excellent Construction solutions, the customers can find our values defining high level of professionalism in every industry. In our offerings of outstanding and ever-ready Construction Solutions, we give material, technical and machinery guidance skillfully. The manpower services we provide add to the efficiency of every dream place. All these services are available at nominal prices without making a time lag. To provide comfort to the clients, we offer various modes of payments and spot the specified location they are required. The solutions we provide are essential for brightening the future of construction and build an excellence. As we are skilled in the volume and complexity of construction knowledge, we provide accordant, correct and safe methods of them. Believing in sharing the best exercises for each building purpose, we also help in reducing the risks of renovation projects.

• Condition: New
• Brand/Make: Kesar
• Automation Grade: Automatic
• Capacity: 300 Tons/hour
• Is It Portable: Portable
• Width (m): 2.5 meter to 4.5 meters
• Power Steering: Yes

• width: 7 m

Asphalt paver was developed by Barbar Green Co that originally manufactured material handling systems. In 1929, the Chicago Testing Laboratory approached them to use their material loaders to construct asphalt roads. This did not result in a partnership but Barber Greene did develop a machine based on the concrete pavers of the day that mixed and placed the concrete in a single process. This set-up did not prove as effective as desired and the processes were separated and the modern paver was on its way. In 1933, the independent float screed was invented and when combined with the tamper bar provided for uniform material density and thickness. Harry Barber filed for a patent a ¨machine for and process of laying roads´ on April 10, 1936 and received patent on December 6, 1938. The main features of the paver developed by Barber Greene Co have been incorporated into most pavers since, although improvements have been made to control of the machine.Further, the country´s thrust on developing roads in the North-East and far flung rural areas of the country entails a new breed of small asphalt pavers to enter the road construction sector. These pavers will be required to address the challenges of flexible operational width and diverse (sometimes extreme) climatic conditions, easy transportability, steep gradients in hilly terrains without compromising on optimum performance characteristics. Innovative technologies and engineering are expected to play a major role in such pavers.

Vinayak road equipmenttakes immense pride in introducing itself as the well-established manufacturer and supplier of Sensor Paver in Ahmedabad, India. It is also known as hydrostatic paver finisher. Our sensor paver is available in two variants wheel mounted and crawler track mounted. We offer our paver machine structurally stable dimensionally accurate and good engineered. These mostly used paving the surface of roads, river, airports, highways etc. The sensor paver machine is available for various work like asphalt paver, concrete paver, slip form sensor concrete road paver, concrete road paver. We offer this at market leading price. In addition to this, we maintain strict quality inspection to deliver a flawless and damage free Sensor Paver at our clients end. Features Easy to shift Better performance Compact design User friendly

550 HSD model of finisher paver holds an extension of screed is hydraulic to a width of 4.5 meters and half meters on each side is of bolting type by removing the time taken in fixing the balance of liner plates. For better results,we have made this model offering high torque and low speed. The drives used in the manufacturing are oiled forseamless operations and lubrication process to boost the performance of the machine. Select the paver variant as per the road construction requirement to acquire the best-in-class results. HIGHLIGHTS   Smooth operations.High performance. High efficiency through lubricating process. Easy and low cost maintenance. Simple and time saving installation. SPECIFICATION   Hydrostatic Transmission Engine Power 76 HP @ 1800 rpm Laying Capacity 180 TPH Hopper Capacity 4.5 M3 Paving Width 2.5 to 4.5 mtr. Weight 10 Ton kg TyreFront Solid Rubber 4 No. Four Wheels on Rear Axle Brake System : Earthmoving Heavy Duty Calliper Disc Brake Innovatively designed Conveyor Chain Drive Sprocket (EN8620 grade) Conveyor & Augur Drive HRC Belt, Hydraulic Scree Leveling Hydraulic Operated All Chain Drive Gear Box Oil Bath Double Operator Seat (Optional) This Paver comprises of : FINOLEX Cables, REXROTH Hydraulics, LUCAS Lamps Manufactured with AUTOMOTIVE parts, AVAILABLE Pan India. APPLICATIONS   Layer of wearing courses, binder and special asphalts. National Roads Country Roads Municipal Roads Building lots Big squares and courtyards Motor ways Air Fields Port area Cities’ streetss Gravel Footpath Cycling Track Narrow Roads Parking Lots Property Entrance
