They are quick, efficient, continuous and less labour intensive. They can be used for drying wet cake/granular having up to 80% moisture but material should have charecrisitc of free following after drying.STANDARD FEATURES The material is feed in mixture, which disintegrates it into smaller lumps, which are then feed into drying chamber by variable feeder,driven by geared motor, having specially designed stirrer. The Hot Air enters the drying chamber and under high turbulence condition, drying process starts. The dried material travels upward in drying chamber under influence of process blower and is separated in cyclone and bag-filter. The material of construction is M.S., S.S, and Aluminum depending upon process requirements. The process air is heated by any of the option:- steam ,thermic fluid ,hot air generator, working on eighther oil, or gas or solid fuel f. The drying capacity up to 800 kg/hr moisture removal rate is offered as standard equipments

spin flash dryer spin flash dryer consist of rotor at conical base of drying chamber fluidised product particles in a drying efficient hot air flow pattern in which any wet lums are rapidly disintegrated. hot air is supply by temperature control hot air generator and speed control fan entering in drying chamber tangentially in order to establish a turbulent, whirling airflow. backed by the support of our experienced professionals in this domain, we have been able to bring forward a qualitative range of spin flash dryer system. the provided dryer system is well manufactured by our experienced professionals using the best quality raw material and modern technology. offered dryer system is widely acknowledged among our clients owing to its long working life and zero maintenance. moreover, our clients can avail this dryer system at most affordable price. advantages of spin flash dryer: high drying efficiency providing low energy cost continuous processing with short processing time low operator overhead and minimum maintenance cost control residence time enabling high temperature drying control particle size capacity range: 10 kghr to 10000 kghr applications: starch powder starch derivatives dyes intermediates h acid bentonite china clay minerals dry distillet grain soluable (ddgs) kumkum gamma acid

At ADVANCED DRYING SYSTEMS, we claim the credit of Manufacturing and Exporting premium quality Spin Flash Dryer, which is extremely suited for drying applications in case the wet cake is a paste or sludge. Equipped with a mechanical agitator, it helps to disperse the wet cake without any requirement for back mixing of the dry powder. We offer our Spin Flash Dryer at competitive prices. Components of Spin Flash DryerFeed tank with agitator and a screw feederCylindrical drying chamber for drying processTangential air distributor of special design directs air in an intense swirl flow Used inPharmaceutical industriesChemical industriesFood industries

Our Spin Flash Dryer is a pneumatic system primarily used as an inexpensive solution for drying powders and granular. We are reputed Manufacturer, Supplier and Exporter of Spin Flash Dryer from Andhra Pradesh. These Spin Flash Dryers are used to dry products in many industries including food, chemical, mineral and polymer. A broad range of feed materials including powders, cakes, granules, flakes, pastes, gels, and slurries can be processed in our Spin Flash Dryer.

• Material: Stainless Steel
• Weight: 50 Ton
• Voltage: 350 V
• Power: 120 Kw
• Warranty: 1 Year
• Drying Temperature: 350±30℃

Advantages Energy consumption is much less than spray dryers, fluidized bed dryers, flash dryers, rotary dries, tray driers etc. Space requirement for installing this dryer is much less than spray dryer, pneumatic dryer, fluidized bed dryer and rotary dryer etc. It is a completely automatic plant with temperature controller etc. Dry product discharge section of the dryer can be installed in your product packing section, hence cost of transport of dry product to the finished product section can be eliminated. Pulverizing after drying will not be required. The unit will dry, classify and convey all in a single operation. Wet cake can be directly fed from filter/centrifuge to lump breaker bin, which feeds the cake in to the dryer and hence all intermediate handling of material can be eliminated. The entire system is closed and hence any chance of contamination is eliminated. Since it is a closed system, wastage and dusting etc. are totally eliminated resulting in clean environment, zero wastage and total recovery of product and pollution free atmosphere. It is possible to vary the bulk densities also by minor changes in the classifier situated near the top of the dryer. Feature High drying efficiency and low energy costs. The energy efficiency of such systems is up to eight percent, which is very high for such types of drying systems. Direct drying and no initial diluting. Continuous processing with short drying time. Ideal for replacing conventional drying systems such as Fluid Bed Dryers, Pneumatic Flash Dryers etc. Pulverizing, conveying, classifying etc. can be done on the same system. Space utilization is most economical and operations are totally automatic. Most of the time, the product can be directly bagged or sent for further processing. Self-regulating, self-adjusting system, which involves minimal attention even while operating at capacity. The system being under negative pressure, there is no dusting and therefore no wastage. The area is free from environmental hazards. Clean operation with minimal manual handling is an important feature of the system. Application Direct contact dryers for bulk drying of various products such as inorganic chemicals, bulk drugs, dyestuffs, insecticides foodstuffs etc. Chemical industry products like Zinc Carbonates, Calcium Carbonate, Magnesium Carbonate, Cobalt Carbonate, Zirconium, Red Ferric Oxide, Aluminum Hydroxide, Lead Sulphate, Zinc Sulphate, Fire retardant Super - fine Calcium Carbonate, Zinc Oxide, Barium Sulphate, kaolin, Pigment, Dyestuff, Pesticide, Mancozeb etc.

• Frequency: 40-50Hz
• Power: 10kW
• Specialities: Precisely Designed
• Motor Power: 10HP
• Type: Spin Flash Dryer
• Brand Name: cybernetik
• Material: SS
• Certification: ISO 9001:2008
• Condition: New
• Finishing: Polished
• Power Source: Electric
• Automatic: Automatic
• Phase: Three Phase
• Warranty: 1 Year
• Country of Origin: India
• Color: ss
• Usage: drying of powders

With the help of our competent professionals and state-of-the-art infrastructure facilities, we pertain to manufacturing, supplying and exporting high quality Spin Flash Dryer. Developed with set industry standards, our dryer is ideal for continuous drying of viscous liquids and cohesive & non-cohesive pastes. Post production, our team of quality controllers checks this dryer on various quality parameters to ensure flawlessness. Made using supreme quality raw materials, our Spin Flash Dryer is highly acknowledged for easy installation, high efficiency, extended service life and low maintenance.

• Material: Mild Steel
• Type: Flash Drying Equipment
• Voltage: 380 V
• Max Height: 5.5m

We at, UNIVERSAL PROCESS ENGINEERS PVT. LTD are engaged in the innovative designing of a new range of Spin Flash Dryer dryer characterized with steam for hot air generating which helps in reducing the drying cost. Primary industries use LDO (Fuel) for hot air generating but it is much expensive then hot air generated from steam. Features InnovativeAdvanced technologyCost-effectiveHassle-free Uses Starch industries

Tunnel and cupboard dryers are inherently costly to run, occupy a larger floor space, involve higher number of manual labor and yet the drying rate is slow with much lower thermal efficiency. Compared to this, the FLASH DRYER in its simplest form of mechanical design; is merely a Hot Air Conveyor into which solids, if reasonable free flowing, may be dropped. The material then gets dispersed, thus exposing maximum surface to the drying process. This leads to a very rapid drying rate and the time required is in seconds and not in minutes or hours. Due to the short exposure time and rapid evaporation of water, even though high temperature is employed; the material remains at wet bulb temperature (W.B.T.) until all traces of surface moisture is removed. Thus it is possible to employ high inlet temperature, may be up to 700 C, without affecting the quality of the material, which may even, if it is a heat sensitive one.

Spin Flash dryer are designed for continuous drying of pastes and filter cakes. The main components of our spin flash dryers are a feed system, the patented drying chambers, and the bag filters. This system consist of feed vat and screw feeding system which is used to deliver or feed the material into the spin Bowl OR drying chamber where the product is buffered and fragmented by an agitator prior to continuous drying. A variable speed is kept of feed screw to control the discharge of feed. The rotor of the drying chamber fluidizes product particles in a drying efficient hot air flow patterns in which any wet lumps are rapidly disintegrated. Hot air comes from temperature controlled air heater, entering the drying chambers at a tangent in order to establish a turbulent, whirling air flow. Powder from the drying chamber is controlled in bag filter or cyclone Seperator while the outlet air leaves the system at the top suction fan, called I.D. fan. Advantage same as flash dryer.

Spin flash dryer Blessed and supported by the team of adroit professionals, our company is considered as one of the eminent manufacturers and suppliers of Spin Flash Dryers which are widely used for drying of wet cakes and pastes which are sensitive to heat. It consists of a horizontal agitator, which disperses the materials while it comes in contact with the hot air and gets dried.

• Specialities: High drying efficiency and low energy costs.

Spin Flash Dryer is used for effective and efficient method of removal of surface or on bound moisture from a feed product. Spin Flash Dryers are designed for continuous drying of cohesive and non-cohesive pastes, filter cakes and high viscosity liquids. Under the action of hot air and mechanical dispersion, the wet cake appears granular and gets fluidized. Instantaneous exchange of heat and mass takes place. The dried product is conveyed through the conveying duct in which additional drying takes place.The spin flash dryer system consists of double shaft screw followed by mono screw to feed homogenized material into dryer housing at controlled rate. Hot air is supplied by a temperature controlled air heater and speed controlled fan, entering the drying chamber at a tangent in order to establish a turbulent, whirling air flow. The rotor at the base of the drying chamber fluidizes the product particles and dispersed using the heat from the air stream; the material dries as it is conveyed. Drying takes place in a matter of seconds. The particle classification orifice on the top of drying chamber allows finer product to pass with exhaust gas to powder collection system while the larger particles remain in the air flow for further drying and powdering. Elevated drying temperatures can be used with many products since the flashing off of surface moisture instantly cools the drying gas without appreciably increasing the product temperature.

 Spin flash dryer is useful for drying the wet cake at moderate temperature of process air and specific particle size is not required, Pharmaceutical products Bulk drugs like activated /precipitated calcium carbonate Aluminium hydroxide, magnesium hydroxide Metallic Stearates Dyes & pigment industries and Chemical industries.

We are offering spin flash dryer is ideal for drying of wet cake, slurry, paste which is normally difficult to dry in other dryers. The material is fed by screw feeder through a variable speed drive into the vertical drying chamber where it is heated by hot air and at the same time disintegrated by a specially designed disintegrator. The heating of air may be direct or indirect depending upon the application. The dry powder is collected through cyclone separator bag filter or with combination of both.

To fulfill the divergent needs of our valued clients, we are betrothed in offering Spin Flash Dryers. Use for continuous drying of cohesive and non-cohesive pastes, these dryers are Pramoted by using supreme quality material & coated with powder from feed, which is viscous. Offered dryers are highly applauded for its flawless range. We are giving these dryers to our patrons in customized options. Features: Require less maintenance Easy to operate High efficiency Other Details: Function and principle of operation Spin Flash dryers are designed for continuous drying of cohesive and non-cohesive pastes and filter cakes, as well as high-viscosity liquids The main components in a complete Spin Flash Drying System are a feed system, drying chamber, bag filler and Exhaust Blower The feed system consists of a feed vat where a discontinuous flow of product is buffered and fragmented by an agitator prior to continuous drying A variable speed feed screw (or pump in the case of fluid feed) forwards the product to the drying chamber Drying chamber The disintegrater at the base of the drying chamber fluidizes product particles in a drying-efficient hot air flow pattern in which any wet lumps are rapidly disintegrated Hot air is supplied by a temperature-controlled air heater and speed-controlled fan, entering the drying chamber at a tangent in order to establish a turbulent, whirling air flow Airborne, fine particles pass through a classifier at the top of the drying chamber, while larger particles remain in the air flow for further drying and powdering The drying chamber is rigidly designed to withstand pressure shock in the event of explosive combustion of flammable particles All bearings are effectively protected against dust and heat Bag filter Powder from the drying chamber is collected in a bag filler, while the outlet air leaves the system at the top via a suction fan

• Type: Spin Flash Dryer
• Certification: ISO 9001:2008
• Weight: 100-1000kg
• Voltage: 110V, 220V
• Condition: New, Used
• Power: 1-2kw, 1-3kw, 10-12kw, 2-4kw, 3-6kw, 4-6kw, 6-8kw, 6-9kw, 8-10kw, 9-12kw
• Warranty: 1year, 2years
• Driven Type: Electric
• Automation Grade: Automatic, Fully Automatic, Semi Automatic

When huge quantities of wet cake/paste as obtained after solid-liquid separation process from centrifuge/filter press needs to be dried quickly then Spin Flash Dryer is the best option as a continuous drying operation. The feed cake from feed vat is fed by screw conveyor into the drying chamber where hot air from Hot Air Generator carries the particles of wet cake upto cyclone and/or bag filter.   The dry powder is collected at bottom through Rotary air lock valve and the air with water vapour is sent out through chimney via blower. Complete SFD is operated through electric panel including safety features

We are Spin Flash Dryer System Manufacturers.There are most practical constant drying systems of consistent and non-consistent filter pressing cakes, this type of dryer can handle moisture content up to 20 – 70 %. As a direct drying process, materials are brought into contact of hot and dried air. This system made by Prochem Systems (India) Pvt. Ltd offers the advantages of very low labor and handling costs.
