Tape Extensometer Dealers

• Tape length: 30 m or 50 m
• Item Code: EDS-80
• Precision in measurement of change: ± 0.2 mm
• LCD resolution: 0.01 mm
• Coefficient of linear expansion: 11 ppm/° C (6.1 ppm/° F)

• Type: Tape Extensometer
• Material: Stainless Steel
• Certification: CE Certified, ISO9001:2008
• Application: Industrial Use
• Display: Digital
• Country of Origin: India
• Product Name: Digital Tape Extensometer
• Product Name: Digital Tape Extensometer
• Name: SISPL

The Model SIS-400 Digital /Dial Tape Extensometer is used to measure displacement between pairs of references in excavations, tunnels, underground power houses, open mines etc. The measurement points may be permanently fixed or demountable type. The Tape Extensometer consists essentially of a steel survey tape, a tension spring, a tension adjustment screw, a digital measuring gage and two attachment hooks, which allow the tape to be stretched between two anchor points.

We are offering tape extensometer. Features: • highly suitable for field applications • easy to refill tape • accurate, highly sensitive and reliable • extremely stable for long term operations • light weight • dial display for fine measurement • water and dust proof enclosures (ip67)

• Range: 30m
• Accuracy: ±0.01mm
• Resolution: 0.01mm
• Calibration Frame: 1m
• Reference Hook: 130mm long, 250mm long other length on request

The tape extensometer is used to detect and monitor changes in the distance between two reference points. Typical applications include: Monitoring convergence of tunnel walls. Monitoring deformations in underground openings. Monitoring displacement of retaining structures, bridge supports, and other structures.
