Stiffness Tester Dealers

The TABER® V-5 Stiffness Tester - Model 150-B or 150-E is used to evaluate stiffness and resiliency properties of materials up to 10,000 Taber Stiffness Units.  This precision instrument provides accurate test measurement to ±1.0% for specimens 0.004" to 0.219" thickness.  Materials include paper products, cardboard, plastics, metals, textiles, rubber, wire, tubing, felts and other sheet materials.  DescriptionIncorporated in the TABER V-5 Stiffness Tester is a bi-directional pendulum weighing system.  Providing an accurate and responsive method for measuring small load increments, this system is a critical component for determining material stiffness or resiliency.  Nine (9) distinct ranges permit testing of materials that are extremely lightweight and flexible (such as cellophane or thin metallic foils) to items that are very rigid (such as plastics).For test ranges 2 - 9, specimens are mounted on the Taber V-5 Stiffness Tester using a clamping system.  Located on the pendulum, the lower faces of the specimen clamp jaws are exactly on the center of rotation.  This ensures a constant test length and deflection angle for accurate and repeatable results. Both jaws of the specimen clamp are adjustable, so the test specimen can be positioned precisely in the center regardless of material thickness. Force is applied to the lower end of the specimen by a pair of rollers. The rollers, which are attached to a driving disc located directly behind the pendulum, push against the test specimen and deflect it from its vertical position.  The pendulum applies increasing torque to the specimen as it deflects further from its original position.  The test point reading occurs when the pendulum mark aligns with the appropriate driving disc mark (7 1/2° or 15°), which points to the stiffness reading on the dial point.  The final reading will depend on the range in which the test is being conducted and what scaling factor to use.  The instrument outputs the moment load applied to the test specimen in TABER Stiffness Units (g · cm).Note: The right hand roller includes a ratchet stop mechanism that greatly reduces the potential for inter-operator error caused by over or under-tightening.  The travel on the right hand assembly automatically stops when the roller contacts the specimen.To allow the testing of materials with different stiffness properties, range weights can be applied to the pendulum.  For extremely light weight materials, a compensator range weight is mounted to the top of the pendulum.  Range weights of 500, 1000 and 2000 "Taber Units" are mounted to the bottom of the pendulum and required for stiffer materials.  An optional range weight set of 3000 and 5000 Taber units is required for test ranges 7, 8 and 9.Range 1 is used with Taber's optional Sensitivity Range Attachment (also referred to as SR or High Sensitivity Attachment) to test extremely lightweight and flexible materials whose Taber Stiffness Unit value are between 0 - 1.  Examples include cellophane, natural fibres and synthetic filaments, tissue paper, metallic foils, films, etc.  The attachment includes two parts, the Driven Pins Holder which is secured between the clamp jaws, and the Driving Pins Holder which is mounted to the studs in place of the left and right hand rollers.  Both parts include precision pins that are oriented horizontal to the face of the V-5 Stiffness Tester. A specimen 1 1/2" x 1 1/2" is mounted such that the second and fourth pins are above the specimen.  As the driving disc rotates, the fourth pin of the Driving  Pins Holder pushes down on the specimen while the first pin pushes up.  As the sample is deflected, the Driven Pins Holder aligns the pendulum to the appropriate stiffness value.  For Range 1, the specimen is only deflected to the right.Many customers have also utilized the Taber V-5 Stiffness Tester to evaluate wire and cable stiffness characteristics. The tester now incorporates a "v-notch" in the clamps to accommodate this testing. Suggested samples are 70mm long and 3mm - 8mm in diameter, and centered in the notch with care so as to not pinch or crimp the sample. For wire and cable samples less than 3mm diameter, it is recommended to secure the sample at a location in the flat region of the clamp.  Samples with curvature may interfere with proper set-up and function of the Stiffness tester and should be avoided. In addition, test results obtained should be used for comparison only - that is, between lots, between materials, etc.   The following chart is used as a guide when setting up the instrument to determine which test range to use for the type of material being tested.

• Brand Name: ANGELS INSTRUMENTS
• Color: Sky Blue
• Condition: New
• Automatic Grade: Semi Automatic
• Power: 25 W
• Power Source: Electric
• Application: LAB USE
• Certification: ISO 9001:2008 Certified

The company has cemented its presence among the reputed Manufacturers, Suppliers and Exporters of Taber Stiffness Tester. Our Stiffness Tester evaluates stiffness and resilient qualities of different materials like paper, plastics, cardboard, light metallic sheets, foil and other flexible material. Buyers can obtain these at market-leading rates from us. Details : The instruments is designed for evaluating stiffness and resilient qualities of paper, plastics, cardboard, light metallic sheets, foil and other flexible material having comparatively strong bending resistance. The 38 mm wide specimen clamped between a vice on a balanced pendulum supported by antifriction bearing and lower end clamp on a rotating disc then specimen is bent by 15 degree at a constant speed. When it becomes 50 mm in load length, bending moment required to bent specimen is measured in gcm unit and the stiffness of the material is determined rotation are clockwise and counter clockwise, so that stiffness can be measured in both the directions. Measuring range - 0-5000 Stiffness Units Model AI 3015

• Type: Stiffness Tester
• Certification: ISO 9001:2008 Certified, CE CERTIFIED
• Application: PAPER INDUSTRY
• Color: Green, Silver
• Feature: Easy To Use, Proper Working, Superior Finish
• Condition: New
• Automatic Grade: Semi Automatic
• Power Source: Electric
• Warrenty: 1year
• Puncture Voltage: 220V
• Brand Name: UEC
• Country of Origin: India
• Power: 220V
• Standard: CE AND ISO
• Certification: CE AND ISO
• Surface Finishing: Polished
• Resistivity: Rust Resistant
• Material: Metal
• Drive Type: Electric

• Application: Household, industrial, Laboratory
• Condition: New
• Power Source: Electric
• Material: Steel
• Finish: Polished

Stiffness Tester is used to determine the stiffness of fabrics. B-Tex Engineering provides Stiffness Tester of high quality, of high standard and with specified warranty. Stiffness Tester provides a quick and accurate method of determining stiffness properties such as flexural rigidity of most textile fabrics and other flexible materials. The principle of Cantilever Test

Electonic stiffness Tester ( Bending Type)- Measuring range 0-5000 mN Accuracy of load cell within ± 2 % of ture reading but not better then ± 1 % of 5000 mN. It is provided with imported load cell. Product Code:GE-2062(B)

• Frequency: 50
• Type: Analog
• Size: 38 X 70 mm
• Load: 5000 Unit At 15 Degree
• Display: Analog
• Measuring Range: 10.5 Mm 11 Mm Factory Calibrated Accuracy of +/- 1% Full Scal
• Phase: Machenical
• Packaging: Wooden Box
• Production Capacity: 6 Pcs

• Type: Stiffness Tester
• Country of Origin: India
• Measuring Range: 0-5000 mN.
• Brand Name: STIPL
• Bending Speed: 50 /s.
• Bending Length: 5, 10, 15, 20 ,25 & 50 mm
• Bending Angle: Infinitely variable 50 & 300 and six fixed positions 50, 7.50 , 150 , 200 , 250 and 300
• Strip Dimensions: Width 38 mm (1.5”) , Thickness max 3 mm

Definition : Bending resistance, the resistance offered to a bending force by a rectangular specimen, which is clamped along one side, measured under specified conditions. The bending resistance is considered to be measured towards the side (felt or wire) that is concave during bending. Bending resistance is commonly referred to as “stiffness” . Standardization : ISO 2493 , TAPPI T556 , SCAN P 29 , NFQ 03048 , APPITA/AS 1301 , DIN 53121 Device Description : The electronic stiffness Tester is easy to handle and calibrate. It is fast and efficient & paper board and intended for determining the bending resistance of a wide range of paper grades. The instrument can also be used for determination of the behavior of paper under long term stress, as well as to determine the bending stiffness. Test Description: one end of the test piece is easily fastened into the clamp. The maximum force required to bend the test piece to a specified angle is presented directly on the digital display . caliberation is easy and can be performed with the help of weight platform.

Fabric Stiffness Tester, to determine the bending height, flexural rigidity and bending modulus of a fabric by simple procedures and calculation   Objectives : To measure the stiffness of the given fabric sample.   Specifications- Tilt angle: 41. 5 º Weight- 4 Kg   Dimensions Width: 350 mm (14 inch) Depth: 150 mm (6 inch) Height: 200 mm ( 8 inch)   Standards - ASTM D1388 BS 3356 DIN 53362 ERT 50-2   Apparatus: Stiffness Tester Scissor Scale   Sample : Cotton woven fabric Size: 6 X 1².

We are offering stiffness tester. precision instrument evaluates material stiffness. the taber stiffness tester utilizes a two directional pendulum-type weighing system to evaluate material stiffness, flexural strength, resiliency and elasticity properties. Force is applied to the lower end of the specimen by a pair of rollers attached to the driving disc. the resulting torque tilts the pendulum from its vertical position and a taber stiffness unit reading (g•cm) is taken automatically when the pendulum mark aligns with the appropriate driving disc mark (71/2° or 15°). Predetermined sample length, deflection angle and rate of loading provide accurate and reproducible test results. onboard computer automates testing. a high resolution optical encoder and a non-contacting photo sensor are incorporated to make this instrument fully automatic. the onboard computer calculates and records testing data (average; standard deviation; high/low; time; date; and a user-defined label), and converts stiffness readings to the appropriate user selected stiffness range. Test results are displayed on a 4 x 20 character display screen, and can be printed, stored or downloaded to a pc. test a wide range of products. nine distinct setups permit the testing of very delicate to extremely rigid materials. Taber stiffness testers will evaluate paper, light metallic foil, laminated plastic, cardboard, wire, and other flexible materials up to 5.5mm (0.219 inches) thick that do not exceed 10,000 taber stiffness units.

• Brand Name: SHAAD ENTERPRISES
• Application: PAPER INDUSTRY

By this product we are evaluating stiffness a resilient qualities of paper , plastic , cardboard , light metalic sheets, foils & other flexible material having comparatively strong bending resistance.

• Type: Stiffness Tester
• Certification: ISO 9001:2015
• Color: White
• Feature: Easy To Use
• Condition: New
• Automatic Grade: Automatic
• Warrenty: 1year
• Brand Name: IKON INDUSTRIES
• Color: White
• Certification: Traceable to NABL
• Display Type: Digital
• Material: Mild Steel
• Grade: Automatic
• Model Number: IK/DST/01

• Type: Stiffness Tester
• Certification: ISI Certified, ISO 9001:2008 Certified
• Condition: New
• Warrenty: Lifetime Buyback Warranty
• Brand Name: Paramount
• Country of Origin: India

A widely used method for determination of Stiffness of Fabric is cantilever Test method. In this test, the fabric specimen is allowed to bend under its own weight as the length, of the overhanging portion of the specimen, is gradually increased. The free length which bends under its own weight sufficiently to make its leading edge intersect a plane of 41.5o inclination, is taken as the measure of stiffness of the fabric. PARAMOUNT Stiffness Tester i9 is used to determine the bending height, flexural rigidity and bending modulus of fabrics by sample procedure s and calculations. It has a solid Aluminum base with Nylon foot-rest to keep the base horizontal . The top plate is made of stainless steel to minimize friction between it and the test specimen. The sides are made from two acrylic plates (one Transparent & other Milky White). The inclined plane etched on the plates is filled with Black ink for permanent markings. A scale , with back up weight, to give the required load on specimen, and rubber lined lower face to grip the s pecimen, is provided for loading the specimen and to directly give its bending length.

• Power: 220V, 50Hz, single phase
• Weight of pendulum: 500, 1000, 2000, 3000, 5000 SU
• Weight of stud: 10 ± 0.001gm
• Sample size: 70 ± 1mm X 38.1 ± 0.3mm
• Angle: 7.5°, 15°
• Motor: 2 RPM

Presto’s stiff resistance tester is the perfect tool to measure the flexural strength of the paper and linear boards or paper boards. Assessing this property is important as it decides the economic value of the paper. It complies with the testing standards of TAPPI – T489 OM-08. It measures the flexural rigidity of the test sample very precisely. This is one of the best methods to determine the quality of the paper and paper boards. The resistance of paper depends on various factors like its composition at the time of manufacturing.    To test the paper, the specimen is mounted on the tester using the clamping system. Located at the pendulum, the lower faces of the clamp jaws are at the centre. The jaws adjust themselves according to the different thickness of the test paper. To get the accurate test results, the test and angle of deflection are kept constant. To get the value of the test, the load is applied on the lower end of the specimen. It is the perfect way to determine the quality of the paper. Stiff resistance tester helps in segregating the substandard paper from the high quality. It is one of the most important test instrument used in paper industry. Presto offers this instrument at very competitive prices. Calibration certificate is provided along with the instrument. This certificate is valid for one year.

Stiffness Testers available with us have flat, smooth and low friction horizontal metallic surface. The lines are marked at determined angle on the two vertical transparent plates.

We provide the clients Digital Stiffness Tester that is intended for measuring the stiffness and resolution quantities of paper card-board, plastic light metallic sheet spring wire with high sensitivity and precision accuracy. The digital stiffness tester is offered to the clients at reasonable rates. We are renowned as well-known digital stiffness tester manufacturer and exporter. comply with the following standards technical association of paper and pup industry tappi t489 m60american society for testing and material astm-0747-61tphysical and chemical standard committee technical sectioncanadian pulp and paper association standard d.28 pjapanese industrial standard jisp8125 connections power supply 220/250 v, l-phase 50 hz 10 va
