Tubular Level Gauges
Get Price Quote
Based in New Delhi, India, we are a leading manufacturer, exporter and supplier of high quality Tubular Level Gauges. Guaranteed to perform, they are made using superior quality material in our high tech manufacturing facility our tubular level gauges are known for their sturdiness, durability, finish and dimensional accuracy. These tubular level gauges go through stringent quality control measures before being offered in the market, thus are trusted for their accuracy. Product Code : JKI-TULG-19 Product Specification : Fostered with a team of highly experienced professionals, we are able to manufacture, export and supply a supreme quality Tubular Level Gauges. Manufactured under the supervision of our deft experts, these gauges are also tested on various quality parameters to ensure their flawlessness. These gauges are simple in construction and permit viewing from any direction. The provided gauges are highly efficient and offer precise results. Apart from this, these Tubular Level Gauges are offered at most affordable rates to the clients. Features : Fine finish Highly durable Superior performance Robust construction Details : J.K. Level indicator for general application with Safety Auto shut off Ball check valve for accidental breakage of glass tube. Max.Pressure up to 10 Kg/cm2 and Temp. Up to 400º F Tubular level gauges simple in construction and permit viewing from any direction. They are provided with protective guard rods or 'C' Frame. End Connections: Screwed / Flanged as per requirement. Material of construction : Carbon Steel, 304/316-SS / PP Glass Tube : Std. 19 MM Borosilicate, Scale- SS-304/acrylic CC-Distance: Max. 02 Meters. End connection- Screwed / Flanged as per requirements
Tubular Level Gauges
4,350 Per Piece
2 Piece(s) (MOQ)
Best Deals from Tubular Level Gauge
Tubular Level Gauge
Get Price Quote
1 Piece (MOQ)
Tubular Level Gauge
2,000 Per piece
5 Piece (MOQ)
Glass Tubular Level Gauge
4,500 - 20,000 Per Unit
1 Piece (MOQ)
Tubular Liquid Level Gauge
Get Price Quote
We are reliable Manufacturer and Supplier of Tubular Liquid Level Gauge. The Tubular Liquid Level Gauge is made from good quality raw components that help in making it durable and give perfect results. Tubular type Level Gauges are used for direct level indication in Tanks and Vessels under Pressure and Temperature. Construction Of The Tubular Liquid Level Gauge The top and a bottom fitting can be fixed on suitable nozzles or bosses at top and bottom of a Tank with a Glass Tube fitted between them. The liquid level in Glass Tube indicates the level of liquid in Tank. The top and bottom Valve fittings can be provided with Isolating Needle Valves Handwheel operated. The minimum Centre to Centre Distance is about 600 mm. Top fitting can have Vent Valve (Needle type Valve) instead of Plug (normally NPT/BSP). Similarly bottom fitting can have Drain Valve. The end connections can be Flanged (normally 20/25 NB Flanged to BS/IS/ANSI/DIN Standard) or Socket Weld type (3000 psi rated normally 20/25 NB) or Screwed type through Union (20/25 NB BSP/NPT- Male; can be Female also). The material of construction can be Carbon Steel, Stainless Steel (SS-304)/316), PVC, Polypropylene, etc. Maximum Hydraulic Test Pressure is 3 Kg/cm² in case of PVC / Polypropylene material of construction. The fittings can be Fabricated (Carbon Steel, SS-304/316). The Valves have Screwed Bonnets. Valve Packing can be Graphoil, Teflon Ring or Teflon Rope and Glass Tube Packing can be Graphoil, Rubber Cone, Teflon Ring or Teflon Rope. Top and bottom fittings are provided with Safety Ball Sealing arrangements to prevent gushing out of liquid and gas under pressure in case of Glass Tube breakage. Needle Valve Spindles are provided with End Pins to disengage Ball if gets stuck in Closed position. For Glass Tube protection against mechanical damage, Twin mild Steel (Epoxy painted) Protector, Metal Tube Protector, 4-Guard Rod Protector (with or without Wire Mesh wrapping) or 3-Glass Protector can be provided. Tubular Level Gauges are normally not recommended for Pressure and Temperature higher than 15 Kg/cm2 and 200oC. Function Of Autoball Check Autoball check facility is provided to prevent liquid loss from vessel during breakage of gauge glass. It consists of a capsule located along the 'neck of the gauge and contains a 'ball, which moves freely along its inner race, between the stopper & orifice. During breakage, the pressure on 'ball' from gauge side will be atmospheric, whereas higher pressure from the vessel side ("operating pressure + liquid column") will cause the ball to move and block the orifice whereby liquid loss will be minimized. Installation Side mounted through tank nozzles, having matching counter flanges / threads, ensuring that CC distance between nozzles corresponds with CC distance (R) of the gauge. Salient Features 19 mm OD (2/3 mm Wall Thickness) Borosilicate Glass Tube as per BS: 3463 360o Visibility Auto ball check is built into end block for preventing liquid loss during glass breakage Deep Stuffing Boxes with Teflon V Ring Packing for Vacuum application Glass removal / replacement possible without dismantling of gauge Offset isolating valves permit cleaning of glass gauge without removal With IBR Certificate, if required Aluminum or Acrylic Plastic Scale with engraved graduations (Min. Graduation is normally 10 mm) Intermediate Support (Straight or Off-set) in case of Centre to Centre Distance more than 1400 mm
Tubular Level Gauge
Get Price Quote
The "KiT" make tubular Level Indicator (Side Mounted) .It is a reliable device for reading the level of liquid. It is a simplest form of level indicator. These level indicators find wide application for level measurement in process tanks, batching tanks, vessels etc.
Tubular Level Gauge
Get Price Quote
Side Mounted Tubular Level Gauge
3,000 - 8,000 Per
1 Piece (MOQ)
Tubular Level Gauge
4,000 - 40,000 Per Piece
Transparent Tubular Level Gauge
Get Price Quote
From Kolkata(India), India, we delight our valuable patrons by providing quality-centralized products. We are immensely accredited for delivering the orders within the stipulated time frame as we have the latest transportation facilities.
Tubular Level Gauge
Get Price Quote
We are instrumental in manufacturing Tubular Level Gauge that is appreciated for its simple construction, long working life and reliable performance among the clients. The Tubular Level Gauge is specially designed to measure visual liquid level. Moreover, we ensure the quality of Tubular Level Gauge and make sure it is manufactured in compliance with international standards. Salient Features : Choice of Tie Rod or C-Frame Construction Available with or without isolating valve Material integrity assured through strict compliance of chemical composition analysis in a Standard Laboratory H Grade Borosilicate glass tube 16/19/25 mm outer dia with Teflon Packing Glass tube an be removed online i.e. without disconnection from vessel Standard Connection : 1/2" / 3/4" / 1" Flange drilled to ASA 150#, others on request Alluminium/SS scale with 5 mm resolution as standard and 1 mm on request Drain Plug 1/2" Vent Plug 3/4" as std and drain/vent valve as optional Safety Ball check device(optional) Defrost/illuminator available on request. Hydro test pressure : 12 KG/cm2, 100 Deg C max working temperature. Tie Rod Construction is light' and permits 360oC visibility C-Frame construction is robust and permits observation from Front & Rear Both constructions are available in integral or inline arrangements High quality, H grade borosilicate glass tube in 16/19/25mm outer dia is used Available in single length having c/c distance = 1600 mm Gland packing design provides tension free tube installation to achieve zero leakage Transparent Acrylic Plate mounted on C-Frame/Acrylic Pipe or slotted metallic pipe clamped on Tie Rod as glass protector can be provided if required, for additional safety to glass & personnel Adjustable proximity/reed switch arrangement for level sensing with alarm relays
Tubular Level Gauge
Get Price Quote
At TELELIN we have always manufactured Level measuring device always keeping in mind our clients critical application and making simple liquid measuring devices easy on use with long life . We have designed Telelin tubular level indicator with auto shut off ball check valves the valve closes if the tube breaks and the ball in the valve controls liquid spillage . Thus due to this arrangement our Model No TL-126 is widely demanded by process plants & tanks manufacturers , consultants due to its safety aspect . Thus tubular level gauge with auto shut off ball check valve is the most exported level indicator of all.
Tubular Level Gauge
Get Price Quote
Features : 360 Visibility With Tie Rod Design Offset Isolating Valves Permit Glass Removal /Replacement Available In Various Material Application : Chemical/Petrochemical Fertilizer Power Generation Pharmaceutical Automobile Water/Waste Water/ETPs Etc
Tubular Level Gauge
Get Price Quote
Telelin Tubular level indicators are the very basic tank level measuring instrument used by process palnts , OEMS etc world over .Our Level Indicators are made in strict accordance as per standard connections and CC distance give by our clients with easy mounting arrangement made for easy installation and direct use . Our Model TL-122 our plain simple level indictaors basically preferred for water application with no drain or isolating valve , standard drain & vent plug are provided .We can also provide scale in volumetric units if exact tank height and dimensions are given at extra cost only . We suggest & manufacture , level indicators to our clients keeping in mind their needs and application our this trait has made us the most demanded level indicator manufacturer, supplier , exporter in Indian.
Tubular Level Gauge
Get Price Quote
TUBULAR LEVEL GAUGE IS THE SIMPLEST FORM OF LEVEL INDICATION IN PROCESS INDUSTRY. IT IS SIMPLE AND RELIABLE DEVICE FOR DIRECT READING IN ATMOSPHERIC OR PRESSURIZED TANK APPLICATIONS. IT IS MOUNTED PARALLEL, ALONG THE SIDE OF TANK. AS THE PROCESS LEVEL FLUCTUATES, THE LEVEL IN THE TRANSPARENT GLASS TUBE CHANGES ACCORDINGLY AND GIVES LOCAL LIQUID INDICATION.
Tubular Level Gauge
Get Price Quote
Simple low cost and reliable for direct reading of clean liquid levels at low pressure & temperature conditions. Gauge is fitted between two end blocks through gland packings. The gauge is mounted parallel to tank so as to form a close loop causing tank liquid to seek its level in the gauge. Guards are provided in the form of tie-rods c-channels around the gauge to protect it from accidental blows. End blocks have built-in isolating valve, drain valve & vent plug.
Tubular Level Gauge
1,500 Per Piece
Tubular Level Gauges
Get Price Quote
We offer tubular level gauges used for measuring the level of the tanks and the height can be provided 250 mm to 5000 mm of material carbon steel,ss-304,ss-316,duplex,pp etc.
Tubular Level Gauge
Get Price Quote
