Tamping Paste Dealers

• Country of Origin: India
• Color: Black
• Ash Content (%): Below 2%
• Purity: 100%
• Density: 1.38 g/mL 25 Degree C

What is Carbon Tamping Paste? Carbon Tamping Paste(CTP) or Ramming Paste is used in the lining of the submerged arc furnace. It is softened by heating and then applied over the refractory lining of the SAF. Good quality Tamping Paste is essential for the long life of the furnace lining. The Manufacturing Process The manufacturing process for Tamping Paste is the same as for Carbon Electrode Paste,the only difference being the fraction sizes of ECA/CPC which are different for Tamping Paste and the binder content is lower.

• Type: Carbon Paste
• Application: Industrial
• Color: Black
• Form: Powder
• Warranty: 1 Year
• Application: Calcium Carbide And Ferro Alloys Plant
• Packaging Size: 25kg

Ours is the noted name involved in providing excellent support in transaction ensuring complete security of the payment. We undertake both online and offline payment processing methods. Our entire array of products is sternly manufactured using certified array of raw materials. These inputs are sourced only from trustworthy vendors present in the market.   Typical Characteristics of CPC Based Carbon Electrode Paste - Green Paste Volatile Matter : 15% Mas Fixed Carbon : 84% Min Ash : 1.0% Max Plasticity : 30 – 40% Apparent Density : 1.55gms/cc. Min Binder Content : 22.25% Baked Paste At 1000 0C Apparent Density : 1.35 gms/ cc. Min Electrical Resistivity : 90 ohm-meter Max Compressive Strength : 200 kg/ cm2 Min Porosity : 35% Max Typical Characteristics of Anthracite Coal Based Carbon Electrode Paste - Green Paste Volatile Matter : 13% Max Ash : 5.5% Max Plasticity Grade-I : 20-30% Grade-II : 25 – 35% Grade – III : 30 – 40% Apparent Density : 1.55 gms/cc. Min Dry Aggregate : 78 – 80% Binder Content : 20- 22% Baked  Paste At 1000 0C Apparent Density: 1.38 gms/cc. Min Electrical Resistivity: 70 ohm-meter Max Cold Compressive Strength : 225 kg/cm2 Min

Tamping Paste or Ramming Paste is used in the lining of submerged arc furnace. First it is softened by heating and then applied over refractory lining of submerged arc furnace. Tamping Paste of superior quality is required for long life of the furnace lining. Manufacturing Process : The manufacturing process for Tamping Paste is same as for Carbon Electrode Paste. The only difference, being the fraction sizes of ECA/CPC, is different for Tamping Paste & binder pitch content is lower than Carbon Electrode Paste. Specifications of Carbon Electrode Paste : Green PasteProperty UnitECA BasedCPC BasedPlasticity%As per customers requirement, typical range 5-15As per customers requirement, typical range 5-15Fixed Carbon%84 Min88 MinVolatile Matter%10-1111-12Ash%5.0 Max0.5 MaxAparent Densitygm/cc1.60 Min1.60 Min

• Type: Tamping Paste
• Material: Carbon
• Application: Industrial Use
• Grade: Industrial Grade
• Form: Granules
• Packaging Type: Plastic Bags

• Size: 25 MM to 100 MM

Carbon Tamping Paste as application in Furnace lining refurnishing of submerged Furnace. Size : In 25 MM to 100 MM OR as per customer's requirement In CylinderBriquette form. Packing : In Small OR Jumbo Bag.

• Apparent Density: 1.35 gms/cc Max

Tamping Paste, also known as Thermal Paste is used in the Ferro Alloys & Allied Industries for the lining of the furnace. The paste is produced from a mixture of different Carbonaceous material (Calcined Petroleum Coke, Calcined Anthracite Coal etc.) and Soft Pitch as Binder. Tamping Paste Thermal Paste is manufactured by screening the CPC and or ECA to different fractions and then pulverizing the same. After the pulverization the TP is stored separately. After this, predetermined quantities of different fractions of the TP are weighed and transferred to the Sigma Mixer where it is heated to a predefined temperature by thermic fluid. The required quantity of Binder is also weighed and added into the Mixer. The mixing is continued for a specific period known as the Mixing Cycle. At the end of the Mixing Cycle, the mixed material is dumped into the mould box for casting into blocks which are then made ready for shipment. Tamping Paste Thermal Paste is manufactured by screening the CPC and or ECA to different fractions and then pulverizing the same. After the pulverization the TP is stored separately. After this, predetermined quantities of different fractions of the TP are weighed and transferred to the Sigma Mixer where it is heated to a predefined temperature by thermic fluid. The required quantity of Binder is also weighed and added into the Mixer. The mixing is continued for a specific period known as the Mixing Cycle. At the end of the Mixing Cycle, the mixed material is dumped into the mould box for casting into blocks which are then made ready for shipment.

Tamping Paste or Lining Paste is used in the Ferro Alloys & Allied Industries for the lining of the furnace, it is either Calcined Petroleum Coke (CPC) based or ECA Coal based and soft pitch as the binder.The manufacturing process of Tamping Paste or Lining Paste is similar to the manufacturing process of Electrode Carbon Paste with differences in fraction sizes of CPC ECA Coal and the content of Binder Pitch is lower then Electrode Carbon Paste.

Tamping paste in diameter ranging from 75 mm upto 800 mm with varying lengths for steel making through EAF route.Used for Ferro Alloy production in Submerged Arc Furnaces. Base material is CPC or Anthracite or a combination of both depending upon required properties application.

also known as thermal paste, our tamping paste is highly appreciated by the clients. the tamping paste is manufactured from high grade ingredients and therefore it is highly appreciated by the clients. used for diverse purposes, our tamping paste can be availed at competitive prices from us. used in the ferro alloys & allied industries for the lining of the furnace contains mixture of different carbonaceous material (calcined petroleum coke, calcined anthracite coal etc.) and soft pitch as binder manufacturing process the first step in the manufacture of tamping/thermal paste is screening the calcined petroleum coke (cpc) and / or (eca) to different fractions and pulverizing and storing it separately. following this, pre-determined quantities of different fractions are weighed and transferred to the sigma mixer which is heated to a predefined temperature by the thermic fluid. the required quantity of binder is also weighed and added into the mixer. the mixing is continued for a specific period known as the mixing cycle. at the end of the mixing cycle, the mixed material is dumped onto the mould box and cast into blocks which are then ready for shipment. quality & specification the thermal insulation of the furnace pots is essential. it is important that the tamping paste does not have any excess binder and fills the wall of the furnace, maintaining proper insulation & minimizing the heat loss.

Tamping Paste, Petroleum Coke, carbon paste

Tamping Paste, also known as Thermal Paste is used in the Ferro Alloys & Allied Industries for the lining of the furnace. The paste is produced from a mixture of different carbonaceous material (Calcined Petroleum Coke, Calcined Anthracite Coal etc.) and Soft Pitch as binder.

Tamping Paste, broken electrode

Tamping Paste, Calcined Petroleum Coke, Electrode Carbon Paste

Tamping Paste, Calcined Petroleum Coke, Electrode Carbon Paste

Tamping Paste, Carbon Electrode Paste, Met Coke

Tamping Paste, Calcined Petroleum Coke, Electrode Carbon Paste

Tamping Paste, pitch, Calcined Petroleum Coke, Carbon Electrode Paste

Tamping Paste, Calcined Petroleum Coke, Electrode Carbon Paste
