Trailing Cable Dealers

• Brand Name: Apar
• Power/Voltage: 300/500V, 450/750V, 1000V
• Desigh Temp.: -35c-+105c
• Insulated: Yes
• Conatct Material: Copper

• Country of Origin: India
• Type: Flex Cable
• Thickness: 0.5-1mm
• Color: Available In Different Colors
• Feature: High Tensile Strength
• Length: 10-20mtr
• Application: Home, Industrial

EPR insulated, outer double PCP sheath with cotton braiding in-between to provide mechanical strength.

• Country of Origin: India
• Type: Crane Cables
• Thickness: 0-25 Mm
• Application: Corrosive, Indoor, Out-Door
• Condition: New
• Finishing: Coated
• Test voltage: 4000 V

BHUWAL CABLES Rubber insulation in Rubber Trailing Cables holds its vital role in specific application where high flexibility and comparatively high temperature is required. Rubber insulation also permits simple splices and terminations. Sythetic rubber such as butyle rubber, Etnylene Propylene rubber, Poly Chloroprene rubber, Chlorosulphunated polyethylene rubber have better heat resistance, oil resistance and resistance against influence as compared to natural rubber. Out of all the synthetic rubber, silicon rubber has excellent die-electric characteristics. It is possible to operate silicon rubber insulated cables at ambient temperature of upto 180oC continuously. The polychloroprene rubber, chlorosulphonatated, nitrille sheating are formulated against high abrasion, oil, weather and fire resistance properties. EPR insulation with CSP sheathing can withstand high ambient condition having long durable ageing properties.   Additional Information: Pay Mode Terms: T/T (Bank Transfer),Other Minimum Order Quantity: 100 Meter Port of Dispatch: Ex Factory Vasai. Production Capacity: 100,000 Meters Delivery Time: Within a week Packaging Details: As we are an Export oriented material Packaging is taken care so that material is not damaged during transit. Material is packed in a rill or roll and is covered with a polythene so that it is not damaged.

• Brand Name: Sheena Cables
• Material: EPR Rubber Insulation and PCP Sheathing
• Usage: Industrial
• Length: 100 Mtrs to 500 Mtrs
• Protection Type: Un-Shielded
• Number of Core: 5 to 8 Cores
• Armored: Cotton Thread Braided
• Frequency: 50-60 Hertz

Details : 5 core x 2. 50 sqmm high mast cable 5 core x 4. 0 sqmm high mast cable  5 core x 6. 0 sqmm high mast cable 8 core x 2. 50 sqmm high mast cable 8 core x 4. 0 sqmm high mast cable 7 core x 2. 50 sqmm high mast cable

Elastomeric Flexible Trailing Cables that are known for features like durability, acute bending radius, unmatched flexibility and resistance to heat, oil, flames and ozone. Readily available in the domestic market, these are used in material handling applications. Some of the material used in developing this quality product line are listed below:

We have maintained high quality standards in the market by offering quality-centralized lot of products. And, this is done by using high grade raw material obtained from reliable sources. We are supported by hi-tech machines and expert personnel that enable us in meeting the bulk packaging of the products. Moreover, we check the entire lot before making the final dispatch.   Gemini Trailing Cables : Gemini manufactures flat and round trailing cable for lift, elevtar, hoist and crane application. Ingeniously developed extra soft and flexible PVC helps cable to retain its original mechanical and physical properties even after prolong use. This PVC also gives Gemini trailing cable minimum turning radius and bending radius, and hence making it suitable for application which require repeatedly bending and folding of cable. Construction : Conductor  - Flexible/Stranded bare/Tinned copper Insulation  -  Special Grade PVC/FR/FRLS PVC Outer Sheath  -  Special Grade PVC/FR/FRLS PVC/TPE Size  -  0.5/0.75/1.0/1.5 Sq mm2 core to 24 core, flat and round Standard  -  IS 6380 & JIS C 3401 Application : For lift, hoist, and crane applications and applications which require frequent bending and folding of cable.Salient Features : Bright annealed electrolytic grade copper having 99.99% purity and maximum conductivity to ensure minimum power losses. Cores are insulated in modern & precise machines and on 100% self generated power to minimize faults due to voltage fluctuations. Indigenous PVC compound provides better agine properties higher operating temperature & enhanceinsulation characteristics. Specially formulated outers heath polymer to give maximum flexibility and elasticity with minimum bending radius for prolong as well as frequent bending and folding.

• Country of Origin: India
• Type: Trailing Cable
• Certification: CE Certified, Iso 9001:2008
• Application: Industrial
• Color: Black
• Feature: Durable, High Ductility
• Voltage: 450/750
• Power: 1-3kw
• Outer Material: Rubber
• Internal Material: Copper
• Jacket Thickness: 0-5mm

We are manufacturing a wide range of trailing composite rubber cables that has been manufactured with high quality raw material. We use quality elastomer materials such as Polypropylene, Chloro-Sulphoneted Polyethylene (CSP), Nitirile Rubber/ PVC blends, Ethylene Polypropylene Rubber (EPR), Ehtylene Vinyle Acetate (EVA) and Silicone, that have been specially designed to meet numerous heat oil and resisting requirements. These electrometric compounds for insulating and setting of cables are formulated to meet the requirement of IS 6380 6899, IEC 60502 and other international specification.   GENERAL CONSTRUCTION (Conforming to IS 9968 Part 1) Conductor Annealed tinned copper wires solid (Class 1), Stranded(Class 2), Flexible (Class 5) Complying with the requirement of IS 8130-1984 applied Separator Tape Suitable material separator tape may be applied over the conductor. Insulation General service elastomer compound type lE 1 of IS 6380-1984 Heat Resisting elastomer compound type Le2 of IS 6380-1984 Silicone Rubber type. IE 5 of IS 6380-1984 Core Identification Colored insulation, Nos. PE tape colored proofed tape. Nos. Printing Filers Natural or synthetic fibers or elastomer suitable for the operating temperature and compatible with the insulating material Sheath General service sheath Type SE1/SE2 of IS 6380-1984 Heavy duty Sheath Type SE3/SE4/of IS 6380-1984

These are the specification of High Mast Cables Manufacturing. 1.1 KV Grade, Flexible Annealed Tinned Copper Conductor As Per IS : 8130, EPR Insulated Type IE-2 As Per IS : 6380, Cores Will Be Identified With Coloured Insulation, All Cores Laid-Up Together With Fillers & Melinex Taped Cotton Reinforcement And Overall Heavy Duty PCP Outer Sheathed Type SE 4 As Per IS : 6380, As Per The IS: 9968/88/Pt.-1.

Specializes in the manufacture of Trailing Composite Rubber Cables. High Temperature Cable, High Voltage Cable, Rubber Cable, Silicone Cable, EPR Cable, Flexible Cables, Welding Cables, electrical cables manufacturers in india, Power cables - medium voltage and high temperature and Submersible Pump Cables Manufacturer in India. American approved Trailing Composite Rubber Cables, CE approved Trailing Composite Rubber Cables, VDE approved Trailing Composite Rubber Cables and IS 9968 approved Trailing Composite Rubber Cables suppliers. Trailing Composite Rubber Cables Specifications Product Specification We hold expertise in offering supreme qualityTrailing Rubber Cables . These cables are widely demanded by our customers for their excellent conductivity and durability. The cables are demanded by various known companies like, ABB, JSW ISPAT as our Trailing Rubber Cables is approved by the IS : 9968 (Pt-1)/88 ISI standards. Quality silicon rubber is used for insulation to protect the cables from water and ensure high tensile strength. Specifications: Heat resisting compound up to 180 0C fiber glass Braided and varnished cable Available in both single and Multi cores cable Equipped with flexible copper conductor up to 6.6 KV Conforming to IS : 9968 (Pt-1)/88 ISI MARKED Applications Steel Mills EOT Cranes Airport Lighting Ships Nuclear & Thermal Power Stations Wind Power Mills Electrical Machines Textile Machines Construction Equipments Turbines

Application: Used in conveyor machinery such as transfer cars, boomstackers, side arm chargers, bulk materials conveyors etc.They find application in almost every industry segment like Steel Mills, Cement plants, Docks, Power Plants, Automobile Industries & Refineries and Petrochemicals.

GEMINI TRAILING CABLES Gemini manufactures flat and round trailing cable for lift, elevtar, hoist and crane application. Ingeniously developed extra soft and flexible PVC helps cable to retain its original mechanical and physical properties even after prolong use. This PVC also gives Gemini trailing cable minimum turning radius and bending radius, and hence making it suitable for application which require repeatedly bending and folding of cable. CONSTRUCTION Conductor :Flexible/Stranded bare/Tinned copper Insulation : Special Grade PVC/FR/FRLS PVC Outer Sheath : Special Grade PVC/FR/FRLS PVC/TPE Size : 0.5/0.75/1.0/1.5 Sq mm2 core to 24 core, flat and round Standard : IS 6380 & JIS C 3401 APPLICATION For lift, hoist, and crane applications and applications which require frequent bending and folding of cable. SALIENT FEATURES Bright annealed electrolytic grade copper having 99.99% purity and maximum conductivity to ensure minimum power losses. Cores are insulated in modern & precise machines and on 100% self generated power to minimize faults due to voltage fluctuations. Indigenous PVC compound provides better agine properties higher operating temprature & enhence insulation characteristics. Specially formulated outersheath polymer to give maximum flexibility and elasticity with minimum bending radius for prolong as well as freuent bending and folding.

We are able to manufacture and supply high quality trailing rubber cables. Made using top quality annealed copper and elastomer compound, rubber cables are very durable and heat resistant. Our huge infrastructure facility is equipped with high-tech machines and technology. We manufacture these cables following modern techniques to obtain the right quality cables. The trailing cable is mainly used for trailing, festooning, mobile machines and eot cranes, stacker reclaimer, winding & rewinding purpose, hoists.

APPLICATION : Designed primarily as a trailing cable for use in the supply of energy for portable or mobile equipment. Heavy Duty Harmonised Cables are not only robust but also extremely flexible. PCP neoprene is also oil and flame retardant i n accordance with BS6007 Table 4 Cenelec code HO 7RN-F.

• Type: Electric Cable
• Brand Name: UNIFIC
• Material: NEOPRENE Rubber

Our H07RN-F is a heavy-duty rubber flexible trailing cable for power supply with a voltage rating of 450/750V designed to provide high flexibility and to withstand chemical, mechanical and thermal stresses. It is suitable for applications such as handling equipment, mobile power supplies, worksites, stage and audio visual equipment, port areas and dams. As part of Eland Cables' portfolio of rubber flexible cables, the tough rubber sheath also makes this cable suitable for use in drainage and water treatment, cold or refrigerated environments, and severe industrial environments. Conductor Flexible copper (Cu Class 5) Insulation Ethylene Propylene Rubber (EPR) Type EI4 Outersheath Polychloroprene (PCP) Type EM2 The H07RN-F trailing duty cable has a temperature rating of -30oC to +60oC for fixed installations (rising to +85oC for fixed protected installations) and from -15oC to +60oC when flexed.This cable is sometimes misspelt as HO7RN-F, using the letter O instead of a zero.

• Voltage: upto 3.3 KV
• conductor: Copper – Flexible – Bare or Tinned
• FEATURES: High mechanical strength, Flexible cables for frequent bending and reeling/ unreeling movements, Excellent heat , oil and fire resistant properties.

We are one of the most well known Industrial Trailing Cable Exporters from Gujarat. In keeping with the company's commitment to technological advancement, elastomeric materials such as Polychloroprene (PCP), Chloro-Sulphoneted Polyethylene (CSP), PVC blends, Ethylene Propylene Rubber (EPR), Ethylene Vinyle Acetate (EVA) and Silicone have been specially compounded to meet numerous heat oils and fire resisting requirements. These Rubber Trailing Cables are highly beneficial since it can resist fire and heated oil. Made of optimum quality raw material it ensures great performance. Our offering Elevator Trailing Cable is also demanded on large basis due to its high strength and unsnap able feature which makes it highly safe for elevators. Uses : Optimum StrengthCorrosion ResistantResistance from heat and fireLengthy volumes Features : Ship wiringCoal handling plantsElevatorsPlatform rigs » General Construction (Conforming to IS 9968 Part 1)ConductorAnnealed tinned Copper wires Solid (Class 1), Stranded (Class 2), flexible (Class 5)complying with the requirement of IS 8130-1984Seperator TapeSuitable material seperator tape may be applied over the conductorInsulationGeneral service elastomer compound Type IE1 of IS 6380-1984 Heat Resisting elastomer compound Type IE2 of IS 6380-1984 Silicone Rubber Type IE 5 of IS 6380-1984Core IdentificationColoured insulation, Nos.PE tape, Coloured proofed tape, Nos. printingFillersNatural or synthetic fibres or elastomer suitable for the operating temperature and compatible with the insulating materialSheathGeneral service sheath Type SE1SE2 of IS 6380-1984 Heavy Duty Sheath Type SE3SE4 of IS 6380-1984 » Working Temperature of Commonly used Elastomeric Insulating and Sheathing MaterialsMaterialsMax. Cond. Temp. for continuous opertation Deg C.Max. Cond. Temp. for short circuit Deg C.Min. Working Temp. Deg C.Natural Rubber (VIR & TRS)60200-55Ethylene Propylene Rubber (EPR)90250-50Polychloroprene (PCP)70200-40Chlorosupphonated Polyethylene (CSP)90200-35Silicone Rubber150 180350-55HR Natural Rubber (HR VIR) 75200-55Styrene Butadience Rubber60200-55Butyl Rubber8522050

Rubber insulation in Rubber Trailing Cables holds its vital role in specific application where high flexibility and comparatively high temperature is required. Rubber insulation also permits simple splices and terminations. Sythetic rubber such as butyle rubber, Etnylene Propylene rubber, Poly Chloroprene rubber, Chlorosulphunated polyethylene rubber have better heat resistance, oil resistance and resistance against influence as compared to natural rubber. Out of all the synthetic rubber, silicon rubber has excellent die-electric characteristics. It is possible to operate silicon rubber insulated cables at ambient temperature of upto 180oC continuously. The polychloroprene rubber, chlorosulphonatated, nitrille sheating are formulated against high abrasion, oil, weather and fire resistance properties. EPR insulation with CSP sheathing can withstand high ambient condition having long durable ageing properties. Technical Specification : Construction : Single cable comprising multiple elements like power cores, control cores, signaling pairs, etc for multipurpose functions. Voltage Grade : 600/1100 V-AC Conductor : Class-5 flexible tinned or bare copper Insulation : EPR Screening (if applicable) : Tinned or bare copper wire braid Inner Sheath : HOFR- Elastomer Anti Kink Braid : Fabric braid embedded between inner and outer sheath Outer Sheath : HOFR Elastomer Features : Designed to withstand continuous reeling and unreeling Sheath materials that have a high degree of flex fatigue resistance Excellent heat, oil and fire resistant properties Operating Temperature : -20 Deg C to +90 Deg C Test Voltage : 2500 V-AC Bending Radius : 10D Core Marking : 1-5 cores colour coded as Green/Yellow, Blue, Brown, Black, Grey or Coloured Rubberised cotton tapes. 6 cores and above with numbered cores, with one earth core of Green/Yellow. Standards : IEC-60228, IEC-60502, IEC-60332
