Tablet Coating PAN Dealers

The wide range of tablet coating pan that we offer is made using high quality materials. These pans are reliable and have a long service life. We ensure that the tablet coating pans we offer conform to the quality standards required by the industry. These pans are used extensively due to their superior structure and features. applications in the pharmaceutical industrypreparing vitamin tablets

• Driven Type: Electric
• Application: Coating Tablets
• Certification: ISI Certified
• Weight: 200-300kg
• Warranty: 1year
• Country of Origin: India
• Material: Stainless Steel
• Finishing: Polished

Our range of tablet coating pans is extensively used for sugar and film coating of tablets, pallets and granules. The unit comprises of ellipsoidal shaped pan fabricated using stainless steel sheet and mounted on the gearbox shaft, which is driven by an electric motor. These tablet coating pan are available in standard and GMP model with SS 304 or 316 contact parts.   Features : The complete drive unit is enclosed in a sturdy cabinet Hot air blower with flexible SS Pipe heaters are provided with thermostat control for fast drying Heaters are interlocked with the blower motor therefore unless the blower is on, heater does not start

• Type: Tablet Coating
• Purity: GMP STD
• Function: Coating
• Dosage Form: GMP STD
• Brand Name: Hallmark
• Place of Origin: India

We have in our store a high- class array of Tablet Coating Pan that stands out of the rest due to its high productivity, durability and high operational fluency. Our Tablet Coating Pan is widely used for sugar and film coating of tablets, pallets and granules. These pans are available with us in standard and GMP models with SS 304 or 316 contact parts. Made up of high quality stainless steel, our Tablet Coating Pan are driven by electric motor. One can get them at feasible prices, from us.   Features : The complete drive unit is enclosed in a sturdy cabinet Hot air blower with flexible SS Pipe heaters are provided with thermostat control for fast drying Heaters are interlocked with the blower motor therefore unless the blower is on, heater does not start   Technical Specification : Size 30″ 36″ 42″ 48″ Heater Capacity in K.W. 1.5 1.5 1.5 3.0 Blower H.P. 0.5 0.5 0.5 0.5 Blower Capacity CFM 90 90 90 90 Pan Mounting Angle 30° 30° 30° 30° Motor HP 1.5 1.5 2.0 2.0 Loading Capacity 45 80 100 150gf

• Weight: 100-200kg
• Color: Silver
• Voltage: 220V
• Automatic Grade: Automatic
• Power: 1-3kw
• Driven Type: Electric

• features: Damper provided for inlet air control.

Coating Pans are used for coating of tablets and drying them simultaneously by hot air. Thermostat provided for easy selection of required temperature.

• Type: Tablet Coating Pan

amt engineering works is a leading and well known manufacturer of tablet coating pan..

• Weight: 100-200kg
• Voltage: 220V
• Automatic Grade: Automatic
• Power: 1-3kw
• Warranty: 1year
• Temperature: 30 to 110 Degree Celsius

Fabricated as per set industrial requirements, Tablet Coating Pan we offer is the best available in the market. Appreciated for its high-end performance, compact design, durability and effectual functioning, Tablet Coating Pan is high on demand in the domestic markets. Consequently, we are counted as a top-notch Tablet Coating Pan Manufacturer and Supplier based in India. Specifications : MS Sheet, Powder coated body, Stainless Steel Pan Provided with main lead 15 amp plug Operated by geared motor that works through timer and air blower, which is further operated by energy regulator Working of the machine through oil immersed gearbox with ¼ H.P Motor resulting or by heavy duty DC geared motor Tablet coating pan 12 ½ dia stainless steel Air blower is operated independently  Switches for blower &motor are fixed on a panel through neon indicators

cGMP Coating Pan is simple unit, which employs the principle of rolling a batch of tablets in an elliptical pan, spraying the coating solution on it and passing hot air across the tablet bed.Salient features Application : For Film coating, enteric coating and sugar coating system. Pan generates tumbling action of tablets/pellets. The Spray gun is provided with inlets for liquid and air connection. Motor is directly coupled to a centrifugal blower employed to supply hot air to the system. Capacity 3KG to 250KG.

12" Dia, Stainless Steel : The machine is worked by oil immersed gearbox with 1/4 H.P. motor driven, or by heavy duty DC geared motor. Air blower is operated independently and air is thermostatically controlled to give temperature 30° to 110°C. Switches for motor & blower are fixed on a panel with neon indicators. Also mains lead with 15 Amp plug provided.

We are trustworthy Supplier of Tablet Coating Pan, based in Kanpur, Uttar Pradesh. Tablet Coating Pan is made using stainless steel, which is known for strength and resistance against corrosion property. Tablet Coating Pan is designed keeping in mind growing demands of pharmaceutical units. Other Information Size : 30", 36" & 42" Hot air blower Mirror-finish S.S. Pan

• Warranty: 1 Year
• Brand: Venus Machinery
• Model Name/Number: VTCM
• Power Consumption: 5HP
• Temperature Range: 35 to 180
• Usage/Application: Used for Sugar & Film Coating in Pharma & Confectionery Industries.
• No Load Speed: 30
• Air Pressure: 600 CFM
• Cup Capacity: 2 to 80 kg
• Dimension: L- 1520 X W-1150X H- 1755 In mm.
• Heat Up Time: 10 to 30 Mins

12" Dia, Stainless Steel : The machine is worked by oil immersed gearbox with 1/4 H.P. motor driven, or by heavy duty DC geared motor. Air blower is operated independently and air is thermostatically controlled to give temperature 30° to 110°C. Switches for motor & blower are fixed on a panel with neon indicators. Also mains lead with 15 Amp plug provided.

• Type: Tablet Coating Pan
• Certification: NA
• Application: Coating Tablets
• Weight: 100-200kg, 200-300kg, 300-400kg, 400-500kg
• Color: Silver
• Voltage: 440V
• Condition: New
• Automatic Grade: Automatic, Manual, Semi Automatic
• Power: 3-6kw, 6-9kw, 9-12kw
• Driven Type: Electric, Mechanical
• Warranty: 1year
• Country of Origin: India
• pharmaceuticals: tablet coating pan

• PAN SIZE: 600 mm
• CAPACITY: 30 kg.

Tablet coating pan The product is to be filled inside the pan. During the rotation motion of the pan, coating material is sprayed by spraying system. At the same time hot air is supplied through inbuilt Hot air blower system which dries the coat rapidly. Thus a solid and smooth surface is formed over the product.Mirror polished SS pans ensure uniform and excellent coating of tablets

TABLET COATING PAN Tablet coating pan 12�dia Stainless Steel, the machine is worked by oil immersed gear box with F.H.P. motor drive. Air blower is operated independently and air is thermostatically controlled to give temperature 30 to 100C. Switches for motor, blower, heater and thermostat are fixed on a panel with neon indicators. Also mains lead with 15 Amp plus provided.

We offer tablet coating pan. tablet coating pan 12" dia stainless steel, the machine is worked by oil immersed gear box with f.h.p. Motor drive. Air blower is operated independently and air is thermostatically controlled to give temperature 30 to 100 oc. Switches for motor, blower, heater and thermostat are fixed on a panel with neon indicators. Also mains lead with 15 amp plug provided.

We are one of the leading manufactures and suppliers of tablet coating pan with a diameter of 12". It is manufactured using stainless steel. The tablet coating machine works on oil immersed gear box with f.h.p. Motor drive. The air blower is operated independently and air is thermostatically controlled to give temperature 30 to 100o c. Tablet coating pan switches for motor, blower, heater and thermostat are fixed on a panel with neon indicators. Also mains lead with 15 amp plug provided.

The machine is worked by oil immersed gearbox with 14 H.P. motor driven, or by heavy duty DC geared motor. Air blower is operated independently and air is thermostatically controlled to give temperature 30° to 110°C. Switches for motor & blower are fixed on a panel with neon indicators. Also mains lead with 15 Amp plug provided.

• Application: Coating Tablets
• Weight: 100-200kg
• Voltage: 220V
• Automatic Grade: Automatic
• Driven Type: Electric
• Warranty: 1year

GPM's Coating Pan is extensively used for sugar and film coating of tablets, pallets and granules. The unit comprises of ellipsoidal shaped pan fabricated using stainless steel material and mounted on the gear box shaft which is driven by prime mover. These tablet coating pans are available in standard and GMP model with SS316 or SS304 contact parts.

• Loading Capacity: 15 Kg.

The Coating Pan can be mounted on Motor Drive unit via Universal Gear (UG), which permits Coating pan to be held at any angle up to 45° with reduction in speed. For drying attachment with adjustable height is provided. The maximum operational capacity is 30 % of coating pan volume. The coating pan is suitable for screwing on all main drives.

We offer coating pan that is designed to perfection and fabricated from best grades of raw material procured from reliable sources. These coating pan are suitable for coating tablets and is checked by our quality controllers for high performance and uniform coating all over the tablet. The different parts of our coating pan machines are listed as under: PAN :The coating pan is SS 304 semi ellipsoidal size pan with a circular mouth for charging & discharging of tablets, Pan mounted at an inclination of 45 degrees to the horizontal. DRIVE ASSEMBLY :The tablet coating pan consists of a suitable HP 3 Phase, 440 V, 1440 RPM TEFC motor with suitable worm reduction gear box and cone pulley arrangement to give three speed output. HOT AIR BLOWER :The tablet coating pan unit is provided with a hot air blower consisting of suitable HP 3 Phase 440 V, 2880 RPM TEFC electric motor & centrifugal blower with damper delivering required CFM. The air is heated by means of suitable electric heater to give air at 30 to 90 degrees Heater with thermostat control and flexible hose pipe.

Pan is made out of stainless steel and rest of the machines parts of mild steel, complete with suitable motor and 0.5 HP hot air blower with suitable starter, indicator and thermostatically controlled heaters, with variable pulley, for controlling of r.p.m of moving pan, fabricated to technical shape and requirement. �G.M.P. Model : M.S Body of the machine cladded with St. Steel sheet� HARRISON�S POLISHING PAN The polishing pan is of canvas cloth, mounted on M.S frame, tighten fully with attachment. The affixed coupling provided on back, is suitable to affix / adjust on the shaft of drive, in place of the coating pan in the above machine, for carrying out polishing operation.

    Introduction: The machine fitted with gear box 1/2 H.P. electric Motorto work by Oil immersed gear box. Air blower is operated independently. An energy regulator is provided to control temperature from 5 deg.C above room temperature to 70 deg. C approx. Punch having switch for motor blower heat with neon indicator to work on 220 Volts. Size HP Pan HP Blower12" dia. 0.5 0.25
