Stepper Motor Controller Dealers

We are offering an exclusive range of Stepper Motor Controller. The provided stepper motor controller is widely used to control the operations of stepper motor. This stepper motor controller is highly demanded among our clients for its less maintenance and long operational life.

• Type: Stepper controller
• Weight: 10-20kg
• Color: Green
• Voltage: 6-24vdc
• Condition: New
• Automatic Grade: Automatic
• Warranty: 1year
• Country of Origin: India
• Brand Name: Tiny Controls
• Output Type: 5v
• Input Voltage: 6-24vdc

We are dependable provider of stepper motor driver (caw). The stepper motor driver, offered by us, is made from high-grade components and materials to ensure its excellent performance and longer working life. The stepper motor driver can be availed from us at the most competitive prices. characteristics : dc power input type : 24v ~ 50vdcoutput current : 1.3a-4.5amircostepping : 1(1.8o), 12, 14, 18, 116, 132, 164, 1128, 1256, 15, 110, 125, 150, 1125, 1250protect form : overheated protect, lock automatic half current ,error connect protectdimensions : 118mm × 76mm × 33mmweight : < 300gworking environment : temperature -15 ~ 40o) humidity < 90% io ports : vcc+ : dc power positive polegnd : dc power cathodea+, a- : stepping motor one windingb+, b- : stepping motor other windingpul+, pul- : stepping pulse input+5v (rising edge effective, rising edge duration >10μs)dir +, dir- : stepping motor direction input, voltage level touched off,high towards, low reverseena+, ena- : motor free note : when ambient temperature is high or working current over 2.7a, fix the module on big metal shell , or use axle flows fan dispels the heat, to make the module run reliably for a long timehalf current automatically : if control machine not send out signal in half second, driver enter half current state of automatically for electricity saving, the phase current of the winding of the electricthe fault phase is protected : when the double-phase electrical machinery is connected with driver , users are apt to connect the phase by mistake, thus would damage the driver seriously. The protecting circuit is within this driver, when users connect by mistake, the driver will not be damaged, but the electrical machinery runs abnormally, shake, and output is small. Please check whether the wiring of electrical machinery is a mistake..

• Application: Tube Filling Machines. Ointment, Colour, Gel Filling Machines
• Inputs: Start signal to run the stepper motor(PNP/NPN), Mark sensor (PNP/NPN), Stepper Speed Adjustment
• Outputs: PWM Current Control, Programmable outputs (if required)
• Motors: Upto 4 Amps Stepper Motor

Controls motion of Stepper motor and precisely positions the tube for sealing. The controller starts on receiving start signal and runs the stepper till the mark sensor senses the mark on the tube. Speed of the motor can be adjusted as per user's requirement.

• Brand Name: Raj Overseas
• Color: Black
• Voltage: 80 v dc
• Weight: 10-20kg
• Frequency: 50/60
• Wattage: 180w
• Country of Origin: Europe
• No. of Phase: 4
• Step Angle: Micro sttep
• Input Phase: Single
• Stepper motor controller: Rs 9200

• Warranty: 1 Year
• Motor Connectors: Screw Terminals
• Operating Voltage: 5V
• Power Consumption: 36 mA (logic)
• Size: 49 x 55 x 33 mm
• Weight: 33 g

We are offering tca3727 2-phase stepper-motor driver. Features: • 2 x 0.75 amp. 50 v outputs. • integrated driver, control logic and current control(chopper). • fast free-wheeling diodes. • max. Supply voltage 52 v. • outputs free of crossover current. • offset-phase turn-on of output stages. • z-diode for logic supply. • low standby-current drain. • full, half, quarter, mini step.

• Voltage Range (V): 24 - 48 DC
• Current Range (A): 0.7 - 2.2
• Drive Type: Step & Direction Advanced
• Dimensions (mm): Card 78 x 68 x 21
• Suggested Motors (Flange Size): NEMA 11 NEMA 17 NEMA 23 60MM

• Country of Origin: India
• Color: Black
• Brand Name: Em Motion Modules
• Input Phase :: 20-70VDC
• Operating voltage: 5V

• Country of Origin: India
• Step Angle: 5.6°
• Operating voltage: 5V
• Operating current: : 0.5A

This is a small, cheap, and high-quality gear stepper motor. It is a widely popular combination of the stepper motor and stepper driver. This combination is very reliable and stable in use. The speed of the motor is 15 rpm. This motor is a unipolar stepper motor that has 5 wires. The driver amplifies the control signals from the Arduino to control the motor. The control of the motor's movement angle is done by controlling the number of stepper motor driver pulses. The speed of the stepper motor rotation is also controllable by controlling the frequency of the pulses. The compact design is perfect for small robots. Features   High-quality stepper motor with driver The speed of the motor is 15 rpm The perfect combination for the robots which need precise control

• Color: silver

Wea re offering stepper motor driver, feature: 1.it adopt special control circuit.the noise will be lower. 2.max. Reaction frequency could be up to 200kpps. 3.driver current could adjust 16 files from 0.5a/phase to 8.0a/pase. 4.the area of voltage:dc60-130v 5.size:80x200x156mm 6.net weight:2.0kgs.

We are supported by a team of professionals who ensure that the offered lot is prepared using the best quality raw material. Also, they confirm that the material is sourced from the certified places. You can make payments through online methods such as net banking, PayPal, or offline methods such as draft depositing, cash on delivery etc. Our policies regarding payment are swift and transparent. Our Stepper Motor Driver undergoes several quality rounds, to ensure its efficient functionality.

capitalizing on our enormous business competency, we are engaged in offering a wide gamut of stepper motor controller. In line with the needs of our customers, these offered products are easy to install and durable. Besides this, these are examined on a number of aspects to maintain their reliability at the end of our customers.description: high torque density. high torque to inertia for quicker start and stops rugged design and long life bearing higher power, rare earth magnets holding torque up to 30nm smallest frame size of 42mm square frame size up to 110mm square frame size up to 110mm square

• Weight: 0.3 Kg
• Brand Name: UNIQUE TECH
• Lead Time: 20Days
• Supply Ability: 50000 Piece/Pieces per Month
• Motor Type: Stepper Motor
• Life Span: Long service life
• Display: Digital
• Place of Origin: Tamil Nadu, India
• Working Area: 1200 x 1200 x 200 mm
• Port: Chennai

• ECG-A: Slider type EBS-G Series, Rod with built-in guide EBR-G Series
• ECG-B: 2-Finger Gripper FLSH-G Series, Table type FLCR-G Series, Rotary type FGRC-G Series

▪ It is a controller for stepping motor drives. One controller system contributing to man-hour and inventory reduction.

A4988 is a complete microstepping motor driver with built-in translator for easy operation. The product can be full, half, 1/4, 1/8 and 1/16 step mode to operate bipolar stepper motor output drive capacity of up to 35 V and ± 2 A. A4988 includes a fixed off-time current regulator, the regulator can slow or mixed decay mode. The converter is the key to the easy implementation of the A4988. In inputting one pulse on the STEP input drives the motor one microstep. No phase sequence tables, high frequency control lines, or complex interfaces to programming. A4988 interface is very suitable for complex microprocessor is unavailable or is overburdened.         Micro-step operation, the chopping control in the A4988 automatically selects the current decay mode (Slow or Mixed). In the mixed decay mode, the device is initially set to fast decay in the part of the fixed off-time, then a slow decay in the rest of the downtime. Mixed-decay current control scheme results in reduced audible motor noise, increased step accuracy, and reduced power consumption. Internal synchronous rectification control circuitry to improve the pulse-width modulation (PWM) power consumption when operating. Internal circuit protection includes: thermal shutdown with hysteresis, undervoltage lockout (UVLO) and crossover current protection. Special power-Sort. A4988 surface mount QFN package (ES), the size of 5 mm x 5 mm nominal overall package height of 0.90 mm, and with exposed pad for enhanced thermal dissipation. The package is Pb (suffixes-T), with 100% matte tin leadframe plating. A stepper motor is one kind of electric motor used in the robotics industry. Stepper motors move a known interval for each pulse of power. These pulses of power are provided by a stepper motor driver and is referred to as a step. As each step moves the motor a known distance it makes them handy devices for repeatable positioning. There is a good article on Wikipedia explaining the technology behind stepper motors. The mechanical operation of a stepper motor is shown in this article.

rated voltage: dc5v-12v 4-phase reduction ratio: 1/64 step torque angle: 5.625°/64 dc resistance: 200ω±7% (25℃) insulation resistance: >10mω (500v) insulation grade: a no-load pull in frequency: >600hz no-load pull out frequency: >1000hz pull in torque: >34.3mn.m(120hz) detent torque: >34.3mn.m temperature rise: .
