Digital Torsion Testing Machine
300,000 - 1,200,000 Per Set
1 Set(s) (MOQ)
We are the prominent Manufacturer & Supplier of high performance Digital Torsion Testing Machine. Fabricated using high-grade parts and components, our Digital Torsion Testing Machine is acknowledged for excellent performance, high strength, accurate results and longer service life. Our machine is thoroughly inspected by our quality analysts and complies with the set standards. We make available our Digital Torsion Testing Machine at market leading rates. Features : 5 Digit 7 Segment ½ inch Red LED Display for LOAD Indication 4 Digit 7 Segment ½ inch Red LED Display for Angle of Rotation 2 Digit 7 Segment ½ inch Red LED Display for Number of Rotation Selection of Units Kgm or Nm for load Selection of Units Deg or Rad for Angle of Rotation Real Time Clock for report generation Password to safeguard unauthorized access for calibration and other important settings Multifunction Keyboard to select the parameters Data storage of last 25 Test Reports. The data of all the settings and reports is in memory even if power is absent. Report Printing facility on DOT MATRIX 80 column printer Rs232 communication facility(optional) Potential free NO contact(rated 2A @ 230Vac) to START/STOP TEST cycle. Safety Fuse Link(20mm) rated 230V,1A provided inside the controller NOTE : DUE TO CONSTANT R&D SPECIFICATION AND FEATURES ARE SUBJECT TO CHANGE WITHOUT NOTICE.
Digital Torsion Testing Machine
Get Price Quote
1 Piece (MOQ)
FEATURES Torsion Testing Machine is designed for conducting torsion and twist on various metal wires, tubes, sheet materials. Torque measurement is by torque transducer system. Torque can be applied to specimen by geared motor through gear box. Autographic recorder gives the relation between torque and angle of twist. The accuracy of torque indication is + 1% of the true torque. The electronic control panel is built using 8085 microprocessor which incorporates state of the art technology with following features – Front panel membrane type key board for test setup. 7 seg digital display of load displacement/extension. Printer port interface. Serial port for communication with PC. Storage of important parameters such as peak load & maximum displacement after test. Preload selection to take care of initial slippage. Optional real time graph & PC software.
Best Deals from Torsion Testing Machine
Torsion Testing Machine
199,000 Per Piece
1 Piece (MOQ)
We hold expertise in offering the wide gamut of Torsion Testing Machine in the industry. Our torsion testing machines are designed and developed for conducting torsion and twist on various metal wires, tubes and sheet materials. The torque is measured by the pendulum dynamometer system. The torque can be adjusted by adding weight to the machine. Torque can also be applied to specimen by geared motor through gear box. Auto graphic recorder gives the relation between torque and Angle of twist. FeaturesTorsion Testing Machine is designed for conducting Torsion and Twist on various metal wires, tubes, sheet materials, torque measurement is by pendulum dynamometer system.Torque ranges can be adjusted by Auto Torque Selector.Torque can be applied to specimen by geared motor through gear box.Autographic recorder gives the relation between torque and angle of twist.The accuracy of torque indication is +1% of the true torque.
KIC- TST-1000-C Computerized Torsion Spring Testing Machine
Get Price Quote
Digital Torsion Testing Machine
Get Price Quote
1 Piece (MOQ)
Torsion Testing Machine
50,000 Per Piece
TTA-20 Torsion Testing Machine
Get Price Quote
1 Piece (MOQ)
Torsion Testing Machine
Get Price Quote
1 Piece (MOQ)
Torsion Testing Machine is designed for conducting Torsion and twist tests on various metal wires, tubes, sheet materials. Torque measurement is by Pendulam. We are a unique entity in the industry, actively committed towards providing an optimum quality range of Torsion Testing Machine.
Mechanical Torsion Testing Machine
250,000 - 700,000 Per Piece
1 Piece (MOQ)
Torsion Testing Machine
Get Price Quote
1 Piece (MOQ)
Torsion Testing Machine
Get Price Quote
Analog Torsion Testing Machine
Get Price Quote
1 Piece (MOQ)
Shri ram industries offer torsion testing machine (sri tt 10), which are designed to check torsional property of various metal wires, tubes and bars. Further, we also calibrate these machines as per the latest and relevant industry standards.
Torsion Testing Machine
Get Price Quote
Torsion Testing Machine we offer is used on diverse metal wires, tubes and steel materials. We are recognized as one of the dependable Torsion Testing Machine Manufacturers and Suppliers in India. The Torsion Testing Machine offered by us is made up of excellent quality materials that ensure notable features like high durability, effective performance and low maintenance. We supply Torsion Testing Machines at market leading rates. Detail Fixed with auto torque selector to regulate torque ranges Contains geared motor to apply torque to specimen through gearbox Attached with autographic recorder for relation between torque and angle of twist Accuracy + 1 % of the true torque Suitable For Torsion and Twist test on diverse metal rods and flats Torque Measurement by pendulum dynamometer system
Digital Torsion Testing Machine
200,000 Per Piece
1 Unit (MOQ)
torsion testing machines
Get Price Quote
TORSION TESTING MACHINE SPECIFICATION:- For conducting torsion and twist tests on various metal wires, tubes, sheet materials . Capacity-50kg-m Ranges- , 50, 25, 25 & 10 kg-m No. of division on dial- 500 Torsion speed & direction- Fixed Reverse Clearance between grips- 0-500mm Grips for round bar- 10-30mm Width- 40 mm Motor- 3 H.P.
0.0
View Profile
Digital Torsion Testing Machine
125,000 Per Piece
1 Piece (MOQ)
Torsion Testing Machine
Get Price Quote
Torsion Testing Machine Suppliers Torsion Testing Machine is designed for conducting torsion and twist on various metal wires, tubes, sheet and other such materials. Torque measurement is done by pendulum dynamometer system. Torque range can be adjusted by auto torque selector. Torque applied to specimen by geared motor through gear box. Autographic recorder gives the relation between torque and angle of twist. Our Torsion Testing Machine is easy to operate and quite durable. We are engaged in manufacturing and supplying of Torsion Testing Machine in India. Being one of the prominent Torsion Testing Machine Suppliers, we have established an extensive network across the country to ensure that orders are delivered on a timely basis.
Torsion Testing Machine
Get Price Quote
We hold expertise in exporting and supplying of Torsion Testing Machine from Patiala, Punjab. Our Torsion Testing Machine is fabricated by using advanced technology under the guidance of expert engineers. We check the Testing Machine on stringent quality parameters from the time of initial procurement till the final delivery. We are proficient in delivering Torsion Testing Machine to buyers across the globe on a timely basis. Details : Suitable for Torsion and Twist test on various metal rods and flats. Torque Measurement by pendulum dynamometer system. Auto torque selector to adjust torque ranges. Geared motor to apply torque to specimen through gearbox. Autographic recorder for relation between torque and angle of twist. Accuracy + 1 % of the true torque Models Available - Mechanical & Digital/Computerised
0.0
View Profile
torsion testing machines
Get Price Quote
For maximum torsion testing capability and versatility, tinius olsen provides a complete range of torsion testing machines in capacities from 1,000 to 30,000 nm. These uniquely superior torsion testers provide weighing and loading capabilities in both rotation directions. This feature helps in determining not just the ultimate torque load of a specimen, but how that specimen behaves under conditions of continuous or intermittent torque loading in both directions. Key features: the key features of torsion testing machines from tinius olsen are: each torsion tester consists of a variable speed drive loading system and a digital control and indicating system in a fixed unit. The weighing head with its strain gage torque sensor is mounted on a moveable unit which is positioned on the rails to accomodate specimens of varying lengths. Software of tinius olsen fully complements the testing hardware turning the hardware into a advanced quality analysis system.
0.0
View Profile
Torsion Testing Machine
199,000 Per Piece
1 Piece (MOQ)
0.0
View Profile
