Swing Barrier Dealers

• Weight: 29 Kg Approx
• Material: Stainless Steel
• Power: 230 VAC Single Phase
• Throughput: 20 Persons Per Minute
• Passage width: 900 Mm
• Use place: Supermaket, Park, Apartment Etc

• Frequency: 50Hz
• Power Supply: 100–240Vac
• Operating Voltage: 24 V
• Power Consumption: 30W
• Unlock Time: 0.2 sec
• Transaction Rate: 35 Person/min

LEAPTOR, E-343 Metallic Swing Type Barrier is the best suited product for pedestrian control. These are space efficient security barriers with compact design yet offers sufficient space to integrate any access control systems. These CE certified barriers are the best suited products for pedestrian control in affordable price. These barriers paired with different access control systems like finger print access controller, face recognition reader as well as card readers. These swing barriers can be mounted with display, passage counter, card reader, alarm system against unauthorised entries, interfaced with PC. The unique arm feature provides a fail-safe safety solution in case of emergency or power failure. It has a special feature of allowing one person at time through each lane to avoid tailgating.

• Type: Swing Barrier
• Material: Stainless Steel
• Application: Apartment, Park, Supermaket
• Color: Silver(standard)
• Feature: Good Quality
• Condition: New
• Packaging Type: Corrugated Box
• Automation Grade: Automatic
• Flap: Acrylic, Glass

• Frequency: 50Hz
• Brand: eSSL
• Working Temperature: -25
• Operational Voltage: 24V DC
• Passage Width: Less Than 450mm (Default)
• Power Supply: 100V
• Throughput Rate: 35 P/M
• Model: SB - TL - 129
• Max Power Consumption: 30 W
• Protection Level: IP 54
• Dimension Excluding Bars: 480 x 280 x 1050 mm
• New Weight: 40 kg

• Frequency: 50Hz
• Passage width (Max): ≤960mm
• Throughput rate: 35/P/M
• Power Supply: 100V
• Operational Voltage: 24V DC
• Max Power Consumprion: 35 W
• Protection Level (IP): ≥ 44
• Working Temperature: -25
• Electro-magnetic Drive: DC
• Dimension excluding bars: 1200 x 280 x 980
• New weight(including Bars): 75 kg

• Color: Silver
• Condition: New
• Type: P Type Swing Barrier
• Country of Origin: India
• Automatic Grade: Automatic
• Warranty: 1year
• Driven: Electric

• Country of Origin: India
• Type: Swing Barrier
• Material: Stainless Steel
• Application: Apartment
• Weight: 150-200 Kgs
• Color: Silver
• Feature: Good Quality, Regulates Access
• Condition: New
• Frequency: 50hz
• Automation Grade: Automatic
• Flap: Acrylic, Poly-carbonate
• Opening- /Closing time (msec.): 300
• C/w Soft Flap (mm): 200
• Protection (IP): 32
• Power supply (V): 230
• Frequency (Hz): 50-60
• Length (mm): 1300
• Width (mm): 250
• Height (mm): 1035

• Material: Stainless steel
• Color: Silver
• Country of Origin: Made in India
• Automation Grade: Automatic
• Item Code: SLB
• Open Style: Flap
• Model Name/Number: SLB
• Brand: SIVA
• I Deal In: New Only
• Barrier Type: Acrylic Flap
• Width Of Passage: 600mm to 900mm
• Throughput Rate: 20 people per minute

• Usage/Application: Entrance Control
• Emergency mode: Y
• Power requirements: AC 100
• Working temperature: -28°C
• Working humidity: 20%-95% (Non-condensing)
• Working environment: Indoor
• Speed of throughput: Maximum 40/ minute
• Lane width(mm): 660
• Footprint(mm*mm): 1600*1040
• Dimensions(mm): L=1600,W=120, H=1200
• Dimensionwith packing(mm): L=1700,W=300, H=1130
• Netweight(kg): 130kg
• Weight with packing(kg): 150kg
• Cabinet material: SUS304 Stainless Steel

Efficient security system at the entry and exit points of Factories, Office Complexes, malls, Condominiums, Parking Lots, Toll Tax Plazas or any road - way entry where medium to heavy traffic is expected.

Swing Barriers are used to better manage crowds and improve safety in congested locations. They have self-detection and self-diagnosis sensors and may be arranged into several lanes with a one-way or bi-directional entrance and exit system. Swing barriers are ideal for use in business buildings, railway stations, and metro stations, among other places. Swing Barriers come with a built-in LED light indicator, fire alarms that immediately activate, and other customizing options. Get in contact with our knowledgeable team of persons below to learn more about the specific goods or to schedule a free consultation for a thorough examination and professional advice.

Swing Barriers by Alaska Group are manufactured as per international standards using supreme quality raw materials. Alaska Group deploys world-class technology with IR sensors best used to control access to the premises. Swing barriers are designed in a way that serve multi-utility to its users by detecting unauthorized entrances and exits. Alaska Swing gates hold an access control system that allows entry and exit post-authentication by ID card swipe, fingerprint, or face authentication. Every place where controlled access is crucial, records are to be kept, and visiting management has to be coordinated to make swing barriers become essential. Alaska swing barriers are high in demand in various locations like airports, stadiums, govt. sector, office entrance, factories, etc.

• Packaging: Carton
• Warranty: 1 year
• Power supply voltage: AC220±10% V,50HZ
• Driving motor: Dc motor 24V/20W
• Working environment temperature: Below zero 40 to 70℃
• Relative humidity: relative humidity≤90%,No lon
• Input interface: 12V level signal or 12V impulse signal of pulse width > 100ms drive current > 10Ma
• Communication interface: RS485 electrical standard
• Communication distance: less than or equal to 1200 meters
• Channel width: 560-600mm
• Speed: 30-40 persons/min (normally open mode), 20-30 persons/min (normally closed mode)
• Gate opening and closing time:  1 second

• weighing: 150 kgs to 600 kgs.

Swing barrier for any kind of installation, residential or industrial. These smooth and silent operators are good for every kind of swing gate for swings weighing from 150 kgs to 600 kgs.

• Parameters: Value
• Make: Divya
• Model / Variants: Standard / Shared Body / Custom
• Body Type: Stainless Steel / Powder Coated Mild Steel*
• Barricade Material: 20mm Thick Clear Acrylic Flap
• No. of Lanes: One / Two / Cascaded
• Response Time: 500msec
• Throughput: Ξ 20 - 50/min based on Configuration
• Mechanism Technique: Direct- Lever Linked Mechanism
• Drive: Motor
• Dampening: Electronic Dampening
• Lock: Electronic + Mechanical
• Passage Mode: Normally Close / Normally Open*
• Direction: UniDirectional / Bi-Directional
• Configuration: Fail Safe / Fail Lock*
• Access Time Out: Settable 1 To 10 sec
• Mechanism Construction: Rust Free Hardened Steel
• Movement / Rotation: Self Lubricated Bearing
• Caging / Blockage: Sensor Controlled Flap
• Movement Orientation: Self Positioning Rectractable Flaps
• Lane Width: 640mm550mm
• Withstand: Force
• Indicator: Green ↗ , Red X LED
• Input Power: 230V AC, 50Hz / 110V AC, 60Hz* / Direct 12 V DC*
• Power Consumption: Standby <5w, operational 50w
• Trigger: Dual Side Potential Free Contact, Fire Alarm / Emergency
• Reader Mounting Provision: On Body
• Anti Pass Back: Sensor Controlled
• Tailgating: Active Detection and Control
• Operating Temperature: -10˚C - 55˚C
• Humidity: 95% non condensing
• Weight*: 65kg
• Dimension (L x D x H): 1470 x 1512/2350 x 2230 mm (Width for One/Two Lane)
• Optional*: Electronic Counter, Network Connectivity, Battery Backup, Mounting Bracket, Canopy, Queue Barricade
• IP Rtaing: IP56 / IP66*

• Function: All smooth finish. No exposed screws, Simplify structure and connection, easy to maintain
• rand: ZKTECO
• Working Temperature: -28 - 60 deg C
• Power requirements: AC110V/220v,50/60HZ
• Working humidity: 5%-80%
• Working environment: Indoor/Outdoor
• Speed of throughput RFID: Maximum 42/minute
• Speed of throughput Fingerprint: Maximum 35/minute
• Speed of throughput Face: Maximum 11/minute
• Speed of throughput Vein: Maximum 23/minute
• Lane width: 1050 mm
• Footprint: 1250x1500 mm
• Dimensions: L=1500, W=260, H=1000 mm
• Dimension with packing: L=1640, W=400, H=1110 mm
• Net weight: 66 kg
• Weight with packing: 98 kg
• LED indicator: Yes
• Cabinet material: SUS304 Stainless Steel
• Lid material: SUS304 Stainless Steel
• Barrier movement: Swing
• Emergency mode: Yes
• Security level: Medium
• MCBF: 2 million

• Brand Name: SSEPL
• Country of Origin: Made in India
• Frequency: 50/60 Hz
• Usage/Application: Commercial
• Model Name/Number: SB-312S
• Passage width: 600 mm
• Working Temperature: -20 to 60 Degree C
• Power supply: 240 V
• Automation: Full Automatic

• Voltage: 110V/220V AC
• Frequency: 50/60 Hz
• Feature: Ideal for wide variety of pedestrian access.,Recommended for heavy passage flow & gateway for outsider entry,Bi directional single passage with free pass/ restricted entry,Categorized as single & dual lane,The lane width can be adjusted as per the require
• Length Width Height: 1400 mm 280 mm 980 mm
• Working Temperature: -25°C to +65 °C
• Max. passenger/min: 30 persons/min (normal open state); 20 persons/min (normal close state)
• Working Humidity: <90 % , without condensation
• Power Supply: 30W
• Emergency Operation:: Power off Arm Open Function
• Finish: Stainless Steel 304
