Tube Expansion System Dealers

We are glad to be one of the leading service provider under Brand Name NEELYOG engaged in manufacturing, Marketing and Exports of Heavy Duty Industrial Hand Tools for Bolting Application and Maintenance. Our technologically driven production techniques provide high performing end products, which in turn establishes us a reputed and trustworthy supplier for various mechanical, hydraulic and pneumatic tools. Our range of products comes under the brand name NEELYOG. Made from premium quality raw materials processed at our state-of-the-art manufacturing unit, our range of products provides durable and reliable services to the users.

We make available different payment options to suit the convenience level of the clients. We entertain both online and offline payment processing methods for the convenience of our customers. We have superior storage capacity to safely store the extensive product range that we offer. Our massive and well-maintained storage space is well-connected with the shipping unit. The offered Hydraulic Tube Expansion System is used to expand tubes without flaring.

• Weight: 15-55kg
• Automatic Grade: Semi Automatic
• Warranty: 1 Year
• Power: 1-3kw
• Driven: Electric
• Material: Metal

For Hydraulic Tube Expansion System (Hydex) at industry-leading rates, you can completely rely on us. We are an eminent Manufacturer, Supplier and Exporter of Hydraulic Tube Expansion Systems from Maharashtra. Our Hydraulic Tube Expansion Systems are compact and thus easy to use inside boilers. The Tube Expansion Systems offered by us require very low maintenance. One can obtain the Tube Expansion Systems at affordable rates.   Features : Drive communicates with the pump via 9v DC remote control. This ensures safety and eliminates the need of electrical cord between pump and drive that other manufacturers provide. Silent during use. In comparison electric and pneumatic tube expansion systems are noisy. Compact, therefore easy to use inside boiler drums. Compatibility - Same powerpack for all the 4 drives to expand 5/8” o.d to 4” o.d tube. Very High Torque Developed - can expand large diameter, thick wall tubes in thick tube sheets easily. Long life + low maintenance. Boiler erections get completed in record time. Can be use for long working hours because drive is unaffected by heat. Dual drive powerpack is available to connect 2 drives to a single powerpack to cut down tube expansion time cycle by a further 50%. Microprocessor controls on the pump automate the expansion cycle. Trip, pause and reverse times for the drive are adjustable. No need for repeated manual STOP/START of the drive during the expansion cycle - completely automatically

We are one of the trustworthy Electric Tube Expansion System Manufacturers and Suppliers, catering the best ranges of Tube Expansion System. Our Tube Expansion Systems are exclusively made for fully automatic solid state electronic tube expansion. We also offer accessories of Tube Expansion System. These systems are highly advanced and based on the latest design. For Fully Automatic Solid State Electronic Tube Expansion Sleek Type Solid State Electronic Digital Display Torque Control Panel Model No: STCP-23010 - With Supply Voltage of 220 VoltsSleek Type Solid State Electronic Digital Display Torque Control Panel Model No: STCP-11020 - With Supply Voltage of 110 Volts

C 900 SERIES EXPANDERS FOR COOLERS AND CONDENSER, RANGE 14 TO 38 inch. (6.3 to 9.5 mm) TUBE OD. MIN. ENTRY(DIA MM.):3.8,4.2,4.56,5.11. SPARE MANDREL(MODEL NO.):M-21, M-23,M-22,M-25, M-27.

• DRIVE WEIGHT: 7.7 11.3
• FULL LOAD TORQUE: 1.26 3.0

The Digital Torque Control Unit is built to operate four types of driving units PD-0, PD-1, PD-2 & PD -3 The drive is a conventional electric drill type machine. The characteristic of the unit is such that the current drawn by the motor increases as the load is applied and by the accurate measurement of this current the effort produced is determined and also the degree of tube expansion, when the preset torque is reached.

• Weight: 4000-5000kg
• Voltage: 220V

This is never the case. Practically, the supply voltages vary as much as 20% to 25%. This directly affects the expansion results as the drive trips at a set current. That means for a 20% higher supply voltage, the tubes will be effectively expanded by 20% more torque than the required one using the electric tube expansion systems. Hence tubes will be over-expanded. For supply voltages less than normal, tubes will be under expanded proportionately

Compact, therefore easy to use inside boiler drums.Long life+low maintenance, Can be use for long working hours becouse drive is unaffected by heat

• Driven Type: Hydraulic
• Color: Grey
• Automatic Grade: Semi Automatic
• Power: 1-3kw
• Application: Tube Expansion
• Voltage: 220V
• Connection: New
• Type: Hydraulic Tube Expansion System, Hydraulic Tube Expansion Machine
• Diameter: 4
• Weight: 100-1000kg
• Warranty: 1year
• Country of Origin: India

Specially designed to expand stainless steel thick walled and exotic harder tubes, where conventional expanders would fail. Can expand tubes in a deep chanel using stepping extension. Quality leak proof joint in 3 to 5 seconds. Precise control of advancing force. Constant RPM even under load condition ensures equal pressure to the rolls for tight fit, leak proof joint between tube and tube sheet. Internal cylindricity of expanded tubes. Durable heavy-duty construction ensures long reliable life. Reduction of tube stretching and internal stresses. Simple operation saves time and reduces operator fatigue. Large oil tank and external filter for better cooling effect and easy filter replacement. Automatic lubrication system increases tool life and reduces consumable cost. Continuous programmed cycle-microprocessor controlled.

We manufactured the System for Tube Expansion which is controlled & operated by Electric Control Panel. Our tube expansion system is used for expansion of tubes of Boilers, Condensers & Heat Exchangers. Our tube expansion system is used mostly for tube expansion of condenser tube Expanders, heat exchanger tube expanders. Automatically controls after reaching the Required Torque by control is panel unit . By pressing the reverse button tube expander retracts out from the tube. The tubes are automatically rolled to maximum tightness without high stress of work in the Tube metal for prevention of damage to tube end or distorting ligaments of Tube Sheet. Our Tube Expansion system is suitable for tubes size (6.4 mm) ¼” to (100.4 mm) 4”

Subzero is a hydraulically driven unit which offers automatic tube expansion of boiler tubes to come over the limitation of conventional tube expansion method thereby offering attractive saving in labor, time & money. Because of its drastically reduced weight and size the drive head can be maneuvered easily inside confined spaces such as drums. Jobs are competed faster with far less manual labor, less operator fatigue.

  We are pioneers in engineering high quality electrical tube expansion system. Our skilled and experienced team of experts design these products that comply to international quality standards. Heavy duty motors imported from Germany are used in these products for high-functionality.

Our firm is engaged in offering quality range of tube expansion system, which are manufactured using latest technology and tools. Our skilled professionals design these products as per the latest trend to efficiently cater to the needs and requirements of the diversified clients. Our products possess unique features like low maintenance, energy efficiency and durability.

• Features: Designed to provide accurate ampere/torque control for SUBZERO electric expansion drives.

These tube cleaning tools are fitted with abrasive nylon rods that spread out when rotated. These tube cleaning tools are used to tube cleaning light deposits in thin tubes and pipes of exotic materials where damage to tubes is to be avoided.

• Condition: New
• Application: Dispensing

Our specialization also lies in manufacturing and supplying quality torque controlled tube expansion system. Manufactured using high-grade material, these products are easy to operate and durable.   Key Features: These systems produce electronic torque that is governed by electronic control panel. The power is automatically shut down by control unit mechanism when the electrically driven motors reaches the desired torque and tube expander retracts from the tube when the reverse button is pressed

• Oil Tank Capacity (Litres): 30, 45
• Hydraulic Oil: SAE VG 68
• Maximum Working Pressure ( bar): 100

Drive communicates with the pump via 9v DC remote control. This ensures safety and eliminates the need of electrical cord between pump and drive that other manufacturers provide. Silent during use. In comparison electric and pneumatic tube expansion systems are noisy. Compact, therefore easy to use inside boiler drums. Compatibility - Same powerpack for all the 4 drives to expand 58” o.d to 4” o.d tube. Very High Torque Developed - can expand large diameter, thick wall tubes in thick tube sheets easily. Long life + low maintenance. Boiler erections get completed in record time. Can be use for long working hours because drive is unaffected by heat. Dual drive powerpack is available to connect 2 drives to a single powerpack to cut down tube expansion time cycle by a further 50%. Microprocessor controls on the pump automate the expansion cycle. Trip, pause and reverse times for the drive are adjustable. No need for repeated manual STOPSTART of the drive during the expansion cycle - completely automaticall

Specially designed to expand stainless steel thick walled and exotic harder tubes, where conventional expanders would fail. Can expand tubes in a deep chanel using stepping extension. Quality leak proof joint in 3 to 5 seconds. Precise control of advancing force. Constant RPM even under load condition ensures equal pressure to the rolls for tight fit, leak proof joint between tube and tube sheet. Internal cylindricity of expanded tubes. Durable heavy-duty construction ensures long reliable life. Reduction of tube stretching and internal stresses. Simple operation saves time and reduces operator fatigue. Large oil tank and external filter for better cooling effect and easy filter replacement. Automatic lubrication system increases tool life and reduces consumable cost. Continuous programmed cycle-microprocessor controlled.
